Renault Megane Hatchback (2015 year). Instruction - part 10

3.15

MANUAL WINDOW WINDERS / SUN VISOR

Manual window winders

Turn handle 1.

1

2

3

Sun visor

Lower the sun visor 2 over the wind-

screen or unclip it and turn it over the

side window.

Courtesy mirrors

Slide cover 3, depending on the vehi-

cle, and the mirror is lit.

3.16

INTERIOR LIGHTING

(1/2)

When the doors or luggage com-

partment are unlocked and opened

the courtesy and footwell lights

come on temporarily.

1

2

3

Courtesy light

Tilt switch 2 to move it to the position

for:
– permanent lighting;
–  intermittent lighting, which comes

on when a door is opened. This

switches off after a time delay, once

the doors concerned have been

closed correctly;

–  immediate switching off.

Front door lights

Light  4 comes on when the door is

opened.

4

Map reading lights

(depending on vehicle)
Move switches 1 or 3.

3.17

Boot light 6

Depending on the vehicle, the light 6

comes on when the boot is opened.

INTERIOR LIGHTING

(2/2)

6

5

Glovebox light 5

Light  5 comes on when the cover is

opened.

3.18

Door pockets 1

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(1/4)

1

Nothing should be placed

on the floor area in front of

the driver as such objects

may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

Sun visor storage 2

This can be used for storing motorway

tickets, cards, etc.

2

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

3.19

Centre console storage

compartments 5

Front centre armrest storage

compartment A

Press the button 3 and lift the cover 4.

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(2/4)

Passenger storage

compartment

Pull the handle 6 to open it.
The glove box can hold A4-size docu-

ments, a large bottle of water, etc.
The storage compartment is ventilated

and refrigerated.

6

3

4

A

5

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

3.20

Door storage compartment 7

Storage compartment 8

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(3/4)

Rear armrest with cup holder

Pull down the armrest 9.

7

8

9

3.21

PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS

(4/4)

Rear centre console storage

compartments 13

13

Depending on the vehicle, the stor-

age compartment 13 may be re-

placed by air vents; refer to Section

3 “Air vents”.

12

Front seat storage pockets 12

10

11

Clothes hooks 10

Grab handle 11

This offers support and can be held

when the vehicle is being driven.
Do not use it for getting into or out of

the vehicle.

3.22

ASHTRAY, ACCESSORIES SOCKET

Accessories sockets 1

They are designed for connecting ac-

cessories with a maximum power rating

of 120 Watts (voltage: 12V) which

have been approved by our Technical

Department.

If your vehicle is not fitted with a cigar lighter and an ashtray, these can be ob-

tained from an approved Dealer.

1

2

2

1

Ashtray 2

To open, lift the cover. To empty, pull the

ashtray towards you and it will be re-

leased from its housing.

Connect accessories

with a maximum power of

120 Watts only.
Fire hazard.

3.23

Press button

1 and lower the

seatback(s) A.

To fold down the seatback
Ensure that the front seats are far

enough forward.
Lower the rear headrests (refer to the

information on the “Rear headrests” in

Section 1).
Place the seat belts 2 in their guides 3.

Sport tourer versions

Depending on the vehicle, seatback A

can be folded down on its own to allow

long or bulky objects to be transported.

REAR BENCH SEAT functions

(1/2)

1

A

2

3

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

Before moving the seat-

back, put seat belt 2 in belt

guide 3 to avoid damaging

it.

3.24

When refitting the seat-

back, make sure it is cor-

rectly locked in place.

If seat covers are fitted,

make sure these do not prevent the

seatback latch from locking in.

Make sure that the seat belts are

positioned correctly.

Reposition the headrests.

The seat and the seatback may be

folded away to allow bulky objects to be

carried.

To fold away the seat base
Tilt seat base B against the front seats.

To fold down the seatback
After folding the seat base down,

remove the rear headrests (refer to the

section on “rear headrests”) then press

button 1 and lower the seatback(s) C.

In all situations, remove the rear

headrests (refer to the informa-

tion on the “Rear headrests” in

Section 1).

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

1

C

B

REAR BENCH SEAT functions

(2/2)

When moving the rear

bench seat, ensure that

nothing obstructs the an-

chorage points (part of the

body, a pet, gravel, cloth, toys, etc.).

3.25

TAILGATE

To open
Press button 1 and lift the tailgate.

To close
Pull down the tailgate using handle 2

inside the tailgate to assist you.

1

Opening manually from

inside the vehicle

Special note:
If it is impossible to unlock the tailgate,

it can be done from inside.
–  access the luggage compartment by

folding forward the seatback(s) of

the rear bench seat,

–  insert a pencil or similar object in

cavity 3 and slide the unit as shown

in the illustration,

–  push the tailgate to open it.

2

3

3.26

Removal

Unhook the two cords 1 (tailgate side).

Do not place any objects,

especially heavy or hard

objects, on the parcel shelf.

These may pose a risk to

the vehicle occupants if the driver

has to brake suddenly or if the vehi-

cle is involved in an accident.

Lift rear parcel shelf 2 slightly and pull it

towards you.
To refit it, proceed in reverse order to

removal.

REAR PARCEL SHELF

1

2

Unclip mountings 3 on either side of

the parcel shelf, then remove the parcel

shelf via the luggage compartment.
To refit it, proceed in the reverse order

to removal.

3

3.27

To remove the flexible

section of the luggage cover

Pull handle 1 gently to release the pins

from their mounting points located on

each side of the luggage compartment.
Guide the luggage cover onto the roller.

Removing the luggage cover

Push the luggage compartment cover

to the left (movement A) and lift the

right-hand side of the inertia reel (move-

ment B).
To refit the luggage compartment cover,

insert the left-hand side, then push it to

the left (movement A) and lower the

right-hand side of the inertia reel into its

housing.

LUGGAGE COMPARTMENT COVER: estate models

1

B

A

Do not place any heavy or solid objects on the luggage cover. These may

pose a risk to the vehicle occupants if the driver has to brake suddenly or

if the vehicle is involved in an accident.

3.28

Anchorage points

(Three- and five-seater versions)
Hooks 2 located on each corner of the

luggage compartment, allow the load to

be secured.

LUGGAGE COMPARTMENT STORAGE SPACE AND FITTINGS

(1/3)

Storage under carpet 1

(depending on vehicle)
To open, fold back carpet A.

2

2

Always place objects being trans-

ported so that the heaviest items

are resting against the back of the

rear bench seat.

Side straps

Side straps 3 are located either side of

the luggage compartment, and can be

used to store an oil can.

3

A

1

3.29

LUGGAGE COMPARTMENT STORAGE SPACE AND FITTINGS

(2/3)

Storage under carpet

(sport tourer version)
To access storage compartments 7,

fold back section B using handle 4 and,

depending on the vehicle, lift flap 6.

B

4

7

5

Anchorage points

(sport tourer version)
Hooks 5, located on either side of the

luggage compartment, allow the load to

be secured.

6

3.30

LUGGAGE COMPARTMENT STORAGE SPACE AND FITTINGS

(3/3)

Separating the luggage

compartment

(sport tourer version)
The loading area can be separated.
Turn locks 8 situated on either side of

the luggage compartment to the first

notch. Lift divider C using handle 4;

when the bolts make contact, push the

divider and it will lock.
Maximum weight: 20 kg.

On the back there is an elastic strip 9 to

hold small objects vertically in position.

8

4

C

C

9

Always place objects being trans-

ported so that the heaviest items

are resting against the back of the

rear bench seat.
