Peugeot 308 CC (2014 year). Instruction - part 8

111

SAFETY

ISOFIX CHILD SEAT RECOMMENDED BY PEUGEOT AND APPROVED FOR YOUR VEHICLE

This child seat can also be used on seats which are not ﬁ tted with ISOFIX mountings.

In this case, it is essential that it is secured to the vehicle's seat by means of the seat belt.

Adjust the vehicle's front seat so that the child's feet do not touch the seat back.

Follow the instructions for ﬁ tting the child seat indicated in the seat manufacturer's installation guide.

"RÖMER Duo Plus ISOFIX"

(size category

B1 )

Group 1: from 9 to 18 kg

Installed in the "forward facing" position only.

Attached to the rings

A without the upper strap.

Three child seat body angles: sitting, reclining and lying positions.

112

SAFETY

LOCATIONS FOR FITTING ISOFIX CHILD SEATS

In accordance with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the

vehicle ﬁ tted with ISOFIX mountings.

In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from

A to G ,

is indicated on the child seat next to the ISOFIX logo.

IL-SU: seat suitable for the installation of an I soﬁ x S emi- U niversal seat either:

- "rearward facing" ﬁ tted with a support leg,

- "forward facing" ﬁ tted with a support leg.

IL1: seat adapted for the installation of a "RÖMER Duo Plus ISOFIX" child seat, approved speciﬁ cally for your vehicle. In this

vehicle, the ISOFIX child seat is used without a top tether.

X: seat which is not suitable for the installation of an ISOFIX seat of the size category indicated.

Weight of the child / indicative age

Less than 10 kg

(group 0)

Up to approx.

6 months

Less than 10 kg

(group 0)

Less than 13 kg

(group 0+)

Up to approx. 1 year

From 9 to 18 kg (group 1)

From approx. 1 to 3 years

Type of ISOFIX child seat

Infant car seat *

" rearward facing"

"forward facing"

ISOFIX size category

ISOFIX universal and semi-

universal child seats which

can be installed on the outer

rear seats

IL-SU

IL1

* Infant car seats and "car" cots cannot be installed on the front passenger seat.

113

SAFETY

ADVICE ON CHILD SEATS

The incorrect installation of a child

seat in a vehicle compromises the

child's protection in the event of an ac-

cident.

When installing a child seat using the

seat belt, ensure that the seat belt is

tightened correctly on the child seat

and that it secures the child seat ﬁ rmly

on the vehicle's seat.

Remember to fasten the seat belts or

the child seat harnesses

keeping the

slack in relation to the child's body to

a minimum , even for short journeys.

For optimum installation of the "for-

ward facing" child seat, ensure that

the back of the child seat is as close

as possible to the backrest of the vehi-

cle's seat, even in contact if possible.

Children at the front
The legislation on carrying children on

a front passenger seat is speciﬁ c to

each country. Refer to the legislation

in force in your country.

Deactivate the passenger airbag

when a "rearward facing" child seat is

installed on the front seat. Otherwise,

the child would risk being seriously

injured or killed if the airbag were to

inﬂ ate.

As a safety precaution, do not leave:

- one or more children alone and

unsupervised in a vehicle,

- a child or an animal in a vehicle

which is exposed to the sun, with

the windows closed,

- the keys within reach of children

inside the vehicle.

Installation of a booster seat
The chest part of the seat belt must

be positioned on the child's shoulder

without touching the neck.

Ensure that the lap part of the seat

belt passes correctly over the child's

thighs.

PEUGEOT recommends the use of

a booster seat which has a back, ﬁ t-

ted with a seat belt guide at shoulder

level.

Do not use the passenger's "AIRWAVE"

system if a child seat is installed on the

front seat.

114

DRIVING

When parking on a slope, direct

your wheels against the pavement,

apply the parking brake and en-

gage a gear.

PARKING BRAKE

Applying
 Pull the parking brake lever fully up

to immobilise your vehicle.

