Peugeot 3008 Hybrid 4 (2017 year). Instruction - part 13

Safety

191

3008-2_en_Chap05_securite_ed01-2016

i-U: suitable for i-Size restraints of the

"universal" category, forward facing or
rearward facing.

i-UF: only suitable for i-Size restraint systems

in the "Universal" category, forward
facing.

X: seating position not suitable for i-Size

restraint systems in the "Universal"
category.

Remove and stow the head restraint
before installing a child seat on a
passenger seat.
Refit the head restraint once the child
seat has been removed.

(a) Refer to the current legislation in your

country before installing a child at this
seating position.

Safety

192

3008-2_en_Chap05_securite_ed01-2016

For optimum installation of the forward facing
child seat, ensure that the back of the child
seat is as close as possible to the backrest
of the vehicle's seat, in contact if possible.
You must remove the head restraint before
installing a child seat with backrest to a
passenger seat.
Ensure that the head restraint is stored or
attached securely to prevent it from being
thrown around the vehicle in the event of
sharp braking. Refit the head restraint when
the child seat is removed.

Advice

Installing a booster seat

Children at the front

The incorrect installation of a child seat in a
vehicle compromises the child's protection in
the event of an accident.
Ensure that there is no seat belt or seat belt
buckle under the child seat, as this could
destabilise it.
Remember to fasten the seat belts or the
child seat harnesses keeping the slack
relative to the child's body to a minimum,
even for short journeys.
When installing a child seat using the seat
belt, ensure that the seat belt is tightened
correctly on the child seat and that it secures
the child seat firmly on the seat of your
vehicle. If your passenger seat is adjustable,
move it forwards if necessary.

The legislation on carrying children on the
front passenger seat is specific to each
country. Refer to the legislation in force in
your country.
Deactivate the passenger's front airbag
when a rearward facing child seat is installed
on the front passenger seat.
Otherwise, the child risks being seriously
injured or killed if the airbag is deployed.

The chest part of the seat belt must be
positioned on the child's shoulder without
touching the neck.
Ensure that the lap part of the seat belt
passes correctly over the child's thighs.
PEUGEOT recommends the use of a booster
seat which has a back, fitted with a seat belt
guide at shoulder level.

At rear seating positions, always leave
sufficient space between the front seat and:
-

a rearward facing child seat,

the child's feet for a child seat fitted
forward facing.

To do this, move the front seat forwards
and, if necessary, move its backrest into the
upright position.

As a safety precaution, do not leave:
-

a child or children alone and
unsupervised in a vehicle,

a child or an animal in a vehicle which
is exposed to the sun, with the windows
closed,

the keys within reach of children inside
the vehicle.

To prevent accidental opening of the doors
and rear windows, use the child lock.
Take care not to open the rear windows by
more than one third.
To protect young children from the rays of
the sun, fit side blinds on the rear windows.

Safety

193

3008-2_en_Chap05_securite_ed01-2016

Manual child lock

Turning the child lock on

F Using the ignition key or the integral key,

depending on version, turn the red control
as far as it will go:
- to the right on the left-hand rear door,
- to the left on the right-hand rear door.

Turning the child lock off

F Using the ignition key or the integral key,

depending on version, turn the red control
as far as it will go:
- to the left on the left-hand rear door,
- to the right on the right-hand rear door.

Do not confuse the child lock control,
which is red, with the back-up locking
control, which is black.

Mechanical system to prevent opening of a rear door using its interior control.
The control, red in colour, is located on the edge of each rear door.
It is identified by a symbol marked on the bodywork.

Safety

194

3008-2_en_Chap05_securite_ed01-2016

Electric child lock

Remotely operated system to prevent opening of the rear doors using their interior controls.
The control is located on the dashboard, driver's side.

Switching on

F Press this button.
The indicator lamp in the button comes on,
accompanied by a confirmation message.
This indicator lamp remains on until the child
lock is switched off.

Switching off

F Press this button again.
The indicator lamp on button goes off,
accompanied by a confirmation message.
This indicator lamp remains on while child lock
is switched on.

