Seat Ateca (2022 year). Manual in english

Operation

last wipe. For the “drip” function to work
again, you have to turn the ignition off and
then on again.

Rain sensor

Fig. 102

Wiper lever: adjust the rain sensor

Fig. 103

Rain sensor sensitive surface

The rain sensor controls the frequency of the
windscreen wiper intervals, depending on the

amount of rain

›››

. The sensitivity of the rain

sensor can be adjusted manually. Manual
wipe

›››

page 122

Move the lever to the required position

›››

Fig. 102

Rain sensor off.
Rain sensor on; automatic wipe if neces-
sary.
Setting sensitivity level of rain sensor

–

Set control to the right: high sensitivity.

–

Set control to the left: low sensitivity.

When the ignition is switched off and then
back on, the rain sensor remains active and
starts operating again when the windscreen
wipers are in position

and the vehicle is

travelling at more than 16 km/h (10 mph).

Modified behaviour of the rain sensor

Possible causes of faults and mistaken read-
ings

on the sensitive surface

›››

Fig. 103

of the

rain sensor include:

●

Damaged wipers: a film of water on the

damaged blades may lengthen the activa-
tion time, reduce the washing intervals or re-
sult in a fast and continuous wipe.

●

Insects: insects on the sensor may trigger

the windscreen wiper.

●

Salt on the road: in winter, salt spread on

the roads may cause an excessively long
wipe when the windscreen is almost dry.

●

Dirt: dry dust, wax, coating on glass (Lotus

effect) or traces of detergent (car wash) may
reduce the effectiveness of the rain sensor or
make it react more slowly, later or not at all.

●

Windscreen crack: the impact of a stone

will trigger a single wipe cycle with the rain
sensor on. Next the rain sensor detects the re-
duction in the sensitive surface area and
adapts accordingly. The behaviour of the
sensor will vary with the size of the damage
caused by the stone.

WARNING

The rain sensor may not detect enough rain
to switch on the wipers.

●

If necessary, switch on the wipers man-

ually when water on the windscreen ob-
structs visibility.

Note

●

Regularly clean the sensitive surface of

the rain sensor

›››

Fig. 103

(arrow) and

check for possible damage to the wiper
blades.

●

To remove wax and coatings, we recom-

mend a window cleaner containing alco-
hol.

124

Visibility

●

Do not put stickers on the windscreen in

front of the rain sensor. This may cause
sensor disruption or faults.

Mirrors

Interior mirror anti-dazzle function

Rear view mirror with automatic anti-daz-
zle function

The anti-dazzle function is activated every
time the ignition is switched on.

When the anti-dazzle function is enabled, the
interior rear vision mirror will darken

auto-

matically

according to the amount of light it

receives. The anti-dazzle function is cancel-
led if reverse gear is engaged.

WARNING

In the event that an automatic anti-dazzle
rear vision mirror breaks, an electrolyte flu-
id may leak. This could cause irritation to
the skin, eyes and respiratory organs. If you
come into contact with this liquid, it must
be rinsed with large quantities of water. If
necessary, get medial help.

CAUTION

In the event that an automatic anti-dazzle
rear vision mirror breaks, an electrolyte flu-
id may leak. This liquid attacks plastic sur-
faces. Clean it with a wet sponge as soon
as possible.

Note

●

If the light falling on the interior mirror is

obstructed (e.g. with the sun blind), the an-
ti-dazzle mirror with automatic adjustment
will not operate perfectly.

●

When the interior lights are on or reverse

gear engaged, the mirrors do not darken
with automatic adjustment for anti-dazzle
position.

●

If you have to stick any type of sticker on

the windscreen, do not do so in front of the
sensors. Doing so could prevent the anti-
dazzle function from working well or even
from working at all.

Adjusting the exterior mirrors

Fig. 104

Detail of the driver's door: control for

the exterior mirror.

Turn the control to the corresponding posi-
tion:

Turning the knob to the desired position,
adjust the mirrors on the driver side (L,
left) and the passenger side (R, right) to
the direction desired.
Depending on the equipment fitted on
the vehicle, the mirrors may be heated
according to the outside temperature.
Folding in mirrors.

Synchronized regulation of the exterior
mirrors

In the infotainment system, using the function
button



> Settings > Mirrors and

wipers > Mirrors

, the exterior rear view

L/R





125

Operation

mirrors can be selected to adjust in a
synchronised manner.