When the vehicle is being driv-

en, if this warning lamp and the

STOP warning lamp come on,

accompanied by an audible sig-

nal and a message on the multifunction

screen, this indicates that the parking

brake is still on or has not been properly

released.

Releasing
 Pull the parking brake lever gently,

press the release button then lower

the lever fully.

6-SPEED MANUAL GEARBOX

As a safety precaution and to facili-

tate starting of the engine:

always select neutral,

press the clutch pedal.

Only engage reverse gear when

the vehicle is stationary with the

engine at idle.

Engaging reverse gear

 Raise the ring under the knob and

move the gear lever to the left then

forwards.

Engaging 5 th or 6 th gear

 Move the lever fully to the right to

engage 5 th or 6 th gear.

115

DRIVING

GEAR SHIFT INDICATOR

System which reduces fuel consump-

tion by advising the driver to change up.

Operation

Depending on the driving situation and

your vehicle's equipment, the system

may advise you to skip one (or more)

gear(s). You can follow this instruc-

tion without engaging the intermediate

gears.

The gear engagement recommenda-

tions must not be considered compulso-

ry. In fact, the conﬁ guration of the road,

the amount of trafﬁ c and safety remain

determining factors when choosing the

best gear. Therefore, the driver remains

responsible for deciding whether or not

to follow the advice given by the system.

This function cannot be deactivated.

The information appears in the instru-

ment panel in the form of an arrow.

The system adapts its gear change

recommendation according to the

driving conditions (slope, load, ...) and

the demands of the driver (power, ac-

celeration, braking, ...).

The system never suggests:

- engaging ﬁ rst gear,

engaging reverse gear,

engaging a lower gear.

Example:

You are in third gear.

- You press the accelerator pedal.

- The system may suggest that you

engage a higher gear.

With an automatic gearbox, the

system is only active in manual

mode.

On vehicle ﬁ tted with a manual

gearbox, the arrow may be ac-

companied by the gear recom-

mended.

116

DRIVING

"PORSCHE TIPTRONIC

SYSTEM" AUTOMATIC

GEARBOX

Six speed automatic gearbox which of-

fers a choice between the comfort of

fully automatic operation, enhanced by

sport and snow programmes, or manual

gear changing.

There are two driving modes:

automatic operation for electronic

management of the gears by the

gearbox, with the

sport programme

for a more dynamic driving style or

the

snow programme to facilitate

driving when grip is poor.

manual

operation for sequential

changing of the gears by the driver.

Gear lever positions

P. Park.

Immobilisation of the vehicle, park-

ing brake on or off.

Starting the engine.

R. Reverse.

Reversing manoeuvres, vehicle sta-

tionary, engine at idle.

N. Neutral.

Immobilisation of the vehicle, park-

ing brake on.

Starting the engine.

D. Automatic operation.

M. + / - Manual operation with sequen-

tial changing of the six gears.



Press forwards to change up

through the gears.



Press rearwards to change down

through the gears.

Displays in the instrument panel

When you move the lever in the gate

to select a position, the corresponding

symbol is displayed in the instrument

panel.

P. Park

R. Reverse

N. Neutral

D1... D6. Drive (Automatic driving)

S. Sport programme

 .

Snow programme

M1... M6. Manual (Sequential driving)

-. Invalid value during manual operation

Gear selection gate

1. Gear lever.

2. Button "S" (sport) .

3. Button "  " (snow) .

117

DRIVING

Moving off

 Apply the parking brake.

 Select position

P or N .

 Start the engine.

If this procedure is not followed, there

is an audible signal, accompanied by a

message in the screen.

 With the engine running,

press the

brake pedal.

 Release the parking brake.

 Select position

R , D or M ,

 Gradually release the brake pedal.

The vehicle then moves off.

If position

N is engaged inadver-

tently while driving, allow the en-

gine to return to idle then engage

position

D to accelerate.

