DRIVING ADVICE, ECO-DRIVING (1/5)
Fuel consumption is accredited in ac-
- in green or white, depending on the
cordance with a standard regulatory
vehicle, when the vehicle is in free-
method. Identical for all manufactur-
1
wheel mode (automatic neutral).
ers, this enables vehicles to be com-
pared with one another. Consumption
On the instrument panel
in real time depends on vehicle usage
2
conditions, the equipment fitted and the
The information display can be organ-
user’s driving style. To optimise fuel
ised and customised based on the in-
consumption, please refer to the follow-
strument panel customisation style se-
ing advice.
lected from the multimedia screen.
Depending on the vehicle, you will have
The rev counter with ECO zone 1
various functions which enable you to
lower your fuel consumption:
Driving in the ECO zone helps you op-
timise fuel consumption under most cir-
- the rev counter;
cumstances.
- gear change indicator;
Free-wheel function
Gear change indicator 2
- the driving style indicator;
On vehicles fitted with an automatic
Depending on the vehicle, to obtain op-
- the journey record and eco-driving
gearbox (depending on the vehicle),
timum consumption levels, a warning
advice via the multimedia screen;
during deceleration phases (driver’s
light on the instrument panel lets you
- ECO mode;
foot fully off the accelerator pedal),
know the best time to move up or down
switching to freewheeling (automatic
a gear:
- the Stop and Start (refer to the infor-
neutral) decreases engine braking and
mation on “Stop and Start function”
allows you to move farther without ac-
Š
move up a gear;
in Section 2).
celerating in order to save fuel.
‰
move down a gear.
Warning light
appears on the in-
strument panel:
- in grey when the vehicle is not in
free-wheel mode;
2.22
DRIVING ADVICE, ECO-DRIVING (2/5)
On the multifunction screen
Journey record
Once the engine is switched off, you
4
will see “Journey record” displayed on
the screen 4, enabling you to view in-
formation relating to your last journey.
This indicates:
- average fuel consumption;
- number of miles/kilometres travelled;
- number of miles/kilometres saved.
This corresponds to driving without
fuel consumption (deceleration and/
or foot off the accelerator pedal).
3
An overall rating from 0 to 100 is dis-
played to let you assess your eco driv-
If you regularly follow this indicator, you
If you regularly monitor this indicator,
ing performance. The higher the rating,
will reduce your vehicle’s fuel consump-
you will reduce your vehicle’s fuel con-
the lower the fuel consumption.
tion.
sumption.
Eco advice is given to help improve
To activate/deactivate the driving style
your performance.
Driving style indicator 3
indicator, please see the multimedia
With your favourite journeys saved,
Informs you about the driving style
system instructions.
you can compare your performance
adopted in real time. You will be notified
between trips and the performance of
by indicator 3.
other vehicle users.
On the multifunction screen
Please refer to the multimedia instruc-
The more petals there are on indica-
tions for further information.
tor 3, the smoother and more economi-
Journey record
cal your driving.
Once the engine is switched off, you
will see “Journey record” displayed on
the screen 4, enabling you to view in-
formation relating to your last journey.
2.23
DRIVING ADVICE, ECO-DRIVING (3/5)
ECO mode
Activating the function
ECO mode is a function which opti-
The function can be activated:
mises fuel consumption. It affects cer-
- by pressing switch 4;
tain driving operations (acceleration,
- Depending on the vehicle, from the
shifting gears, cruise control, decelera-
navigation menu on the multimedia
tion etc.).
4
screen (please refer to the multime-
Limiting acceleration enables low fuel
dia instructions).
consumption in urban and surrounding
areas.
The warning light
comes on on
the instrument panel to confirm activa-
tion.
While driving, it is possible to leave the
ECO mode temporarily in order to im-
prove engine performance.
To activate/deactivate the “free wheel”
For this, depress the accelerator pedal
mode, see “Vehicle settings customisa-
firmly and fully.
tion menu” in Section 1.
ECO mode is reactivated when you
take pressure off the accelerator pedal.
Disabling the function
Press switch 4.
The warning light
goes out on
the instrument panel to confirm deac-
tivation.
2.24
DRIVING ADVICE, ECO-DRIVING (4/5)
- Do not overrev the engine in the in-
- Bad weather, flooded roads:
termediate gears.
