Seat Ibiza (2022 year). Manual in english

Information for the user

Information for the user

Information stored by the
control units

Storage of accident data (Event
Data Recorder)

Your vehicle has an event data recorder
(EDR).

The EDR’s function is to record data in the
event of a mild or serious accident. These da-
ta are used to support the analysis of how dif-
ferent vehicle systems behaved.

The EDR records, over a reduced time range
(normally 10 seconds or less), dynamic driv-
ing data and data from the restraint systems,
such as:

●

How different vehicle systems worked.

●

Whether the driver and the occupants were

wearing their seat belts.

●

How hard the acceleration or brake pedal

was pressed.

●

Vehicle speed.

●

GPS position.

These data will provide a better understand-
ing of the circumstances of the accident.

Data from the driving assist systems are also
recorded. This includes data such as whether
the systems were inactive or active and if
such action had an impact on the vehicle’s
dynamic behaviour, changing its path in the
aforementioned situations, accelerating or
decelerating the vehicle.

Depending on vehicle equipment, this in-
cludes data from systems such as:

●

Adaptive Cruise Control (ACC)

●

Emergency brake assistance system (Front

Assist).

●

Park Pilot system

The EDR data are only recorded in specific
accident situations. No data are recorded in
normal driving conditions.

No audio or video data inside or around the
vehicle are recorded. Under no circumstan-
ces are personal data such as name, age, or
gender recorded. Nevertheless, third parties
(such as criminal proceedings authorities)
may relate the contents of the EDR data to
other data sources and create a personal
reference in the context of an accident inves-
tigation.

In order to read the EDR data it is necessary
to access (if legally permitted to do so) the

vehicle's ODB (“On-Board-Diagnose”) inter-
face while the vehicle is switched on.

SEAT will not have access to EDR data unless
the owner (or, in “Leasing” cases, the lessee
or hirer) gives their consent. There may be ex-
ceptions to this, depending on legal or con-
tractual provisions.

Due to legal requirements in safety-related
products, SEAT may use the EDR data for
field research and in order to improve vehicle
system quality. Any data used for the purpo-
ses of research will be treated anonymously
(in other words, no reference will be made to
the vehicle, their owner or the lessee/hirer).

Other important information

Environmental compatibility

Environmental protection is a top priority in
the design, choice of materials and manufac-
ture of your new SEAT.

Constructive measures to encourage re-
cycling

●

Joints and connections designed for easy

dismantling.

●

Modular construction to facilitate disman-

tling.

●

Increased use of single-grade materials.

301

Information for the user

●

Plastic parts and elastomers are marked in

accordance with ISO 1043, ISO 11469 and
ISO 1629.

Choice of materials

●

Use of recycled materials.

●

Use of compatible plastics in the same part

if its components are not easily separated.

●

Use of recycled materials and/or materials

originating from renewable sources.

●

Reduction of volatile components, including

odour, in plastic materials.

●

Use of CFC-free coolants.

Ban on heavy metals, with the exceptions
dictated by law (Annex II of ELV Directive
2000/53/EC):

cadmium, lead, mercury,

hexavalent chromium.

Manufacturing methods

●

Reduction of the quantity of thinner in the

protective wax for cavities.

●

Use of plastic film as protection during vehi-

cle transport.

●

Use of solvent-free adhesives.

●

Use of CFC-free coolants in cooling sys-

tems.

●

Recycling and energy recovery from resi-

dues (RDF).

●

Improvement in the quality of waste water.

●

Use of systems for the recovery of residual

heat (thermal recovery, enthalpy wheels,
etc.).

●

The use of water-soluble paints.

Recycling of electrical or electron-
ic devices

All electrical or electronic devices (EED) that
are not permanently fitted in the vehicle must
be marked with the following symbol:



This symbol indicates that EED must not be
discarded as home waste but through selec-
tive waste collection.

Radioelectrical equipment

Simplified declaration of conformi-
ty

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Directive
2014/53/EU when legally required.

The full text of the EU compliance declaration
is available online at the following address:

www.seat.com/generalinfo



United Kingdom

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with the UK Radio
Equipment Regulations 2017 (SI 2017/1206) if
required by law.

The full text of the declaration of conformity is
available online at the following Internet ad-
dress:

www.seat.com/generalinfo

Ukraine

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Ukraine Decree
355/2017 (TR Radio Equipment) where legal-
ly required.

