Renault Master (2022 year). Manual in english - page 3
CHILD SEATS: attachment by seat belt (1/24)
2-seater van version
Using a child safety system
which is not approved for
this vehicle will not correctly
³
Check the status of the airbag
¬
Seat which allows a child seat
protect the baby or child.
before fitting a child seat or allowing a
with “Universal” approval to be attached
They risk serious or even fatal injury.
passenger to use the seat.
by a seat belt.
B2: Seat enabling a child seat with “B2”
²
Seat not suitable for fitting child
approval to be attached by seat belt.
seats.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.44
CHILD SEATS: attachment by seat belt (2/24)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
WITHOUT PASSENGER
2-seater van version
WITH PASSENGER AIRBAG
AIRBAG
Child seat group
Weight of the child
Front passenger seat
Front passenger seat
Rear-facing shell seat
< 13 kg
U (1) (2)
U (2)
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1) (2)
U (2)
Group 0+ and 1
9 to 18 kg
Forward-facing seat
9 to 18 kg
U (1) (2)
U (2)
Group 1
Booster seat
15 kg to 25 kg and
U / B2 (1) (2)
U / B2 (2)
Group 2 and 3
22 to 36 kg
U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
RISK OF DEATH OR SERIOUS INJURY, before installing a child seat:
(1) on the front passenger seat, check that the airbag has been deactivated ➥ 1.80;
(2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly ➥ 1.20. Adjust the seat belt
position to the lowest position. Make sure that the seat belt is locked in position correctly after you have adjusted it
➥ 1.23.
1.45
CHILD SEATS: attachment by seat belt (3/24)
3-seater van version
Using a child safety system
which is not approved for
this vehicle will not correctly
³
Check the status of the airbag
¬
Seat which allows a child seat
protect the baby or child.
before fitting a child seat or allowing a
with “Universal” approval to be attached
They risk serious or even fatal injury.
passenger to use the seat.
by a seat belt.
B2: Seat enabling a child seat with “B2”
²
Seat not suitable for fitting child
approval to be attached by seat belt.
seats.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.46
CHILD SEATS: attachment by seat belt (4/24)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
3-seater van version
WITH PASSENGER AIRBAG
WITHOUT PASSENGER AIRBAG
Central front
Side front
Central front
Side front
Child seat group
Weight of the child
passenger seat
passenger seat
passenger seat
passenger seat
Rear-facing shell seat
< 13 kg
U (1)
U (1)
U
U
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1)
U (1)
U
U
Group 0+ and 1
9 to 18 kg
Forward-facing seat
9 to 18 kg
U (1)
U (1)
U
U
Group 1
Booster seat
15 kg to 25 kg and
U (1)
U / B2 (1)
U
U / B2
Group 2 and 3
22 to 36 kg
U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a child seat in the front passenger seat, make sure that the
front passenger airbag has been deactivated ➥ 1.80.
1.47
CHILD SEATS: attachment by seat belt (5/24)
7-seater double cab version
Using a child safety system
which is not approved for
this vehicle will not correctly
³
Check the status of the airbag
¬
Seat which allows a child seat
protect the baby or child.
before fitting a child seat or allowing a
with “Universal” approval to be attached
They risk serious or even fatal injury.
passenger to use the seat.
by a seat belt.
B2: Seat enabling a child seat with “B2“
²
Seat not suitable for fitting child
approval to be attached by seat belt.
seats.
B3: Seat enabling a child seat with “B3“
approval to be attached by seat belt.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.48
CHILD SEATS: attachment by seat belt (6/24)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
WITH PASSENGER
WITHOUT PASSENGER
7-seater double cab version
AIRBAG
AIRBAG
Rear
Central
Central
Rear side
Side front
Side front
central
Weight of
front
front
seats
Child seat group
passenger
passenger
seats
the child
passenger
passenger
seat
seat
seat
seat
Rear-facing
shell seat
< 13 kg
U (1)
U (1)
U
U
U
X
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1)
U (1)
U
U
U
X
Group 0+ and 1
9 to 18 kg
Forward-facing seat
9 to 18 kg
U (1)
U (1)
U
U
U
X
Group 1
15 kg to 25
Booster seat
kg and
U (1)
U / B2 (1)
U
U / B2
U / B2 / B3
X
Group 2 and 3
22 to 36 kg
X = Seat not suitable for fitting child seats of this type.
U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
B3 = Seat enabling a child seat with “B3” approval to be attached by seat belt; check that it can be fitted.
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a child seat in the front passenger seat, make sure that the
front passenger airbag has been deactivated ➥ 1.80.