You should always use the highest
Do not drive through
gear possible.
floods if the water is
- Avoid sudden acceleration.
above the lower edge of
- Brake as little as possible. If you an-
the wheel rims.
ticipate an obstacle or bend in ad-
vance, you may then simply release
the accelerator pedal.
- Do not try to maintain the same
speed up a hill, accelerate no more
than you would on flat ground. Keep
your foot in the same position on the
accelerator pedal.
- Double declutching and accelerating
before switching off are unnecessary
Driving advice, Eco-driving
in modern vehicles.
Behaviour
- Drive carefully for the first few miles
until the engine reaches its normal
operating temperature, rather than
let it warm up while the vehicle is sta-
tionary.
Obstructions to the driver
- Speed is expensive.
On the driver’s side, only
- Dynamic driving with a lot of frequent
use mats suitable for the
acceleration and braking is expen-
vehicle, attached with the
sive on fuel in comparison to the time
pre-fitted components, and check
saved.
the fitting regularly. Do not lay one
mat on top of another.
There is a risk of wedging the
pedals.
2.25
DRIVING ADVICE, ECO-DRIVING (5/5)
- In vehicles fitted with air condi-
tioning, it is normal to observe an
increase in fuel consumption (espe-
cially in urban conditions) when it is
used. For vehicles fitted with manual
air conditioning, switch off the system
when it is not required.
Recommendations for reducing
consumption and therefore help-
ing to preserve the environment:
If the vehicle has been parked in the
sun, open the doors for a few mo-
ments to let the hot air escape before
starting the engine.
- Do not leave an empty roof rack
Tyres
Advice on use
fitted to the vehicle.
- It is better to fit a trailer for bulky ob-
– An underinflated tyre increases fuel
- Favour the ECO mode.
jects.
consumption.
- Electricity is fuel; switch off all the
- When towing a caravan, fit a wind
– Opt for the highest speed pressure
electrical components which are
deflector and adjust it carefully.
or the pressure recommended to op-
not really needed. However (safety
- Avoid using the car for door-to-door
timise fuel consumption indicated
first), keep your lights on when the
calls (short journeys with long waits
on edge of the driver’s door (please
visibility is bad (“see and be seen”).
in between) because the engine
refer to the information on “Tyre infla-
- Use the air vents. Driving with the
never reaches its normal operating
tion pressure” in Section 4).
windows open at 60 mph (100 km/h)
temperature.
– The use of non-recommended tyres
will increase fuel consumption by
can increase fuel consumption.
4%.
- Never fill the fuel tank right to the
brim to avoid overflow.
2.26
MAINTENANCE AND ANTIPOLLUTION ADVICE
Your vehicle complies with criteria for
In addition, replacing engine, fuel
- Air filter, fuel filter: a choked ele-
recycling and recovering vehicles at the
supply system and exhaust compo-
ment will reduce efficiency. It must
end of their service life, which entered
nents with parts other than those origi-
be replaced.
into force in 2015.
nally recommended by the manufac-
turer may alter your vehicle so that it
Some parts of your vehicle have there-
Exhaust gas monitoring
no longer complies with anti-pollution
fore been designed to facilitate future
regulations.
system
recycling.
Have your vehicle adjusted and
The exhaust gas monitoring system will
These parts are easy to remove so
checked by an authorised dealer, in ac-
detect any operating faults in the vehi-
that they can be recovered and repro-
cordance with the instructions given in
cle’s antipollution system.
cessed by recycling companies.
your maintenance schedule: they will
If this system malfunctions, toxic sub-
By virtue of its design, moderate fuel
have all the equipment necessary for
stances may be released into the at-
consumption and initial settings, your
ensuring that your vehicle is maintained
mosphere or damage may occur.
vehicle also conforms to current an-
to its original standard.
This warning light on the in-
tipollution regulations. The manufac-
Ä
strument panel will indicate if
turer is actively striving to reduce pol-
there are any faults in the system:
lutant exhaust gas emissions and to
Engine adjustments
This lights up when the ignition is
save energy. But the fuel consumption
- Spark plugs: for optimum condi-
switched on and goes out when the
of your vehicle and the level of pollutant
tions of use, output and performance
engine is started.
exhaust gas emissions are also your
the specifications laid down by our
- If it lights up continuously, consult an
responsibility. Ensure that it is main-
Design Department must be strictly
approved Dealer as soon as possi-
tained and used correctly.
applied.
ble;
If the spark plugs have to be changed,
- if it flashes, reduce the engine speed
use the make, type and gap specified
until the light stops flashing. Contact
Maintenance
for your vehicle’s engine. Contact an
an authorised dealer as soon as pos-
It is important to remember that fail-
authorised dealer for this.
sible.
ure to respect antipollution regulations
- Ignition and idle speed: no adjust-
Refer to the information on
could lead to legal action being taken
ment is needed.
against the vehicle owner.
