Peugeot 508 RXH (2016 year). Instruction

191

Driving

508_en_Chap06_conduite_ed01-2016

F Press

1, the cruise control is activated

but remains paused.

F Set the programmed speed by

accelerating to the required speed,
then press button 2 or 3 (e.g.: 70 mph
(110 km/h)).

Programming

You can then change the programmed speed using buttons 2 and 3:
-

by + or - 1 mph (km/h) = short press,

by + or - 5 mph (km/h) = long press,

in steps of + or - 5 mph (km/h) = maintained press.

F Pause the cruise control by pressing button 4: the screen confirms

the suspension with with "Pause".

F Switch the cruise control back on by pressing button 4 again.

Exceeding the programmed speed

Intentional or unintentional exceeding of the programmed speed results in
flashing of this speed on the display.
Return to the programmed speed, by means of intentional or unintentional
deceleration of the vehicle, automatically cancels the flashing of the speed.

When the cruise control is switched on,
be careful if you maintain the pressure
on one of the programmed speed
changing buttons: this may result in a
very rapid change in the speed of your
vehicle.
Do not use the cruise control on
slippery roads or in heavy traffic.
On a steep descent, the cruise control
will not be able to prevent the vehicle
from exceeding the programmed speed.
to avoid any risk of jamming of the
pedals:
-

ensure that the mat is positioned
correctly,

never fit one mat on top of another.

In the event of a cruise control fault, the speed
is cleared resulting in flashing of the dashes.
Have it checked by a PeugeOt dealer or a
qualified workshop.

Operating fault

Off / Return to normal driving

F Press

5; cruise control mode is deactivated the screen returns to

the distance recorder.

192

Driving

508_en_Chap06_conduite_ed01-2016

Memorising speeds

You can memorise up to 5 speeds in the
system.
By default, some speeds are already
memorised.
F go to the "Main menu" in the instrument

panel screen by pressing the "CONFIG"
button.

F Select the "Vehicle parameters" menu

and confirm.

F Select the "Driving assistance" line and

conform.

F Select the "Speeds memorised" line and

confirm.

to select a memorised speed:
F press and hold the "+" or

"-" button; the system stops
at the nearest memorised
speed,

As a safety measure, the driver must
carry out these operations when
stationary, using the instrument panel
screen.
these operations are only possible
when stationary.

Operation

F Select "Activation" to use the memorised

speeds.

F Select the speed M1 to M5 that you want to

use.

F Move the cursor to the desired value then

press "CONFIG" to modify it.

F Select "OK" and confirm to save the

modifications.

Selection

F press and hold again the "+" or "-" button to

select another memorised speed.

A reminder of the speed and the state of the
system (on / off) is displayed in the instrument
panel.

this memorising of speeds applies to both the speed limiter and the cruise control.

193

Driving

508_en_Chap06_conduite_ed01-2016

this system indicates the proximity of an
obstacle (person, vehicle, tree, gate, etc.)
which comes within the field of detection of
sensors located in the bumper.
Certain types of obstacle (stake, roadworks
cone, etc.) detected initially will no longer be
detected at the end of the manoeuvre, if they
are located in blind spots in the sensors' field
of detection.

Parking sensors

this system cannot in any circumstances replace
the need for vigilance on the part of the driver.

the system is switched on by engaging reverse
gear.
this is confirmed by an audible signal.
the system is switched off when you come out
of reverse gear.

Rear parking sensors

Audible assistance

the proximity information is given by an
intermittent audible signal, the frequency of which
increases as the vehicle approaches the obstacle.
the sound emitted by the speaker (right or left)
indicates the side on which the obstacle is located.
When the distance between the vehicle and
the obstacle becomes less than approximately
thirty centimetres, the audible signal becomes
continuous.

Visual assistance

this supplements the audible signal by
displaying bars in the screen which move
progressively nearer to the vehicle.
When the obstacle is very close, the "Danger"
symbol is displayed in the screen.

194

Driving

508_en_Chap06_conduite_ed01-2016

In addition to the rear parking sensors, the
front parking sensors are triggered when an
obstacle is detected in front and the speed of
the vehicle is still below 6 mph (10 km/h).
the front parking sensors are interrupted if
the vehicle stops for more than three seconds
in forward gear, if no further obstacles are
detected or when the speed of the vehicle
exceeds 6 mph (10 km/h).

Front parking sensors

the function will be deactivated
automatically if a trailer is being towed
or a bicycle carrier is fitted (vehicle
fitted with a towbar or bicycle carrier
recommended by PeugeOt).

Deactivation / Activation of the
front and rear parking sensors

the function is deactivated by pressing this button. the indicator lamp in the button comes on.
Pressing this button again reactivates the function. the indicator lamp in the button goes off.

the sound emitted by the speaker (front
or rear) indicates whether the obstacle
is in front or behind.