The full text of the declaration of conformity is
available online at the following Internet ad-
dress:

www.seat.com/generalinfo



Addresses of the manufacturers

The address of the manufacturers of compo-
nents that, due to their size or nature, cannot

302

Information for the user

include a sticker are listed below, as long as it
is legally required:

Central control unit (BCM)

Robert Bosch GmbH/Braunschweig
Theodor-Heuss-Strasse 12
38122 - Braunschweig, Germany
Phone: 0049 53188890

Keyless Access system

HELLA GmbH & Co. KGaA/Hamm
Roemerstr. 66
59075 - Hamm, Germany
Phone: 0049 23817980

Roof antenna

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Mitsumi Electronics Europe GmbH
Siemensstrasse 32
63225 Langen, Germany
Phone: +49 (0) 6103913-0
Website: www.minebeamitsumi.co.jp

Molex CVS Hildesheim GmbH
Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Antenna amplifiers

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1
31137 Hildesheim, Germany
Phone: +498031184-0
Website: www.kathrein.com

Molex CVS Hildesheim GmbH
Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Navigation antenna

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1
31137 Hildesheim, Germany
Phone: +498031184-0
Website: www.kathrein.com

Connectivity Box

Molex CVS Dabendorf GmbH
Märkische Strasse 72
15806 Zossen OT Dabendorf, Germany
Phone:+49 3377 3160
Website: www.molex.com

Basic infotainment system

Panasonic Automotive Systems Czech
U Panasonicu 266
530 06, Pardubice, Czech Republic

Optional infotainment system

LG Electronics Mlawa SP
LG Electronics 7
06 500, Mlawa

Remote control key

Digades GmbH Digitales Und Ana/Zittau
Äußere Weberstr. 20
02763 - Zittau, Germany
Phone: 0049 358357750

303

Information for the user

Instrument panel

Analogue SE38x/SE316

Visteon Electronics Germany GmbH
Visteonstr. 4-10
50170 Kerpen, Germany

Analogue all other models

Continental Automotive Spain, S.A.
Crta. de Rubí a Ullastrell, nº 12-30
08191 Rubí (Barcelona - Spain)

FPK (digital)

Continental Automotive GmbH
VDO-Strasse 1,
64832 Babenhausen, Germany

Panasonic Automotive Systems Europe
GmbH
Robert Bosch Str. 27-29
63225 Langen, Germany

Panasonic Automotive Systems Czech,
s.r.o.
U Panasonicu 266
530 06, Pardubice, Czech Republic

Front radar sensors

MRR for SE38X

Robert Bosch GmbH
Markwiesenstrasse, 46
72770 Reutlingen (Kusterdingen) Germany

MRR for Tarraco, Ateca, Ibiza, Arona

Automotive Distance Control Systems
GmbH
Peter-Dornier-Strasse, 10
88131, Lindau, Germany

Rear radar sensors

Hella GmbH & Co. KGaA
Rixbecker Straße 75
59552 Lippstadt (Germany)

Online Connectivity Unit

LG ELECTRONICS INC.
10, Magokjungang 10-ro,
Gangseo-gu, Seoul, Republic of Korea

Frequency bands, station power

Radioelectrical equipment

Frequency band

Max. station power

Valid for models

Radiofrequency remote control (vehicle)

433.05-434.78 MHz

10 mW (ERP)

All SEAT models

433.05-434.79 MHz

10 mW

868.0-868.6 MHz

25 mW

434.42 MHz

32 µW

Radio frequency remote control (auxiliary

heater)

868.7-869.2 MHz (869.0 MHz)

25 mW

Leon, Ateca and Tarraco

868.0-868.6 MHz (868.3 MHz)

3.1 mW

Alhambra

304

Information for the user

Radioelectrical equipment

Frequency band

Max. station power

Valid for models

Transmitted-Receiver (independent heating)

868.0-868.6 MHz (868.3 MHz)

23.5 mW

Alhambra

868.7-869.2 MHz (869.0 MHz)