“Reagent tank” in Section 1.
2.27
ENVIRONMENT
Your vehicle has been designed with
Emissions
- At the end of the vehicle’s service
respect for the environment in mind for
life, it should be sent to approved
Your vehicle has been designed to emit
its entire service life: during production,
centres to ensure that it is recycled.
fewer greenhouse gases (CO2) while in
use and at the end of its life.
use, and therefore to consume less fuel
- In all cases, comply with local legis-
(eg. 140 g/km, equivalent to 5.3 l/100
lation.
Manufacture
km for a diesel vehicle).
Your vehicle has been manufactured at
Our vehicles are also equipped with
Recycling
a factory which complies with a policy
an emission control system including a
Your vehicle is 85% recyclable and
to reduce the environmental impact
catalytic converter, an oxygen sensor
95% recoverable.
on the surrounding areas (reduction of
and an active carbon filter (the latter
water and energy consumption, visual
prevents vapour from the fuel tank
To achieve these objectives, many of
and noise pollution, atmospheric emis-
being released into the open air).
the vehicle components have been de-
sions and waste water; sorting and re-
signed to enable them to be recycled.
For certain diesel vehicles, this system
using waste).
The materials and structures have
also has a particle filter to reduce the
been carefully designed to allow these
volume of soot particles emitted.
components to be easily removed and
reprocessed by specialist companies.
Please make your own
In order to preserve raw material re-
contribution towards
sources, this vehicle incorporates nu-
protecting the environment
merous parts made from recycled plas-
tics or renewable materials (vegetable
too
or animal-derived materials such as
- Worn parts replaced in the course of
cotton or wool).
routine vehicle maintenance (vehi-
cle battery, oil filter, air filter, batter-
ies, etc.) and oil containers (empty or
filled with used oil) must be disposed
of through specialist organisations.
2.28
TYRE PRESSURE MONITORING SYSTEM (1/3)
Resetting the standard level
Resetting procedure
for the tyre pressures
With the ignition on:
1
2
3
- repeatedly and briefly press control 2
This should be done:
to select the tyre pressure display
- when the standard tyre pressure
and the “Tyre pressure” function;
needs to be changed to adapt to
- press and hold (around 3 seconds)
usage conditions (empty, carrying a
the button 2 to launch the reset. The
load, motorway driving, etc.);
flashing tyres followed by the mes-
- after swapping a wheel (however
sages “Learning TP initiated” and
this practice is not recommended);
then “Tyres location in progress” in-
- after changing a wheel.
dicates that the reset request for the
It should always be done after checking
tyre pressure reference value has
the tyre pressure of all four tyres when
been acknowledged.
cold.
Reset can take several minutes of driv-
Tyre pressures must correspond to the
ing.
current usage of the vehicle (empty,
If the vehicle is equipped with the func-
If the resetting is followed by short
carrying a load, motorway driving, etc.).
tion, this system monitors the tyre pres-
trips, the message “Tyres location in
sure.
progress” can remain displayed after
successive restarts.
Operating principle
Note
The standard tyre pressure cannot be
Each wheel (except for the emergency
less than that recommended and indi-
spare wheel) has a sensor in the infla-
cated on the door frame.
tion valve which periodically measures
the tyre pressure.
The system displays the current pres-
sures on the instrument panel 1 and
alerts the driver in the event of insuffi-
cient pressure.
Resetting can also be done from the
multifunction screen 3 if your vehi-
cle is fitted with a navigation system.
Select “Vehicle”, “Tyre pressure”.
2.29
TYRE PRESSURE MONITORING SYSTEM (2/3)
“Puncture”
1
A wheel Bis shown in red, the warning
A
light 4
comes on, the message
“Puncture” appears and there is a beep.
This message appears along with the
®
warning light.
They indicate that the affected wheel
4
is punctured or severely underinflated.
