TRANSMISSION 29 29 - 6 Bellows - Bearing assembly to the gearbox Maintaining the transmission on the press, on both sides, shall be ensured on the G groove made on shaft, by means of a device type FACOM U 53 G, ( the flat side towards bellows) in The pressing effort of the bearing on the transmission shaft ahas the value of = 100 – 700 daN. Press again the assembled tripod on the transmission shaft observing the marks made when depressing. The press effort of the tripod assembly on the grooved area of the shaft end, shall be between 60 – 600 daN. Remount the blocking ring (Zeger lock) in the groove made on the transmission shaft. Left transmission G |