Any other status of the indicator lamp
indicates a fault with the electric child
lock. Have it checked by a PEUGEOT
dealer or a qualified workshop.

This system is independent and in no
circumstances does it take the place of
the central locking control.
Check the status of the child lock each
time you switch on the ignition.
Always remove the key from the ignition
when leaving the vehicle, even for a
short time.
In the event of a serious impact, the
electric child lock is switched off
automatically to permit the exit of the
rear passengers.

Driving

195

3008-2_en_Chap06_conduite_ed01-2016

Driving recommendations

Observe the driving regulations and remain
vigilant whatever the traffic conditions.
Pay close attention to the traffic and keep your
hands on the wheel so that you are ready to
react at any time to any eventuality.
On a long journey, a break every two hours is
strongly recommended.
In difficult weather, drive smoothly, anticipate
the need to brake and increase the distance
from other vehicles.

Driving on flooded roads

We strongly advise against driving on flooded
roads, as this could cause serious damage
to the engine or gearbox, as well as to the
electrical systems of your vehicle.

Important!

If you are obliged to drive through water:

check that the depth of water does not
exceed 15 cm, taking account of waves
that might be generated by other users,

deactivate the Stop & Start system,

drive as slowly as possible without stalling.
In all cases, do not exceed 6 mph
(10 km/h),

do not stop and do not switch off the
engine.

Never drive with the parking brake
applied - Risk of overheating and
damage to the braking system!
Risk of fire!
As the exhaust system of your vehicle
is very hot, even several minutes after
switching off the engine, do not park
or run the engine over areas where
inflammable substances and materials
are present: grass, leaves, etc.

Never leave a vehicle unsupervised
with the engine running. If you have
to leave your vehicle with the engine
running, apply the parking brake
and put the gearbox into neutral or
position N or P, depending on the type
of gearbox.

On leaving the flooded road, as soon as
circumstances allow, make several light brake
applications to dry the brake discs and pads.
If in doubt on the state of your vehicle, contact
a PEUGEOT dealer or a qualified workshop.

Driving

196

3008-2_en_Chap06_conduite_ed01-2016

When towing

Distribution of loads

F Distribute the load in the trailer so that the

heaviest items are as close as possible to
the axle and the nose weight approaches
the maximum permitted without
exceeding it.

Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load must
be reduced by 10 % for every 1 000 metres of
altitude.

Side wind

F Take into account the increased sensitivity

to side wind.

For more information on Weights, refer to the
corresponding section.

F If the warning lamp and the

STOP warning lamp come on,
stop the vehicle and switch off
the engine as soon as possible.

Braking

Towing a trailer increases the braking distance.
To avoid overheating of the brakes, the use of
engine braking is recommended.

Tyres

F Check the tyre pressures of the towing

vehicle and of the trailer, observing the
recommended pressures.

Lighting

F Check the electrical lighting and signalling

on the trailer and the headlamp beam
height of your vehicle.

For more information on Adjusting the
headlamp beam height, refer to the
corresponding section.

The rear parking sensors will be
deactivated automatically to avoid the
audible signal if a genuine PEUGEOT
towbar is used.

Cooling

Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its cooling
capacity is not dependent on the engine speed.
F To lower the engine speed, reduce your

speed.

The maximum towed load on a long incline
depends on the gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.

Driving

197

3008-2_en_Chap06_conduite_ed01-2016

It has 3 positions:
- position

1 (Stop): insert and removing the

key, steering column locked,

- position

2 (Ignition on): steering column

unlocked, ignition on, Diesel preheating,
engine running,

- position

3 (Starting).

Ignition on position

It allows the use of the vehicle's electric
equipment or portable devices to be charged.
Once the state of charge of the battery drops
to the reserve level, the system switches to
energy economy mode: the power supply is
cut off automatically to preserve the remaining
battery charge.

Starting / Switching off the engine with the key

Ignition switch

Avoid attaching heavy objects to the
key or the remote control, which would
weigh down on its blade in the ignition
switch and could cause a malfunction.
It could adversely affect the deployment
of the front airbag.

Switching off the engine leads to a loss
of braking assistance.

Anti-theft protection

In the event of a malfunction, you are informed
by a message in the instrument panel screen.

