Renault Twingo (2018 year). Instruction - part 3

1.34

CHILD SAFETY: attachment using the ISOFIX system

(2/3)

The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-

tions in force are respected.

4-seater vehicle: Fitting a child seat ISOFIX.

Type of child seat

Weight of

the child

Seat size

Front passenger seat (1) (2)

Rear side seats

Carrycot fitted across the

vehicle

Group 0

< 10 kg

F, G

IL (3)

Rear-facing shell seat

Group 0 and 0+

< 13 kg

IL (4)

rear-facing seat

Group 0+ and 1

< 13 kg and 9 to

18 kg

IL (4)

Forward-facing seat

Group 1

9 to 18 kg

A, B, B1

IUF - IL

IUF - IL (5)

Booster seat

Group 2 and 3

15 to 25 kg and

22 to 36 kg

(1) RISK OF DEATH OR SERIOUS INJURY: before installing a child seat on the front passenger seat, check that the

airbag has been deactivated (refer to “Child safety: front passenger airbag deactivation, activation” Section 1).

1.35

CHILD SAFETY: attachment using the ISOFIX system

(3/3)

X = Seat not suitable for fitting child seats ISOFIX.

IUF/IL = On equipped vehicles, seat which allows an approved “Universal”/“semi-universal” or “vehicle specific” child seat to be

attached using the ISOFIX system; check that it can be fitted.

(2) raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).

(3) A carrycot can be installed across the vehicle and will take up at least two seats. Place the child with its feet nearest the door.

(4) Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will

go, although without allowing it to come into contact with the child seat.

(5) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. In all situa-

tions, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the child seat

(please refer to the section entitled “Rear headrests” in Section 3).

1.36

CHILD SAFETY: deactivating, activating the front passenger air bag

(1/3)

Deactivating the front

passenger airbags

(on equipped vehicles)
Before fitting a child seat on the front

passenger seat you must deactivate

the passenger airbag.

The passenger airbag must

only be deactivated or acti-

vated when the vehicle is

stationary.

If it is interfered with when the ve-

hicle is being driven, indicator lights

and

will come on.

Switch the ignition off then on again

to reset the airbag in accordance

with the lock position.

To deactivate the airbags: with the

vehicle stopped and the ignition off,

push and turn lock 1 to the OFF posi-

tion.
With the ignition on, you must check

that the warning light

]

on the dis-

play 2 is switched on.
This light remains permanently lit to

let you know that you can fit a child

seat.

1.37

DANGER
Since operation of the front

passenger airbag is not

compatible with the po-

sition of a rear-facing child seat,

NEVER fit a rear-facing child re-

straint system in a seat protected

by an ACTIVATED front AIRBAG.

This can lead to the DEATH of the

CHILD or SERIOUS INJURY.

The markings on the dashboard and

labels A on each side of passenger sun

blind 3 (example: label shown above)

remind you of these instructions.

CHILD SAFETY: deactivating, activating the front passenger air bag

(2/3)

1.38

CHILD SAFETY: deactivating, activating the front passenger air bag

(3/3)

The passenger airbag must

only be deactivated or acti-

vated when the vehicle is

stationary.

If it is interfered with when the ve-

hicle is being driven, indicator lights

and

will come on.

Switch the ignition off then on again

to reset the airbag in accordance

with the lock position.

Activating the front

passenger airbags

You should reactivate the airbags as

soon as you remove the child seat from

the front passenger seat to ensure the

protection of the front passenger in the

event of an impact.

Operating faults

It is forbidden to fit a rear-facing child

seat to the front passenger seat if the

airbags activation/deactivation system

is faulty.
Allowing any other passenger to sit in

that seat is not recommended.
Contact your approved dealer as soon

as possible.

To reactivate the airbags: with the

vehicle stopped and the ignition off,

push and turn lock 1 to the ON position.
With the ignition switched on, you must

check that the warning light

]

out and that the warning light



comes on the display 2 after each start-

up for around 60 seconds.
The front passenger seat belt additional

restraint systems are activated.

1.39

Door mirrors with manual

adjustment

To adjust the door mirror, move

switch 2.

Door mirrors with electrical

adjustment

With the ignition on, turn the button 3:

– position C to adjust the left-hand

door mirror;

– position E to adjust the right-hand

door mirror.

D is the inactive position.

Heated door mirrors

With the engine running, mirror de-

icing is activated simultaneously with

rear screen de-icing/demisting.

Interior rear view mirror

Its position can be adjusted. For night

driving, to avoid being dazzled by the

headlights of the car behind you, flip the

small lever 1 located behind the rear

view mirror.

REAR VIEW MIRRORS

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

The driver’s door mirror may have two clearly defined zones. Zone B

shows what can normally be seen in an ordinary rear view mirror. Zone A

increases rear side visibility.
Objects in the mirror are closer than they appear.