●

Turn the knob to position

●

Adjust the left-hand exterior mirror. The

right exterior mirror will be adjusted at the
same time (synchronised).

●

If necessary, correct the right-hand rear-

view mirror: rotate the control to position

Memory function

The memory buttons

›››

page 131

can be

used to save and turn on settings for the exte-
rior mirrors.

The settings will also be saved in the key or in
the user of the online services.

Tilt function for front passenger exterior
mirror

When parking backwards, and in order to be
able to see the kerb, the passenger side mir-
ror can be automatically tilted towards the
passenger to provide a better view of the
kerb. The control must be in the position

for this feature to be operational.

The mirror returns to its original position as
soon as you drive forward at over 15 km/h
(9 mph) or switch off the ignition. It also re-

turns to its original position if the position of
the control is adjusted.

Storing the rear view mirror settings for the
tilt function

●

Switch the ignition on.

●

In the infotainment system, select



Settings > Mirrors and wipers > Mir-
rors > Lower in reverse gear

›››

page 85

●

Select the

1 )

position on the control.

●

Select reverse gear.

●

Adjust the front passenger exterior mirror so

that you can see, for example, the kerb area
well.

●

Release the reverse gear.

●

The adjusted position for the rear view mir-

ror is stored.

Fold the rearview mirrors when locking the
vehicle

In the infotainment system, using the function
button



> Settings > Mirrors and

wipers > Mirrors

, the exterior mirrors can

be selected to fold in when the vehicle is
parked and locked

›››

page 85

When the vehicle is locked with the remote
control, the exterior mirrors are retracted au-
tomatically. When the vehicle is opened with
the remote control, the exterior mirrors are
deployed automatically.

WARNING

Convex or wide-angle exterior mirrors give
a larger field of vision. However, they make
objects look smaller and further away than
they really are. If you use these mirrors to
estimate the distance to vehicles behind
you when changing lane, you could mis-
judge the distance. Risk of accident!

WARNING

Fold and unfold the exterior mirror, taking
care to avoid injuries.

●

Only fold or unfold the exterior mirror

when there is no-one in the way of the mir-
ror.

●

When moving the mirror, take care not to

trap fingers between the mirror and the
mirror bracket.

CAUTION

●

If for any reason (e.g. a bump when ma-

noeuvring) one of the rear view mirrors is
knocked out of position, the mirrors must

Regulation in right-hand drive vehicles is sym-

metrical.

126

Visibility

first be fully retracted with the electric
control. The rear view mirror must not be
placed by hand in the starting position, as
the folding mechanism can be damaged.

●

Before washing the vehicle in an auto-

matic car wash, please make sure to fold
the exterior mirrors in to prevent them from
being damaged. Electrically retractable
exterior mirrors must not be folded in or out
by hand, always use the electrical power
control.

Note

●

If the electrical adjustment should fail to

operate, both of the mirrors can be adjus-
ted by hand by lightly pressing the edge of
the mirror glass.

●

The fold-in function on the exterior mir-

rors will not activate at speeds over
40 km/h (25 mph).

Sun protection

sun blind

Fig. 105

Sun visor

Options for adjusting driver and front pas-
senger sun visors

●

Lower the sun visor towards the wind-

screen.

●

The sun visor can be pulled out of its

mounting and turned towards the door

›››

Fig. 105

●

Swing the sun visor towards the door, longi-

tudinally backwards.

There is a vanity mirror on the sun visor, with a
cover. When the cover is opened

a light

comes on.

The lamp goes out when the vanity mirror
cover is closed or the sun visor is pushed
back up.

WARNING

Folded sun blinds can reduce visibility.

●

Always store sun blinds and visors in their

housing when not in use.

Note

The light above the sun visor automatically
switches off after a few minutes in certain
conditions. This prevents the 12-volt vehicle
battery from discharging.

127

Operation

Seats and headrests

Adjusting seats

Manual adjustment of the front
seats

Fig. 106

Front seats: manual seat settings.

Forwards/backwards: pull the lever and
move the seat. The seat must engage
when the lever is released!
Raise/lower: pull the lever up or push
down (several times if necessary) from its
home position.
Tilting the backrest: turn the hand wheel.
Lumbar support: move the lever until the
required position is achieved.

WARNING

Incorrect seat adjustment may lead to ac-
cidents and severe injuries.

