39

.

PEUGEOT Connect Nav

Radio

QUESTION

RESPONSE

SOLUTION

The reception quality of the tuned radio station
gradually deteriorates or the stored stations
are not working (no sound, 87.5 MHz is
displayed , etc.).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels,
basement car parks, etc.) block reception,
including in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for
example when going through a car wash or into
an underground car park).

Have the aerial checked by a franchised dealer.

I cannot find some radio stations in the list of
stations received.
The name of the radio station changes.

The station is not received or has changed its
name in the list.
Some radio stations send other information
in place of their name (the title of the song for
example).
The system interprets these details as the
station name.

Press on the "Update list" button in the "Radio
stations" secondary menu.

40

PEUGEOT Connect Nav

Media

QUESTION

RESPONSE

SOLUTION

Playback of my USB memory stick starts only
after a very long wait (around 2 to 3 minutes).

Some files supplied with the memory stick
may greatly slow down access to reading
the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

The CD is ejected every time or is not played.

The CD is upside down, cannot be read, does
not contain audio files or contains audio files of
a format not recognised by the audio system.
The CD has been recorded in a format that is
not compatible with the player (udf, etc.).
The CD is protected by an anti-pirating system
not recognised by the audio system.

Check that the CD is inserted in the player the
right way up.
Check the condition of the CD: the CD cannot
be played if it is too badly damaged.
Check the content in the case of a recorded CD:
consult the advice in the "AUDIO" section.
The audio system CD does not read DVDs.
Due to insufficient quality, certain burned CDs
will not be read by the audio system.

There is a long waiting period following the
insertion of a CD or connection of a USB
memory stick.

Upon insertion of a new key, the system reads
a certain amount of data (directory, title, artist,
etc.). This may take from a few seconds to a few
minutes.

This is perfectly normal.

The CD sound is of poor quality.

The CD used in scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambience) are
unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

Some information characters in the currently
playing media are not displayed correctly.

The audio system does not display some types
of characters.

Use standard characters to name tracks and
folders.

Playback of streaming files does not start.

The connected device does not automatically
launch playback.

To start playback from the device.

Names of tracks and playing time are not
displayed on the audio streaming screen.

The Bluetooth profile does not allow the transfer
of this information.

41

.

PEUGEOT Connect Nav

Telephone

QUESTION

RESPONSE

SOLUTION

I cannot connect my Bluetooth telephone.

The telephone's Bluetooth function may be
switched off or the telephone may not be visible.

Check that your telephone has Bluetooth
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with
the system.

You can check the compatibility of your
telephone at the Brand's website (services).

The volume of the telephone connected in
Bluetooth mode is inaudible.

The sound depends on both the system and the
telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume
of the telephone if necessary.

Ambient noise affects the quality of the
telephone call.

Reduce the ambient noise level (close the windows,
reduce the booster fan speed, slow down, etc.).

Some contacts are duplicated in the list.

The options for synchronising contacts are
synchronising the contacts on the SIM card, the
contacts on the telephone, or both. When both
synchronisations are selected, some contacts
may be duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

The contacts are listed in alphabetical order.

Some telephones offer display options.
Depending on the settings chosen, contacts can
be transferred in a specific order.

Modify the telephone directory display settings.

The system does not receive SMS.

The Bluetooth mode does not permit sending
SMS text messages to the system.

42

PEUGEOT Connect Nav

Settings

QUESTION

RESPONSE

SOLUTION

When changing the setting of treble and bass
the equalizer setting is deselected.
When changing the equalizer setting, the treble
and bass settings are reset.

The selection of an equalizer setting imposes
the settings for treble and bass and vice versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

When changing the balance setting, distribution
is deselected.
When changing the distribution setting, the
balance setting is deselected.

The selection of a distribution setting imposes
the balance settings and vice versa.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

There is a difference in sound quality between
the different audio sources.

To allow for optimal listening quality, the
audio settings can be tailored to different
sound sources, which can generate audible
differences when changing source.

Check that the audio settings are adapted to
the sources listened to. It is recommended that
the audio settings (Bass:, Treble:, Balance)
be adjusted to the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

When the engine is off, the system stops after
several minutes of use.