1.49
CHILD SEATS: attachment by seat belt (7/24)
6-seater double cab version (3 front seats and 3 rear seats)
Using a child safety system
which is not approved for
this vehicle will not correctly
³
Check the status of the airbag
¬
Seat which allows a child seat
protect the baby or child.
before fitting a child seat or allowing a
with “Universal” approval to be attached
They risk serious or even fatal injury.
passenger to use the seat.
by a seat belt.
B2: Seat enabling a child seat with “B2”
²
Seat not suitable for fitting child
approval to be attached by seat belt.
seats.
B3: Seat enabling a child seat with “B3”
Carrying a passenger is
approval to be attached by seat belt.
STRICTLY PROHIBITED.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.50
CHILD SEATS: attachment by seat belt (8/24)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
6-seater double cab version
WITH PASSENGER
WITHOUT PASSENGER
(3 front seats and 3 rear seats)
AIRBAG
AIRBAG
Rear
Rear side
Central
Central
centre
Side front
Side front
seats
Weight of
front
front
seat
Child seat group
passenger
passenger
the child
passenger
passenger
seat
seat
seat
seat
Rear-facing shell
seat in groups
< 13 kg
U (1)
U (1)
U
U
U
X
0+ and 1
Rear-facing seat
< 13 kg and
U (1)
U (1)
U
U
U
X
in groups 0+ and 1
9 to 18 kg
Forward-facing
9 to 18 kg
U (1)
U (1)
U
U
U
X
seat in group 1
15 kg to 25
Booster seat in
kg and
U (1)
U / B2 (1)
U
U / B2
U / B2 / B3
X
groups 2 and 3
22 to 36 kg
X = Seat not suitable for fitting child seats of this type.
U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
B3 = Seat enabling a child seat with “B3” approval to be attached by seat belt; check that it can be fitted.
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a child seat in the front passenger seat, make sure that the
front passenger airbag has been deactivated ➥ 1.80.
1.51
CHILD SEATS: attachment by seat belt (9/24)
6-seater double cab version (2 front seats and 4 rear seats)
Using a child safety system
which is not approved for
this vehicle will not correctly
³
Check the status of the airbag
¬
Seat which allows a child seat
protect the baby or child.
before fitting a child seat or allowing a
with “Universal” approval to be attached
They risk serious or even fatal injury.
passenger to use the seat.
by a seat belt.
B2: Seat enabling a child seat with “B2”
²
Seat not suitable for fitting child
approval to be attached by seat belt.
seats.
B3: Seat enabling a child seat with “B3”
approval to be attached by seat belt.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.52
CHILD SEATS: attachment by seat belt (10/24)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
WITH
WITHOUT
6-seater double cab version
PASSENGER
PASSENGER
(2 front seats and 4 rear seats)
Rear central
AIRBAG
AIRBAG
Rear side seats
seats
Front passenger
Front passenger
Child seat group
Weight of the child
seat
seat
Rear-facing
shell seat
< 13 kg
U (1) (2)
U (2)
U
X
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1) (2)
U (2)
U
X
Group 0+ and 1
9 to 18 kg
Forward-facing seat
9 to 18 kg
U (1) (2)
U (2)
U
X
Group 1
Booster seat
15 kg to 25 kg and
U / B2 (1) (2)
U / B2 (2)
U / B2 / B3
X
Group 2 and 3
22 to 36 kg
X = Seat not suitable for fitting child seats of this type.
U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
B3 = Seat enabling a child seat with “B3” approval to be attached by seat belt; check that it can be fitted.
RISK OF DEATH OR SERIOUS INJURY, before installing a child seat:
(1) on the front passenger seat, check that the airbag has been deactivated ➥ 1.80;
(2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly ➥ 1.20. Adjust the seat belt
position to the lowest position. Make sure that the seat belt is locked in position correctly after you have adjusted it
➥ 1.23.
1.53
CHILD SEATS: attachment by seat belt (11/24)
5-seater double cab version
Using a child safety system
which is not approved for
this vehicle will not correctly
³
Check the status of the airbag
¬
Seat which allows a child seat
protect the baby or child.
before fitting a child seat or allowing a
with “Universal” approval to be attached
They risk serious or even fatal injury.
passenger to use the seat.
by a seat belt.
B2: Seat enabling a child seat with “B2”
²
Seat not suitable for fitting child
approval to be attached by seat belt.
seats.
B3: Seat enabling a child seat with “B3”
Carrying a passenger is
approval to be attached by seat belt.