●

Only adjust the seats when the vehicle is

stationary, as the seats could move unex-
pectedly while the vehicle is in motion and
you could lose control of the vehicle. Fur-
thermore, an incorrect position is adopted
when adjusting the seat.

●

Adjust the height, position and inclination

of the front seats only when their move-
ment area is empty.

●

Make sure there are no objects in that

area.

●

Make sure that the movement and lock-

ing areas of the seats are clean.

WARNING

Incorrectly using upholstery and seat cov-
ers might cause an accidental activation of
the electrical seat adjustment system and
make it move unexpectedly while driving.
This might cause loss of control of the vehi-
cle and thus accidents or injuries. More-
over, the electrical components of the front
seats might be damaged.

●

Never attach or place seat upholstery or

covers on the electric controls.

●

Never use upholstery or seat covers that

have not been explicitly authorised for the
seats of the vehicle.

Electric driver's seat adjustment

Fig. 107

Driver's seat: electric seat settings.

Adjust the lumbar support: press the but-
ton according to the desired position.
Seat forwards/backwards: press the but-
ton forwards/backwards.
Seat up/down: Press the rear part of the
button up/down. To adjust the angle of
the seat cushion, press the front of the
button up/down.
Backrest further upright/further reclined:
press the button forwards/backwards.

128

Seats and headrests

The position will be saved automatically in
the SEAT Connect Active user when the igni-
tion is switched off

WARNING

●

If the electric front seats are used negli-

gently or without paying due attention, it
can cause serious injury.

●

The front seats can also be electrically

adjusted when the ignition is switched off.
Never leave a child or any other person
who may need help in the vehicle.

●

In the event of an emergency, electrical

adjustment can be stopped by pressing
any control.

CAUTION

To avoid damaging the electrical compo-
nents of the front seats, please refrain from
kneeling on the seat or applying sharp
pressure at a single point to the seat cush-
ion and backrest.

Note

●

It may not be possible to electrically ad-

just the seat if the charge of the 12-volt ve-
hicle battery is very low.

●

If the engine is started while the seats are

being electrically adjusted, the adjustment
will stop.

●

When changing user a warning will be

shown on the infotainment system's screen
during the time that the seat is moving to
the saved position. This movement can be
stopped by pressing the stop button on the
screen.

Headrest

Introduction

The possibilities for the adjustment and disas-
sembly of the headrests are described below.
Always make sure that the seats are correctly
adjusted

›››

page 13

All seats are equipped with a headrest. The
central rear headrest is only intended for the
central seat of the rear bench. Therefore, do
not install it on any other seat.

Correct adjustment of headrest

Adjust the headrest so that its upper edge is
at the same level as the top of your head and
under no circumstances below eye level.

Keep the back of your head always as close
to the headrest as possible.

Adjusting the headrest for short people

Lower the headrest completely, even if your
head is below its upper edge. In the lowest
position, there may be a small distance be-
tween the headrest and the backrest.

Adjusting the headrest for tall people

Push the headrest up as far as it will go.

WARNING

If travelling with the headrests removed or
improperly adjusted, the risk of severe or
fatal injuries in the event of accidents and
sudden braking or manoeuvres increases.

●

Always travel with the headrest correctly

installed and adjusted.

●

To decrease the risk of cervical injuries in

the event of an accident, adjust the head-
rest correctly based on your height, always
making sure that its upper edge is at the
same height as the top of the head, but
never below eye level. Keep the back of
your head always as close to the headrest
as possible and centred.

●

Never adjust the headrest while the vehi-

cle is in motion.

Valid for vehicles fitted with the Infotainment

Connect System.

129

Operation

●

Under no circumstances should the rear

passengers travel while the headrests are
in the non-use position.

CAUTION

When assembling and disassembling the
headrests, do not let them meet the top lin-
ing of the vehicle, the back rest of the front
seat or other parts of the vehicles. If not,
this could damage the vehicle.

Adjusting the headrests

Fig. 108

Front seat: headrest adjustment.

Fig. 109

Rear headrest: headrest adjustment.

Adjusting the height of the headrests

●

Grab the sides of the headrests with both

hands and push upwards to the desired posi-
tion. To lower it, repeat the same action,
pressing the

›››

Fig. 108

›››

Fig. 109

button

on the side.

●

The headrest must lock correctly in one po-

sition.

Removing and fitting the headrests

Fig. 110

Front headrest: removal.

Fig. 111

Rear headrest: removal.

Removing the front headrests

●

Lower the head restraint if necessary.