With audio system or for HYbrid4 version

With touch screen

195

Driving

508_en_Chap06_conduite_ed01-2016

In bad weather or in winter, ensure
that the sensors are not covered with
mud, ice or snow. When reverse gear is
engaged, an audible signal (long beep)
indicates that the sensors may be dirty.
Certain sound sources (motorcycle,
lorry, pneumatic drill, etc.) may trigger
the audible signals of the parking
sensor system.

In the event of a malfunction of
the system, when reverse gear
is engaged this warning lamp is

Operating fault

displayed in the instrument panel and/or a
message appears in the screen, accompanied
by an audible signal (short beep).
Contact a PeugeOt dealer or a qualified
workshop.

196

Driving

508_en_Chap06_conduite_ed01-2016

Blind spot monitoring system

this driving assistance system warns the driver
of the presence of another vehicle in the blind
spot angle of their vehicle (areas masked from
the driver's field of vision), as soon as this
presents a potential danger.

A warning lamp appears in the door mirror on
the side in question:
-

immediately, when being overtaken,

after a delay of about one second, when
overtaking a vehicle slowly.

this system is designed to improve
safety when driving and is in no
circumstances a substitute for the use
of the interior rear view mirror and door
mirrors. It is the driver's responsibility to
constantly check the traffic, to assess
the distances and relative speeds
of other vehicles and to predict their
movements before deciding whether to
change lane.
the blind spot sensor system can never
replace the need for vigilance on the
part of the driver.

197

Driving

508_en_Chap06_conduite_ed01-2016

No alert will be given in the following situations:
-

in the presence of immobile objects
(parked vehicles, barriers, street lamps,
road signs...),

with vehicles moving in the opposite
direction,

driving on a sinuous road or a sharp
corner,

Sensors fitted in the front and rear bumpers
monitor the blind spots.
the alert is given by a warning lamp which
comes on in the door mirror on the side in
question as soon as a vehicle - car, lorry,
cycle - is detected.
For this, the following conditions must be met:
-

all the vehicles must be moving in the
same direction,

the speed of your vehicle is between 7 and
75 mph (12 and 140 km/h),

when you overtake a vehicle with a speed
difference of less than 6 mph (10 km/h),

when a vehicle overtakes you with a speed
difference of less than 15 mph (25 km/h),

the traffic must be flowing normally,

in the case of an overtaking manoeuvre,
if this is prolonged and the vehicle being
overtaken remains in the blind spot,

you are driving on a straight or slightly
curved road,

your vehicle is not pulling a trailer,
a caravan...

Operation

F On switching on the ignition, or

engine running, press this button
to activate the function; the
warning lamp comes on.

With audio system or for HYbrid4 version

With touch screen

198

Driving

508_en_Chap06_conduite_ed01-2016

when overtaking (or being overtaken by) a
very long vehicle (lorry, coach...) which is
at the same time detected at the rear in the
blind spot angle and present in the driver's
forward field of vision,

in very heavy traffic: vehicles detected in
front and behind are confused with a lorry
or a stationary object,

when overtaking quickly.

F to deactivate the system, press

this button again; the warning
lamp goes off.

Operating fault

the system may suffer temporary
interference in certain weather
conditions (rain, hail...).
In particular, driving on a wet surface
or moving from a dry area to a wet area
can cause false alerts (for example, the
presence of a fog of water droplets in
the blind spot angle is interpreted as a
vehicle).
In bad or wintry weather, ensure that
the sensors are not covered by mud, ice
or snow.
take care not to cover the warning zone
in the door mirrors or the detection
zones on the front and rear bumpers
with adhesive labels or other objects;
they may hamper the correct operation
of the system.

In the event of a fault, the warning
lamp in the button flashes then
goes off.

Have it checked by a PeugeOt dealer or a
qualified workshop.

the state of the system remains in memory on
switching off the ignition.

the system is automatically deactivated
when towing with a towbar approved by
PeugeOt.

199

Driving

508_en_Chap06_conduite_ed01-2016

Reversing camera

the reversing camera is activated automatically
when reverse gear is engaged.
Depending on version, the image is displayed
in the touch screen or the instrument panel.

the reversing camera cannot in any
circumstances be a substitute for the
vigilance and responsibility of the driver.

the reversing camera function completes the
parking assistance.

the superimposed representation of guide
lines helps with the manoeuvre.
they are represented by lines marked "on
the ground" and do not allow the position of
the vehicle to be determined relative to tall
obstacles (for example: other vehicles, ...).

the blue lines represent the general direction
of the vehicle (the difference corresponds to
the width of your vehicle without the mirrors).
the red lines represent a distance of about
30 cm beyond the edge of your vehicle's rear
bumper.
the green lines represent distances of
about 1 and 2 metres beyond the edge of your
vehicle's rear bumper.

