Peugeot 307 SW Dag (2007.5). Instruction - part 4

COMFORT

Manual operation

If you wish, you can make a different

choice from that offered by the sys-

tem by changing a setting. The other

functions will still be controlled auto-

matically. Pressing the "AUTO"

but-

ton returns the system to completely

automatic operation.

Press this button to stop air

cooling.
Avoid prolonged use of this

mode (risk of condensation,
odour, humidity).

Press this button again as soon as

possible to return to automatic op-

eration of the air conditioning. The
symbol "A/C"

is displayed.

6. Air distribution adjustment

Pressing this button sev-

eral times in succession

enables the air l ow to be

directed in turn towards:

- the windscreen and side windows

(de-icing or demisting),

- the windscreen, the side windows

and the footwells,

- the footwells,

- the centre vents, the side vents

and the footwells,

- the centre and side vents.

7. Air l ow adjustment

Press the "small fan" or "large fan"

button respectively to decrease or in-

crease the l ow of air.

The air l ow symbol, the fan, i lls pro-

gressively in relation to the value re-

quired.

8. Air intake/Air recirculation

9. Demisting the rear screen and

the mirrors

10. Switching the system off
Press the "small fan" button of the

air l ow 7 until the fan symbol disap-

pears.

This action switches off all of the

functions of the air conditioning sys-

tem, with the exception of the demist-

ing of the rear screen 9 .
Temperature related comfort is no

longer guaranteed but a slight l ow of

air, due to the movement of the vehi-

cle, can still be felt.
Pressing the "large fan" button of

the air l ow 7 again or the AUTO but-

ton reactivates the system with the

values set before it was switched off.

Press this button for re-

circulation  of  the  interior
air.  The  air  recirculation
symbol  8

is displayed.

Air recirculation enables the

passenger compartment to be isolat-

ed from exterior odours and smoke.

Avoid prolonged recirculation of inte-

rior air (risk of condensation and de-

terioration of the air quality).

As soon as possible, press this but-

ton again to permit the intake of out-

side air and prevent condensation.

5. Air conditioning On/Off

Press this button to demist

the rear screen and the ex-

terior mirrors. The button  9
indicator light comes on.
Demisting  switches  off  au-

tomatically to prevent an

excessive consumption of current.

It is possible to stop operation of the

demisting before it is switched off

automatically by pressing the button

again.

COMFORT

In certain cases of particu-

larly arduous use (towing the

maximum load on a steep

gradient in high tempera-

tures), switching off the air condition-

ing permits the recovery of engine

power and therefore an increase in

the towing capacity.
In order for the air conditioning to be

fully effective, the windows must be

closed.
The air conditioning system does not

contain chlorine and does not present

any danger to the ozone layer.
Operate the air conditioning for 5 to

10 minutes, once or twice a month, to

keep it in good working order.

The water produced by the air con-

ditioning condensation is discharged

through an opening provided for this

purpose. Therefore, a puddle of wa-

ter may form underneath the vehicle

when stationary.

In order to ensure that the air condi-

tioning system operates correctly, reg-

ular checks are also recommended.
If the system does not produce

cold air, do not use it and contact a
PEUGEOT dealer.

COMFORT

Electric exterior mirrors

Adjustment


Slide switch A to the right or to the

left to select the corresponding

mirror.

 Move knob B in all four directions

to adjust.



Return switch A to the centre

position.

Folding

- from inside:



with the ignition on, pull switch

rearwards.

- from outside:



lock the vehicle using the re-

mote control or the key.

Unfolding
- from inside:



with the ignition on, pull switch

rearwards.

- from outside:



unlock the vehicle using the re-

mote control or the key.

The folding and unfolding of

the exterior mirrors can be

deactivated by a PEUGEOT
dealer.

Note: if the mirrors are folded using

switch A , they will not unfold when

the vehicle is unlocked using the

remote control or the key. Switch A

must be pulled again.

MIRRORS

The end of the driver's mir-

ror glass is aspherical (outer

zone marked by a dotted
line) in order to reduce the

"blind spot".