●

To unlock it, look for the rabbet on the bot-

tom of the backrest and press in the direction
of the arrow

›››

Fig. 110

●

Remove the headrest in the direction of the

arrow

130

Seats and headrests

Fitting the front headrests

●

Place the headrest in the correct position

on the guides of the corresponding backrest
and insert it.

●

Press the headrest downwards until the

bars lock.

●

Adjust the headrest according to the in-

structions on the correct position of the seat.

Removing the rear headrests

To remove the headrest, the corresponding
backrest must be partially folded forward.

●

Unlock the backrest

›››

page 132

●

Move the headrest upwards until it arrives

to the top.

●

Press button

›››

Fig. 111

, while simultane-

ously pressing on the security hole

with a

flat screwdriver a maximum of 5 mm wide,
and remove the headrest.

●

Move the backrest until it engages properly

›››

in Folding down and raising the rear

seat backrest on page 133

Fitting the rear headrests

To mount the external headrests, the corre-
sponding backrest must be partially folded
forward.

●

Unlock the backrest

›››

page 132

●

Insert the headrest bars into the guides until

they perceptibly engage. It should not be

possible to remove the headrest from the
backrest.

●

Move the backrest until it engages properly

›››

in Folding down and raising the rear

seat backrest on page 133

WARNING

Remove the rear headrests only when it is
necessary to fit a child seat. After removing
a child seat, refit the headrest immediately.

Seat functions

Memory function

Fig. 112

On the outer side of the driver's seat:

memory buttons.

Memory buttons

The memory buttons can be used to save
and turn on settings for the driver seat and
the exterior mirrors.

The settings will also be saved in the key or in
the user of the online services, depending on
the version.

Save the settings of the driver seat and
the exterior mirrors while driving forward

●

Apply the electronic parking brake.

●

Move the gearshift to the neutral position.

●

Switch the ignition on.

●

Adjust the driver seat and the exterior mir-

rors.

●

Press



for longer than 1 second

›››

Fig. 112

●

Press the memory button in which to store

the settings within approx. 10 seconds. A
warning sound will confirm they have been
stored.

Storing the passenger rear view mirror
settings while driving in reverse

●

Apply the electronic parking brake.

●

Move the gearshift to the neutral position.

●

Switch the ignition on.

●

Press the required memory button.

●

Select reverse gear.

●

Adjust the front passenger exterior mirror so

that you can see, for example, the kerb area
well.

131

Operation

●

The new position of the mirror will be stored

automatically and allocated to the vehicle
key that was used to unlock the vehicle.

Activating settings

●

With the vehicle stopped and the ignition

switched on, press and hold the correspond-
ing memory button until the saved position is
reached.

●

OR:

With the ignition switched off and the

driver's door open, briefly press the corre-
sponding button.

●

The front passenger side exterior mirror au-

tomatically changes from the position stored
for reversing as soon as the vehicle moves
forward at a speed of at least 15 km/h
(10 mph) or when the gear selection lever is
changed to a position other than

›››

page 125

Initialising the seat position memory

The position memory system must be restar-
ted if, for example, the driver seat has been
changed.

Restarting deletes all memories and assign-
ments for the seat with position memory. The
memory keys can then be programmed
again.

●

Open the driver door and do not get into

the vehicle.

●

Operating the seat settings from outside

the vehicle.

●

Tilt the backrest fully forward.

●

Release the control to set the angle and

then press again until an audible warning is
heard.

WARNING

Adjust the memory function only when the
vehicle is stationary.

Note

If the driver door is opened approx. 10 mi-
nutes after the vehicle was unlocked or lat-
er, the driver seat and the exterior mirrors
do not move automatically.

Folding down and raising the rear
seat backrest

Fig. 113

Rear seat: folding the backrest.

Fig. 114

In the luggage compartment: levers

for remote release of the left part

and right

part

of the rear seat backrest.

The rear seat backrest is split and each part
can be lowered forward separately to extend
the luggage compartment.

Lowering the rear seat backrest with the
unlock button

●

Push the headrest down as far as it will go

›››

page 129

●

Pull the unlock button

›››

Fig. 113

forward

and lift the backrest at the same time. The
rear seat backrest is not engaged when the
red marking of the button

is visible.

Folding down the backrest from the boot
with the unlocking levers

●

Push the headrest down as far as it will go

›››

page 129

●

Open the rear lid

›››

page 105

132

Seats and headrests

●

Pull the unlocking lever

›››

Fig. 114

of the

part of the backrest to fold down.

