Peugeot 3008 Hybrid 4 (2017 year). Instruction

Lighting and visibility

143

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Switching on the lighting
after switching off the
ignition

To reactivate the lighting control stalk,
turn the ring A to position "0" - lighting
off, then to the position of your choice.
When the driver's door is opened, a
temporary audible signal warns you that
the vehicle's lighting is on.
They switch off automatically after a
period which depends on the state of
charge of the battery (entry to energy
economy mode).

Daytime running lamps /
Sidelamps

The light-emitting diodes (LEDs) in these
lamps, front and rear, come on automatically
when the engine is started.
They provide the following functions:
-

Daytime running lamps (lighting control
stalk at position "0" or "AUTO" with
adequate light level).

Sidelamps (lighting control stalk at
position "AUTO" with a low ambient light
level or "Sidelamps only" or "Main or
dipped beam headlamps").

In some weather conditions (e.g. low
temperature or humidity), the presence
of misting on the internal surface of the
glass of the headlamps and rear lamps
is normal; it disappears after the lamps
have been on for a few minutes.

Travelling abroad

If using your vehicle in a country that
drives on the other side of the road, the
headlamps must be adjusted to avoid
dazzling on-coming drivers.
Contact a PEUGEOT dealer or a
qualified workshop.

Switching off the lighting
when switching off the ignition

When the ignition is switched off, all of the
lamps switch off immediately, except for the
dipped beam headlamps if automatic guide-
me-home lighting is activated.

Lighting and visibility

144

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Direction indicators

F Left: lower the lighting stalk passing the

point of resistance.

F Right: raise the lighting stalk passing the

point of resistance.

Three flashes of the direction

indicators

F Press briefly upwards or downwards,

without going beyond the point of
resistance; the direction indicators will
flash 3 times.

If you forget to cancel the
direction indicators for more than
twenty seconds, the volume of the
audible signal will increase if the speed
is above 40 mph (60 km/h).

On versions fitted with LED direction indicators,
the line of LEDs is illuminated sequentially.
The brightness of the daytime runnning lamps
is reduced during sequential operation of the
direction indicators.

Parking lamps

Side markers for the vehicle by illumination of
the sidelamps on the traffic side only.

F Depending on version, within one minute

of switching off the ignition, operate the
lighting control stalk up or down depending
on the traffic side (for example: when
parking on the left; lighting control stalk
upwards; the right hand sidelamps are on).

This is confirmed by an audible signal and
illumination of the corresponding direction
indicator warning lamp in the instrument panel.
To switch off the parking lamps, return the
lighting control stalk to the central position.

Lighting and visibility

145

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Headlamp beam height adjustment

Automatic adjustment of
"Full LED" technology
headlamps

This system automatically adjusts the height
of the beams from this type of headlamp,
according to the load in the vehicle, to avoid
causing a nuisance to other road users.

Do not touch the "Full LED" technology
headlamps. Risk of electrocution!
Have the system checked by a
PEUGEOT dealer or a qualified
workshop.

The initial setting is position "0".

Manual adjustment of
halogen headlamps

To avoid causing a nuisance to other road
users, the beams of the halogen headlamps
should be adjusted according to the load in the
vehicle.
0

Driver or driver + front passenger.

Driver + front passenger + rear
passengers.

5 people.

5 people + a load in the boot.

Driver + a load in the boot.

If a fault occurs, this warning lamp
comes on in the instrument panel,
accompanied by a message and an
audible signal.

The system then places the headlamp beams
in the lowest position.

Lighting and visibility

146

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Automatic guide-me-home
lighting

With the "Automatic illumination of headlamps"
function activated, under low ambient light, the
sidelamps, dipped beam headlamps and door
mirror spotlamps come on automatically when
the ignition is switched off.

Activation, deactivation and the duration of the
guide-me-home lighting are set in the vehicle
parameters menu in the screen.

Automatic illumination of headlamps

When a low level of ambient light is detected by a sunshine sensor, the number plate
lamps, sidelamps and dipped beam headlamps are switched on automatically, without any action
on the part of the driver. They can also come on if rain is detected, at the same time as automatic
operation of the windscreen wipers.
As soon as the brightness returns to a sufficient level or after the windscreen wipers are switched
off, the lamps are switched off automatically.

Activation

F Turn the ring to the "AUTO" position.
Activation of the function is accompanied by
the display of a message.

Operating fault

In the event of a malfunction of the
sunshine sensor, the lighting comes
on, this warning lamp is displayed in
the instrument panel accompanied by
an audible signal and/or a message.
Contact a PEUGEOT dealer or a
qualified workshop.