STRICTLY PROHIBITED.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.54
CHILD SEATS: attachment by seat belt (12/24)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
WITH
WITHOUT
5-seater double cab version
PASSENGER
PASSENGER
AIRBAG
AIRBAG
Rear side seats
Rear centre seat
Weight of
Front passenger
Front passenger
Child seat group
the child
seat
seat
Rear-facing
shell seat
< 13 kg
U (1) (2)
U (2)
U
X
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1) (2)
U (2)
U
X
Group 0+ and 1
9 to 18 kg
Forward-
facing seat
9 to 18 kg
U (1) (2)
U (2)
U
X
Group 1
15 kg to 25
Booster seat
kg and
U / B2 (1) (2)
U / B2 (2)
U / B2 / B3
X
Group 2 and 3
22 to 36 kg
X = Seat not suitable for fitting child seats of this type.
U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
B3 = Seat enabling a child seat with “B3” approval to be attached by seat belt; check that it can be fitted.
RISK OF DEATH OR SERIOUS INJURY, before installing a child seat:
(1) on the front passenger seat, check that the airbag has been deactivated ➥ 1.80;
(2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly ➥ 1.20. Adjust the seat belt
position to the lowest position. Make sure that the seat belt is locked in position correctly after you have adjusted it
➥ 1.23.
1.55
CHILD SEATS: attachment by seat belt (13/24)
The table below summarises the information already shown on the diagram on the next page, to ensure the regulations
in force are respected.
5-seater Combi version
Front passenger seat
Rear seats
2nd row side seats
WITH
WITHOUT
Weight of
2nd row
Child seat group
PASSENGER
PASSENGER
Behind
the child
Behind
centre seat
AIRBAG
AIRBAG
front
driver
passenger
Carrycot fitted across
the vehicle
< 10 kg
X
X
X
X
X
Group 0
Rear-facing shell seat
< 13 kg
U (1) (2)
U (2)
X
X
X
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1) (2)
U (2)
X
X
X
Group 0+ and 1
9 to 18 kg
Forward-facing seat
9 to 18 kg
U (1) (2)
U (2)
UF (3)
X
X
Group 1
15 kg to
Booster seat
25 kg and
U / B2 (1) (2)
U / B2 (2)
UF (3)
X
X
Group 2 and 3
22 to 36 kg
1.56
CHILD SEATS: attachment by seat belt (14/24)
X = Seat not suitable for fitting child seats of this type.
U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
UF = Seat which allows a forward-facing seat with “Universal” approval only to be attached by seat belt; check that it can be fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
(3): In all situations, remove the headrest of the rear seat on which the child seat is positioned. This must be done before fitting
the child seat ➥ 1.19. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat
and the child’s legs.
RISK OF DEATH OR SERIOUS INJURY, before installing a child seat:
(1) on the front passenger seat, check that the airbag has been deactivated ➥ 1.80;
(2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly ➥ 1.20. Adjust the seat belt
position to the lowest position. Make sure that the seat belt is locked in position correctly after you have adjusted it
➥ 1.23.
1.57
CHILD SEATS: attachment by seat belt (15/24)
5-seater Combi version
Using a child safety system
Seat which allows a child seat
Check the status of the airbag
which is not approved for
¬
with “Universal” approval to be
³
before fitting a child seat or al-
this vehicle will not cor-
attached by a seat belt.
lowing a passenger to use the seat.
rectly protect the baby or
child. They risk serious or even fatal
Seat not suitable for fitting
B2: Seat enabling a child seat with “B2”
injury.
²
child seats.
approval to be attached by seat belt.
Seat which only allows a for-
ward-facing seat with
“Universal” approval to be attached
with a seat belt.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.58
CHILD SEATS: attachment by seat belt (16/24)
6-seater Combi version
Using a child safety system
Seat which allows a child seat
Check the status of the airbag
which is not approved for
¬
with “Universal” approval to be
³
before fitting a child seat or al-
this vehicle will not cor-
attached by a seat belt.
lowing a passenger to use the seat.
rectly protect the baby or
child. They risk serious or even fatal
Seat not suitable for fitting
B2: Seat enabling a child seat with “B2”
injury.
²
child seats.
approval to be attached by seat belt.