●

The corresponding part of the backrest will

be unlocked or will be folded forward.

●

If necessary, close the rear lid

›››

page 105

Folding up the rear seat backrest

●

Lift the backrest and press it firmly into the

lock until it engages

›››

●

It should not be possible to see the red

mark of the unlock button

●

Make sure that the seat belt is not trapped.

●

The backrest must be properly engaged.

●

If necessary, adjust the headrest.

WARNING

Serious injuries can be caused if the rear
seat backrest is lowered or lifted without
due care and attention.

●

When folding down the rear seat, always

make sure there are no people or animals in
the backrest area.

●

Never lower or lift the rear seat backrest

while driving.

●

Do no trap or damage the seat belt when

raising the rear seat backrest.

●

When lowering or lifting the rear seat

backrest, keep your hands, fingers, feet
and other body parts out of its path.

●

For the rear seat belts to offer the neces-

sary protection all the parts of the rear

backrest must be properly engaged. This is
particularly important in the case of the
centre rear seat. If someone is seated in a
seat whose backrest is not properly engag-
ed they will be thrown forwards, along with
the backrest, during an accident or a sud-
den driving or braking manoeuvre.

●

When the rear seat backrest is lowered or

is not properly engaged nobody else can
travel in the corresponding seats (not even
a child).

CAUTION

Serious damage can be caused to the vehi-
cle and other objects if the rear seat back-
rest is lowered or lifted without due care
and attention.

●

Before folding the rear seat backrest for-

ward, always adjust the front seats so that
neither the headrests nor the cushions of
the rear backrest can hit them.

●

Before folding the rear seat backrest, al-

ways make sure there are no objects in the
movement area of the backrest.

Front centre armrest

Fig. 115

Front centre armrest

raise

the armrest, pull it fully up in the di-

rection of the arrow

›››

Fig. 115

up or step by

step depending on the desired opening.

lower

the armrest, first lift it to its highest

position. Then lower it down.

move

the armrest horizontally, move it for-

ward

›››

Fig. 115

or backward as much as

possible in the direction of the corresponding
arrow.

WARNING

The front centre armrest may obstruct the
driver's arm movements, which could
cause an accident and severe injuries.

●

Keep the storage compartments of the

centre armrest closed at all times while the
vehicle is in motion.

133

Operation

●

Never let anyone sit on the centre arm-

rest while the vehicle is in motion, not even
a child. This position is incorrect and may
cause severe injuries.

Transport and practical
equipment

Storing objects

Positioning the luggage and cargo

It is possible to carry objects and luggage in
the vehicle, in a trailer

›››

page 289

and on

the roof

›››

page 141

. When doing so, please

consider all legal provisions.

Placing luggage inside the vehicle safely

●

Distribute the load in the vehicle as evenly

as possible.

●

Always place equipment and heavy ob-

jects in the boot

›››

●

Position heavy items in the boot as far for-

ward as possible.

●

Take into account the maximum authorised

weight per axle, as well as the maximum au-
thorised weight of the vehicle

›››

page 350

●

Secure the objects to the fastening rings of

the boot using appropriate chains or belts

›››

page 138

●

Also place small objects safely.

●

Adapt tyre pressure to the load. Take into

account the pressure adhesive of the tyres

›››

page 324

●

In vehicles equipped with tyre pressure

control system, adjust to the new load status
if necessary

›››

page 328

WARNING

Loose or unsecured objects can cause seri-
ous injury in case of sudden manoeuvring
or braking or in case of an accident. Partic-
ularly if the airbag hits them when deploy-
ing and they are thrown across the inside of
the vehicle. Please observe the following
rules to minimise the risk of injury:

●

Place all objects inside the vehicle safe-

ly.

●

Secure all objects, little and large.

●

Place the objects in the cabin in such a

way that they can never reach the airbag
deployment areas while the vehicle is in
motion.

●

Keep the storage compartments closed

at all times while the vehicle is in motion.

●

Place the objects in such a way that they

never force any occupant of the vehicle to
sit in an incorrect position.

●

When transporting objects that take up a

seat, never let anyone use that seat.

●

Never leave hard, sharp or heavy objects

loose in open storage compartment of the
vehicle, on the cover behind the rear seat
or on the dashboard.

●

Remove all hard, sharp or heavy objects

from the fabrics and bags inside the cabin
and store them safely.

