Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

The audio system will only play audio files
with" .wma, .aac, .flac, .ogg and .mp3" file
extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, etc.) can be played.
".wma" files must be of the standard wma 9 type.
The sampling rates supported are 32, 44 and
48 KHz.

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g. " " ? ; ù) to avoid any playing
and displaying problems.

Information and advice

Use only USB memory sticks formatted to
FAT32 (file allocation table).

The system supports USB mass
storage devices, BlackBerry

devices

or Apple

players via USB ports. The

adaptor cable is not supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied).

It is recommended that the USB cable
for the portable device is used.

To protect the system, do not use a
USB hub.

In order to be able to play a recorded CDR or
CDRW, when recording it is preferable to select
the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it may
not be played correctly.
It is recommended that the same recording
standard is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Bluetooth

audio streaming

Streaming allows audio files on your telephone
to be played through the vehicle's speakers.

Connect the telephone: see the "Telephone"
section, then "Bluetooth".
Choose the "Audio" or "All" profile.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the peripheral device or by
using the audio system buttons.

Once connected in streaming mode,
the telephone is considered to be a
media source.
It is recommended that you activate
"Repeat" on the Bluetooth

peripheral.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts).
The default classification used is by
artist. To modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Settings

Level 2

Audio settings

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Comments

Settings

Audio settings

Ambience

Choose the sound ambience.

Balance

Sound distribution using the Arkamys

system.

Sound effects

Set the volume or activate the link to vehicle
speed.

Ringtones

Set the telephone ringtone and volume.

Voice

Set the volume and voice for speaking street
names.

Confirm

Save your settings.

Settings

Turn off screen

Function that turns off the display.
Pressing the screen reactivates it.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Units

Display screen

Configuration

Adjust date and time

Factory settings

Level 1

Level 2

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Comments

Settings

Secondary page

System Settings

Units

Set the units used to display distance, fuel
consumption and temperature.

Delete data

Select the desired data in the list then press
Delete.

Factory settings

Return to factory settings.

Confirm

Save the settings.

Settings

Secondary page

Time/Date

Confirm

Set the date and time then confirm.

Settings

Secondary page

Screen settings

Activate automatic text scrolling

Activate or deactivate the setting then confirm.

Activate animations

Confirm

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Choice of language

Calculator

Configuration

Calendar

Level 1

Level 2

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Comments

Settings

Secondary page

Languages

Confirm

Select the language then confirm.

Settings

Secondary page

Calculator

Select the calculator.

Settings

Secondary page

Calendar

Select the calendar.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Audio settings

Press on Settings to display the
primary page.

Select "Audio settings".

Select "Ambience"

"Balance"

"Sound effects"

"Ringtones"

"Voice".

On-board audio: Arkamys

Sound

Staging optimises sound distribution in
the passenger compartment.

The distribution (or spatialisation using
the Arkamys

system) of sound is an

audio process that allows the audio
quality to be adapted to the number of
passengers in the vehicle.
Available only with the 6-speaker
configuration.

The audio settings (Ambience, Bass:,
Treble: and Loudness) are different
and independent for each sound
source.
The settings for Distribution and
Balance are common to all sources.

- "Ambience" (choice of 6 musical

ambiences)

- "Bass:"
- "Treble:"
- "Loudness" (Activate/Deactivate)
- "Distribution" ("Driver", "All

passengers", "Front only")

- "Audible response from touch

screen"

- "Volume linked to speed"

(Activate/Deactivate)

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Press on Settings to display the
primary page.

Press on the secondary page.

Press on the secondary page

Press on the secondary page.

Select "System Settings".

Select "Time/Date" to change the
time zone, synchronisation with GPS,
the time and its format, then the date.

Select "Screen settings".

Select "Units" to change the units
of distance, fuel consumption and
temperature.

Select "Languages" to change
language.

Activate or deactivate "Activate
automatic text scrolling" and
"Activate animations".

Select "Delete data" to delete the
list of recent destinations, personal
points of interest, contacts in the
directory.

Select "Calculator" to display a
calculator.

Choose the item then select "Delete".

Select "Calendar" to display a
calendar.

Select "Factory settings" to return
to the original settings.

Modifying system settings

The system does not manage changes
between summer time and winter time
automatically (depending on country).

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

MirrorLink

Optional depending on the
smartphone and operating system.

Connected services

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

As a safety measure and because it
requires sustained attention by the
driver, using a smartphone when
driving is prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
MirrorLink

technology to be displayed

in the vehicle's screen.
The principles and standards
are constantly evolving. For the
communication process between the
smartphone and the system to work
correctly, the smartphone must be
unlocked; update the operating system
of your smartphone as well as the date
and time in the smartphone and the
system.
For the list of eligible smartphones,
connect to the brand's internet website
in your country.

As a safety measure, applications
can only be viewed with the vehicle
stationary; display is interrupted once
the vehicle is moving.

When connecting a smartphone to
the system, it is recommended that
Bluetooth

be started on the smartphone

Start the application on the
smartphone (optional, depending
on the smartphone and operating
system).

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons

During the procedure, several screen
pages relating to certain functions
are displayed.
Accept to start and complete the
connection.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press on "MirrorLink

" to

start the application in the
system.

Once connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

If only one application has been downloaded to
the smartphone, it starts automatically.

MirrorLink

smartphone

connection

Press the end of the lighting control stalk to
start voice recognition of your smartphone via
the system.
Voice recognition requires a compatible
smartphone connected to the vehicle by
Bluetooth

Voice recognition

Please note:
-

if your smartphone is supported, to
make it "MirrorLink

" compatible,

some phone manufacturers
nevertheless invite you to first
download a dedicated application.

From the system, press on
"Connected services" to display the
primary page.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Comments

Connected

services

MirrorLink

Access or return to the applications already
downloaded to your smartphone and adapted to
MirrorLink

technology.

Access to a menu list depending on the
application chosen.
"Back": abandon the current operation, go up one
level.
"Home": access or return to the "Car mode" page.

Access to the "Connected services" primary
page.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

CarPlay
