Dacia Solenza (engine E7J). Manual - part 147

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 45

Diagnostic – General

REPLACEMENT AND SETTING

New parts are not coded. Once mounted on vehicle, in order to become under operation,

the memorization of a code it is necessary.

In order to perform this procedure, it is absolutely necessary that some vehicle parts are

already coded (with the vehicle code).

Refer to the assignations table:

ATTENTION

 :if a part is memorizing the code this one is assigned to this  specific vehicle

and it is impossible that subsequently this code is erased or a second code is memorized. The
first time memorized code can not be anymore erased.

ASSIGNATION TABLE

〈

The key assigned to a vehicle must be new and already programmed on that vehicle.

REMARK :

this may be programmed n vehicle but it is not effective (not assigned)

.

ATTENTION :

only the keys presented when performing this operation are to be under

operation.

AFTER

SALE

INTERVENTION

ELEMENTS CONDITION

REPARATION

CODE

NECESSITY

Cockpit Central

Unit

Ke y

Injection

computer

Cockpit Central Unit
programming
Key’ assignation or
deletion
Injection computer
programming

new

coded

coded

coded

new*

coded

coded

-

new

YES

YES

N O

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 46

Cockpit central Unit is not coded. Once mounted on vehicle, in order to become under

operation, the memorization of a code it is necessary.
In order to perform this procedure, it is obligatory to have at least one of the vehicle old keys,
to know the reparation code and the injection computer must be correctly coded (please refer
to the assignation table).

 isvehicle, in order to become under operation, the memorization of a

code it is necessary.
I

ATTENTION: if Cockpit Central Unit is memorizing a code, this one is assigned only to

that vehicle. It is impossible the code erasing or memorizing another code.

 eh old keys, to knhe

re

IMPORTANT: only the keys presented when performing this procedure are  becoming

under operation, with the condition:

- they have been already coded on this vehicle.
-    they are new (not coded).

 icn computer must be correctly coded (please refer to tho

REMARK: if only Cockpit Central Unit is to be replaced, it is not necessary to perform

any intervention to the injection computer: this one will keep the same anti starting code.

SPECIAL SITUATIONS

If the screen displays:
“ Inserted after-sale code does not cor-

respond to the presented key. Check if the
code was correctly entered and if a vehicle
key was presented”: the code is not corre-
sponding to the vehicle or a new key has been
used.

“Cockpit Central Unit is not empty. Start

the keys programming procedure”. Cock-
pit Central Unit is already coded on this ve-
hicle.

“Cockpit Central unit programming fail-

ure, key not possible to be used on this
vehicle”; the key code does not correspond
to the entered code (the key is belonging to a
vehicle of  another  type).

Diagnostic – General

PROGRAMMING PROCEDURE  OF
THE COCKPIT CENTRAL UNIT

By means of the CLIP tester:
Enter in dialogue with system “Anti-start-

ing”.

In menu “Control module”,  “Spec ific

control”, validate  line  “SC027: Cockpit
Central Unit programming”

The tester is displaying “ Take off the key

from anti-theft contact”

The tester is displaying “Introduce the

after-sale code”. With the contact off, insert
the after-sale secret code (12 hexadecimal
characters), the validate it.

If the code format is correct, the tester is

displaying “Insert an already coded key on
the vehicle,  set the contact on and  then
validate” and the programming procedure is
under way.

The tester is displaying  “ UCH pro-

grammed. Start the keys programming
procedure” and the Cockpit Central Unit is
coded. In this moment, it is necessary to enter
in the key programming mode, in order assign
the others keys (maximum four). More sec-
onds may pass before this message is displayed.

ATTENTION: the maximum interval between
each  operation is of  5 minute s if  not the
procedure is canceled.

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 47

THE PROCEDURE OF COCKPIT CENTRAL UNIT PROGRAMMING

Diagnostic – General

The code can be entered only when

contact is  et off

Enter in  dialogue  with system “Anti-starting”

Select menu “Control menu” and “Specific

control”.

Select control  “SC027 Cockpit Central

Unit Programming”.

 Tester is displaying:

 “Take off the key from anti-theft contact”

Tester is displaying:

“Enter the  after-sale code”

Enter the code (12 hexadecimal

characters, capital letters)

Tester is displaying:

“Insert an already programmed key on

vehicle”



Insert a key belonging to the vehicle and set

the contact  on.

The procedure can not be  performed with a

new key.

A

If tester is displaying:

“Cockpit Central Unit is no

empty.

Start the key programming

procedure”.

Cockpit Central Unit is  already

coded on this vehicle

82

ACCOUSTIC WARNING - ANTI STARTING

82 - 48

Diagnostic – General

A

If tester is displaying:

“The after-sale code does
not correspond to the pre-

sented key. Check if the

code was correctly  en-

tered and if a vehicle key

was presented

”.

If tester is displaying:

“UCH programming fail-

ure. Key not  in use on

this vehicle”.

The entered code does not

correspond to the vehicle’s key,

the key does not belong to that

vehicle or  it is new.

The key code does not

correspond with the entered code
(the key belongs to other vehicle).
