Seat Ateca (2022 year). Manual in english - page 22

Information for the user

Radioelectrical equipment

Frequency band

Max. station power

Valid for models

Wireless charging

110-120 kHz

5 W

Ibiza, Arona, Leon, Ateca and Tarraco

Instrument panel

125 kHz

40 dBµA/m

Ibiza, Arona, Ateca, Tarraco and
Alhambra

Online Connectivity Unit

EGSM900: 880-915 MHz

33 dBm

Ibiza, Arona, Leon, Ateca and Tarraco

DCS1800: 1710-1785 MHz

31 dBm

UMTS FDD 1: 1920-1980 MHz

24 dBm

UMTS FDD 3: 1710-1785 MHz

24 dBm

UMTS FDD 8: 880-915 MHz

24 dBm

E-UTRA FDD 1: 1920-1980 MHz

23.5 dBm

E-UTRA FDD 3: 1710-1785 MHz

23.0 dBm

E-UTRA FDD 7: 2500-2570 MHz

23.5 dBm

E-UTRA FDD 8: 880-915 MHz

23.0 dBm

E-UTRA FDD 20: 832-862 MHz

23.5 dBm

E-UTRA FDD 28: 703-748 MHz

23.0 dBm

The commissioning or authorisation of radioelectrical technology may be restricted in some European countries, forbidden or only allowed with additional requirements.

Additional information for coun-
tries outside the European Union

Mexico

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Directive

RLVCOAR15-0008 when legally required. The
full text of the declaration of conformity is
available online at the following Internet ad-
dress:

https://www.seat.mx/servicio/mi-seat/manual-
del-propietario.html

Certificate: RLVHERS17-0286. RS4 Hella
KGaA Hueck & Co. short-range radar
IFT:RLVHERS17-0286. The operation of this
equipment is subject to the following two
conditions: (1) this equipment or device may
not cause harmful interference, and (2) this

348

Information for the user

equipment or device must accept any inter-
ference, including interference that may
cause undesired operation.

United Kingdom

This vehicle has various radio equipment de-
vices installed.

The following acts as importer of the radio
equipment devices for the United Kingdom
market within the meaning of The Radio
Equipment Regulations 2017:

Volkswagen Group United Kingdom Ltd.

Yeomans Drive, Blakelands
Milton Keynes, MK 14 5AN
United Kingdom

Türkiye
Telsiz Ekipmanları Yönetmeliği
(2014/53/AB)

Aracınızda çeşitli telsiz ekipmanları bulun-
maktadır.

Telsiz Ekipmanlari Yönetmeliği (2014/53/AB)
açısından Türkiye pazarı için radyo ekipmanı
ithalatçısı (bu bilgi sadece resmi temsilcimiz
olan Doğuş Otomotiv Servis ve Ticaret A.Ş.’nin
ithal ettiği ürünler için geçerlidir):

Doğuş Otomotiv Servis ve Ticaret A.Ş.

Şekerpınar Mahallesi, Anadolu Caddesi,
No: 22 ve 45
41420 Çayırova/Kocaeli

Ukraine

Імпортер

ТОВ

Порше

Україна

просп

Павла

Тичини

, 1

офіс

„

“, 4-

поверх

02152

Київ

Україна

Importer:

Porsche Ukraine LLC
Pavla Tychyny ave. 1V, Office “B”, 4th floor
02152 Kyiv, Ukraine.

349

Technical data

Technical data

Indications about the
technical data

Important information

Introduction

The values indicated in the technical data
may differ depending on optional equipment
or version of the model, as well as in the case
of special vehicles and equipment for certain
countries.

The information in the official vehicle docu-
mentation takes precedence at all times.

Abbreviations used in the Technical Speci-
fications section

Kilowatt, engine power measurement.

Pferdestärke (horsepower), formerly

used to denote engine power.

rpm, 1/min

Revolutions per minute - engine speed.

Newton metres, unit of engine torque.

Cetane number, indication of the die-
sel combustion power.

RON

Research octane number, indication of
the knock resistance of petrol.

Vehicle identification data

Vehicle ID number

The vehicle ID number can be found in the
following places:

●

One the vehicle's data label.

●

In front, under the windscreen.

●

To the right in the engine compartment.

Type plate

The type plate is located on the vehicle’s right
hand door frame. Vehicles for certain export
countries do not have a type plate.