When the engine is running at idle,

with the brakes released, if posi-

tion

R , D or M is selected, the vehicle

moves even without the accelerator

being pressed.

When the engine is running, never

leave children in the vehicle without

supervision.

When carrying out maintenance with

the engine running, apply the park-

ing brake and select position

P .

A message is displayed if you try

to move the gear lever from posi-

tion

P without pressing the brake

pedal.

Automatic operation



Select position

for

automatic

changing of the six gears.

The gearbox then operates in auto-

adaptive mode, without any intervention

on the part of the driver. It continuously

selects the most suitable gear accord-

ing to the style of driving, the proﬁ le of

the road and the load in the vehicle.

D and the gears selected automatically

appear in succession in the instrument

panel.

For maximum acceleration without

touching the lever, press the accelera-

tor pedal down fully (kick down). The

gearbox changes down automatically

or maintains the gear selected until the

maximum engine speed is reached.

On braking, the gearbox changes down

automatically to provide efﬁ cient engine

braking.

If you release the accelerator sharply,

the gearbox will not change to a higher

gear for safety reasons.

Never select position

N while the

vehicle is moving.

Never select positions

P or R un-

less the vehicle is completely sta-

tionary.

Sport and snow programmes

These two special programmes supple-

ment the automatic operation in very

speciﬁ c conditions of use.

Sport programme "S"
 Press button

"S" , after starting the

engine.

The gearbox automatically favours a

dynamic style of driving.

S appears in the instrument

panel.

Snow programme "  "
 Press button "  ", after starting the

engine.

The gearbox adapts to driving on slip-

pery roads.

This programme improves starting and

drive when traction is poor.

 appears in the instrument

panel.

PRND

118

DRIVING

Return to automatic operation

 At any time, press the button select-

ed again to quit the programme en-

gaged and return to auto-adaptive

mode.

Manual operation



Select position

for

sequential

changing of the six gears.

 Push the lever towards the

+ sign to

change up a gear.

 Pull the lever towards the

- sign to

change down a gear.

It is only possible to change from one

gear to another if the vehicle speed and

engine speed permit; otherwise, the

gearbox will operate temporarily in au-

tomatic mode.

and the gears engaged

manually appear in succes-

sion in the instrument panel.

If the engine speed is too low or too

high, the gear selected ﬂ ashes for a few

seconds, then the actual gear engaged

is displayed.

It is possible to change from position

(automatic) to position

M (manual) at

any time.

When the vehicle is stationary or mov-

ing very slowly, the gearbox selects

gear

M1 automatically.

The sport and snow programmes do not

operate in manual mode.

Invalid value during manual

operation

This symbol is displayed if a

gear is not engaged correctly

(selector between two posi-

tions).

Stopping the vehicle

Before switching off the engine, you

can engage position

P or N to place the

gearbox in neutral.

In both cases, apply the parking brake

to immobilise the vehicle.

Operating fault

There is a risk of damage to the

gearbox:

- if you press the accelerator and

brake pedals at the same time,

- if you force the lever from posi-

tion

P to another position when

the battery is ﬂ at.

To reduce fuel consumption during

a long period stationary with the

engine running (trafﬁ c jam, etc.),

place the gear lever in position

and apply the parking brake.

If the lever is not in position

P ,

when the driver's door is opened

or approximately 45 seconds after

the ignition is switched off, there is

an audible signal is heard accom-

panied by a message.

 Return the lever to position

P ;

the audible signal stops and the

message disappears.

When the ignition is on, the il-

lumination of this warning lamp,

accompanied by an audible

signal and a message in the

screen, indicates a gearbox malfunction.

In this case, the gearbox switches

to emergency mode and is locked in

3rd gear. You may feel a substantial

knock when changing from

P to R and

from

N to R . This will not cause any

damage to the gearbox.

Do not exceed a speed of 60 mph

(100 km/h), local speed restrictions per-

mitting.