For reasons of safety and theft
protection, do not leave your electronic
key in the vehicle, even when you are
close to it.
It is recommended that you keep it on
your person.

Electronic engine immobiliser

The keys contain an electronic chip which has
a secret code. When the ignition is switched
on, this code must be recognised in order for
starting to be possible.
This electronic engine immobiliser locks the
engine management system a few minutes
after the ignition is switched off and prevents
starting of the engine by anyone who does not
have the key.

In this case, your vehicle does not start; contact
a PEUGEOT dealer if required.

Driving

198

3008-2_en_Chap06_conduite_ed01-2016

Starting the engine

F With a petrol engine, operate the starter

motor by turning the key to position 3
without pressing the accelerator pedal,
until the engine starts. Once the engine is
running, release the key.

F With a Diesel engine, turn the key to

position 2, ignition on, to operate the
engine pre-heating system.

Wait until this warning lamp goes off
in the instrument panel then operate
the starter motor by turning the key
to position 3 without pressing the
accelerator pedal, until the engine
starts. Once the engine is running,
release the key.

If the engine does not start straight
away, switch off the ignition. Wait a
few moments before operating the
starter motor again. If the engine does
not start after several attempts, do not
keep trying: you risk damaging the
starter motor or the engine. Contact
a PEUGEOT dealer or a qualified
workshop.

Never leave the engine running in
an enclosed area without adequate
ventilation: internal combustion
engines emit toxic exhaust gases,
such as carbon monoxide. Danger of
intoxication and death!
In very severe wintry conditions
(temperatures below -23°C), to ensure
the correct operation and durability of
the mechanical components of your
vehicle, engine and gearbox, it is
necessary to leave the engine running
for 4 minutes before moving off.

In certain cases, you may have to apply
more force to the steering (wheels on
full lock, for example).

In wintry conditions, the warning lamp
can stay on for a longer period. When
the engine is hot, the warning lamp
does not come on.

In temperate conditions, do not leave
the engine at idle to warm up but move
off straight away and drive at moderate
speed.

With the parking brake applied and the gearbox
in neutral or position N or P:
F depress the clutch pedal fully (manual

gearbox),

or
F press the brake pedal firmly (automatic

gearbox),

F insert the key into the ignition switch; the

system recognises the code,

F unlock the steering column by simultaneously

turning the steering and the key.

Driving

199

3008-2_en_Chap06_conduite_ed01-2016

Switching off the engine

Energy economy mode

After switching off the engine (position 1-Stop),
for a maximum of 30 minutes you can still use
functions such as the audio and telematic
system, the wipers, dipped beam headlamps,
courtesy lamps, ...

F Check that the parking brake is correctly

applied, particularly on sloping ground.

Never switch off the ignition before the
vehicle is at a complete stop. With the
engine off, the braking and steering
assistance systems are also cut off: risk
of loss of control of the vehicle.

To facilitate unlocking of the steering
column, it is recommended that the
wheels be returned to the straight ahead
position before switching off the engine.

When you leave the vehicle, keep the
key with you and lock the vehicle.

For more information on Energy
economy mode, refer to the
corresponding section.

Key left in the "Ignition on"
position

If the key has been left in the ignition switch
at position 2 (Ignition on), the ignition will
be switched off automatically after one hour.
To switch the ignition back on, turn the key
to position 1 (Stop), then back to position 2
(Ignition on).

F Stop the vehicle.
F With the engine running at idle, turn the key

to position 1.

F Remove the key from the ignition switch.
F To lock the steering column, turn the

steering until it locks.

Driving

200

3008-2_en_Chap06_conduite_ed01-2016

Starting / Switching off the engine with
Keyless Entry and Starting

Starting the engine

F Briefly press the "START/

STOP" button while maintaining
pressure on the pedal until the
engine starts.

The presence of the "Keyless Entry
and Starting" electronic key in the
recognition zone is essential.
If the electronic key is not detected in
this zone, a message is displayed.
Move the electronic key into this zone
so that the engine can be started.
If there is still a problem, refer to the
"Key not detected - Back-up starting"
section.