Opening the boot causes the display to
disappear.

Clean the reversing camera regularly
using a soft, dry cloth.

High pressure jet washing

When washing your vehicle, do not direct the
lance within 30 cm of the camera lens.

It is normal to be able to see part of
the number plate at the bottom of the
screen.

200

Practical information

508_en_Chap07_info-pratiques_ed01-2016

Fuel

Additions of fuel must be of at least 5 litres to
be registered by the fuel gauge.
Opening the filler cap may result in an inrush of
air. this vacuum is entirely normal and results
from the sealing of the fuel system.
F take care to select the pump that delivers

the correct fuel type for your vehicle's
engine (reminder on a label on the inside of
the filler flap).

F Open the filler cap by turning it a 1/4 turn to

the left.

F Remove the filler cap and hang it on its

carrier (on the filler flap).

Fuel tank

Capacity of the tank: approximately 72 litres (or 55 litres according to version).

If you have put in the wrong fuel for
your vehicle, you must have have
the tank drained and refilled with
the correct fuel before starting the
engine.

With Stop & Start, never refuel with
the system in StOP mode; you must
switch off the ignition with the key, or
the StARt/StOP button if your vehicle
has Keyless entry and Starting.

Opening

Press the switch.

this control remains active for a few
minutes after switching off the ignition. If
necessary, switch the ignition on again to
reactivate it.

Refuelling

F Introduce the nozzle and push it in fully

(pushing on the the metal non-return
valve A).

F Fill the tank. Do not continue past the third

cut-off of the nozzle, as this may cause
malfunctions.

F Refit the filler cap turning it a 1/4 turn to the

right.

F Push the filler flap to close it.

Your vehicle is fitted with a catalytic converter,
a device which helps to reduce the level of
harmful emissions in the exhaust gases.
For petrol engines, you must use unleaded
fuel only.
the filler neck is narrower, admitting petrol
nozzles only.

201

Practical information

508_en_Chap07_info-pratiques_ed01-2016

Low fuel level

When the low fuel level in the tank is
reached, this warning lamp comes on
in the instrument panel, accompanied
by an audible warning and a message
in the instrument panel screen.

Fuel supply cut-off

Your vehicle is equipped with a safety device
which cuts off the fuel supply in the event of
a collision.

It is still possible to use a fuel can to fill
the tank but this must be done slowly.
In order to ensure a good flow of fuel,
do not place the nozzle of the fuel can
in direct contact with the flap of the
misfuel prevention device.

Diesel misfuel prevention

Travelling abroad

As Diesel fuel pump nozzles may be different
in other countries, the presence of the misfuel
prevention device may make refuelling
impossible.
Not all Diesel vehicles are fitted with misfuel
protection, so before travelling abroad, we
recommend that you check with the PeugeOt
dealer network, whether your vehicle is suitable
for the fuel pumps in the country in which you
want to travel.

When it first comes on, around 7 litres of fuel
remain in the tank.
You must refuel as soon as possible to avoid
running out.

Mechanical device which prevents filling the tank of a Diesel vehicle with petrol. It avoids the risk of
engine damage that can result from filling with the wrong fuel.
Located in the filler neck, the misfuel prevention device appears when the filler cap is removed.

When a petrol filler nozzle is introduced into the
fuel filler neck of your Diesel vehicle, it comes
into contact with the flap. the system remains
closed and prevents filling.
Do not persist, but introduce a Diesel filler
nozzle.

202

DIESEL

Practical information

508_en_Chap07_info-pratiques_ed01-2016

Fuel used for petrol engines

the petrol engines are compatible with
e10 type petrol biofuels (containing 10 %
ethanol), conforming to european standards
eN 228 and eN 15376.
e85 type fuels (containing up to 85 % ethanol)
are reserved exclusively for vehicles marketed
for the use of this type of fuel (BioFlex
vehicles). the quality of the ethanol must
comply with european standard eN 15293.

Fuel used for Diesel
engines

the Diesel engines are compatible with
biofuels available at the pumps which meet
current and future european standards:
-

Diesel fuel that meets standard eN 590
mixed with a biofuel that meets standard
eN 14214,

Diesel fuel that meets standard eN16734
mixed with a biofuel that meets standard
eN14214 (possibly containing up to 10 %
Fatty Acid Methyl ester),

Paraffinic Diesel fuel that meets standard
eN15940 mixed with a biofuel that meets
standard eN14214 (possibly containing up
to 7 % Fatty Acid Methyl ester).

the use of B20 or B30 fuel meeting standard
eN16709 is possible in your Diesel engines.
However, this use, even occasional, requires
strict application of the special servicing
conditions referred to as "Arduous conditions".
For more information, contact a PeugeOt
dealer or a qualified workshop.
the use of any other type of (bio)fuel
(vegetable or animal oils, pure or diluted,
domestic fuel...) is strictly prohibited (risk of
damage to the engine and fuel system).
Only the use of Diesel fuel additives that meet
the standard B715000 is authorised.