Furthermore, objects seen in the

driver and passenger mirrors are, in

reality, closer than they appear.
Therefore, this must be taken into

account in order to judge correctly

the distance of vehicles approaching

from behind.

COMFORT

This automatically and gradually

changes between the day and night

positions. To prevent dazzling, the

glass of the mirror darkens auto-

matically depending on the intensity

of the light from behind. It clears as

the light (headlamps of following ve-

hicles, sunlight) decreases, ensuring

maximum visibility.

Manual interior mirror

The interior mirror has two positions:

- day (normal),

- night (anti-dazzle).
To change from one to the other,

push or pull the lever on the lower

edge of the mirror.

Operation
Switch on the ignition and press

switch 1 :

- Indicator light 2 lit (switch

pressed): automatic operation.

- Indicator light 2 off: automatic

system off. The mirror remains at
its most clear.

Special feature
To ensure maximum visibility during

manoeuvres, the mirror clears auto-

matically when reverse gear is en-

gaged.

When the vehicle is stationary, un-

lock the steering wheel by pulling

handle A .
Adjust the height and depth of the

steering wheel.

Lock it by pushing handle A down

fully.

STEERING WHEEL HEIGHT
AND DEPTH ADJUSTMENT

Automatic day/night interior
mirror

COMFORT

This automatically and gradually

changes between the day and night

positions. To prevent dazzling, the

glass of the mirror darkens auto-

matically depending on the intensity

of the light from behind. It clears as

the light (headlamps of following ve-

hicles, sunlight) decreases, ensuring

maximum visibility.

Manual interior mirror

The interior mirror has two positions:

- day (normal),

- night (anti-dazzle).
To change from one to the other,

push or pull the lever on the lower

edge of the mirror.

Operation
Switch on the ignition and press

switch 1 :

- Indicator light 2 lit (switch

pressed): automatic operation.

- Indicator light 2 off: automatic

system off. The mirror remains at
its most clear.

Special feature
To ensure maximum visibility during

manoeuvres, the mirror clears auto-

matically when reverse gear is en-

gaged.

When the vehicle is stationary, un-

lock the steering wheel by pulling

handle A .
Adjust the height and depth of the

steering wheel.

Lock it by pushing handle A down

fully.

STEERING WHEEL HEIGHT
AND DEPTH ADJUSTMENT

Automatic day/night interior
mirror

COMFORT

FRONT SEATS

1. Forwards-backwards adjustment
Lift the control and slide the seat for-

wards or backwards.

2. Driver's or passenger's seat

height adjustment

Pull the handle upwards or push it

downwards as many times as neces-

sary to obtain the required position.

3. Seat back angle adjustment
Push the handle towards the rear.

4. "Aircraft" type table
There is an "aircraft" type table, i t-

ted with a can holder, on the back of

each front seat.

COMFORT

5. Head restraint height and angle

adjustment

To raise the head restraint, pull it up-

wards.

To remove the head restraint, press the

lug A

and pull the head restraint up-

wards.

To put the head restraint back in posi-

tion, locate the stems of the head re-

straint in the holes taking care to keep

them in line with the seat back.

To lower the head restraint, press the

lug A and the head restraint at the

same time.

The head restraint has a frame with a

latch which prevents the head restraint

from lowering; this safety device pro-

vides protection in the event of an im-

pact.

8. Heated seats control

Never drive with the head re-

straints removed; they must

be in place and correctly

adjusted.

REAR HEAD RESTRAINTS

These have a high position for when

they are in use and a low position for

when they are stored.

The head restraints are also remov-

able.
To remove them, pull upwards as far

as the stop then press the lug (side

seat) or the two lugs (centre seat).

6. Armrests
These can be folded down and are

removable.
To remove them, press the button lo-

cated between the armrest and the

side of the seat and pull.

7. Storage drawers
There is a storage drawer under each

front seat * .
- To open it, lift it and pull.

- To take it out, open it to its full

extent, press the ends of the

slides and lift it, then remove it

completely.

- To put it back in place, with it fully

closed, press on the top of the

drawer to secure it.

Under the front passenger seat, the

layout of the l oor allows for storage

of a i rst aid kit and a warning triangle

(small version).