Do not cover the sunshine sensor,
coupled with the rain sensor and
located at the top centre of the
windscreen behind the rear view mirror;
the associated functions would no
longer be controlled.

Deactivation

F Turn the ring to another position.
Deactivation of the function is accompanied by
the display of a message.

In fog or snow, the sunshine sensor
may detect sufficient light. In this
case, the lighting will not come on
automatically.

Lighting and visibility

147

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Manual guide-me-home
lighting

The temporary illumination of the dipped beam
headlamps after the vehicle's ignition has been
switched off makes the driver's exit easier
when the light is poor.

Switching on

F With the ignition off, "flash" the headlamps

using the lighting stalk.

F A further "headlamp flash" switches the

function off.

Switching off

For versions without "Automatic illumination
of headlamps", the manual guide-me-home
lighting switches off automatically after
30 seconds.
For versions with "Automatic illumination of
headlamps", the period of operation of the
manual guide-me-home lighting is the same
as that set for the automatic guide-me-home
lighting.

Automatic exterior
welcome lighting

Activation, deactivation and the duration of the
exterior welcome lighting are set in the vehicle
parameters menu in the screen.

Lighting and visibility

148

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Door mirror spotlamps

Switching on

Whatever the position of the front courtesy
lamp switch, they also come on with the
exterior welcome lighting and the guide-me-
home lighting.

when you unlock the vehicle,

when you open a door,

when you use the remote control to locate
the vehicle.

When the front courtesy lamp
switch is in this position,
the spotlamps come on
automatically:

To make your approach to the vehicle easier,
these illuminate:
-

the zones facing the driver’s and
passenger’s doors,

the zones forward of the door mirrors and
rearward of the front doors.

Remote operation of
exterior lighting

Availability of this function depends on version.

F Make a short press on this

remote control button.

Pressing again before the end of the timed
period switches off the lighting immediately.

The sidelamps, dipped beam headlamps,
number plate lamps and door mirror spotlamps
come on for 30 seconds.

Switching off

They go off automatically after 30 seconds.

Lighting and visibility

149

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Automatic headlamp dipping

This system is a driving aid.
The driver remains responsible for the
vehicle's lighting, its correct use for the
prevailing conditions of light, visibility,
traffic and observation of driving and
vehicle regulations.

The system will be operational as soon as
you have exceeded 15 mph (25 km/h).
If the speed drops below 9 mph (15 km/h),
the system no longer operates.

System which automatically changes between dipped and main beam according to the ambient light level and the driving conditions, using a camera
located at the top of the windscreen.

Lighting and visibility

150

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Activation

F Turn the lighting control stalk ring to the

"AUTO" position.

Operation

Once the function is activated, the system
operates as follows:
If the ambient light level is sufficient and/or if
the traffic conditions do not allow illumination of
the main beam headlamps:

Pause

If the situation requires a change of headlamp
beam, the driver can take over at any time.
F Flashing the headlamps pauses the

function and the system changes to
"automatic illumination of headlamps"
mode:
- if the "AUTO" and "Dipped beam"

indicator lamps are on, the system
changes to main beam,

- if the "AUTO" and "Main beam" indicator

lamps are on, the system changes to
dipped beam.

To reactivate the system, flash the headlamps
again.

dipped beam is
maintained, this indicator
lamp comes on in the
instrument panel.

If the ambient light level is very low and the
traffic conditions permit:

main beam comes
on automatically: this
indicator lamp comes on
in the instrument panel.

Deactivation

The system may suffer interference or
not work correctly:
-

under conditions of poor visibility
(falling snow, heavy rain or thick
fog, ...),

if the windscreen is dirty, misted or
obscured (by a sticker, ...) in front of
the camera,

if the vehicle is facing highly
reflective signs.

The system is not able to detect:
-

road users that do not have their
own lighting, such as pedestrians,

vehicles whose lighting is obscured
(for example: vehicles running
behind a safety barrier on a
motorway),

vehicles at the top or bottom of a
steep slope, on twisty roads, on
crossroads.

F In the Driving menu, select

"Driving assistance", then
"Automatic headlamp dip".

F In the Driving menu, select the

"Driving assistance" tab, then
"Automatic headlamp dip"; the
system changes to "automatic
illumination headlamps" mode.

The state of the system stays in memory when
the ignition is switched off.