Have it checked by a PEUGEOT dealer

or a qualiﬁ ed workshop.

This warning lamp may also come on if

a door is opened.

119

DRIVING

STOP & START

The Stop & Start system puts the en-

gine temporarily into standby - STOP

mode - during stops in the trafﬁ c (red

lights, trafﬁ c jams, etc...). The engine

restarts automatically - START mode -

as soon as you want to move off. The

restart takes place instantly, quickly and

silently.

Perfect for urban use, the Stop & Start

system reduces fuel consumption, ex-

haust emissions and the noise level

when stationary.

Operation

Going into engine STOP mode

The

"ECO" warning lamp comes

on in the instrument panel and the

engine goes into standby:

with a manual gearbox , at speeds

below 12 mph (20 km/h), when you

put the gear lever into neutral, and

you release the clutch pedal.

If your vehicle is ﬁ tted with

it, a time counter calculates

the sum of the periods in

STOP mode during a jour-

ney. It rests itself to zero ev-

ery time the ignition is switched on with

the key.

For your comfort when parking,

STOP mode is not available for a

few seconds after coming out of

reverse gear.

STOP mode does not affect the

functionality of the vehicle, such

as braking, power steering, for ex-

ample.

Never refuel with the engine in

STOP mode; you must switch off

the ignition with the key.

Special cases: STOP mode

unavailable
STOP mode is not invoked when:

the driver's door is open,

- the driver's seat belt is not fastened,

- the vehicle has not exceeded 6 mph

(10 km/h) since the last engine start

using the key,

- the engine is needed to maintain a

comfortable temperature in the pas-

senger compartment,

demisting is active,

some special conditions (battery

charge, engine temperature, brak-

ing assistance, ambient tempera-

ture...) where the engine is needed

to assure control of a system.

The

"ECO" warning lamp ﬂ ash-

es for a few seconds, then goes

off.

This operation is perfectly normal.

In STOP mode of Stop & Start, the

"AIRWAVE" system stops working.

120

DRIVING

Going into engine START mode

The

"ECO" warning lamp goes

off and the engine starts:

with a manual gearbox , when you

fully depress the clutch pedal.

Special cases: START invoked

automatically

For your safety and comfort, START

mode is invoked automatically when:

you open the driver's door,

- you unfasten the driver's seat belt,

- the speed of the vehicle exceeds

15 mph (25 km/h) with a manual

gearbox,

some special conditions (battery

charge, engine temperature, brak-

ing assistance, ambient tempera-

ture...) where the engine is needed

to assure control of a system.

The

"ECO" warning lamp ﬂ ash-

es, then goes off.

This operation is perfectly normal.

Deactivation

If the system has been deactivated

in STOP mode, the engine restarts

immediately.

At any time, press the

"ECO

OFF" switch to deactivate the system.

This is conﬁ rmed by the switch warn-

ing lamp coming on accompanied by a

message in the screen.

Reactivation

Press the

"ECO OFF" switch again.

The system is active again; this is con-

ﬁ rmed by the switch warning lamp go-

ing off, accompanied by a message in

the screen.

The system is reactivated auto-

matically at every new start using

the key.

With a manual gearbox in STOP

mode, if a gear is engaged without

fully depressing the clutch pedal, a

message is displayed asking you

to depress the clutch pedal to re-

start the engine.

121

DRIVING

Operating fault

In the event of a malfunction with the

system, the

"ECO OFF" switch warning

lamp ﬂ ashes, then comes on continu-

ously.

Have it checked by a PEUGEOT dealer

or a qualiﬁ ed workshop.

In the event of a fault in STOP mode,

the vehicle may stall. It is then neces-

sary to switch off the ignition and start

the engine again using the key.

Maintenance

Before working under the bonnet,

deactivate the Stop & Start system

to avoid any risk of injury result-

ing from automatic operation of

START mode.