When the engine is switched off, the system's
operating time depends on the state of charge
of the battery.
In normal off state, the system automatically
goes into energy economy mode to maintain an
adequate charge in the battery.

Turn the ignition on to increase the charge of
the battery.

The date and time cannot be set.

Setting of the date and time is only available
if the synchronisation with the satellites is
deactivated.

Settings menu / Options / Time-Date setting.
Select the "Time" tab and deactivate the "GPS
synchronisation" (UTC).

43

.

PEUGEOT Connect Nav

44

PEUGEOT Connect Nav

45

.

PEUGEOT Connect Nav

1

.

PEUGEOT Connect Radio

PEUGEOT Connect Radio

Multimedia audio system –
Applications – Bluetooth

®



telephone

Contents

First steps

2

Steering mounted controls

3

Menus

4

Applications

6

Radio

7

DAB radio (Digital Audio Broadcasting)

9

Media

10

Telephone

12

Configuration

18

Frequently asked questions

21

The different functions and settings
described vary according to the version
and configuration of your vehicle.

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary and the
ignition on.

The system is protected in such a way that
it will only operate in your vehicle.
The display of the Energy Economy
Mode message signals that a change to
standby is imminent.

The link below gives access to OSS (Open
Source Software) codes for the system.
https://www.groupe-psa.com/fr/oss/
https://www.groupe-psa.com/en/oss/

2

PEUGEOT Connect Radio

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns
the system on.

Adjustment of the volume.

Use the buttons either side of or below the
touch screen for access to the menus, then
press the virtual buttons in the touch screen.

Depending on the model, use the "Source" or
"Menu" buttons either side of the touch screen
for access to the menus, then press the virtual
buttons in the touch screen.

You can display the menu at any time by
pressing the screen briefly with three fingers.

All of the touch areas of the screen are white.
Press in the grey zone to go back a level or
confirm.
Press the back arrow to go back a level or
confirm.

The touch screen is of the "capacitive"
type.
To clean the screen, use a soft, non-
abrasive cloth (spectacles cloth) with no
additional product.
Do not use sharp objects on the screen.
Do not touch the screen with wet hands.

*  Depending on equipment.

Certain information is displayed permanently in
the upper band of the touch screen:
-  Repeat of the air conditioning information

(depending on version), and direct access to
the corresponding menu.

-  Reminder of the Radio Media and

Telephone menu information.

-  Access to the Settings of the touch screen

and digital instrument panel.

Selecting the audio source (depending on
version):
-  FM / AM* / DAB* radio stations.
-  Telephone connected via Bluetooth and

multimedia broadcast Bluetooth* (streaming).

-  CD player (depending on model).
-  USB key.
-  Media player connected via the auxiliary

socket (depending on model).

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with the
possibility of entering a multitude of
settings (radio presets, audio settings,
ambiences, etc.); these settings are taken
into account automatically.

3

.

PEUGEOT Connect Radio

In very hot conditions, the volume may
be limited to protect the system. It may go
into standby (screen and sound off) for at
least 5 minutes
The return to normal takes place when
the temperature in the passenger
compartment has dropped.

Steering mounted controls

Steering mounted controls –
Type 1

Radio:
Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media:
Select the previous / next track.
Select the previous / next item in a
menu or a list.

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of
folders.
Long press: display the available
sorting options.

Change audio source (radio; USB;
AUX if equipment connected; CD;
streaming).

Confirm a selection.

Increase volume.

Decrease volume.

Mute / Restore sound by
simultaneously pressing the
increase and decrease volume
buttons.

Steering mounted controls
– Type 2

Depending on model.

Voice commands:
This control is located on the
steering wheel or at the end of the
lighting control stalk (depending on
model).
Short press, smartphone voice
commands via the system.