If one of the starting conditions is not met,
a reminder message is displayed in the
instrument panel.
In some circumstances, it is necessary
to turn the steering wheel slightly while
pressing the "START/STOP" button to
assist unlocking of the steering column; a
message warns you when this is needed.

F With a manual gearbox, put the gear lever

into neutral.

F With the electronic key inside the vehicle,

fully depress the clutch pedal.

or
F With an automatic gearbox, place the

gear selector at position P or N.

F With the electronic key inside the vehicle,

fully depress the brake pedal.

The steering column unlocks and the engine
starts.

F With a manual gearbox, you should keep

the clutch pedal fully depressed until the
warning lamp goes off and not press the
"START/STOP" button again until the
engine is running.

or
F With an automatic gearbox, you should

keep the brake pedal fully depressed until
the warning lamp goes off and not press
the "START/STOP" button again until the
engine is running.

For Diesel engines, in temperatures below
zero and/or with a cold engine, the engine will
not start until the pre-heater warning lamp has
gone off.

If this warning lamp comes on after
pressing the "START/STOP" button:

As a safety measure, never leave the
vehicle while the engine is running.

Driving

201

3008-2_en_Chap06_conduite_ed01-2016

Switching off the engine

F Immobilise the vehicle, engine at idle.
F With a manual gearbox, put the gear lever

into neutral.

or
F With an automatic gearbox, place the

gear selector at position P or N.

Never leave your vehicle with the
electronic key still inside.

Switching off the engine leads to a loss
of braking assistance.

If the vehicle is not immobilised, the
engine will not stop.

F With the electronic key inside

the vehicle, press the "START/
STOP" button.

The engine stops and the steering
column locks.

Ignition on
(without starting)

With the Keyless Entry and Starting remote
control inside the vehicle, pressing the "START/
STOP" button, with no action on the pedals,
allows the ignition to be switched on.
This also allows the accessories to be used
(for example: audio system, lighting...).

F Press the "START/STOP" button,

the instrument panel comes on
but the engine does not start.

F Press the button again to switch off the

ignition and allow the vehicle to be locked.

With the ignition on, the system
automatically goes into energy
economy mode to maintain an adequate
state of charge in the battery.

Driving

202

3008-2_en_Chap06_conduite_ed01-2016

Key not detected

Back-up starting

A back-up reader is fitted to the steering
column to allow the engine to be started if
the system does not detect the key in the
recognition zone, or when the battery in the
electronic key is discharged.
F Place and hold the remote control against

the reader.

F If your vehicle has a manual gearbox, place

the gear lever in neutral then fully depress
the clutch pedal.

F If your vehicle has an automatic gearbox,

select position P then press the brake
pedal firmly.

F Press the "START/STOP" button.
The engine starts.

Emergency switch-off

In the event of an emergency only, the engine
can be switched off without conditions (even
when driving).
Press the "START/STOP" button for about
five seconds.
In this case, the steering column locks as soon
as the vehicle stops.

F To confirm the instruction to switch off the

engine, press the "START/STOP" button
for about five seconds.

In the event of a fault with the electronic key,
contact a PEUGEOT dealer or a qualified
workshop.

Back-up switch off

When the electronic key is not detected or is
no longer in the recognition zone, a message
appears in the instrument panel when closing a
door or trying to switch off the engine.

Driving

203

3008-2_en_Chap06_conduite_ed01-2016

Electric parking brake

The system provides, in automatic operation,
the application of the parking brake on
switching off the engine and release as the
vehicle moves off.
The driver can take over at any time to apply
or release the parking brake, by operating the
control lever:
F by briefly pulling the control lever to apply

the brake,

F by briefly pushing the control lever, while

pressing the foot brake, to release it.

Automatic mode is activated by default.

Indicator lamp

This indicator lamp comes on in the
instrument panel and in the control
lever to confirm the application of the
parking brake.

It goes off to confirm the release of the parking
brake.
The indicator lamp in the control lever flashes
during manual application or release.

