Renault Master (2018 year). Instruction - part 1

1.2

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(1/3)

Radio frequency remote

control B

1 Locking all the opening elements.

2 Unlocking all the opening elements.

3 Key for ignition switch, doors and

fuel filler cap.

4 Locking/unlocking the luggage com-

partment and, depending on the ve-

hicle, the sliding side doors.

Radio frequency remote

control A

1  Locking all the opening elements.
2  Unlocking all the opening elements.
3  Key for ignition switch, doors and

fuel filler cap.

The key must not be used for any

function other than those described

in the handbook (removing the cap

from a bottle, etc.).

Advice
Avoid leaving the remote control in

hot, cold or humid areas.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.3

Radio frequency remote

control operating range

This varies according to the environ-

ment: take care not to lock or unlock

the doors by inadvertently pressing the

buttons on the remote control.
Note: on certain vehicles, if a door is

not opened within approximately 2 min-

utes of the door being unlocked by

remote control, the doors will lock again

automatically.

Interference

Interference by factors in the imme-

diate vicinity (external installations or

the use of equipment operating on the

same frequency as the remote control)

may affect the operation of the remote

control.

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(2/3)

Radio frequency remote

control D

1 Locking all the opening elements.

2 Unlocking all the opening elements.

3 Key for ignition switch, doors and

fuel filler cap.

5 To release the insert from its hous-

ing, press button 5, it comes out au-

tomatically. Press button 5 and guide

the insert back into its housing.

6 Locking/unlocking the luggage com-

partment and, depending on the ve-

hicle, the sliding doors.

Radio frequency remote

control C

1 Locking all the opening elements.

2 Unlocking all the opening elements.

3 Key for ignition switch, doors and

fuel filler cap.

5 Locking/unlocking the key insert for

remote control C.

To release the insert from its hous-

ing, press button 5, it comes out au-

tomatically.

Press

button

5 and guide the insert

back into its housing.

1.4

Replacement, additional remote

control or transmitter/receiver

You must only contact an approved

Dealer.
– To replace a remote control, the

vehicle must be taken to an ap-

proved Dealer as both the vehi-

cle and the remote control are

needed to initialise the system.

– Depending on the vehicle, you

may use up to four remote con-

trols or two transmitter/receivers.

Remote control unit failure

Make sure that the correct battery

type is being used, and that the

battery is in good condition and in-

serted correctly. These batteries

have a service life of approximately

two years.

Refer to the information on the “Key,

radio frequency remote control: bat-

teries” in Section 5 for the battery

changing procedure.

Hands-free access

transmitter/receiver E

This enables the vehicle doors to be

locked/unlocked without using the

remote control unit. Refer to the infor-

mation on “Hands-free access transmit-

ter/receiver: use” in section 1.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(3/3)

1.5

KEY, RADIO FREQUENCY REMOTE CONTROL: use

(1/2)

Remote controls A and B are used to

lock and unlock the doors.

They are powered by a battery which

must be replaced (refer to the informa-

tion on the “Key/radio frequency remote

control: batteries” in section 5).

Locking the doors

Pressing button 1 locks the doors and

tailgate. The hazard warning lights and

side in- dicator lights flash twice to in-

dicate that the doors have locked.

Note: depending on the vehicle, when

a door or the tailgate is left open or not

properly closed, all the doors and the

tailgate lock/unlock quickly without the

hazard warning lights flashing.

Unlocking the doors

Pressing button 2 unlocks the doors

and tailgate. The hazard warning lights

and side in- dicator lights flash once to

indicate that the doors have unlocked.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

To lock/unlock the doors from inside,

refer to the information on “Central

door locking/unlocking” in section 1.

1.6

Remote controls C and D are used to

lock and unlock the doors and the lug-

gage compartment.

They are powered by a battery which

must be replaced (refer to the informa-

tion on the “Key/radio frequency remote

control: batteries” in section 5).

Locking the doors

Pressing button 1 locks the doors and

tailgate.
A short press on button 3 locks/unlocks

the luggage compartment and, de-

pending on the vehicle, the sliding side

doors.

