Renault Kangoo Z.E. (2018 year). Instruction

1.82

Interior rear view mirror

The interior rear view mirror is adjusta-

ble. When driving at night, tilt lever 1 to

avoid being dazzled by the headlights

of the vehicle behind.

REAR-VIEW MIRRORS

Heated door mirrors

When the engine is started, mirror de-

icing is activated with the rear screen

de-icing/demisting.

Folding door mirrors

Move button 2 to position D to fold the

door mirrors in. To reset them for driv-

ing, return to position B.
If you fold the door mirrors in manually

before resetting them to driving posi-

tion B, you must first turn button 2 to

position D.

Door mirrors with electrical

adjustment

With the ignition on, turn button 2:
– position A to adjust the left-hand

door mirror;

– position C to adjust the right-hand

door mirror.

B is the inactive position.

1.83

Hazard warning lights

Pressing switch 3 illuminates

all four direction indicators and the

side-mounted indicator lights simul-

taneously. It must only be used in an

emergency to warn other drivers that

you have had to stop in an area where

stopping is prohibited or unexpected, or

that you are obliged to drive under spe-

cial conditions.
Depending on the vehicle, the hazard

warning lights may come on automati-

cally under heavy deceleration. You can

switch them off by pressing switch 3.

Horn

Press one of points 2.

Direction indicators

Move stalk 1 parallel to the steering

wheel and in the direction you are going

to turn.
When driving on the motorway, the

steering wheel is not often turned

enough to return the stalk automatically

to 0.

There is an intermediate position in

which the switch may be held when

changing lanes.
You can also briefly place stalk 1 in the

intermediate position, causing the indi-

cator light to flash three times.
When the stalk is released, it automati-

cally returns to 0.

Headlight flasher

Pull stalk 1 towards you to flash the

headlights.

AUDIBLE AND VISUAL SIGNALS

1.84

PEDESTRIAN HORN

Electric vehicles are particularly quiet.

This system enables you to warn

people of your presence – especially

pedestrians and cyclists.
The system is activated automatically

when the engine is started. The sound

triggers when the vehicle speed is be-

tween 1 and 20 mph (1 and 30 km/h).

Deactivating the system

With the engine running, press the

switch 1 to deactivate the function. The

warning light 2 in the switch 1 comes

on.

Activating the system

With the engine running, press the

switch 1 to activate the function. The

warning light 2 in the switch 1 goes out.

System activated:
– it goes on standby automatically

when the vehicle speed is above ap-

proximately 20 mph (30 km/h);

– The system is activated automati-

cally when the vehicle is being driven

at a speed below approximately

20 mph (30 km/h).

Warning noise selection

– Keep the switch 1 depressed.

The various sounds will be played in

succession;

– release the switch 1 on the sound of

your choice.

1.85

Main beam headlights

With stalk 1 in dipped beam headlights

position, move the stalk towards you.

The indicator light on the instrument

panel then lights up.
To return to the dipped beam head-

light position, pull the stalk towards you

again.

Side lights

Turn the end of stalk 1 until the

symbol is opposite mark 2.
The instrument panel will light up.

EXTERNAL LIGHTING AND SIGNALS

(1/3)

Before driving at night:

check the electrical equip-

ment is operating correctly

and adjust your headlights

(if your vehicle is not carrying its

normal load). As a general precau-

tion, check that the lights are not

obscured (by dirt, mud, snow or ob-

jects being transported).

Dipped beam

headlights

Manual operation
Turn the end of stalk 1 until the symbol

is opposite mark 2. This indicator light

on the instrument panel comes on.

Automatic operation

(depending on vehicle)
When the engine is started, the dipped

beam headlights switch on or off auto-

matically depending on the brightness

of the light outside, without any action

on stalk 1.

This function can be deactivated or re-

activated.
– To switch it on: with the ignition on

and the vehicle stationary, press and

hold button 3 for at least four sec-

onds. Depending on the vehicle, the

message “lights ON” appears on the

instrument panel.

– To deactivate: with the ignition on

and the vehicle stationary, press and

hold button 3 for at least four sec-

onds. Depending on the vehicle, the

message “lights OFF” appears on

the instrument panel.

1.86

“See-me-home lighting”

function

(depending on vehicle)
This function (useful, for example,

when opening a gate, garage, etc.) en-

ables you to switch the dipped head-

lights on momentarily.
With the ignition off and the headlights

off, pull stalk 1 towards you: the dipped

beam headlights come on for approxi-

mately sixty seconds.
This action may be carried out no more

than four times for a maximum lighting

period of four minutes.
To switch off the lights before they

switch off automatically, turn the end of

stalk 1 then bring it back to position 0,

or switch on the ignition.