In the event of a battery failure, the
electric parking brake no longer works.
As a safety measure, if the parking
brake is not applied, immobilise the
vehicle by engaging a gear (with a
manual gearbox) or placing the chocks
supplied against one of the wheels.
Contact a PEUGEOT dealer or a
qualified workshop.

Driving

204

3008-2_en_Chap06_conduite_ed01-2016

When towing, parking on a steep slope,
or if your vehicle is heavily laden,
turn the wheels towards the kerb and
engage a gear (with a manual gearbox)
or place the gear selector at position P
with an automatic gearbox.
For towing, you vehicle is approved for
parking on slopes of up to 12%.

Manual operation

Manual application

With the vehicle stationary: briefly pull the control lever.

If you push the control lever without
pressing the brake pedal, the parking
brake will not be released and a
message is displayed.

Manual release

With the ignition on or the engine running, to
release the parking brake:
F press the brake pedal,
F while maintaining pressure on the brake

pedal, briefly push the control lever.

The complete release of the parking brake
is confirmed by the brake indicator lamp and
the P indicator lamp in the control lever going
off, accompanied by the display of the message
"Parking brake released".

Never leave a child alone inside the
vehicle with the ignition on, as they
could release the parking brake.

Before leaving the vehicle, check that
parking brake is applied: the indicator
lamps in the instrument panel and
the control lever must be on fixed, not
flashing.
If the parking brake is not applied, there
is an audible signal and a message is
displayed on opening the driver's door.

Label on door panel

Confirmation of the instruction is signaled by
flashing of the indicator lamp in the control
lever.

Application of the parking brake
is confirmed by illumination of
the brake indicator lamp and
the P indicator lamp in the control
lever, accompanied by the display of
the message "Parking brake applied".

Driving

205

3008-2_en_Chap06_conduite_ed01-2016

Automatic operation

Automatic release

Ensure first that the engine is running and the
driver's door is properly closed.
The electric parking brake releases
automatically and progressively when the
vehicle is moving.
With a manual gearbox
F Fully depress the clutch pedal,

engage 1

gear or reverse.

F Press the accelerator pedal and release

the clutch pedal.

With an automatic gearbox
F  Press the brake pedal.
F  Select position D, M or R.
F  Release the brake pedal and press the

accelerator pedal.

With an automatic gearbox, if the brake
does not release automatically, check
that the front doors are correctly closed.

When stationary with the engine running, do not
depress the accelerator pedal unnecessarily,
you risk releasing the parking brake.

Automatic application

With the vehicle stationary, the parking brake
is automatically applied when the engine
is switched off by pressing the START/STOP
button.

Application of of the parking brake
is confirmed by illumination of
the brake indicator lamp and the
P indicator lamp in the control lever,
accompanied by the display of the
message "Parking brake applied".

Automatic application does not take
place if the engine stalls or goes into
STOP mode of Stop & Start.

With automatic operation, you can also
manually apply or release the parking
brake using the control lever.

Driving

206

3008-2_en_Chap06_conduite_ed01-2016

Special cases

In some situations, you may need to operate
the parking brake manually.

Immobilisation of the vehicle
with the engine running

To immobilise the vehicle with the engine
running, briefly pull the control lever.

In very cold conditions (ice), it is
recommended that the parking brake
not be applied.
To immobilise your vehicle, engage a
gear or fit the chocks supplied against
one of the wheels.

Application of of the parking
brake is confirmed by illumination
of the brake indicator lamp and
the P indicator lamp in the control
lever, accompanied by the display of
the message "Parking brake applied".

Parking the vehicle with the
brake released

Immobilisation of the vehicle with the
parking brake released
F Switch off the engine.

Illumination of the warning lamps in the
instrument panel and control lever confirm
application of the parking brake.

F Switch on the ignition again, without

starting the engine.

F Release the parking brake manually by

pushing the control lever while keeping
your foot on the brake.

The complete release of the parking
brake is confirmed by the brake
indicator lamp and the P indicator
lamp in the control lever going off,
accompanied by the display of the
message "Parking brake released".

F Switch off the ignition.

With an automatic gearbox, P mode is
automatically selected when the ignition
is switched off. The wheels are blocked.

Content .. 11 12 13 14 ..