KEY/RADIO FREQUENCY REMOTE CONTROL: use

(2/2)

The hazard warning lights and side in-

dicator lights flash twice to indicate

that the doors have locked.
Note: depending on the vehicle, when

a door or the tailgate is left open or not

properly closed, all the doors and the

tailgate lock/unlock quickly without the

hazard warning lights flashing.

The key must not be used for any

function other than those described

in the handbook (removing the cap

from a bottle, etc.).

Unlocking the doors

Pressing button 2 unlocks the doors

and tailgate.
A short press on button 3 locks/unlocks

the tailgate and, depending on the vehi-

cle, the sliding side doors. The hazard

warning lights and side in- dicator lights

flash once to indicate that the doors

have unlocked.

1.7

DEADLOCKING

Never use deadlocking if

someone is still inside the

vehicle.

If fitted to the vehicle, this allows the

doors to be locked and prevents them

from being opened with the interior

handles (for example, by breaking the

window and then trying to open the

doors from the inside).

To activate deadlocking

Press button 1 twice in quick succes-

sion.

The side indicator lights and hazard

warning lights flash five times to indi-

cate that the doors have locked.

To deactivate deadlocking

Unlock the vehicle using button 2.

The hazard warning lights and side in-

dicator lights flash once to indicate that

the doors have unlocked.

1.8

HANDS-FREE ACCESS TRANSMITTER/RECEIVER: use

(1/2)

For vehicles equipped with transmitter/

receiver 1, in addition to the functions

of the remote control, it can be used to

lock/unlock without using the remote

control locking unit when it is in access

zone 2.
Note: the hands-free access transmit-

ter/receiver only works with the front

doors and the tailgate.

It is powered by a battery which must

be replaced (refer to the information on

the “Hands-free access transmitter/re-

ceiver: batteries” in Section 5).

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.9

Unlocking the vehicle

With the transmitter/receiver in one

of the access zones 2, press button 3

or 4, and all the doors will unlock.
The hazard warning lights flash once

to indicate that the doors have been un-

locked.

HANDS-FREE ACCESS TRANSMITTER/RECEIVER: use

(2/2)

Interference

Interference by factors in the imme-

diate vicinity (external installations or

the use of equipment operating on the

same frequency as the remote control)

may affect the operation of the remote

control.

Locking the vehicle

With the transmitter/receiver in one

of the access zones 2, press button 3

or 4, and all the doors will lock.
The hazard warning lights flash once

for 4 seconds to indicate the doors

have been locked.
Note: when a door or the tailgate is

left open or is not properly closed, all

the doors and the tailgate lock/unlock

quickly without the hazard warning

lights flashing.

1.10

Locking the doors with the

tailgate open

To lock the vehicle leaving a door open

(e.g. when transporting something in

the luggage compartment which pre-

vents it from being closed), or when

the vehicle is located in a zone of high

electromagnetic radiation, or if the key

is faulty: with the engine switched off,

press and hold switch 1 for more than

five seconds.

Locking the opening

elements without the remote

control

With the engine off, the rear doors

closed and a front door open, press

switch 1 for more than five seconds.

Make sure you have your key with you

before you leave your vehicle.

When the door is closed, all the doors

and tailgate will be locked.

Unlocking the driver’s door from out-

side the vehicle is only possible with the

key or the remote control.

Doors and tailgate status

indicator light

When the ignition is on, the indicator

light integrated in switch 1 informs you

of the status of the doors and tailgate:

– indicator light on, the doors and tail-

gate are locked;

– light off, the doors and tailgate are

unlocked.

When the ignition is off, the indicator

light remains lit and then goes out when

you lock the doors.

Interior locking/unlocking

door control

This enables all the doors to be locked

simultaneously.

Lock or unlock the doors by pressing

switch 1.
If a door or the tailgate is open or not

closed properly, the doors and tailgate

lock/unlock quickly.

CENTRAL DOOR LOCKING, UNLOCKING

Never leave your vehicle

with the key, remote con-

trol or transmitter/receiver

inside.

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.11

MANUAL DOOR LOCKING, UNLOCKING

Manual control

Using the key

Lock or unlock the doors equipped

with locks by inserting the key fully into

lock 1, then turning it.

