IGNITION AND INJECTION 17 17 - 62 Diagnostic – Conformity checking RECOMMENDATIONS The values shown on this conformity checking are only as indication. Performing conditions: Stopped engine, contact set on. Sequence Function Parameter / Controlled state or action Visualization Diagnostic and Observations 3 Anti-starting ET002 : Anti starting PASSIVE In case of a problem consult the DF004 diagnostic. 4 Valve position Acceleration pedal released. Yes PR017 : measured valve position. 0 < x < 47 PR008 : position memorized vale for released pedal. 0 < x < 47 Acceleration pedal slightly pressed. In case of a ET003 : released pedal valve position. NO problem ET005 : valve p osition at maximum acceleration NO consult Acceleration pedal fully pressed. the DF017 ET003 : valve position for released pedal. NO diagnostic. ET005 : valve p osition at maxim um acceleration. YES PR017 : measured valve position. 170 < x < 255 5 Water In case of a temperature PR002 : water temperature X= engine problem sensor temperature ± 5°C consult the PR002 diagnostic 6 Air In case of a temperature PR003 : air temperature X = under bonnet problem sensor temperature ± 5°C consult the PR003 diagnostic 7 Pressure PR016 : atmospheric pressure X = atmospheric In case of a transducer pressure problem PR001 : manifold pressure X = atmospheric consult pressure the PR001 diagnostic |