Replace it or contact an approved
dealer if it is punctured. Top up the tyre
pressure if the wheel is deflated.
B
“Check tyre pressure sensors”
A wheel A disappears, the warning
light 4
flashes for several sec-
Display
“Adjust tyre pressure”
onds then comes on continuously and
The display 1 and the warning light 4
A wheel B is shown in orange, the
the message “Check tyre pressure sen-
sors” appears.
on the instrument panel warn
warning light 4
comes on and
This message appears along with the
you of any tyre pressure faults (flat tyre,
the message “Adjust tyre pressure” ap-
warning light. They indicate that
punctured tyre, system fault, etc.).
pears.
at least one wheel is not fitted with sen-
They indicate that a wheel is deflated.
sors (e.g. emergency spare wheel).
Check and, if necessary, readjust the
Otherwise, consult an authorised
pressures of the four wheels when cold.
dealer.
The warning light 4
goes off after
a few minutes’ driving.
For your safety, the warning
light
®
requires you
to stop immediately as soon
as traffic conditions allow.
The sudden loss of pressure in a tyre (burst tyre, etc.) cannot be detected by the
system.
2.30
TYRE PRESSURE MONITORING SYSTEM (3/3)
“Tyres location failure”
Replacing wheels/tyres
Tyre repair product and
This message “Tyres location failure”
This system requires specific equip-
inflation kit
appears when driving if one or more
ment (wheels, tyres, hubcaps, etc.).
Because the valves are specially de-
wheels have been fitted with sensors
Please see the information on “Tyres”
signed, only use equipment approved
not recognised by Renault.
in Section 5.
by the approved network. Please refer
Consult an approved dealer
Contact an approved Dealer to fit new
to “Tyre inflation kit” in Section 5.
tyres and to find out about available ac-
cessories compatible with the system
Readjustment of tyre
and available from your dealer net-
pressures
work: the use of any other accessory
Changing a wheel
could affect the correct operation of the
The tyre pressures should be ad-
The system may take sev-
system or damage a sensor.
justed when cold (please refer to the
eral minutes depending on
label located on the edge of the driver’s
use for the new wheel po-
door). If the tyre pressures cannot be
Emergency spare wheel
sitions and pressures to be recog-
checked when the tyres are cold, the
nised; check the tyre pressures after
If the vehicle is equipped with an emer-
recommended pressures should be in-
all operations.
gency spare wheel, it will not have a
creased by 0.2 to 0.3 bar (3 PSI).
sensor.
Never deflate a hot tyre.
This function is an addi-
tional driving aid.
However, the function is
not intended to replace the
driver. It cannot, therefore, under
any circumstances replace the vig-
ilance or the responsibility of the
driver. Check the tyre pressures, in-
cluding the emergency spare wheel,
once a month.
2.31
DRIVER CORRECTION DEVICES AND AIDS (1/6)
Depending on the vehicle, they will con-
ABS (anti-lock braking
sist of:
system)
-
ABS (anti-lock braking system) ;
Under heavy braking, the ABS prevents
the wheels from locking, allowing the
–
ESC (electronic stability control)
stopping distance to be managed and
with understeer control and trac-
keeping control of the vehicle.
tion control;
Under these circumstances, the vehi-
-
emergency brake assist;
cle can be steered to avoid an obstacle
-
advanced traction control;
whilst braking. In addition, this system
can increase stopping distances, par-
–
hill start assistance.
ticularly on roads with low surface grip
(wet ground, etc.).
You will feel a pulsation through the
These functions are an ad-
brake pedal each time the system is
ditional aid in the event of
activated. The ABS does not in any
critical driving conditions,
way improve the vehicle's physical per-
enabling the vehicle behav-
formance relating to the road surface
iour to be adapted to suit the driving
and road-holding. It is still essential to
conditions.
follow the rules of good driving practice
(such as driving at a safe distance from
The functions do not take the place
the vehicle in front, etc.).
of the driver. They do not increase
the vehicle’s limits and should
not encourage you to drive more
quickly. Therefore, they can under
no circumstances replace the vigi-
lance or responsibility of the driver
when manoeuvring the vehicle (the
driver must always be ready for
In an emergency, apply firm and
sudden incidents which may occur
continuous pressure to the brake
when driving).
pedal. There is no need to pump
it repeatedly. The ABS will modu-
late the force applied in the braking
system.
