Peugeot 308 SW BL (2013 year). Instruction

303

04 NAVIGATION - GUIDANCE

ALERT PARAMETERS
RISK AREAS

Select:
-  "Visual alert"
-  "Audible alert"
-

"Alert only in guidance"

"Overspeed alarm only".

The choice of time of notifi cation defi nes

how long in advance that speed camera

warnings are given.
Select " OK " to confi rm the screen.

Select " Guidance options " and confi rm,

then select "Set parameters for risk

areas " and confi rm.

These functions are only available if risk areas have been

downloaded and installed on the system.
The detailled procedure for updating risk area POIs can be found at

www.peugeot.com.

Press NAV to display the " Navigation -

guidance" menu.

304

04 NAVIGATION - GUIDANCE

ADDING A STAGE

Press NAV to display the

"Navigation - guidance " menu.

Select " Journey leg and route " then

confi rm.

Select " Close to " a route passing

close to the stage or " Strict " for a route

passing through the stage.
Confi rm " OK " to start the guidance, and

give a general indication of the guidance

route.

Select "Add a stage " then confi rm.
The address of the stage is entered as

a destination, by "Enter an address",

a contact in " Directory ", or " Previous

destinations".

ORGANISING STAGES

To organise stages, carry out operations

1 to 2 again, then select " Order/delete

journey legs" and confi rm.

Select and confi rm to save the

modifi cations.

Select the stage that you want to move

in the order.

Select "Delete " to delete the stage.

305

04 NAVIGATION - GUIDANCE

ROUTE OPTIONS

CALCULATION CRITERIA

Select " Guidance options " and confi rm.

Select " OK " and confi rm to save the

modifi cations.

Select " Defi ne calculation criteria" and

confi rm.
This function allows modifi cation of:
- the

guidance criteria: (" Fastest

route", " Shortest route",

"Distance/Time "),

the exclusion criteria: (" With tolls"

or "With Ferry "),

- traffi c avoidance: (" Traffi c info ").

Press NAV to display the

"Navigation - guidance" menu.

If traffi c avoidance (Traffi c info) is selected, the system suggests

an alternative route if there is a delay on the guidance route.

306

04 NAVIGATION - GUIDANCE

Press NAV to display the

"Navigation - guidance" menu.

MAP MANAGEMENT

SELECTING THE POINTS OF INTEREST DISPLAYED ON

THE MAP

Select " Map management " and confi rm.

Select from the various categories the

ones that you want to display on the

screen.

Select "Map details" and confi rm.

Select " By default" to have only "Oil stations, garages" and

"Accident-prone area " appear on the map (if installed in the

system).

Select " OK " then confi rm and select

"OK" again then confi rm to save the

modifi cations.

307

04 NAVIGATION - GUIDANCE

Select " Map management " and confi rm.

Select:
-

"Vehicle direction" to have the map

follow the direction of travel,

"North direction" to keep the map

always North up,

"Perspective view " to display a

perspective view.

Select "Map orientation " and confi rm.

The colour of the map, different from the day and night mode, is

confi gured in the " SETUP" menu.

MAP ORIENTATION

Press NAV to display the

" Navigation - guidance" menu.

Street names are visible on the map from the 100 m scale.

308

04 NAVIGATION - GUIDANCE

Press NAV to display the

"Navigation - guidance" menu.

ADJUSTING THE GUIDANCE SPEECH SYNTHESIS

Select " Guidance options " and confi rm.

ADJUSTING THE VOLUME/DEACTIVATION

Select " Set speech synthesis" and

confi rm.

Select the volume graph and confi rm.

Select "Deactivate " to deactivate voice messages.

Select " OK " and press the dial to

confi rm.

Adjust the volume to the desired level

and confi rm.

The volume of messages can be adjusted during the transmission

of the message using the volume adjustment control.

The volume setting of guidance messages is also accessible via the

"SETUP" / " Voice synthesis " menu.

309

04 NAVIGATION - GUIDANCE

MALE VOICE / FEMALE VOICE

Press SETUP to display the

confi guration menu.

Select "Select male voice " or "Select

female voice" then confi rm " Yes

" to

activate a male or female voice. The

system restarts.

Select "Voice synthesis " and confi rm.

310

05 TRAFFIC INFORMATION

Access to the "TRAFFIC INFORMATION" menu

Go from the list to the menu (left/right).

""""""" a c

at o

Traffi c information

Traffic information

T ffi i f

"""""""

Press "TRAFFIC".

311

05 TRAFFIC INFORMATION

CONFIGURE THE FILTERING AND DISPLAY OF TMC MESSAGES

TMC (Traffi c Message Channel) messages contain information on traffi c and weather conditions, received in real time and transmitted to the

driver in the form of audible announcements and symbols on the navigation map.
The navigation system can then suggest an alternative route to avoid a traffi c problem.

Press the TRAFFIC button to display the

Traffi c information menu.

Select the "Geographic fi lter" function

and confi rm.

The system offers a choice of:
- "

Retain all the messages",

or
-

"Retain the messages"

● "Around the vehicle ", (confi rm

the mileage to modify and select

the distance),

● "

On the route".

Confi rm " OK " to save the modifi cations.