Lighting and visibility

151

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Cornering lighting

Present on vehicles fitted with "Full LED"
technology headlamps, this system makes use
of the beam from a front foglamp to illuminate
the inside of a bend, when the main or dipped
beam headlamps are on and the vehicle speed
is below 25 mph (approximately 40 km/h)
(urban driving, winding road, junctions, parking
manoeuvres...).

With cornering lighting

Activation / Deactivation

Switching on

This system starts:
-

when the corresponding direction indicator
is switched on,

or
-

from a certain angle of rotation of the
steering wheel.

Switching off

The system does not operate:
-

below a certain angle of rotation of the
steering wheel,

above 25 mph (40 km/h),

when reverse gear is engaged.

Without cornering lighting

The cornering lighting can be
activated or deactivated in the
Driving menu of the touch screen.

Lighting and visibility

152

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Programming

Your vehicle may also include some functions
that can be configured:
-

automatic rain sensitive windscreen wipers,

rear wiping on engaging reverse gear.

In wintry conditions, remove snow, ice
or frost present on the windscreen,
around the wiper arms and blades and
the windscreen seal, before operating
the wipers.

Without AUTO wiping

With AUTO wiping

Windscreen wiper

A. Wiping speed control stalk: raise or lower

the stalk to the desired position.

Fast wiping (heavy rain).

Normal wiping (moderate rain).

Intermittent wiping (proportional to
the speed of the vehicle).

Park.

Single wipe (press downwards or pull
the stalk briefly towards you, then
release).

Automatic wiping (press
down, then release).

Wiper control stalk

Single wipe (pull the stalk briefly towards you).

Do not operate the wipers on a dry
windscreen. Under extremely hot or
cold conditions, ensure that the wiper
blades are not stuck to the windscreen
before operating the wipers.

Lighting and visibility

153

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

B. Rear wiper selection ring: turn the ring

to place the desired symbol against the
marking.

Rear wiper

Park.

Intermittent wipe.

Wash-wipe.

F Pull the wiper control stalk towards you.
The screenwash and then the wiper operate for
a fixed time.

The screenwash includes a wiper blade
system with integral washer jets called
"Magic Wash".
The screenwash fluid is sprayed from
all along the length of the wiper blade;
this improves visibility and reduces the
consumption of screenwash fluid.

Windscreen wash

Reverse gear

When reverse gear is engaged, the rear wiper
will come into operation automatically if the
windscreen wipers are operating.

The function is activated or deactivated via the
vehicle settings menu in the screen.

In the event of snow or hard frost,
deactivate the automatic rear wiper via
the vehicle settings menu in the screen.

Turn the ring fully; the rear screen wash, then
the rear wiper automatically operate for a set
duration.

This function is activated by default.

Lighting and visibility

154

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Special position of the
windscreen wipers

This position permits release of the windscreen
wiper blades.
It is used for cleaning or replacement of the
wiper blades. It can also be useful, in winter, to
release the wiper blades from the windscreen.

F Any action on the wiper stalk within

one minute after switching off the ignition
places the wiper blades vertically on the
screen.

F To park the wiper blades again, switch on

the ignition and operate the wiper stalk.

To maintain the effectiveness of the
wiper blades, it is advisable to:
-

handle them with care,

clean them regularly using soapy
water,

avoid using them to retain
cardboard on the windscreen,

replace them at the first signs of
wear.

Screenwash fluid low level

When the low fluid level is reached in the
reservoir, this warning lamp comes on in
the instrument panel, accompanied by a
message and an audible signal.

The warning lamp come son when the ignition
is switched on, or every time the stalk is
operated, until the reservoir is refilled.
Next time you stop, refill the screenwash fluid
reservoir.

To avoid damaging the wiper blades or
the pump, do not operate the screenwash
if the screenwash reservoir is empty.
Only operate the screenwash if there
is no risk of the fluid freezing on the
windscreen and hindering visibility.
Always use screenwash fluid suitable
for low temperatures during the winter
period.

Lighting and visibility

155

3008-2_en_Chap04_eclairage-et-visibilite_ed01-2016

Automatic rain sensitive windscreen wipers

Switching on

F Briefly push the control stalk down.
A wiping cycle confirms that the instruction has
been accepted.

Switching off

F Briefly push the control stalk down again,

or place the control stalk in another
position (Int, 1 or 2).

The automatic rain sensitive windscreen
wipers must be reactivated by pushing
the control stalk downwards, if the
ignition has been off for more than
one minute.

This warning lamp comes on in the
instrument panel, accompanied by a
message.

This warning lamp goes off in the
instrument panel, accompanied by a
message.