A B

1.40

DRIVING POSITION: LEFT-HAND DRIVE

(1/2)

1.41

DRIVING POSITION: LEFT-HAND DRIVE

(2/2)

1 Stalk for:

– direction indicator lights;

– exterior lights;

– front fog lights;

– rear fog lights.

2 Side air vent.

3 Side window demister outlet.

4 Driver Airbag and horn location.

5 Instrument panel.

6 Stalk for:

– windscreen and rear screen

wash/wipe;

– trip computer and warning

system information readout.

7 Switch for:

– hazard warning lights;

– electric door locking.

The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY.

8 Centre air vent.

9 Windscreen demister outlet.

10 Multimedia/radio touchscreen.

11 Glovebox.

12 Passenger

Airbag location.

13 Heating or air conditioning con-

trols.

14 Token holder.

15 Main switch for:

– speed limiter;

– cruise control.

16 Handbrake.

17 ECO mode switch.

18 Gear lever.

19 Ignition switch.

20 Radio and/or navigation system

remote control.

21 Multimedia system voice control

button.

22 Steering wheel adjustment control.

23 Cruise control/speed limiter con-

trol.

24 Headlight adjustment control.

25 Controls for:

– activation/deactivation of the

parking distance control system;

– activation/deactivation of the

Stop and Start function;

– activation/deactivation of the

lane departure warning func-

tion.

1.42

DRIVING POSITION: RIGHT-HAND DRIVE

(1/2)

6 7

1.43

DRIVING POSITION: RIGHT-HAND DRIVE

(2/2)

The equipment fitted, described below, DEPENDS ON THE VERSION AND COUNTRY.

1 Side window demister outlet.

2 Side air vent.

3 Passenger

Airbag location.

4 Heating or air conditioning con-

trols.

5 Multimedia/radio touchscreen.

6 Centre air vent.

7 Switch for:

– hazard warning lights;

– electric door locking.

8 Windscreen demister outlet.

9 Stalk:

– direction indicator lights;

– exterior lights;

– front fog lights;

– rear fog lights.

10 Instrument panel.

11 Driver Airbag and horn location.

12 Stalk for:

– windscreen and rear screen

wash/wipe;

– trip computer and warning

system information readout.

13 Multimedia system voice control

button.

14 Radio and/or navigation system

remote control.

15 Controls for:

– activation/deactivation of the

parking distance control system;

– activation/deactivation of the

Stop and Start function;

– activation/deactivation of the

lane departure warning func-

tion.

16 Ignition switch.

17 Headlight adjustment control.

18 Cruise control/speed limiter con-

trols.

19 Steering wheel adjustment control.

20 Gear lever.

21 Token holder.

22 Main switch for:

– speed limiter;

– cruise control.

23 ECO mode switch.

24 Handbrake.

25 Glovebox.

1.44

WARNING LIGHTS

(1/5)

Side light warning light

Main beam headlight tell-

tale

Dipped beam headlight tell-

tale

Front fog light tell-tale

Rear fog light telltale

Left-hand direction indicator

tell-tale

Right-hand direction indica-

tor tell-tale

Airbag warning light

This lights up when the ignition

is switched on and goes out after a few

seconds.

If it does not come on when the igni-

tion is switched on, or comes on when

the engine is running, there is a fault in

the system.

Contact your approved Dealer as soon

as possible.

Low fuel level warning light

This lights up when the ignition

is switched on, alongside a beep, and

goes out after a few seconds.

If it comes on when driving and is ac-

companied by a beep, fill up with fuel

as soon as possible. There is only ap-

proximately 30 miles (50 km) worth of

fuel left.

If no lights or sounds are ap-

parent, this indicates a fault

in the instrument panel. This

indicates that it is essential

to stop immediately (as soon as traf-

fic conditions allow). Ensure that the

vehicle is correctly immobilised and

contact an approved Dealer.

Instrument panel A: lights up when the

ignition is switched on.
With the lights on, you can adjust the

brightness by turning the knob 1.

Warning light

means you

should drive very carefully to an

authorised dealer as soon as

possible. Failure to follow this rec-

ommendation risks damaging your

vehicle.

Warning light

re-

quires you to stop immedi-

ately, for your own safety,

as soon as traffic conditions

allow. Switch off the engine and do

not restart it. Contact an approved

Dealer.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

1.45

WARNING LIGHTS

(2/5)

STOP light

This lights up when the ignition

is switched on and goes out as soon as

the engine is started. It lights up at the

same time as other warning lights, and

is accompanied by a beep.
It requires you to stop immediately, for

your own safety, as soon as traffic con-

ditions allow. Switch off the engine and

do not restart it.
Contact an approved Dealer.