2.32
DRIVER CORRECTION DEVICES AND AIDS (2/6)
Operating faults:
-
and x
lit up on the in-
strument panel accompanied
by the messages
“Check ABS”,
“WARNING: Check Braking System”
and “Check ESC”: this indicates that
the ABS, the ESC and the emer-
gency brake assist are disabled.
Braking is always enabled;
- x
, D
,
and
®
lit on the instrument panel accom-
panied by the message “WARNING:
Braking System”: this indicates a
fault with the braking system.
In both cases, please consult an
Authorised Dealer.
For your own safety, the
Your braking systems
®
warning light re-
are partially operational.
quires you to stop immedi-
However, it is dangerous
ately, as soon as traffic con-
to brake suddenly and it
ditions allow. Switch off the engine
is essential to stop immediately, as
and do not restart it. Call an ap-
soon as traffic conditions allow. Call
proved Dealer.
an approved Dealer.
2.33
DRIVER CORRECTION DEVICES AND AIDS (3/6)
Electronic stability control
Understeer control
Operating faults
ESC with understeer control
This system optimises the action of the
When the system detects an operating
and traction control
ESC in the case of pronounced under-
fault the message “Check ESC” and
steering (loss of front axle road hold-
appear
Electronic stability program ESC
ing).
on the instrument panel.
This system helps you to keep control
Traction control
In this case, the ESC and traction con-
of the vehicle in critical driving condi-
tions (avoiding an obstacle, loss of grip
This system helps to limit wheelspin of
trol system are deactivated. Call an ap-
on a bend, etc.).
the drive wheels and to control the ve-
proved Dealer.
hicle when pulling away accelerating or
Operating principle
decelerating.
A sensor in the steering wheel detects
Operating principle
the direction selected by the driver.
Using the wheel sensors, the system
Other sensors throughout the vehicle
measures and compares the speed of
measure the actual direction.
the drive wheels at all times and slows
down their over-rotation. If a wheel is
The system compares driver input to
starting to slip, the system brakes au-
the actual trajectory of the vehicle and
tomatically until the drive supplied be-
corrects the trajectory if necessary by
comes compatible with the level of grip
controlling the braking of certain wheels
under the wheel again.
and/or engine power. In the event that
the system is engaged, indicator light
The system also adjusts the engine
speed to the grip available under the
flashes on the instrument panel.
wheels, independently of the pressure
exerted on the accelerator pedal.
2.34
DRIVER CORRECTION DEVICES AND AIDS (4/6)
The traction control system offers ad-
ditional safety. It is recommended that
you do not drive with the function dis-
abled. Correct this as soon as possible
by pressing switch 1 again.
Note: the function is reactivated auto-
matically when the ignition is switched
on or when a speed of approximately
25 mph (40 km/h) is exceeded.
1
Emergency brake assist
This system supplements the ABS
and helps reduce vehicle stopping dis-
tances.
These functions are an ad-
ditional aid in the event of
Operating principle
critical driving conditions,
Deactivating the function
The system is for detecting an emer-
enabling the vehicle behav-
(depending on vehicle)
gency braking situation. In this case,
iour to be adapted to suit the driving
the braking assistance immediately de-
In some situations (driving on very wet
conditions.
velops maximum power and may trig-
ground: snow, mud, etc. or driving with
ger ABS regulation. ABS braking is
The functions do not take the place
snow chains fitted), the system may
maintained as long as the brake pedal
of the driver. They do not increase
reduce the engine output to limit wheel-
is applied.
the vehicle’s limits and should
spin. If this is not required, it is possible
not encourage you to drive more
to deactivate the function by pressing
Hazard warning lights illumination
quickly. Therefore, they can under
switch 1.
Depending on the vehicle, these may
no circumstances replace the vigi-
light up in the event of sudden decel-
The message “TRACTION CONTROL
lance or responsibility of the driver
eration.
OFF” is displayed on the instrument
when manoeuvring the vehicle (the
panel to inform you.
driver must always be ready for
sudden incidents which may occur
when driving).
2.35
DRIVER CORRECTION DEVICES AND AIDS (5/6)
Advanced traction control
“Soft ground” mode
If fitted on the vehicle, traction control
Turn the selector
2: the integrated
makes it easier to control the vehicle on
warning light
comes on, accom-
low grip surfaces (soft ground, etc.).
panied by a message on the instrument
panel “Grip Extend Loose Surface ON”.