  The  adjustment  is  correct  when
the  upper  edge  of  the  head
restraint  is  level  with  the  top  of
the head.

To adjust the angle of the head restraint,

tilt the lower part forwards or backwards.

Do not place heavy objects

in the drawers.

With the engine running, press the

switch. The temperature is controlled

automatically.
Pressing the switch again stops op-

eration.
Note: the command for activation of
the heating of the seat(s) remains

memorised for two minutes after the

ignition has been switched off.

* According to model.

COMFORT

Exit from the 3rd row or folding
from the boot
Place the head restraint in the low

position.
Fold the seat back onto the cushion

using the strap B .
Note: you can lock the seat back in

this position (for removal) by press-

ing down on it.

Pull the strap C upwards to release

the rear feet.
Place the seat in the folded position.

Forwards-backwards
adjustment *

Lift the bar A

and slide the seat for-

wards or backwards.

* Except additional seat.

Seat back angle adjustment

Pull the strap B , at the front of the

seat on the right or on the left, then

adjust to the required angle.

Release the strap to lock.

To adjust the angle of the seat back

from the 3rd row or the boot, pull the

strap  B  at the rear of the seat.
  Note:   the  additional  seat  can  be
angled  and  folded  by  means  of  the

strap B at the rear of the seat on the

right or on the left.

Access to the 3rd row
Place the head restraint in the low

position.

If necessary, push the seat back us-

ing bar A .
Fold the seat back onto the cushion

using the strap B .
Note: you can lock the seat back

in this position (e.g. for removal) by

pressing down on it.

Pull the strap C upwards to release

the rear feet.
Place the seat in the "folded" position.

Folding a side seat

REAR SEATS

COMFORT

Place the head restraint in the low

position.
Fold the seat back onto the cushion

using the strap B .

You now have a small table with four

can holders, two pen holders and a

document holder.

Folding the centre seat

Place the head restraint in the low

position.
Fold the seat back onto the cushion

using the strap B .
Note: you can lock the seat back in

this position (for removal) by press-

ing down on it.

Pull the strap C upwards to release

the rear feet.
Place the seat in the folded position.

  While  driving,  attach  the  retain-
ing strap (contained in the storage
pocket of one of the front seats) on
one  side  to  the  carrying  handle  F
and on the other side, to one of the
stems of a front head restraint.

Place the head restraint in the low

position.

Pull the strap B (at the rear of the

seat to the right or to the left) back-

wards then press on the seat back to

release it, while continuing to pull the

strap.
Fold the seat back onto the seat
cushion.
Note: you can lock the seat back in

this position (for removal) by press-

ing down on it.

Push the two levers D upwards to un-

lock the rear feet.
Place the seat in the folded position.

  While  driving,  attach  the  retain-
ing strap (contained in the storage
pocket  of  the  additional  seat)  on
one  side  to  the  carrying  handle  F
and  on  the  other  side,  to  the  rear
armrest grab handle.

Centre seat table position

Folding an additional seat

COMFORT

Fold the corresponding seat.

Tilt the two red levers E under the

seat to release the front feet.
Lift it and carry it using the carrying
handle F .
In the 3rd row, position the i xing point

closers to obtain a l at boot l oor.

Refitting a seat

In the 3rd row, i rst remove the l oor

i xing point closers using a thin

screwdriver.

Before positioning the 3rd row seats,

move those of the 2nd row forward if

necessary.
Check that nothing is obstructing

the l oor i xing points thus pre-

venting correct locking of the seat
feet.
Carry  the  seat  using  the  carrying
handle  F .
Position the front feet in the securing

points and lock them by means of the

two red levers E .

Locked

Pull the strap C upwards to check

that the rear feet are free.
Tilt the folded seat backwards.

The rear feet lock automatically.
Check that the seat is locked

cor-

rectly.
Lift the seat back, i rst releasing it by

pulling the strap B .

To lock the additional seats, press

the two levers D .

Only lock the seat back on
the cushion occasionally, to

avoid undue wear of the seat

covers.

Avoid placing luggage on folded

seats.
Never use the adjusting straps to re-

move, rei t or carry a seat, use the

carrying handle provided for this pur-

pose.