This system requires a battery with a

special speciﬁ cation and technology

(reference numbers available from a

PEUGEOT dealer or a qualiﬁ ed work-

shop).

Fitting a battery not listed by

PEUGEOT introduces the risk of mal-

function of the system.

The Stop & Start system makes

use of advanced technology. All

work on this battery must be done

by a PEUGEOT dealer or a quali-

ﬁ ed workshop.

DRIVING

TYRE UNDER-INFLATION

DETECTION

A pressure sensor is located in the

valve of a each of these tyres.

The system triggers an alert if a drop

in pressure is detected in one or more

tyres.

This system does not avoid the

need to check the tyre pressures

regularly and before a long journey.

Driving with under-inﬂ ated tyres

adversely affects road holding,

extends braking distances and

causes premature tyre wear, par-

ticularly under arduous conditions

(vehicle loaded, high speed, long

journey).

System which automatically checks the

pressures of the tyres while driving.

The system continuously monitors the

pressures of the four tyres, as soon as

the vehicle is moving.

The tyre under-inﬂ ation detection

system is an aid to driving which

does not replace the need for the

driver to be vigilant or to drive re-

sponsibly.

Driving with under-inﬂ ated tyres in-

creases fuel consumption.

The tyre pressures for your vehicle

can be found on the tyre pressure

label (see the "Identiﬁ cation mark-

ings" section).

The tyre pressures must be

checked when the tyres cold (vehi-

cle stopped for 1 hour or after driv-

ing for less then 6 miles (10 km) at

moderate speed). Otherwise, add

0.3 bar to the values indicated on

the label.

Spare wheel
Don't forget to also check the tyre

pressure of the spare wheel.

If your vehicle has an alloy spare

wheel, this also has a sensor.

If your vehicle has a steel spare

wheel, this may be ﬁ tted with a

sensor * . Check whether a sensor

is ﬁ tted to a steel wheel.

123

DRIVING

The alert is given by the ﬁ xed il-

lumination of this warning lamp,

accompanied by an audible signal

and the display of a message.

Operating fault

Under-inflation alert

The loss of pressure detected does

not always lead to visible deforma-

tion of the tyre. Do not rely on just

a visual check.

The alert is maintained until the

tyre or tyres concerned is reinﬂ at-

ed, repaired or replaced.

The ﬂ ashing and then ﬁ xed il-

lumination of this warning lamp

accompanied by the illumination

of the service warning lamp in-

dicates a fault with the system.

This alert is also displayed when

one or more wheels is not ﬁ tted

with a sensor (steel spare wheel *

or other wheels ﬁ tted with winter

tyres).

Go to a PEUGEOT dealer or a

qualiﬁ ed workshop to have the

system checked or, following the

repair of a puncture, to have the

original wheel, equipped with a

sensor, reﬁ tted.

In this case, monitoring of the tyre pres-

sures is not assured.

 Reduce speed, avoid sudden steer-

ing movements or harsh brake ap-

plications.

 Stop as soon as it is safe to do so.

 In the event of a puncture, use the

temporary puncture repair kit or the

spare wheel (according to equip-

ment),

 if you have a compressor, the one in

the temporary puncture repair kit for

example, check the four tyre pres-

sures when cold,

 if it is not possible to check the tyre

pressures at the time, drive carefully

at reduced speed.

* Depending on version.

In the event of a problem on one of the

tyres, a symbol or a message is dis-

played, depending on equipment, to

identify it.

124

DRIVING

SPEED LIMITER

System which prevents the vehicle from

exceeding the speed programmed by

the driver.

When the programmed speed limit is

reached, pressing the accelerator pedal

no longer has any effect.

The speed limiter is

switched on man-

ually: it requires a programmed speed

of at least 20 mph (30 km/h).

The speed limiter is

switched off by

manual operation of the control.

The programmed speed can be ex-

ceeded temporarily by pressing the ac-

celerator ﬁ rmly.

To return to the programmed speed,

simply slow down to a speed below the

programmed speed.