The windscreen wipers operate automatically, adapting their speed to the intensity of the rainfall without any action on the part of the driver.
Detection of rainfall is by means of a sensor at the top centre of the windscreen, behind the rear view mirror.

Operating fault

If a fault occurs with the automatic rain
sensitive wipers, the wipers will operate in
intermittent mode.
Have them checked by PEUGEOT dealer or a
qualified workshop.

Do not cover the rain sensor, linked with
the sunshine sensor and located in the top
centre of the windscreen.
Switch off the automatic rain sensitive
wipers when using an automatic car wash.
In winter, it is advisable to wait until the
windscreen is completely clear of ice
before activating the automatic rain
sensitive wipers.

Safety

156

3008-2_en_Chap05_securite_ed01-2016

General safety recommendations

Labels are applied at various
points on your vehicle. They carry
safety warnings as well as vehicle
identification information. Do not
remove them: they form an integral part
of your vehicle.

For any work on your vehicle, use
a qualified workshop that has the
technical information, skills and
equipment required, all of which a
PEUGEOT dealer is able to provide.

We draw your attention to
the following points:

The fitting of electrical equipment
or accessories not listed by
PEUGEOT may cause excessive
current consumption and faults and
failures with the electrical system of
your vehicle. Contact a PEUGEOT
dealer for information on the range
of recommended accessories.

As a safety measure, access to
the diagnostic socket, used for
the vehicle's electronic systems,
is reserved strictly for PEUGEOT
dealers or qualified workshops,
equipped with the special tools
required (risk of malfunctions of the
vehicle's electronic systems that
could cause breakdowns or serious
accidents). The manufacturer
cannot be held responsible if this
advice is not followed.

Any modification or adaptation
not intended or authorised by
Automobiles PEUGEOT or
carried out without meeting the
technical requirements defined
by the manufacturer would lead
to the suspension of the legal and
contractual warranties.

Installation of accessory
radio communication
transmitters

Before installing a radio communication
transmitter, you must contact a
PEUGEOT dealer for the specification
of transmitters which can be fitted
(frequency, maximum power,
aerial position, specific installation
requirements), in line with the Vehicle
Electromagnetic Compatibility
Directive (2004/104/EC).

Depending on the legislation in force in
the country, certain safety equipment
may be compulsory: high visibility
safety vests, warning triangles,
breathalysers, spare bulbs, spare fuses,
fire extinguisher, first aid kit, mud flaps
at the rear of the vehicle...

Safety

157

3008-2_en_Chap05_securite_ed01-2016

Hazard warning lamps

Visual warning with all of the direction
indicators flashing to alert other road users to a
vehicle breakdown, towing or accident.
F Press this button, all of the direction

indicators flash.

They can operate with the ignition off.

Automatic operation of
hazard warning lamps

When braking in an emergency, depending on
the force of deceleration, the hazard warning
lamps come on automatically. They switch off
automatically the first time you accelerate.
It is also possible to switch them off by pressing
the switch on the dashboard.

Horn

Audible warning to alert other road users to an
imminent danger.
F Press the central part of the multifunction

steering wheel.

Safety

158

3008-2_en_Chap05_securite_ed01-2016

Emergency or assistance call

If an impact is detected by the airbag
control unit, and independently of
the deployment of any airbags, an
emergency call is made automatically.

PEUGEOT Connect SOS

In an emergency, press this
button for more than 2 seconds.
Flashing of the green LED and
a voice message confirm that
the call has been made to the
"PEUGEOT Connect SOS" call
centre*.

Pressing this button again immediately cancels
the request.
The green LED goes off.

The green LED remains on (without flashing)
when communication is established.
It goes off at the end of the call.

"PEUGEOT Connect SOS" immediately locates
your vehicle, starts communication with you in
your language**, and where necessary sends
the appropriate public emergency services**. In
countries where the service is not available, or
when the locating service has been expressly
declined, the call is sent directly to the
emergency services (112) without the vehicle
location.

** Depending on the geographical cover of

"PEUGEOT Connect SOS", "PEUGEOT
Connect Assistance" and the official national
language selected by the owner of the vehicle.

The list of countries covered and PEUGEOT
CONNECT services is available from dealers
or at www.peugeot.co.uk.

* Subject to the general conditions for the

service available from dealers and subject to
technological and technical limitations.

If you benefit from the PEUGEOT
Connect Packs offer with the SOS and
assistance pack included, there are
additional services available to you in
your MyPEUGEOT personal space, via
the Internet website for your country.

Peugeot 3008 Hybrid 4 (2017 year). Instruction - part 10
