5.41

OPERATING FAULTS

(6/6)

Electrical equipment

POSSIBLE CAUSES

WHAT TO DO

Traces of condensation in the lights.

Traces of condensation may be a nat-

ural phenomenon caused by varia-

tions in temperature.
In this case, the traces will disappear

slowly once the lights are switched

on.

The front seat belt reminder light

comes on when the seat belts are

fastened.

An object is stuck between the floor

and the seat and is disrupting the op-

eration of the sensor.

Remove all objects from underneath the

front seats.

6.2

VEHICLE IDENTIFICATION PLATES

1
2
3
4

The information shown on the ve-

hicle identification plate should be

quoted on all correspondence or

orders.
The presence and location of the in-

formation depends on the vehicle.

Vehicle identification plate A

1 Manufacturer name.

2 EC design number or approval

number.

3 Identification number.

Depending on the vehicle, this

information is also given on

marking B.

4 MAM (Maximum Authorised Mass)

5 GTW (Gross train weight: vehicle

fully loaded, with trailer).

6 MPAW (Maximim Permissible

Weight) for front axle.

7 MPAW on rear axle.

8 Reserved for related or additional

entries.

9 Diesel exhaust emissions.

10 Paint reference (colour code).

6.3

ENGINE IDENTIFICATION PLATES

(1/2)

Quote the information on the identi-

fication plate or label A in all corre-

spondence or when ordering parts.

(Location varies depending on engine)

1 Engine type.

2 Engine suffix.

3 Engine number.

6.4

Quote the information on the identi-

fication plate or label A in all corre-

spondence or when ordering parts.

(Location varies depending on engine)

1 Engine type.

2 Engine suffix.

3 Engine number.

ENGINE IDENTIFICATION PLATES

(2/2)

6.5

DIMENSIONS (in metres)

(1/3)

Three door version

0.862

2.640

0.797

1.546

4.299

1.423*

1.547

1.785

* Unladen

6.6

DIMENSIONS (in metres)

(2/3)

0.862

2.641

0.792

1.546

4.292

1.471*

* Unladen

1.547

1.808

Five door version

6.7

DIMENSIONS (in metres)

(3/3)

Sport tourer versions

0.862

2.703

0.994

1.546

4.558

1.461*

* Unladen

1.547

1.766

6.8

Versions

1.2 TCe

1.6 16V

2.0 16V

2.0 T

1.5 dCi

1.6 dCi

1.9 dCi

2.0 dCi

Engine type

(see engine plate)

H5F Turbo

K4M

M4R

F4R Turbo

K9K

R9M

F9Q

M9R

Cubic capacity (cc)

1 197

1,598

1,998

1,461

1 598

1,870

1,995

Type of fuel

Octane Rating

It is essential that you use unleaded petrol of the

octane rating stated on the label inside the fuel

filler flap.

If not available, for a limited time only, use un-

leaded fuel:
– with an octane rating of 91 for a label showing

95 or 98;

– with an octane rating of 87 for a label showing

91, 95 or 98.

Diesel

The label located in the fuel filler

flap indicates authorised fuels.

Spark plugs

Only use the spark plugs specified for your vehi-

cle’s engine.

The type should be marked on a label affixed

inside the engine compartment. If it is not then

contact your approved dealer.

Fitting spark plugs which are not to specification

may damage the engine.

ENGINE SPECIFICATIONS

6.9

WEIGHTS (in kg)

The weights indicated for a basic vehicle without options: they vary depending on the your vehicle’s equipment. Consult

your approved Dealer.

Five door

Estate

Three door

Maximum permissible all-up weight (MMAC)

Gross Train Weight (MTR)

Weights are indicated on the vehicle identification plate (refer to

the information on “Vehicle identification plates” in Section 6)

Braked trailer weight*

found by calculating: MTR - MMAC

Unbraked trailer weight*

635

Permissible nose weight*

Permissible load on the roof with the carrying device

80 kg (including the carrying device)

Prohibited

* Towing weight (towing a caravan, boat, etc.)
Towing is prohibited when the MTR - MMAC calculation is equal to zero, or when the MTR is equal to zero (or is not listed) on the

identification plate.

– It is important to comply with the towing weights, governed by local legislation in each country and, in particular, laid down in

the Road Traffic Regulations. Contact an approved Dealer about any towing equipment.

– When towing, under no circumstances may the total train weight (vehicle + trailer) be exceeded. However the following is

permitted:

– rear axle MMTA exceeded by no more than 15%,

– maximum MMAC exceeded by no more than 10% or 100 kg (whichever is reached first).

In either case, the maximum speed of the vehicle and trailer must not exceed 60 mph (100 km/h) and the tyre pressures must

be increased by 0.2 bar (3 PSI).

– The engine output and climbing capability are reduced with altitude. We recommend that the maximum load be reduced by 10%

at an altitude of 1,000 metres and by an additional 10% for each 1,000 metres thereafter.

Load transfer Sport Tourer versions

If the Maximum Authorised Mass of the vehicle has not been reached, up to 200 kg can be transferred to the braked trailer, within

the limits of the Gross Train Weight.

6.10

Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same

level of quality as the parts fitted originally.
If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out

within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the

repair order.

REPLACEMENT PARTS AND REPAIRS

6.11

SERVICE SHEETS

(1/6)

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

VIN: ..................................................................................

6.12

SERVICE SHEETS

(2/6)

VIN: ..................................................................................

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

6.13

SERVICE SHEETS

(3/6)

VIN: ..................................................................................

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

6.14

SERVICE SHEETS

(4/6)

VIN: ..................................................................................

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

6.15

SERVICE SHEETS

(5/6)

VIN: ..................................................................................

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

6.16

SERVICE SHEETS

(6/6)

VIN: ..................................................................................

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page

Date:

Miles

(km):

Invoice

number:

Comments/miscellaneous

Type of operation:

Stamp

Service

□

.......................................

□

Anticorrosion check:
OK □ Not

OK*

□

*See specific page