EXTERNAL LIGHTING AND SIGNALS

(2/3)

Switching off the lights

There are two possibilities:

– manually, move stalk 1 to its original

position;

– automatically, the lights are switched

off when the engine is stopped, the

driver’s door is opened or, depend-

ing on the vehicle, when the vehicle

is locked. In this case, the next time

the engine is started the lights will be

switched back on according to the

position of the ring 2.

Lights-on reminder buzzer

A warning beep sounds when the driv-

er’s door is opened to warn you that the

lights are still on.

1.87

Rear fog light

The front fog lights and the

side lights or dipped beam headlights

must be on.
Turn ring 5 on stalk 1 until the symbol

is opposite mark 4, then release it. This

indicator light on the instrument panel

comes on.
To avoid inconveniencing other road

users, remember to switch off the rear

fog light when it is no longer needed.

Turning off the fog lights

Turn ring 5 again to position mark 4 op-

posite the symbol for the light you wish

to switch off.
Switching off the exterior lights or the

ignition switches off the front and rear

fog lights.

Front fog lights

(depending on vehicle)

The side lights or dipped beam head-

lights must be on.
Turn ring 5 on stalk 1 until the symbol

is opposite mark 4, then release it. This

indicator light on the instrument panel

comes on.

EXTERNAL LIGHTING AND SIGNALS

(3/3)

1.88

HEADLIGHT BEAM ADJUSTMENT

(1/2)

Control knob 1 is used to adjust the

height of the headlight beams accord-

ing to the load.
Turn control knob 1 downwards to

lower the headlights and upwards to

raise them.
Unladen, control knob 1 should be at 0.
When the vehicle is partially or com-

pletely laden, the headlight beam

should be set to light the road at be-

tween 50 and 100 metres. Then use

positions 1 to 4 on the control knob.

100 m

50 m

A Poor adjustment: the lights are set

too high and could dazzle other

drivers. Turn the control knob

downwards to lower the beam.

B Good adjustment: the beam’s

maximum range is between 50

and 100 metres.

1.89

HEADLIGHT BEAM ADJUSTMENT

(2/2)

Temporary adjustment

Open the bonnet and identify the mark-

ing B next to one of the front headlight

projectors.
For each headlight, using a screw-

driver, turn the screw 1 by a quarter

turn towards the - symbol to lower the

beams.
Return to the starting point once your

trip is over: turn the screw 1 by a quar-

ter turn towards the + symbol to raise

the beams.

When driving on the left in a left-

hand drive vehicle (or vice versa),

you must adjust your lights tempo-

rarily during your stay.

1.90

Windscreen wiper

With the ignition on, move stalk 1 paral-

lel to the steering wheel:

A Park

B Intermittent wiping

The wipers will pause for several

seconds between sweeps. It is

possible to change the time be-

tween sweeps by turning ring 2.

C Normal wiping speed

D Fast wiping speed

FRONT WINDSCREEN WASHER, WIPER

(1/2)

Special note
When the vehicle is being driven, the

wiping speed slows down whenever

the vehicle stops. For example, fast

wiping speed will slow to normal wiping

speed. As soon as the vehicle moves

off, wiping will return to the speed origi-

nally selected.
If stalk 1 is operated, it overrides and

cancels the automatic function.

If for any reason the wipers are

jammed (e.g. frozen to windscreen

by ice etc.), the system will auto-

matically cut the power supply to

the wipers.

Automatic wiper function

(depending on vehicle)
With the engine running, move stalk 1.

A Park

B Automatic wiper function

When this position is selected, the

system detects the presence of

water on the windscreen and trig-

gers wiping at a suitable wiping

speed. The triggering threshold

and the time between sweeps can

be adjusted by turning ring 2.

NB: in foggy weather or during

snowfalls, the wiping is not automati-

cally triggered and remains under

the driver’s control.

C Normal wiping speed

D Fast wiping speed

1.91

Windscreen wiper

With the ignition on, pull stalk 1 to-

wards you.
A brief pull will trigger a single sweep

of the wipers, in addition to the wind-

screen washer.
A longer pull will trigger three sweeps

of the wipers followed, a few seconds

later, by a fourth, in addition to the wind-

screen washer.

FRONT WINDSCREEN WASHER, WIPER

(2/2)

Before any action on the

windscreen (washing the

vehicle, de-icing, cleaning

the windscreen, etc.) return

stalk 1 to position A (off).
Risk of injury and/or damage.

In freezing or snowy weather, ensure

they are not stuck to the windscreen

(including the central area located

behind the interior rear-view mirror)

before starting the wipers (risk of

motor overheating).

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:
– it must remain clean: clean the

blade and the screen regularly

with soapy water;

– do not use it when the screen is

dry;

– free it from the screen when it has

not been used for a long time.