23.5 mW

Leon, Ateca and Tarraco

Bluetooth

2402-2480 MHz

6 dBm

All SEAT models

2400-2483.5 MHz

10 dBm

Connection to the external antenna of the car

GSM 900: 880-915 MHz

33 dBm

Leon, Alhambra and Tarraco

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

WCDMA FDD lll: 1710-1785 MHz

21 dBm

Tarraco and Leon

WCDMA FDD VIII: 880-915MHz

21 dBm

LTE FDD1: 1920-1980 MHz

23 dBm

LTE FDD3: 1710-1785 MHz

23 dBm

LTE FDD7: 2500-2570 MHz

23 dBm

LTE FDD8: 880-915 MHz

23 dBm

LTE FFD20: 832-862 MHz

23 dBm

Wireless hotspot

2400-2483.5 MHz

10 dBm

Leon, Ateca and Tarraco

Keyless Access

434.42 MHz

32 µW

Ibiza, Arona, Leon, Ateca and Tarraco

Radar sensors for front assist systems

76 GHz-77 GHz

28.2 dBm

Leon and Alhambra

35.0 dBm

Ibiza, Arona, Ateca and Tarraco

Radar sensors for rear assist systems

24050-24250 MHz

20 dBm

Ibiza, Arona, Leon, Ateca and Tarraco

Wireless charging

110-120 kHz

5 W

Ibiza, Arona, Leon, Ateca and Tarraco

305

Information for the user

Radioelectrical equipment

Frequency band

Max. station power

Valid for models

Instrument panel

125 kHz

40 dBµA/m

Ibiza, Arona, Ateca, Tarraco and
Alhambra

Online Connectivity Unit

EGSM900: 880-915 MHz

33 dBm

Ibiza, Arona, Leon, Ateca and Tarraco

DCS1800: 1710-1785 MHz

31 dBm

UMTS FDD 1: 1920-1980 MHz

24 dBm

UMTS FDD 3: 1710-1785 MHz

24 dBm

UMTS FDD 8: 880-915 MHz

24 dBm

E-UTRA FDD 1: 1920-1980 MHz

23.5 dBm

E-UTRA FDD 3: 1710-1785 MHz

23.0 dBm

E-UTRA FDD 7: 2500-2570 MHz

23.5 dBm

E-UTRA FDD 8: 880-915 MHz

23.0 dBm

E-UTRA FDD 20: 832-862 MHz

23.5 dBm

E-UTRA FDD 28: 703-748 MHz

23.0 dBm

The commissioning or authorisation of radioelectrical technology may be restricted in some European countries, forbidden or only allowed with additional requirements.

Additional information for coun-
tries outside the European Union

Mexico

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Directive
RLVCOAR15-0008 when legally required. The
full text of the declaration of conformity is

available online at the following Internet ad-
dress:

https://www.seat.mx/servicio/mi-seat/manual-
del-propietario.html

Certificate: RLVHERS17-0286. RS4 Hella
KGaA Hueck & Co. short-range radar
IFT:RLVHERS17-0286. The operation of this
equipment is subject to the following two

conditions: (1) this equipment or device may
not cause harmful interference, and (2) this
equipment or device must accept any inter-
ference, including interference that may
cause undesired operation.

United Kingdom

This vehicle has various radio equipment de-
vices installed.

306

Information for the user

The following acts as importer of the radio
equipment devices for the United Kingdom
market within the meaning of The Radio
Equipment Regulations 2017:

Volkswagen Group United Kingdom Ltd.

Yeomans Drive, Blakelands
Milton Keynes, MK 14 5AN
United Kingdom

Türkiye
Telsiz Ekipmanları Yönetmeliği
(2014/53/AB)

Aracınızda çeşitli telsiz ekipmanları bulun-
maktadır.

Telsiz Ekipmanlari Yönetmeliği (2014/53/AB)
açısından Türkiye pazarı için radyo ekipmanı
ithalatçısı (bu bilgi sadece resmi temsilcimiz
olan Doğuş Otomotiv Servis ve Ticaret A.Ş.’nin
ithal ettiği ürünler için geçerlidir):

Doğuş Otomotiv Servis ve Ticaret A.Ş.

Şekerpınar Mahallesi, Anadolu Caddesi,
No: 22 ve 45
41420 Çayırova/Kocaeli

Ukraine

Імпортер

ТОВ

Порше

Україна

просп

Павла

Тичини

, 1

офіс

„

“, 4-

поверх

02152

Київ

Україна

Importer:

Porsche Ukraine LLC
Pavla Tychyny ave. 1V, Office “B”, 4th floor
02152 Kyiv, Ukraine.

307

Technical data

Technical data

Indications about the
technical data

Important information

Introduction

The values indicated in the technical data
may differ depending on optional equipment
or version of the model, as well as in the case
of special vehicles and equipment for certain
countries.

The information in the official vehicle docu-
mentation takes precedence at all times.