4

21,5

18,5

PEUGEOT Connect Radio

 or

Increase volume.

 or

Mute / Restore the sound.
Or
Mute by pressing the volume
increase and decrease buttons
simultaneously.
Restore the sound by pressing one
of the two volume buttons.

 or

Decrease volume.

 or

Media (short press): change the
multimedia source.
Telephone (short press): start
telephone call.
Call in progress (short press):
access telephone menu.
Telephone (long press): reject an
incoming call, end call; when no call
is in progress, access telephone
menu.

 or

Radio (rotate): previous / next
preset.
Media (rotate): previous / next track,
move in a list.
Short press: confirm a selection; if
nothing selected, access to presets.

Radio: display the list of stations.
Media: display the list of tracks.
Radio (press and hold): update the
list of stations received.

Menus

Depending on model / Depending on version

Air conditioning

Manage the different temperature
and air flow settings.

5

.

PEUGEOT Connect Radio

Applications

Access configurable equipment.

Radio Media

Select an audio source or radio
station.

Telephone

Connect a telephone by Bluetooth

®

.

Operate certain applications on
a smartphone connected via
MirrorLink

TM

, CarPlay

®

 or Android

Auto.

Settings

Configure a personal profile and/
or configure the sound (balance,
ambience, etc.) and the display
(language, units, date, time, etc.).

Driving

Activate, deactivate or configure
certain vehicle functions.

6

PEUGEOT Connect Radio

Applications

Viewing photos

Insert a USB memory stick in the USB port.

To protect the system, do not use a USB
hub.

The system can read folders and image files in
the formats: .tiff; .gif; .jpg/jpeg; .bmp; .png.

Press "Applications" to display the
primary page.

Press "Photos".

Select a folder.

Select an image to view.

Press this button to display the
details of the photo.

Press the back arrow to go back a
level.

Managing messages

Press "Applications" to display the
primary page.

Press "SMS".

Select the "SMS" tab.

Press this button to select the
display settings for messages.

Press this button to search for a
contact.

Select the "Quick messages" tab.

Navigation

Configure the guidance and select
your destination via MirrorLink

TM

,

CarPlay

®

 or Android Auto.

Press this button to select the
display settings for messages.

7

.

PEUGEOT Connect Radio

Radio

Selecting a station

Press "Radio Media" to display the
primary page.

Press one of the buttons for an
automatic search for radio stations.

Or

Move the cursor for a manual search
for frequencies up or down.

Or

Press the frequency.

Enter the FM and AM waveband
values using the virtual keypad.

Press "OK" to confirm.

Radio reception may be affected by the
use of electrical equipment not approved
by the Brand, such as a USB charger
connected to the 12 V socket.
The external environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS mode.
This is a normal effect of the way in
which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

Changing waveband

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Band" to change waveband.

Press in the grey zone to confirm.

Presetting a station

Select a radio station or frequency.

Make a short press on the star
outline. If the star is solid, the radio
station is already preset.

Or

Select a radio station or frequency.

Press "Preset".

Make a long press on one of the
buttons to preset the station.

Activating / Deactivating
RDS

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "RDS".

Press in the grey zone to confirm.

8

PEUGEOT Connect Radio

The RDS, if activated, enables you to continue
listening to the same station by automatically
retuning to alternative frequencies. However,
in certain conditions, coverage of this RDS
station may not be assured throughout the
entire country as radio stations do not cover
100% of the territory. This explains the loss of
reception of the station during a journey.

Display text information

The "Radio Text" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "News".

Press in the grey zone to confirm.

Play TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station that carries
this type of message. While traffic
information is being broadcast, the current
media is automatically interrupted so that
the TA message can be heard. Normal
play of the media previously playing is
resumed at the end of the message.

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "TA".

Press in the grey zone to confirm.

Audio settings

Press "Radio Media" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Audio settings".

Select the "Tone" or "Balance"
or "Ringtones" or "Sound" tab to
configure the audio settings.

Press the back arrow to confirm.

In the tab "Tone", the Ambience audio
settings, as well as Bass, Medium and
Treble are different and independent for
each audio source.
On the "Balance" tab, the All
passengers, Driver and Front only
settings are common to all sources.
On the "Sound" tab, activate or deactivate
"Volume linked to speed", "Auxiliary
input" and "Touch tones".