Seat which only allows a for-
ward-facing seat with
“Universal” approval to be attached
with a seat belt.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.59
CHILD SEATS: attachment by seat belt (17/24)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
6-seater Combi version
Front passenger seats
Rear seats
WITHOUT
WITH PASSENGER
PASSENGER
2nd row side seats
AIRBAG
AIRBAG
Weight of
2nd row
Child seat group
the child
Behind
centre seat
Behind
central
side
central
side
front
driver
passenger
Carrycot fitted
across the vehi-
< 10 kg
X
X
X
X
X
X
X
cle
Group 0
Rear-facing shell
seat
< 13 kg
U (1)
U (1)
U
U
X
X
X
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1)
U (1)
U
U
X
X
X
Group 0+ and 1
9 to 18 kg
Forward-facing
seat
9 to 18 kg
U (1) (2)
U (1) (2)
U (2)
U (2)
UF (2)
X
X
Group 1
15 kg to
Booster seat
U / B2
25 kg and
U (1) (2)
U (2)
U / B2 (2)
UF (2)
X
X
Group 2 and 3
(1) (2)
22 to 36 kg
1.60
CHILD SEATS: attachment by seat belt (18/24)
X = Seat not suitable for fitting child seats of this type.
U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
UF = Seat which only allows a forward-facing seat with “Universal” approval to be attached with a seat belt; check that it can be
fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
(2): In all situations, remove the headrest of the rear seat on which the child seat is positioned. This must be done before fitting
the child seat. ➥ 1.19. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat
and the child’s legs.
(1) RISK OF DEATH OR SERIOUS INJURY: before fitting a child seat in the front passenger seat, make sure that the
front passenger airbag has been deactivated ➥ 1.80.
1.61
CHILD SEATS: attachment by seat belt (19/24)
The table below summarises the information already shown on the diagram on the next page, to ensure the regulations
in force are respected.
8-seater Combi version
Front passenger seat
Rear seats
2nd row side seats
WITHOUT
2nd row
Weight of
WITH PASSENGER
3rd
Child seat group
PASSENGER
centre
the child
AIRBAG
Behind
row
AIRBAG
Behind
seat
front
driver
passenger
Carrycot fitted
across the vehi-
< 10 kg
X
X
X
X
X
X
cle
Group 0
Rear-facing shell
seat
< 13 kg
U (1) (2)
U (2)
X
X
X
X
Group 0 or 0 +
Rear-facing seat
< 13 kg and
U (1) (2)
U (2)
X
X
X
X
Group 0+ and 1
9 to 18 kg
Forward-facing
seat
9 to 18 kg
U (1) (2)
U (2)
UF (3)
X
X
X
Group 1
15 kg to
Booster seat
25 kg and
U / B2 (1) (2)
U / B2 (2)
UF (3)
X
X
X
Group 2 and 3
22 to 36 kg
1.62
CHILD SEATS: attachment by seat belt (20/24)
X = Seat not suitable for fitting child seats of this type.
U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
UF = Seat which only allows a forward-facing seat with “Universal” approval to be attached with a seat belt; check that it can be
fitted.
B2 = Seat enabling a child seat with “B2” approval to be attached by seat belt; check that it can be fitted.
(3): In all situations, remove the headrest of the rear seat on which the child seat is positioned. This must be done before fitting
the child seat ➥ 1.19. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat
and the child’s legs.
RISK OF DEATH OR SERIOUS INJURY, before installing a child seat:
(1) on the front passenger seat, check that the airbag has been deactivated ➥ 1.80;
(2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly ➥ 1.20. Adjust the seat belt
position to the lowest position. Make sure that the seat belt is locked in position correctly after you have adjusted it
➥ 1.23.
1.63
CHILD SEATS: attachment by seat belt (21/24)
8-seater Combi version
Using a child safety system
Seat which allows a child seat
which is not approved for
¬
with “Universal” approval to be
³
Check the status of the airbag
this vehicle will not cor-
attached by a seat belt.
before fitting a child seat or allowing a
rectly protect the baby or
passenger to use the seat.
child. They risk serious or even fatal
Seat not suitable for fitting
injury.
²
child seats.
B2: Seat enabling a child seat with “B2”
approval to be attached by seat belt.
Seat which only allows a for-
ward-facing seat with
“Universal” approval to be attached
with a seat belt.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.64
CHILD SEATS: attachment by seat belt (22/24)
9-seater Combi version
Using a child safety system
Seat which allows a child seat
Check the status of the airbag
which is not approved for
¬
with “Universal” approval to be
³
before fitting a child seat or al-
this vehicle will not cor-
attached by a seat belt.
lowing a passenger to use the seat.
rectly protect the baby or
child. They risk serious or even fatal
Seat not suitable for fitting
B2: Seat enabling a child seat with “B2”
injury.
²
child seats.
approval to be attached by seat belt.
Seat which only allows a for-
ward-facing seat with
“Universal” approval to be attached
with a seat belt.
RISK OF DEATH OR
SERIOUS INJURY: before
fitting a child seat in the
front passenger seat, make
sure that the front passenger airbag
has been deactivated. ➥ 1.80.
1.65