Abbreviations used in the Technical Speci-
fications section

Kilowatt, engine power measurement.

Pferdestärke (horsepower), formerly

used to denote engine power.

rpm, 1/min

Revolutions per minute - engine speed.

Newton metres, unit of engine torque.

Cetane number, indication of the die-
sel combustion power.

RON

Research octane number, indication of
the knock resistance of petrol.

Vehicle identification data

Vehicle ID number

The vehicle ID number can be found in the
following places:

●

One the vehicle's data label.

●

In front, under the windscreen.

●

To the right in the engine compartment.

Type plate

The type plate is located on the vehicle’s right
hand door frame. Vehicles for certain export
countries do not have a type plate.

Fuel consumption

Approved consumption values are derived
from measurements performed or supervised
by certified EU laboratories, according to the
legislation in force at the time (for more infor-
mation, see the Publications Office of the Eu-
ropean Union on the EUR-Lex website: © Eu-
ropean Union, http://eur-lex.europa.eu/) and
apply to the specified vehicle characteristics.

The values relating to fuel consumption and
CO

emissions can be found in the documen-

tation provided to the purchaser of the vehi-
cle at the time of purchase.

Fuel consumption and CO

emissions de-

pend on the equipment/features of each indi-

vidual vehicle, as well as on the driving style,
road conditions, traffic conditions, environ-
mental conditions, load or number of passen-
gers.

Filling capacities

Tank level

Petrol engines

40 l, 7 l reserve

Natural gas en-
gine

approx. 13.8 kg

Additional petrol tank: 9 l, of

which approx 7.6 l is a reserve

The capacity depends on the efficacy and charac-

teristics of the natural gas pumps. The capacity indi-
cated is based on a minimum loading pressure of 200
bar.

Capacity of the windscreen washer fluid con-
tainer

Windscreen washer

fluid container

approx. 3 litres

Weights

Load on the roof

The maximum authorised roof load for your
vehicle is 75 kg.

308

Technical data

Engine specifications

Petrol engines

1.0 MPI Start-Stop

1.0 TSI Start-Stop

Power output in kW (PS) at 1/min

59 (80)/6,300

70 (95)/5,000-5,500

81 (110)/5,500

Maximum torque (Nm at 1/min)

93/3,700-3,900

175/1,600-3,500

200/2,000-3,000

No. of cylinders/displacement (cm

)

3/999

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

manual

DSG

Top speed (km/h)

170 (IV)

186 (V)

195 (V)

195 (VI)

Acceleration from 0-100 km/h (seconds)

15.3

10.9

10.2

10.0

Maximum authorised weight (kg)

1,620

1,640

1,670

1,680

Varies depending on the features.

Petrol engines

1.0 EcoTSI Start-Stop

1.5 TSI Start-Stop

1.6 MPI

Power output in kW (PS) at 1/min

85 (115)/5,000-5,500

110 (150)/5,000-6,000

81 (110)/5,800

Maximum torque (Nm at 1/min)

200/2,000-3,500

250/1,500-3,500

155/3,800-4,000

No. of cylinders/displacement (cm

)

3/999

4/1,498

4/1,598

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

manual

DSG

manual

automatic

Top speed (km/h)

195 (V)

216 (VI)

190

192

Acceleration from 0-100 km/h (seconds)

9.3

8.2

10.4

10.8

Maximum authorised weight (kg)

1,660

1,720

1,640

1,670

Varies depending on the features.

310

Indications about the technical data

Natural gas / petrol engine

1.0 TGI Start-Stop

Power output in kW (PS) at 1/min

66 (90)/4,000-5,500

Maximum torque (Nm at 1/min)

160/1,800-3,800

No. of cylinders/displacement (cm

)

3/999

Fuel

CNG

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

manual

Top speed (km/h)

181 (V)

Acceleration from 0-100 km/h (seconds)

12.1

Maximum authorised weight (kg)

1,690

Varies depending on the features.

311

Technical data

Dimensions.

Fig. 200

Dimensions.

Fig. 200

IBIZA

A/B

Front and rear projections (mm)

796/699

Wheelbase (mm)

2,564

Length (mm)

4,059

E/F

Front/rear

track width (mm)

1,525/1,505

Width (mm)

1,780

Height at kerb weight (mm)

1,447

This data will change depending on the type of wheel rim. Values for wheel 185/65 R15 ET40.

312

Seat Ibiza (2022 year). Manual in english - page 19