Replace wiper blades as soon as

their performance starts to diminish:

Approximately every year (refer to

the information on “Wiper blades” in

section 5).

Precautions for using the

wipers

– In freezing or snowy weather,

clear the screen before starting

the wipers (risk of motor over-

heating);

– ensure that no objects are ob-

structing the travel of the blade.

1.92

Rear screen wash/wipe

(depending on vehicle)

Turn the end of stalk 1 to position the

symbol opposite mark 2.
When the stalk is released, it returns to

the rear screen wiper position.

Speed-dependent rear

screen wiper with

timer

(depending on vehicle)
Turn the end of stalk 1 to position the

symbol opposite mark 2.
Wiping frequency varies with speed.

Special note
If the windscreen wipers are opera-

tional when you select reverse gear, the

rear screen is wiped intermittently.

REAR WINDSCREEN WASHER, WIPER

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:
– it must remain clean: clean the

blade and the screen regularly

with soapy water;

– do not use it when the screen is

dry;

– free it from the screen when it has

not been used for a long time.

Replace wiper blades as soon as

their performance starts to diminish:

Approximately every year (refer to

the information on “Wiper blades” in

section 5).

Precautions for using the

wipers

– In freezing or snowy weather,

clear the screen before starting

the wipers (risk of motor over-

heating);

– ensure that no objects are ob-

structing the travel of the blade.

Before any action involving

the rear screen (washing

the vehicle, de-icing, clean-

ing etc.) return stalk 1 to the

stop position.
Risk of injury and/or damage.

Do not use the wiper arm to open or

close the tailgate.

1.93

Useful capacity of fuel tank: 13 litres

approx.
To open the fuel filler flap, place your

finger into recess C.
Use the ignition key to open cap B.

ADDITIONAL HEATING TANK

Fuel grade

Use a high-grade fuel that complies

with the legislation in force in each

country and which must conform to

the specifications given on the label on

cover A.
Fuel odours and smoke may be present

after a long period without using the ad-

ditional heating.

Fuel filler cap: this is of a

special type.
If you have to replace it,

make sure it is identical

to the original cap. Contact an ap-

proved Dealer.

Never place the cap near a source

of heat or flame.
Do not wash the filler area with a

high-pressure washer.

Fuel filling

– Insert the nozzle so that the valve

is open and fully insert the nozzle

before engaging it in order to fill the

tank (risk of splash-back).

– Keep the nozzle in this position

throughout the entire filling opera-

tion.

When the pump cuts out automatically

at the end of the filling procedure, a

maximum of two further filling attempts

may be made so as to leave sufficient

room for expansion.

Persistent smell of

fuel

If you notice a persistent

smell of fuel you should:
– stop the vehicle as soon as traf-

fic conditions allow and switch off

the ignition;

– switch on the hazard warning

lights and ask your passengers

to leave the vehicle and to keep

away from traffic;

– contact an approved Dealer.

Do not operate the addi-

tional heating when the ve-

hicle fuel tank is being filled.

2.1

Section 2: Driving

(Advice on use relating to fuel economy and the environment)

Starting, stopping the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2

Gear control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4

Handbrake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5

Driving advice, ECO-driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.6

Vehicle range: advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.8

Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.10

Tyre pressure loss warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.11

Driver correction devices/aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.15

Speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.18

Cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21

Parking distance control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.25

Reversing camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.27

2.2

STARTING, STOPPING THE ENGINE

(1/2)

“Stop and steering lock”

position St

To unlock: turn the key and the steering

wheel slightly.
To lock: remove the key and turn the

steering wheel until the steering column

locks.

“Accessories” position A

When the ignition is switched off, any

accessories (radio, etc.) will continue to

function.

The vehicle can only be started if

the charging cord is unplugged from

the vehicle.

The vehicle can only be started if

the selector lever is at P. Please see

the information on “Gear control” in

Section 2.

“On” position M

The ignition is switched on:

Start position D

Starting the engine
– Move lever 1 to position P only ;

– turn the key to position D and then

release it.

Warning light

Ṑ

may flash on the ins-

trument panel, along with a beep. As
soon as light

Ṑ

stops flashing and

the beep stops, the vehicle is ready to

drive.

2.3

Stopping the engine
With the engine running, turn the key

back to the “Stop” position St. Warning
light

Ṑ

goes out.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

Never switch off the igni-

tion before the vehicle has

come to a complete stop.

Switching off the engine di-

sables the assistance equipment:

brakes, power-assisted steering,

etc., and the passive safety devices

such as airbagsand pretensioners.

STARTING, STOPPING THE ENGINE

(2/2)

Renault Kangoo Z.E. (2018 year). Instruction - part 6