134

Transport and practical equipment

WARNING

The transport of heavy object changes ve-
hicle handling and increases braking dis-
tance. Heavy objects that are not properly
placed or secured may cause loss of con-
trol of the vehicle and thus severe injuries.

●

Never put too much load in the vehicle.

Both the carrying capacity as well as the
distribution of the load in the vehicle have
effects on the driving behaviour and brak-
ing ability.

●

When transporting heavy objects, the

driving behaviour of the vehicle varies due
to the displacement of the centre of gravi-
ty.

●

Always distribute the load in the vehicle

as evenly and horizontally as possible.

●

Always place heavy objects in the boot

before the rear axle and as far away from it
as possible.

●

Objects in the luggage compartment

that are unsecured could move suddenly
and modify the handling of the vehicle.

●

Adapt your speed and driving style at all

times to suit visibility, weather, road and
traffic conditions.

●

Accelerate with particular care and cau-

tion.

●

Avoid sudden braking and manoeuvres.

●

Brake earlier than usual.

WARNING

●

Never leave your vehicle unattended, es-

pecially when the rear lid is open. Children
could climb into the luggage compartment,
closing the door behind them; they will be
trapped and run the risk of death.

●

Close and lock all the doors and the rear

lid when you leave the vehicle. Before you
lock the vehicle, make sure that there are
no adults or children in the vehicle.

CAUTION

Electrical wires or, depending on the fea-
tures, the antenna embedded into the rear
windows could be damaged, even irrepara-
bly, if they are in contact with objects.

Note

Straps for securing the load to the fasten-
ing rings are commercially available from
accessory shops.

Luggage compartment

Luggage compartment shelf

Fig. 116

In the luggage compartment: remov-

ing and fitting the shelf.

Fig. 117

In the luggage compartment: remov-

ing and fitting the shelf.

Removing

●

Detach the cord loops

›››

Fig. 116

from

their hooks

135

Operation

●

Remove the rear shelf from the side sup-

ports

›››

Fig. 117

by pulling it upwards and

then take it out.

If necessary, the rear shelf can be stored un-
der the luggage compartment double floor

›››

page 136

Fitting

●

Insert the cover horizontally so that the “re-

cess” fits onto the axis of the supports

›››

Fig. 117

and press down until it engages.

●

Hook the loops

›››

Fig. 116

to the rear lid.

WARNING

Animals, loose or unsecured or objects car-
ried on the rear shelf can cause serious in-
jury in case of sudden manoeuvring or
braking or in case of an accident.

●

Do not leave hard, sharp or heavy ob-

jects or in bags on the rear shelf.

●

Never transport animals on the rear shelf.

CAUTION

●

Before closing the rear lid, ensure that

the rear shelf is correctly fitted.

●

An overloaded luggage compartment

could mean that the rear shelf is not cor-
rectly seated and it may be bent or dam-
aged.

●

If the luggage compartment is overloa-

ded, remove the tray.

Note

Ensure that, when placing items of clothing
on the luggage compartment cover, rear
visibility is not reduced.

Store the rear shelf

Fig. 118

In the luggage compartment: covers

for storing the rear shelf.

Fig. 119

In the luggage compartment: fitting

the rear shelf.

Depending on the equipment, once the lug-
gage compartment shelf has been removed,
it can be stored under the boot floor.

●

Remove the left and right covers

›››

Fig. 118

●

Place the rear shelf in the corresponding

housing

›››

Fig. 119

●

Put the left and right covers in their original

position.

136

Transport and practical equipment

Variable luggage compartment
floor

Fig. 120

Variable luggage compartment floor:



raised position;



lowered position.

Fig. 121

Variable luggage compartment floor:

inclined position.

Variable floor in high position

●

To move from the low position to the high

position, lift the floor using the handle

›››

Fig. 120

, and pull it back until the front

of the floor has fully passed the supports

›››

Fig. 120

●

Move the floor forward over the supports as

far as the rear seat backrest and then lower
the floor with the handle

Variable floor in low position

●

To move from the high position to the low

position, lift the floor using the handle

›››

Fig. 120

, and pull it back until the front

of the floor has fully passed the supports

›››

Fig. 120

●

Now let the front part fall to the floor and

slide the floor forwards as far as the rear seat
backrest; lower the floor at the same time
with the handle

Variable floor in the tilted position

When the variable floor is tilted you can ac-
cess the spare wheel or anti-puncture kit
area.

