Renault Megane (2018 year). Instruction - part 14

3.22

ELECTRIC WINDOWS

(1/2)

Electric windows

These systems operate:
– with the engine running;
– with the ignition off until one of the

front doors is opened (limited to ap-

proximately 12 minutes).

– with the engine off, front doors

closed, after pressing the start

button.

Press the window switch down or pull it

up to lower or raise the window to the

desired height: the rear windows do not

open fully.

Safety of rear occupants

The driver can prevent operation of the rear electric windows by pressing

switch 4. A confirmation message is displayed on the instrument panel.
Driver’s responsibility

Never leave your vehicle with the RENAULT card or key inside, and never leave

a child, adult who is not self-sufficient or a pet, even for a short while. They may

pose a risk to themselves or to others by starting the engine or activating equip-

ment (such as the gear lever or electric windows). If any part of the body becomes

trapped, reverse the direction of the window immediately by pressing the relevant

switch.
Risk of serious injury.

Avoid resting any objects against

a half-open window: there is a risk

that the electric window could be

damaged.

From the driver’s seat, use switch:

1 for the driver’s side;

2 for the front passenger side;

3 and 5 for the rear passenger win-

dows.

From the passenger seats, use

switch 6.

3.23

ELECTRIC WINDOWS

(2/2)

Operating faults

In case of a fault when closing a

window, the system reverts to normal

mode: pull the switch as many times as

necessary until the window closes com-

pletely, hold the switch (still on the clo-

sing side) for around one second, then

completely lower then raise the window

to reset the system.
If necessary, contact an approved

Dealer.

When closing the windows,

ensure that no part of the

body (arm, hand, etc.) is

protruding from the vehicle.

Risk of serious injury.

One-touch mode
This mode works in addition to the ope-

ration of the electric windows described

previously.

Briefly press or pull the window switch

fully: the window is fully lowered or

raised. Pressing the switch again stops

the window moving.
Note: if the window detects resistance

when closing (e.g.: branch of a tree,

etc.) it stops and then lowers again by a

few centimetres.

Remote control window closing

(vehicles with 4 one-touch electric win-

dows).

When you lock the doors from the out-

side, press the locking button on the

RENAULTcard twice in quick suc-

cession, or on the driver’s door in

hands-free mode, and all the windows

will close automatically (and, depend-

ing on the vehicle, the sunroof).

It is recommended that the user only

operates the system when the vehi-

cle can be seen clearly and no one is

inside.

Manual window winder

controls

Turn the handle 7.

3.24

ELECTRIC SUNROOF

(1/3)

To slide the curtain 1

– to open: push the handle 2 rear-

wards to move the blind to the de-

sired position;

– to close: pull the handle 2 forwards

to move the blind to the desired posi-

tion.

To slide the sunroof

– To tilt: move the marked position 3

to position A.

– to open: move the marked posi-

tion 3 to position B, C or D depend-

ing on the type of opening required;

– to close: move the marked posi-

tion 3 to position 0.

Driver’s responsibility
Never leave your vehicle

with the RENAULT card

inside, and never leave a

child who is not self-sufficient or a

pet, even for a short while.
The reason for this is that the child

may endanger himself or others by

starting the engine, activating equip-

ment such as the window winders

for example, or locking the doors.
If something gets trapped, reverse

the direction of travel as soon as

possible by turning button 4 fully to

the right (position D).
Risk of serious injury.

3.25

ELECTRIC SUNROOF

(2/3)

Special features
Your vehicle is fitted with an anti-pinch

facility: when the sunroof encounters

resistance whilst closing (branch of

a tree, etc.), it stops and then moves

back a few centimetres.
After closing the sunroof by remote

control, pressing button 4 allows the

sunroof to return to its previous posi-

tion.
The sunroof will not open when the

temperature is below -20°C. However,

it will still close.

Closing the sunroof by

remote control

If you press the locking button on

the card twice in quick succession

RENAULT,, the windows and the elec-

tric sunroof will close automatically.
It is recommended that the user only

operates the system when the vehi-

cle can be seen clearly and no one is

inside.

If the vehicle is equipped

with this function, this action

will activate deadlocking.
Refer to the information on

“RENAULT card: deadlocking" or

"Radiofrequency remote control:

deadlocking" in section 1.
Check that there is no-one still

inside the vehicle

When closing the sunroof,

ensure that no part of the

body (arm, hand, etc.) is

protruding from the vehicle.

Risk of serious injury.

3.26

Precautions during use

– Vehicle with loaded roof bars.

As a general rule, if there is a load

on the roof, use of the sunroof is not

recommended.
Before using the sunroof, check the

objects and/or accessories (bike

racks, roof boxes, etc.) attached to

the roof bars: they should be prop-

erly arranged and secured and

should not interfere with the opera-

tion of the sunroof.
Contact an approved dealer for de-

tails of possible conversions;

– check that the sunroof is properly

closed before leaving your vehicle;

– clean the seal every three months

using products recommended by our

Technical Department;

– do not open the sunroof immedi-

ately after it has rained or immedi-

ately after washing the vehicle.

Operating faults

If the sunroof will not close, move the

marked position 3 to position 0 then

press button 4 until the sunroof is com-

pletely closed: consult an approved

dealer.

Important: during this operation, the

sunroof anti-pinch function is de-

activated. Contact your approved

Dealer as soon as possible.