Fuel consumption

Approved consumption values are derived
from measurements performed or supervised
by certified EU laboratories, according to the
legislation in force at the time (for more infor-
mation, see the Publications Office of the Eu-
ropean Union on the EUR-Lex website: © Eu-
ropean Union, http://eur-lex.europa.eu/) and
apply to the specified vehicle characteristics.

The values relating to fuel consumption and
CO

emissions can be found in the documen-

tation provided to the purchaser of the vehi-
cle at the time of purchase.

Fuel consumption and CO

emissions de-

pend on the equipment/features of each indi-

vidual vehicle, as well as on the driving style,
road conditions, traffic conditions, environ-
mental conditions, load or number of passen-
gers.

Filling capacities

Tank level

Vehicles with front-wheel

drive:

50 l, of which approx. 7l

reserve

Vehicles with four-wheel
drive:

55 l, of which approx.

8.5 l reserve

Capacity of the windscreen washer fluid con-
tainer

approx. 3 litres

Weights

Load on the roof

The maximum authorised load on the roof of
your vehicle is 75 kg.

Empty weight, total weight, axle loads

The empty weight of the vehicle with driver
(75 kg) was calculated according to the (EU)
1230/2012 standard. Optional equipment can
increase the empty weight, which means that
the possible useful load decreases propor-
tionally.

350

Indications about the technical data

Trailer weight

The maximum permitted drawbar load on the
ball head of the towing bracket is

90 kg

WARNING

The values indicated for the maximum per-
mitted weights must not be exceeded.
There is a risk of accident and damage!

351

Technical data

Engine specifications

Petrol engines

1.0 TSI Start-Stop

1.4 TSI Start-Stop

1.5 TSI Start-Stop

2.0 TSI Start-Stop

Power output in kW (PS) at 1/min

81 (110)/5,500

110 (150)/5,000-6,000

140 (190)/4,200-6,000

Maximum torque (Nm at 1/min)

200/2,000-3,000

250/1,500-3,500

320/1,500-4,100

No. of cylinders/displacement (cm

)

3/999

4/1,395

4/1498

4/1,984

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

manual

DSG

manual

DSG

DSG 4Drive

Top speed (km/h)

180 (V)

195 (VI)

198 (V)

202 (V)

214 (V)

Acceleration from 0-100 km/h (seconds)

11.4

9.1

9.3

9.1

7.1

Maximum authorised weight (kg)

1,870

1,950

1,930

2,090

Diesel engines

2.0 TDI CR Start-Stop 2.0 TDI CR Start-Stop 2.0 TDI CR Start-Stop

2.0 TDI CR Start-Stop

Power output in kW (PS) at 1/min

85 (116)/2,750-4,250

105 (143)/3,500-4,000

110 (150)/3,250-4,200

110 (150)/3,000-4,200

Maximum torque (Nm at 1/min)

300/1,600-2,500

320/1,750-3,000

340/1,600-3,000

360/1,600-2,750

No. of cylinders/displacement (cm

)

4/1,968

Fuel

Diesel according to standard EN 590, min. 51 CN

Gearbox

manual

DSG

manual

DSG

DSG 4Drive

Top speed (km/h)

185 (V)

193 (V)

202 (V)

202 (VI)

197 (VI)

Acceleration from 0-100 km/h (seconds)

10.9

9.4

9.3

9.0

8.7

Maximum authorised weight (kg)

2,000

2,030

2,130

Data not available as this edition goes to print.

352

Indications about the technical data

Dimensions.

Fig. 225

Dimensions.

353

Technical data

›››

Fig. 225

ATECA

ATECA 4Drive

Front projection (mm)

871

Rear projection (mm)

872

880

Wheelbase (mm)

2,638

2,630

Length (mm)

4,381

Front

track (mm)

1,576

1,572

Back

track (mm)

1,541

1,544

Width (mm)

1,841

Height at kerb weight (mm)

1,601

1,615

1,611

1,625

Ground clearance between the axles (mm)

176

189

Front projection angle limited by the bumper

maximum 18.9°

maximum 19.9°

Rear projection angle limited by the bumper

maximum 27.4°

maximum 27.8°

Turning radius (m)

10.2

This data will change depending on the type of wheel rim.

Distance to the roof.

Dimension to the roof bars.

354