This position enables optimal usage on
soft ground (mud, sand, dead leaves,
etc.).
“Soft ground” mode uses traction con-
trol functions. The system automatically
For your safety and to
switches to “Road” mode above around
comply with the law.
2
25 mph (40 km/h), and the integrated
When they need to be re-
placed, only tyres of the
warning light
on the selector 2
same make, size, type and profile
comes on.
should be used on a single axle.
“Road” mode
They must: either have a load ca-
When the vehicle is started up, the
pacity and speed rating at least
equal to those of the original
warning light
on the selector 2
tyres, or conform to those recom-
comes on, along with the instrument
mended by an authorised dealer.
panel message “Grip Extend Traction
Failure to heed these instructions
Control”.
could endanger your safety and
This position enables optimal usage
affect your vehicle’s roadworthi-
under normal driving conditions (dry-
ness.
ness, humidity, light snow, etc.).
Risk of loss of control of the ve-
hicle.
“Road” mode uses traction control func-
tions.
2.36
DRIVER CORRECTION DEVICES AND AIDS (6/6)
“Expert” mode
Hill start assistance
Turn the selector
2: the integrated
Depending on the gradient of the in-
cline, this system assists the driver
warning light
comes on, accom-
when starting on a hill. It prevents the
panied by a message on the instrument
vehicle from rolling backwards by au-
panel “Grip Extend Expert Mode ON”.
The hill start assistance
tomatically applying the brakes when
This position enables optimum usage
system cannot completely
the driver lifts his/her foot off the brake
in extreme conditions (very snowy or
prevent the vehicle from
pedal to depress the accelerator pedal.
muddy roads). The engine speed is left
rolling backwards in all sit-
under the control of the driver.
uations (extremely steep gradients
System operation
etc.).
The system automatically switches to
It only operates when the gear lever is
“Road” mode above around 25 mph
In all cases, the driver may depress
in a position other than neutral (other
(40 km/h), and the integrated warning
the brake pedal to prevent the vehi-
than N or P for automatic transmis-
sions) and the vehicle is completely
cle from rolling backwards.
light
on the selector 2 comes on.
stationary (brake pedal depressed).
The hill start assistance function
The system holds the vehicle for ap-
should not be used for prolonged
proximately 2 seconds. The brakes are
stops: use the brake pedal.
then released (the vehicle will move ac-
This function is not designed to im-
cording to the slope).
mobilise the vehicle permanently.
If necessary, use the brake pedal to
stop the vehicle.
The driver must remain particularly
vigilant when driving on slippery or
low-grip surfaces.
Risk of serious injury.
2.37
ACTIVE EMERGENCY BRAKING (1/4)
If the driver depresses the brake pedal
and the system still detects a risk of col-
lision, the brake force is increased.
2
If the driver fails to react following
an alert of an imminent collision, the
system activates the brakes.
1
Using the sensor 1, the system calcu-
Operation
lates the distance separating the vehi-
While driving (at speeds of between 19
cle from the one in front and alerts the
and 87 mph (30 and 140 km/h)), if there
driver if there is a risk of a front-end col-
is a risk of collision with the vehicle in
lision. The driver can then brake the ve-
front, the warning light 2 will be dis-
hicle to limit the damage arising from a
played on the instrument panel in red,
collision.
together with a beep.
Sensor location
Make sure that the radar 1 is not ob-
scured (by dirt, mud, snow etc. or by
the fitting of accessories such as bull
bars).
The system only detects vehicles
driving in the same direction of traf-
fic. The system cannot detect mo-
torcycles because of the difficulty in
forecasting their trajectory.
2.38
ACTIVE EMERGENCY BRAKING (2/4)
Press the switch 5 OK again to activate
or deactivate the function:
=
function activated
3
function deactivated
<
5
6
The warning light
is displayed on
4
the instrument panel when the system
is deactivated. This system is reacti-
vated each time the ignition is switched
on.