Driver’s responsibility
Never leave your vehicle

with the RENAULT card

inside, and never leave a

child who is not self-sufficient or a

pet, even for a short while.
The reason for this is that the child

may endanger himself or others by

starting the engine, activating equip-

ment such as the window winders

for example, or locking the doors.
If something gets trapped, reverse

the direction of travel as soon as

possible by turning button 4 fully to

the right (position D).
Risk of serious injury.

ELECTRIC SUNROOF

(3/3)

3.27

Note: for vehicles fitted with a naviga-

tion system, you can use the multime-

dia screen to deactivate/activate the

courtesy lights which come on when

the doors or boot are opened. To do

this, please refer to “Vehicle settings

customisation menu” in Section 1.

Glove box light 5

The light comes on when the cover is

opened.

Courtesy light

Press switch 3 for:
– permanent lighting;
– intermittent lighting, which comes

on when a door is opened. It only

switches off after a time delay and

when the doors concerned have

been closed correctly;

– lighting switches off immediately.

Map reading lights
Press switches 2 and 4.

Map reading lights

Press switch 1 to get:
– permanent lighting;
– immediate switching off.

When the doors or boot are un-

locked and opened, the reading and

footwell lights come on temporarily.

INTERIOR LIGHTING

(1/2)

3.28

INTERIOR LIGHTING

(2/2)

Luggage compartment light 6

The light comes on when the luggage

compartment is opened.

With the doors properly shut, lock-

ing or starting the engine makes the

interior lights and the courtesy lights

go out.

3.29

Ticket holder 4

Can be used to hold motorway toll tick-

ets, maps, etc.

SUN VISOR, BLINDS

Front sun visor

Lower the sun visor 1 on the wind-

screen or unclip it and lower it over the

side window.

Vanity mirror

Lift the cover 3.
The light 2 switches on automatically.

When driving, ensure the

courtesy mirror cover is

closed. Risk of injury.

3.30

Door pockets 1

It can hold a bottle.

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(1/4)

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” sto-

rage compartments in such

a way that they may fall onto pas-

sengers during sudden turning or

braking.

Passenger storage

compartment

Pull handle 2 to open it.
The glove box can hold A4-sized docu-

ments, a bottle etc.

3.31

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(2/4)

Central storage

compartment 4

A sliding system 5 holds maintains the

cups.

Central storage

compartment 3

Cup holders 6

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.
There is a risk of burning if hot liquid

escapes.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” stor-

age compartments in such

a way that they may fall onto pas-

sengers during sudden turning or

braking.

3.32

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(3/4)

Central storage

compartment 8

With the sliding armrest 7 in its rear-

most position, raise it.

Grab handle 9

This offers support and can be held

when the vehicle is being driven.
Do not use it for getting into or out of

the vehicle.

Clothes hooks 10

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

3.33

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(4/4)

Rear door storage

compartment 11

Front seat storage pockets 12

Rear central storage

compartment 13

Rear armrest with cup holder

Lower armrest 14.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” sto-

rage compartments in such

a way that they may fall onto pas-

sengers during sudden turning or

braking.

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.
There is a risk of burning if hot

liquid escapes.

3.34

ASHTRAY, CIGARETTE LIGHTER, ACCESSORIES SOCKET (1/2)

Cigarette lighter 1

With the ignition on, push in cigar

lighter 1, it will spring back with a click

when it is ready. Pull it out to use. After

use, replace it without pushing it all the

way in.

Connect accessories with

a maximum power of

120 watts (12 V) only.

When several accessory

sockets are used at the same time,

the total power of the connected

accessories must not exceed

180 watts.

Fire hazard.

If your vehicle is not fitted with a

cigar lighter and an ashtray, these

can be obtained from an authorised

dealer.

Ashtray 3

It can be housed in either position 2.
To open, lift the cover. To empty, pull the

ashtray towards you and it will be re-

leased from its housing 2.

3.35

Accessories sockets 4

You can use the one of sockets 4.

They are provided for connecting ac-

cessories approved by our Technical

Department.

Connect accessories with

a maximum power of

120 watts (12 V) only.

When several accessory

sockets are used at the same time,

the total power of the connected

accessories must not exceed

180 watts.

Fire hazard.

ASHTRAY, CIGARETTE LIGHTER, ACCESSORIES SOCKET (2/2)

3.36

REAR HEADRESTS (1/2)

Position for using the central

headrest A

Raise the headrest as far as possible to

use it in the high position. Check that it

is correctly locked.

The headrest is a safety

component; check that it is

fitted and in the correct po-

sition. The top of the head-

rest should be as close as possible

to the top of the head.

Centre seat headrest B

storage position

Press the button 1 and lower the head-

rest completely.
Set the headrest at the lowest po-

sition or tilted forwards for storage

only: do not set it in this position when

the seat is occupied or if the child seat

is fitted.

To remove a headrest

Raise the headrest as far as it will go,

then press button 1 and remove the

headrest.

To refit a headrest

Insert the rods in the holes, press the

button 1 and lower the headrest. Check

that the bonnet is correctly locked.

3.37

REAR HEADRESTS (2/2)

Storage position for the side

headrests

Press the button 1 and, depending on

the vehicle:
– fully lower (movement A) the head-

rest 2, or

– lower and tilt (movement B) the

headrest 3 fully forwards.

Content .. 12 13 14 15 ..