●

Lift the variable floor in the high position us-

ing handle

›››

Fig. 120

, pull it up and push

it towards the backrest of the rear seats until
it folds along the hinge line and the movable
part of the floor is resting on itself.

●

Rest the floor on its housings

›››

Fig. 121

(ar-

rows).

Variable floor with folded seats

●

To move from the high position to the low

position, lift the floor using the handle

›››

Fig. 120

and pull it back a little.

●

Push the variable floor towards the folded

rear seats with the handle

using some

downward pressure so that the moving part
of the floor is flush with the backs of the rear
seats.

WARNING

●

Always secure objects, even when the

luggage compartment floor is properly lif-
ted.

●

Only objects that do not protrude more

than 2/3 the height of the floor may be car-
ried between the rear seat and the raised
luggage compartment floor.

137

Operation

●

Only objects that do not weigh than ap-

proximately 7.5 kg may be carried between
the rear seat and the raised luggage com-
partment floor.

CAUTION

●

The maximum weight that can be loaded

on the luggage compartment variable floor
in the top position is 100 kg.

●

Do not let the luggage compartment

floor fall when closing it. Always carefully
guide it downwards in a controlled manner.
Otherwise, the lining and the floor of the
luggage compartment could be damaged.

Fastening rings

Fig. 122

In the luggage compartment: fasten-

ing rings.

There are fastening rings

›››

Fig. 122

on the

front and rear of the boot to secure loose ob-

jects and luggage with fastening belts and
cords.

In order to use the fastening rings, they must
be lifted beforehand.

WARNING

If unsuitable or damaged belts or retaining
straps are used, they could break in the
event of braking or an accident. Objects
could then be launched across the passen-
ger compartment and cause serious or fa-
tal injuries.

●

Always use belts or straps that are suita-

ble and in good condition.

●

Tighten the belts and straps in a cross

layout over the load placed on the boot
floor and secure them to the fastening rings
safely.

●

Never exceed the maximum tensile load

of the fastening rings when securing ob-
jects.

●

Make sure that, particularly for flat ob-

jects, the upper edge of the load is higher
than the fastening rings.

●

Depending on the features, take into ac-

count the instruction panels on the boot on
how to place the load.

●

Never secure a child seat to the fastening

rings.

Note

●

The maximum tensile load that the fas-

tening rings can support is approx. 3.5 kN.

●

Belts, straps and securing systems for the

appropriate load can be obtained from
specialised dealerships. SEAT recom-
mends visiting a SEAT dealership for this.

●

The fastening rings are rendered unusa-

ble for versions with a spare wheel.

138

Transport and practical equipment

Net bag

Fig. 123

In the luggage compartment: net bag

hooked up at floor level.

Fig. 124

In the luggage compartment: rings

and hooks

for attaching the net bag.

The luggage compartment prevents light
luggage from moving. The net bag has a zip
and can be used to store small objects.

The net bag can be hooked up to the lug-
gage compartment in different ways.

Hooking the net bag into the luggage
compartment floor

If necessary, the front eyes must be unfolded
first

›››

page 138

●

Secure the net hooks to the fastening rings

and

›››

Fig. 123

›››

. The bag zip

should be facing upwards.

Hook the net bag next to the load thresh-
old

●

Secure the short net hooks to the fastening

rings

›››

Fig. 124

›››

. The bag zip should

be facing upwards.

●

Secure the straps in the bag hooks

Removing the net bag

The hooked up net bag is taut

›››

●

Release the net bag from the fastening

rings.

●

Store the net bag in the luggage compart-

ment.

WARNING

To secure the elastic net bag on the fasten-
ing rings of the boot it must be stretched
out. Once hooked up it is taut. If the net bag
is hooked up or unhooked incorrectly the
hooks could cause injuries.

●

Always secure the bag hooks properly so

that they do not suddenly release from the

fastening rings when hooking or unhooking
them.

●

On hooking or unhooking them, protect

your eyes and face in case the hooks are
released suddenly.

●

Always hook up the net bag hooks in the

described order. If a hook is unfastened
suddenly, this may cause injuries.

Bag hooks

Fig. 125

In the luggage compartment: bag

hooks.

There may be hooks for hanging bags on
both sides of the luggage compartment

›››

Fig. 125

The retaining hooks have been designed to
secure light shopping bags.

139

Seat Ateca (2022 year). Manual in english - page 8