We recommend:
-

a fi lter on the route and

a fi lter around the vehicle of:

- 12

miles

(20 km) in urban areas,

- 30

miles

(50 km) on motorways.

312

05 TRAFFIC INFORMATION

PRINCIPAL TMC SYMBOLS

Red and yellow triangle: traffi c information, for example:

Black and blue triangle: general information, for example:

RECEIVING TA MESSAGES

The TA (Traffi c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a traffi c report

is transmitted, the current audio source (Radio, CD, USB, ...) is

interrupted automatically to play the TA message. Normal playback

of the audio source resumes at the end of the transmission of the

message.

Press RADIO to display the "FM / AM

band " menu.

Select " Guidance options " then

confi rm.

Select " Activate / Deactivate TA" then

confi rm.

The volume setting for TA messages can be adjusted only during the

transmission of this type of alert.

Activate or deactivate the function at any time by pressing the button.
During a message, press the button to interrupt it.

313

06 USING THE TELEPHONE

Access to the "TELEPHONE" menu

"""""""

e ep o e

Telephone

T l

"""""""

Go from the list to the menu (left/right).

Press PHONE .

To make a call, select a number in the list and confi rm "OK"

to start the call.

Connecting a different telephone deletes the list of

recent calls.

No telephone connected.

Telephone connected.

Incoming call.

Outgoing call.

Synchronisation

of address book in

progress.
Telephone call in

progress.

In the top bar of the permanent

display

314

PAIRING A BLUETOOTH TELEPHONE
FIRST CONNECTION

For reasons of safety and because they require prolonged attention

on the part of the driver, the operations for pairing the Bluetooth

mobile telephone to the hands-free system of the audio unit must be

carried out with the vehicle stationary.

Activate the telephone's Bluetooth

function and ensure that it is "shown to

all" (telephone confi guration).

Press this button.

Select the name of the desired

peripheral from the list of devices

detected then select "Connect " and

confi rm.

The system offers to connect the

telephone:
-

in "Hands-free mode" (telephone

only),

in "Audio" mode (streaming: playing

music fi les on the telephone),

or "All " (for selection of both

modes).

Select " OK " and confi rm.

Select " Bluetooth functions " and

confi rm.

Select "Peripherals search" and

confi rm.
The list of peripherals detected is

displayed. Wait until the " Connect"

button is available.

USING THE TELEPHONE

Visit www.peugeot.co.uk for more information (compatibility,

additional help, ...).

315

Enter the same code on the telephone then accept

the connection.

Then accept automatic connection on the telephone to allow the

telephone to reconnect automatically every time the vehicle is

started.

The ability of the system to connect in only one mode depends on

the telephone. The two modes may both connect by default.

USING THE TELEPHONE

The "Hands-free mode " should be used in preference if

"Streaming" is not desired.

The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone

manual and with your network provider for details of the services available to you.

Select a code for the connection then

confi rm "OK".

Depending on the type of telephone, the system will ask you to

accept or not the transfer of your contacts.

On return to the vehicle,the last telephone connected

automatically reconnects, within around 30 seconds after

switching on the ignition (Bluetooth activated and visible).
To modify the automatic connection mode, remove the pairing

and pair the telephone again with the desired mode.

316

06 USING THE TELEPHONE

DIRECTORY / SYNCHRONIZING CONTACTS

Press PHONE then select " Contacts

management " and confi rm.

Select "New contact " to enter a new

contact.

Select "Delete all contacts" to delete

the contacts saved in the system.

Select "Import all the entries " to import

all the contacts in the telephone and

save them in the system.
Once imported, a contact remains visible

whatever telephone is connected.

Selection "Synchronization options":
- No

synchronization: only the

contacts saved in the system

(always present).

- Display telephone contacts: only the

contacts saved in the telephone.

- Display SIM card contacts: only the

contacts saved on the SIM card.

Display all phone contacts:

contacts on the SIM card and in the

telephone.

Select "Contact mem. status" to see the

number of contacts saved in the system

or imported, and the free memory.

317

MANAGING CONTACTS

Press PHONE then select "Directory of

contacts" and confi rm.

Select the desired contact and confi rm.

Select " Import" to copy one contact to

the system.

Select " Call" to start the call.

Select " Open " to view an external contact

or modify a contact saved in the system.

Select OK or ESC to exit this menu.

Select " Delete" to delete a contact saved

in the system.

It is necessary to import an external contact to modify the record.

It will be saved in the system. It is not possible to modify or delete

contacts in the telephone or the SIM card via the Bluetooth

connection.

USING THE TELEPHONE

318

06 USING THE TELEPHONE

Press PHONE twice.

Select " Dial" then confi rm.

Select " Directory of contacts" then

confi rm.

Dial the telephone number using the

virtual keypad selecting each number

in turn.
Confi rm " OK " to make the call.

Press TEL or twice on PHONE.

CALLING A NEW NUMBER CALLING

CONTACT

Select the desired contact and confi rm.
If access was via the PHONE button,

select "Call" and confi rm.

Select the number and confi rm to start

the call.

MAKING A CALL

Use of the telephone is not recommended while driving. We

recommended that you park safely or make use of the steering

mounted controls.