Oil pressure warning light
This lights up when the ignition

is switched on and goes out after a few

seconds.
If it comes on on the road, accompa-
nied by the

warning light and a

beep, stop immediately and cut the ig-

nition.
Check the oil level. If the level is normal,

the indicator light is being lit by some-

thing else. Contact an approved Dealer.

Warning light

This lights up when the ignition

is switched on and goes out as soon as

the engine is started. It may light up in

conjunction with other warning lights.

You should drive very carefully to an

authorised dealer as soon as possible.

Failure to follow this recommendation

risks damaging your vehicle.

Handbrake on and brake cir-

cuit incident warning light

This comes on when the ignition is

switched on and goes out as soon as

the handbrake is released.

If it comes on during braking and is ac-
companied by the

warning light

and a beep, it indicates that the fluid

level in the circuit is low or that there is

a braking system fault.

Stop as soon as traffic conditions allow

and contact an approved Dealer.

Battery charge warning light
This lights up when the ignition

is switched on and goes out after a few

seconds.
If it comes on on the road, accompa-
nied by the

warning light and a

beep, this indicates an overload or dis-

charge in the electrical circuit.
Stop as soon as traffic conditions allow

and contact an approved Dealer.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

1.46

Anti-lock braking warning

light

This lights up when the ignition is

switched on and goes out after a few

seconds.

If it lights up when you are driving, it in-

dicates a fault in the anti-lock braking

system.

Braking will then be as normal, without

the ABS. Contact an approved Dealer

as soon as possible.

Coolant temperature warn-

ing light

This comes on when the ignition is

switched on.
If it turns red, stop and let the engine

idle for a minute or two.
The temperature should lower and the

warning light should return to a blue

colour. If not, stop the engine. Let the

engine cool down before checking the

coolant.
Contact an approved Dealer.

WARNING LIGHTS

(3/5)

Toxic Fume Filter System

Warning Light

On vehicles which are equipped with it,

this light comes on when the engine is

started and, depending on the vehicle,

when the ignition is switched off if the

vehicle is in the engine standby phase

(refer to the information on the 'Stop

and Start Function' in section 2) then

goes out.
– If it lights up continuously, consult an

authorised dealer as soon as possi-

ble;

– If it flashes, reduce the engine speed

until the light stops flashing. Contact

an approved dealer as soon as pos-

sible.

Please refer to the information on

“Maintenance and anti-pollution advice”

in Section 2.



Warning light for electronic

stability program ( ESC ) and

traction control system
This lights up when the ignition is

switched on and goes out after a few

seconds.
There are several reasons for the warn-

ing light to come on: please refer to

the information on “Dynamic driving

control: ESC” and “Traction control” in

Section 2.



Lane departure system

warning light

Please refer to the information on “Lane

departure warning” in Section 2.

Î¦

Speed limiter and cruise

control indicator lights

See the information on the “Speed lim-

iter” and “Cruise control” in Section 2.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

1.47

WARNING LIGHTS

(4/5)

Door(s) open warning light



Engine standby warning

light

Please see information about “Stop and

Start function” in Section 2.



Unavailability of engine

standby warning light

Please see information in the para-

graph on “Stop and Start Function” in

Section 2.



Mode warning light ECO
This comes on when ECO

mode is activated.

Please refer to the information on

“Driving advice, Eco-driving” in

Section 2.

Electronic fault warning light
This lights up when the ignition

is switched on and goes out after a few

seconds.

If it comes on when driving, this indi-

cates a fault in the injection computer.

Contact your approved Dealer as soon

as possible.

Š‰

Gear change indicator.

This lights up to advise you to

change to a higher gear (up arrow) or

lower gear (down arrow).



Tyre pressure loss warning
Please refer to the information

on the “Tyre pressure loss warning” in

Section 2.

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Variable power-assisted

steering warning light

This comes on when the ignition is

switched on and goes out after a few

seconds.
If it lights up when you are driving, this

indicates a fault in the system. Consult

an approved Dealer as soon as possi-

ble.

1.48

Central display B: lights up when the

ignition is switched on.

Seat belt reminder warning

lights

Please see the information on “Seat

belts” in Section 1.

Front passenger airbag deac-

tivated warning light
Please see the information on “Seat

belts” in Section 1.



Front passenger airbag acti-

vated warning light
Please see the information on “Seat

belts” in Section 1.

WARNING LIGHTS

(5/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND THE COUNTRY.

1.49

DISPLAYS AND INDICATORS

Speedometer 1

(km or miles per hour)

Overspeed buzzer

Depending on the vehicle, a warning

beep sounds for approximately 10 sec-

onds every 30 seconds, as long as the

vehicle is travelling in excess of 75 mph

(120 km/h).

Fuel level gauge 2

Automatic gearbox display 3

This indicates the gear engaged (de-

pending on the vehicle). Refer to the in-

formation on the “Automatic gearbox” in

Section 2.

Content .. 1 2 3 4 ..