Conditions for non-activation of the
system
The system does not activate:
- when the gear lever is in neutral;
Activating or deactivating the
For vehicle not fitted with a
- when the parking brake is activated;
navigation system
- while cornering;
system
- for
4-wheel drive vehicles, when
- with the vehicle at a standstill, press
For vehicles fitted with a navigation
Electronic Stability Programme
and hold the switch 5 OK to access
system
(ESC) ESC with understeer and trac-
the settings menu;
tion control is deactivated (please
From the multimedia screen 3, select
- repeatedly press the control 6 up or
see “Electronic Stability Programme
the
“Vehicle” menu,
“Driving assis-
down until you reach the “Driving as-
(ESC) ESC with understeer and trac-
tance”, “Active braking” then choose
sistance” menu. Press the switch 5
tion control” above). Warning light
“ON” or “OFF”.
OK;
- repeatedly press control 6 up or down
comes on.
until you reach the “Active braking”
menu, then press the switch 5 OK.
You can access menu “Driving as-
sistance” directly from button
4
2.39
ACTIVE EMERGENCY BRAKING (3/4)
Temporarily not available
If the system detects a temporary fault,
warning light appears on the
the
instrument panel.
The possible causes are:
Active emergency braking
– the system is temporarily disrupted
(for example: radar obscured by
This function is an additional driving aid. However, this function is not
dirt, mud, snow etc.). In this case,
under any circumstances intended to replace the due care and attention
park the vehicle and switch off the
of the driver, who should at all times be in control of the vehicle.
engine. Clean the detection zone of
System servicing/repairs
the radar. When you next start the
engine, the warning light and the
- In the event of an impact, the sensor alignment may become changed, and its
message go out;
operation will consequently be affected. Deactivate the function, then consult
an authorised dealer.
- if this is not the case, this may arise
from another cause, contact an
- Any work in the area where the radar is located (repairs, replacements, touch-
Approved Dealer.
ing up of paintwork) must be carried out by a qualified professional.
- Fitting accessories which may block the radar is prohibited (bull bars etc.).
Operating faults
Only an authorised dealer is qualified to service the system.
and
displayed on the in-
strument panel: this indicates an oper-
In the event of system disturbance
ating fault. Consult an approved dealer.
Some conditions can disturb or damage the operation of the system, such as:
- a complex environment (metal bridge, etc.);
- poor weather conditions (snow, hail, black ice, etc.).
In these conditions, the system may not react, may warn the driver or may brake
inadvertently.
2.40
ACTIVE EMERGENCY BRAKING (4/4)
Active emergency braking
Limitation of the system operation
- The system will only respond to vehicles which are moving or which have been sensed as moving.
- A vehicle travelling in the opposite direction will not trigger any alert or any action on the system operation.
- The sensor area should be kept clean and free of any modifications in order to ensure the proper operation of the system.
- The system cannot respond to small vehicles such as motorbikes or bicycles as effectively as to other vehicles.
In these conditions, the system may not react, may warn the driver or may brake inadvertently.
Deactivating the function
The function should be deactivated if:
- the brake lights are not functioning;
- the front of the vehicle has undergone an impact or been damaged;
- the vehicle is being towed (breakdowns).
Halting the function
You can halt the active braking function at any time by tapping the accelerator pedal.
If the driver notices any unusual behaviour in the system, please consult an authorised dealer.
2.41
TRANSMISSION: 4-wheel drive (4WD) (1/4)
Mode selector
“2WD" mode
Depending on the road conditions, turn-
To activate this mode, turn the selec-
ing the selector 1 enables the following
tor 1 to the “2WD” position. The warn-
modes to be selected:
ing light ‘
on the instrument panel
- AUTO ;
will come on.
- 2WD ;
Operating principle
- 4WD Lock.
The “2WD” mode uses the front wheels
only. Use this mode on dry roads with
“AUTO" mode
good grip.
To activate this mode, turn selector 1 to
To deactivate this mode, turn the selec-
1
the “AUTO” position.
tor 1 to the “AUTO” position. Warning
Operating principle
light ‘
goes out on the instrument
panel.
“AUTO” mode automatically distributes
the engine torque between the front and
rear axles according to the road condi-
Remember that driving a vehicle off-
tions and the vehicle speed. This po-
road is very different to driving it on
sition optimises roadholding. Use this
the road.
mode on any type of road (dry, snow-
covered, slippery, etc.) or when towing
To make the most of your vehicle
(trailer or caravan).
in an off-road situation, we recom-
mend that you are trained to drive a
The warning light
on the instru-
4x4 (4WD) vehicle.
ment panel will come on.
The safety of both you and your
passengers is your responsibility,
and depends on your skill and the
care you take when driving off-road.
2.42