Locking the doors manually

With the door open, turn screw 2 (using

the end of the key) or press button 3

and close the door. This means that the

doors are then locked from the outside.

The doors may then only be opened

from inside the vehicle or with the key

for the front doors.

1.12

RAID (AUTOMATIC LOCKING WHEN DRIVING)

You can decide whether you want to

activate this function.

To activate

With the ignition on, press switch 1

for approximately 5 seconds until you

hear a beep.
The indicator light built into the switch

comes on when the doors are locked.

To deactivate

With the ignition on, press and hold

switch 1 for approximately 5 seconds,

until you hear a beep. The indicator

light in the switch goes out.

Operating principle

When the engine is started, the system

automatically locks the doors when the

vehicle reaches a speed of approxi-

mately 4 mph (7 km/h).

Operating faults

If you notice an operating fault (auto-

matic locking impossible), first check

that all doors are correctly locked. If

they are correctly locked and the fault

is still present, contact an approved

Dealer.
Also make sure that locking has not

been inadvertently deactivated.
If it has, switch the ignition off and on

again and reactivate it.

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.13

FRONT DOORS

(1/2)

Opening the doors from the

outside

Unlock a door equipped with lock 2

using the key.
Vehicles with a remote control

Pull handle 1.
Vehicles with a transmitter/receiver

Press button 3 and pull handle 1.

Closing from the outside

Push the door. Use the key in lock 2 to

lock it, or use the remote control or the

hands-free access transmitter/receiver

by pressing button 3.

Opening from the inside

Pull handle 6 and open the door.

Closing from the inside

Pull the door using only handle 5.

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

1.14

FRONT DOORS

(2/2)

Manual locking

With the door closed, lock the door by

pressing button 4.

Lights-on reminder buzzer

If you have switched off the ignition

and left the lights switched on, a re-

minder buzzer will sound when a door

is opened.

NOTE
The front door mechanism cannot

be locked if the door is open.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or by locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.15

SLIDING SIDE DOOR

(1/2)

Opening from the inside

Pull lever 2 towards the rear and open

the sliding door until it locks into posi-

tion.

Opening the doors from the

outside

Unlock the lock with the key or with

the remote control, if the vehicle is

equipped with this function.

Pull handle 1 towards you and slide the

door towards the rear.

Note: the transmitter/receiver does not

work on the sliding side door (no button

on the handle).

Closing from the outside

Pull handle 1 and slide the door to-

wards the front of the vehicle until it

closes completely. Lock with the key or

using the remote control.

Closing from the inside

Pull lever 2 towards the front and close

the door until it latches.

Manual locking from inside

Lower button 3.

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

1.16

Recommendations con-

cerning the sliding side

door.
Care must be taken when

opening or closing the sliding door,

as is the case for any of the opening

elements on the vehicle:
– Check that the door will not come

into contact with any person, part

of the body, animal or object.

– Only use the handles on the

inside and outside of the door to

operate it.

– Take care when opening and

closing the door.

– Take particular care when the ve-

hicle is parked on a slope: open

or close the door fully until it

latches into its locking position.

– Before moving off, always ensure

that the sliding door is properly

closed.

Child locks

With the door open, turn lever 4 and

close the door.
This means that the door is then locked

from the inside.
The door can only be opened from the

outside of the vehicle.

SLIDING SIDE DOOR

(2/2)

1.17

Lower lever 4 to open the door.

If the vehicle is parked on

the hard shoulder with tail-

gate open, the rear lights

may be obscured. You

should make other road users aware

of your vehicle by using a warning

triangle or other equipment speci-

fied by the road traffic regulations of

the country you are driving in.

REAR DOORS

(1/2)

Opening the doors from the

outside

Unlock lock 1 using the key or, on

equipped vehicles, use the remote con-

trol or the hands-free access remote

control by pressing button 3. Pull

handle 2 towards you and open the

door.

Opening the doors to 180°

Open the door, but not fully.

Remove tie rod 7 from its housing 5.

Lock the tie rod on the hook 6.

Open the door as far as possible.

Do not leave the hinged

rear doors open in case of

strong winds. Risk of injury.

For your safety, check that

all the vehicle’s doors are

properly closed before

starting the engine.

Content .. 1 2 ..