Free

Removing a seat

COMFORT

SEAT MODULARITY AND DIFFERENT CONFIGURATIONS

The design of your vehicle and of its seats offers multiple

seat coni gurations.

There are side seats

which can be installed in the 2nd or

3rd row, on the right or on the left.

Once the centre seat has been removed from the 2nd row,

you can recentre the side seats for more comfort.

There is also a centre seat

, i tted in the central position of

the 2nd row, which can also be installed in the left position

in the 3rd row.

In this case, you must use the 3rd row rear left seat belt

without passing it through the strap guide.

You can add up to two additional seats in the 3rd row, on

the right or on the left.

The various operations resulting in modii cation of

the existing coni guration must be carried out when

the vehicle is stationary (see "Seats" section).

Examples of varied arrangements combining
comfort and practicality:

5 seats

4 seats with table position

COMFORT

5 seats with centre seat in the 3rd row

Transportation of long objects

4 seats with side seat in the 3rd row

Loading of a large volume

COMFORT

6 seats with an additional seat and the centre
seat in the 3rd row

5 seats with table position and one additional
seat

7 seats with two additional seats

5 seats with two folded additional seats

COMFORT

"Forwards-facing"
When a "forwards-facing" child seat

is installed on the front passenger
seat

, adjust the vehicle's seat to the

intermediate longitudinal position

with the seat back upright and leave

the passenger air bag armed.

INSTALLING A CHILD SEAT
USING A THREE POINT SEAT
BELT

"Rearwards-facing"
When a "rearwards-facing" child seat

is installed on the front passenger
seat

, it is essential that the passen-

ger air bag is disarmed. Otherwise,

the child would risk being seri-
ously injured or killed if the air bag

were to inl ate .

GENERAL POINTS RELATING
TO CHILD SEATS

Although one of PEUGEOT's main

criteria when designing your vehicle,

the safety of your children also de-

pends on you.

For maximum safety, please follow

these precautions:

- in accordance with Directive

2003/20, all children under
the age of 12 or less than one

metre i fty * tall must travel in

approved child seats suited to
their weight

, on seats i tted with a

seat belt or ISOFIX mountings * ,

- statistically, the safest seats in

your  vehicle  for  the  transpor-
tation  of  children  are  the  rear
seats,

- a child weighing less than 9 kg

must  travel  in  the  "rearwards-
facing"  position  both  in  the
front and in the rear.

PEUGEOT recommends

that chil-

dren should travel in the rear seats

of your vehicle:

- "rearwards-facing" up to the

age of 2,

- "forwards-facing" over the age

of 2.

* The rules for transporting children

are specii c to each country. Con-

sult the current legislation in your
country.

Intermediate longitudinal

position

COMFORT

Passenger air bag OFF

CHILD SEATS RECOMMENDED BY PEUGEOT

PEUGEOT offers a complete range of recommended child seats which are se-

cured using a three point seat belt

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

"RÖMER Baby-Safe plus"

Installed in the rear-facing position.

Groups 1, 2 and 3: from 9 to 36 kg

"KIDDY Life"

For the safety of young children (from 9 to 18 kg),

PEUGEOT recommends use of the restraining cushion.

Groups 2 and 3: from 15 to 36 kg

"RECARO Start"

"KLIPPAN Optima"

From the age

of 6 years

(approximately 22 kg),

the booster is used on

its own.

COMFORT

Passenger air bag OFF

CHILD SEATS RECOMMENDED BY PEUGEOT

PEUGEOT offers a complete range of recommended child seats which are se-

cured using a three point seat belt

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

"RÖMER Baby-Safe plus"

Installed in the rear-facing position.

Groups 1, 2 and 3: from 9 to 36 kg

"KIDDY Life"

For the safety of young children (from 9 to 18 kg),

PEUGEOT recommends use of the restraining cushion.

Groups 2 and 3: from 15 to 36 kg

"RECARO Start"

"KLIPPAN Optima"

From the age

of 6 years

(approximately 22 kg),

the booster is used on

its own.

Content .. 2 3 4 5 ..