The programmed speed remains in the

memory when the ignition is switched off.

The speed limiter cannot, in any cir-

cumstances, replace the need to re-

spect speed limits, nor can it replace

the need for vigilance and responsi-

bility on the part of the driver.

Steering mounted controls

The controls of this system are grouped

together on stalk

A .

1. Speed limiter mode selection wheel

2. Value decrease button

3. Value increase button

4. Speed limiter on / off button

Displays in the instrument panel

The programmed information is grouped

together in the instrument panel screen.

5. Speed limiter on / off indication

6. Speed limiter mode selection indication

7. Programmed speed value

125

DRIVING

Programming

 Turn wheel

1 to the "LIMIT" po-

sition: the speed limiter mode is

selected but is not switched on

(OFF / Pause).

You do not have to switch the speed

limiter on in order to set the speed.

 Set the speed value by pressing button

2 or 3 (e.g.:

55 mph (90 km/h)).

You can then change the programmed speed using buttons

and

3 :

- by + or - 1 mph (km/h) = short press,

- by + or - 5 mph (km/h) = long press,

- in steps of + or - 5 mph (km/h) = maintained press.

 Switch the speed limiter on by pressing button

4 .

 Switch the speed limiter off by pressing button

4 : the

display conﬁ rms that it has been switched off (OFF /

Pause).

 Switch the speed limiter back on by pressing button

again.

Exceeding the programmed speed

Pressing the accelerator pedal to exceed the programmed

speed will not have any effect unless you press the pedal

ﬁ rmly past the point of resistance .

The speed limiter is deactivated temporarily and the pro-

grammed speed, which is still displayed, ﬂ ashes.

Returning to the programmed speed, by means of intention-

al or unintentional deceleration of the vehicle, automatically

cancels the ﬂ ashing of the programmed speed.

Return to normal driving

 Turn wheel

1 to the "0" position: the speed limiter mode

is deselected.

Operating fault

In the event of a speed limiter malfunc-

tion, the speed is cleared resulting in

ﬂ ashing of the dashes.

Have it checked by a PEUGEOT dealer

or a qualiﬁ ed workshop.

On a steep descent or in the event

of sharp acceleration, the speed

limiter will not be able to prevent

the vehicle from exceeding the pro-

grammed speed.

To avoid any risk of jamming of the

pedals:

ensure that the mat is posi-

tioned correctly,

- do not ﬁ t one mat on top of an-

other.

126

DRIVING

CRUISE CONTROL

System which automatically maintains

the speed of the vehicle at the value

programmed by the driver, without any

action on the accelerator pedal.

The cruise control is

switched on

manually: it requires a minimum vehicle

speed of 25 mph (40 km/h) and the en-

gagement of:

- fourth gear on a manual gearbox,

- second gear on an automatic gear-

box, in sequential driving mode,

position

D on an automatic gearbox.

The cruise control is

switched off man-

ually or by pressing the brake or clutch

pedal or on triggering of the DSC/ASR

systems for safety reasons.

It is possible to exceed the programmed

speed temporarily by pressing the ac-

celerator pedal.

To return to the programmed speed,

simply release the accelerator pedal.

Switching off the ignition cancels any

programmed speed value.

The controls of this system are grouped

together on lever

A .

1. Cruise control mode selection wheel

2. Speed programming / decrease pro-

grammed value button

3. Speed programming / increase pro-

grammed value button

4. Cruise control off / resume button

The programmed information is grouped

together on the instrument panel screen.

5. Cruise control off / resume indica-

tion

6. Cruise control mode selection indi-

cation

7. Programmed speed value

Steering mounted controls

Displays in the instrument panel

The cruise control cannot, in any

circumstances, replace the need to

respect speed limits, nor can it re-

place the need for vigilance and re-

sponsibility on the part of the driver.

You are advised to keep your feet

near the pedals at all times.

Content .. 6 7 8 9 ..