203

Practical information

508_en_Chap07_info-pratiques_ed01-2016

Snow chains

In wintry conditions, snow chains improve traction as well as the behaviour of the vehicle when braking.

the snow chains must be fitted only
to the front wheels. they must never
be fitted to "space-saver" type spare
wheels.

use only the chains designed to be fitted to the
type of wheel fitted to your vehicle:

Advice on installation

F If you have to fit the chains during a

journey, stop the vehicle on a flat surface
on the side of the road.

F Apply the parking brake and position any

wheel chocks to prevent movement of your
vehicle.

F Fit the chains following the instructions

provided by the manufacturer.

F Move off gently and drive for a few

moments, without exceeding 30 mph
(50 km/h).

F Stop your vehicle and check that the snow

chains are correctly tightened.

Avoid driving with snow chains on roads
that have been cleared of snow, to
avoid damaging your vehicle's tyres and
the road surface. If your vehicle is fitted
with alloy wheels, check that no part of
the chain or its fixings is in contact with
the wheel rim.

For more information on snow chains,
contact a PeugeOt dealer or a
qualified workshop.

It is strongly recommended that before
you leave, you practise fitting the snow
chains on a level and dry surface.

take account of the legislation in force in your
country on the use of snow chains and the
maximum running speed authorised.

Original tyre size

type of chain

215/60R16
215/55R17

225/55 R17

Maximum link size:

9 mm

135/80R18
235/45R18
235/40R19

245/45 R18

Cannot be fitted with

chains

204

Practical information

508_en_Chap07_info-pratiques_ed01-2016

Very cold climate screen

Before fitting or removing the screen,
ensure that the engine is off and
the cooling fan has stopped. It is
recommended that the screen be fitted
and removed by a PeugeOt dealer or
a qualified workshop.

Do not forget to remove the very cold
climate screen:
-

when the ambient temperature exceeds
10° C (for example: in summer, ...),

when towing,

at speeds above 75 mph (120 km/h).

Removable protective screen which prevents the accumulation of snow at the radiator cooling fan.

Fitting

F Offer up the screen to the front of the top

section of the front bumper upper grille.

F Press on the screen to engage its fixing

clips.

Removal

F use a screwdriver as a lever to unclip each

retaining clip in turn.

205

Practical information

508_en_Chap07_info-pratiques_ed01-2016

towing a trailer

Driving with a trailer places greater
demands on the towing vehicle and the
driver must take particular care.
For more advice on driving when
towing, refer to the corresponding
section.

Your vehicle is primarily designed for
transporting people and luggage, but it may
also be used for towing a trailer.

Blanking cover

When towing, you must remove the blanking
cover if your vehicle has one.
Contact a PeugeOt dealer or a qualified
workshop for this.

For more information on weights (and
the towed loads which apply to your
vehicle) refer to the corresponding
section.

We recommend the use of genuine
PeugeOt towbars and their harnesses
that have been tested and approved
from the design stage of your vehicle,
and that the fitting of the towbar is
entrusted to a PeugeOt dealer or a
qualified workshop.
If the towbar is not fitted by a
PeugeOt dealer, it must still be
fitted in accordance with the vehicle
manufacturer's instructions.

206

Practical information

508_en_Chap07_info-pratiques_ed01-2016

towbar with quickly detachable towball

Presentation

this towbar allows the towball to be fitted and
removed quickly and easily without the use
of tools. Installed behind the rear bumper, the
towbar is invisible after removing the towball
and folding the trailer harness socket carrier.
1. Carrier.
2.  Protective blanking plug.
3.  Security ring.
4.  Folding trailer harness socket.
5.  Detachable towball.
6.  Locking / unlocking wheel.
7.  Security key lock.
8.  Locking wheel protector.
9.  Ball protector.
10.  Storage bag.

A. Locked position

the locking wheel is not in contact with the
towball (gap of about 5 mm).
the green mark is visible.
the lock for the locking wheel is facing
rearward.
the bolt is visible and extends beyond the
towball.

B. Unlocked position

the locking wheel is in contact with the towball.
then green mark is hidden.
the lock for the locking wheel is facing forward.
the peg is not visible.

Observe the legislation in force in the
country in which you are driving.

For information on the maximum trailer
weight and the recommended nose
weight, refer to the "technical data"
section.
For information on safely towing a
trailer, refer to the "towing a trailer"
section.

Peugeot 508 RXH (2016 year). Instruction - part 13
