PEUGEOT Connect Radio

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

When connecting a smartphone
to the system, it is recommended
that Bluetooth

be started on the

smartphone

Telephone connected by
Bluetooth

From the system, press
"Telephone" to display the primary
page.

Press the "PHONE" button to display the
secondary page.

Press "Android Auto" to start the
application in the system.

Different audio sources remain accessible in
the margin of the Android Auto display, using
touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

There may be a wait for the availability of
applications, depending on the quality of
your network.

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary and the
ignition on.

Activate the Bluetooth function on the
telephone and ensure that it is "visible to
all" (telephone configuration).

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Procedure from the system

Press "Telephone" to display the
primary page.

Press "Bluetooth search".
The list of telephones detected is
displayed.

Select the name of the chosen
telephone in the list.

PEUGEOT Connect Radio

On return to the vehicle, if the last
telephone connected is present again, it is
automatically recognised and within about
30 seconds of switching on the ignition,
the connection is established without any
action on your part (Bluetooth activated).

To modify the connection profile:

Press "Telephone" to display the
primary page.

Press the "PHONE" button to go to the
secondary page.

Press "Bluetooth connection" to
display the list of paired devices.

Press the "details" button of a paired
device.

The system offers to connect the telephone
with 3 profiles:
- "Telephone" (hands-free kit, telephone

only),

- "Streaming" (streaming: wireless playing of

the audio files on the telephone),

- "Internet data".

Select one or more profiles.

Press "OK" to confirm.

The ability of the system to connect to just
one profile depends on the telephone.
All three profiles may connect by default.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check the instructions for your
telephone and with your service provider
for the services to which you have access.

The profiles compatible with the system
are: HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Go to the Brand's website for more information
(compatibility, additional help, etc.).

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press "Telephone" to display the
primary page.

Press the "PHONE" button to go to the
secondary page.

If the pairing procedure fails, it is
recommended that you deactivate and
then reactivate the "Bluetooth" function in
your telephone.

Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

Automatic reconnection

PEUGEOT Connect Radio

Press "Bluetooth connection" to
display the list of paired devices.

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Deleting a telephone

Press the basket at the top right
of the screen to display a basket
alongside the telephone chosen.

Press the basket alongside the
telephone chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted PHONE button to accept
an incoming call.

And

Make a long press

on the steering mounted PHONE
button to reject the call.

Press "End call".

Making a call

Using the telephone is not recommended
while driving.
Park the vehicle.
Make the call using the steering mounted
controls.

Calling a new number

Press "Telephone" to display the
primary page.

Enter the phone number using the
digital keypad.

Press "Call" to start the call.

Calling a contact

Press "Telephone" to display the
primary page.

Or make a long press

on the steering mounted PHONE
button.

Press "Contacts".

Select the desired contact from the list offered.

Press "Call".

PEUGEOT Connect Radio

Calling a recently used
number

Press "Telephone" to display the
primary page.

Make a long press

on the steering mounted button.

Press "Recent calls".

Select the desired contact from the list offered.

It is always possible to make a call directly
from the telephone; as a safety measure,
first park the vehicle.

Setting the ringtone

Press "Telephone" to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Ring volume" to display the
volume bar.

Press the arrows or move the cursor
to set the ring volume.

Configuration

Profile settings

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the vehicle stationary.

Press "Settings" to display the
primary page.

Press "Profiles".

Select "Profile 1" or "Profile 2" or "Profile 3"
or "Common profile".

Press this button to enter a name for
the profile using the virtual keypad.

Press "OK" to save.

PEUGEOT Connect Radio

Press the back arrow to confirm.

Press this button to activate the
profile.

Press the back arrow again to
confirm.

Press this button to initialise the
profile selected.

Adjust brightness

Press "Settings" to display the
primary page.

Press "Brightness".

Move the cursor to adjust the
brightness of the screen and/or of
the instrument panel (according to
version).
Press in the grey zone to confirm.

Modifying system settings

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "System configuration".

Select "Units" to change the units of distance,
fuel consumption and temperature.

Press "Factory settings" to return to the initial
settings.

Returning the system to factory settings
activates the English language by default
(according to version).

Select "System info" to display the versions of
the different modules installed in the system.

Press the back arrow to confirm.

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "Screen configuration".

Press "Brightness".

Move the cursor to adjust the
brightness of the screen and/or of
the instrument panel (according to
version).

Press "Animation".

Activate or deactivate: "Automatic
scrolling".

Select "Animated transitions".

Press the back arrow to confirm.

PEUGEOT Connect Radio

Select the language

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Select "Language" to change the
language.

Press the back arrow to confirm.

Setting the time

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "Date and time".

Select "Time".

Press this button to adjust the time
using the virtual keypad.

Press "OK" to save the time.

Press this button to define the time
zone.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

Press the back arrow to save the
settings.

The system does not automatically
manage the change between winter and
summer time (depending on the country
of sale).

Setting the date

Press "Settings" to display the
primary page.

Press "Configuration" to go to the
secondary page.

Press "Date and time".

Select "Date".

Press on this button to define the
date.

Press the back arrow to save the
date.

Select the display format of the date.

Press the back arrow again to
confirm.

PEUGEOT Connect Radio

Adjustment of the time and date is only
available if "GPS Synchronisation" is
deactivated.
The change between winter and summer
time is done by changing the time zone.

Frequently asked
questions

The following information groups together the
answers to the most frequently asked questions
concerning your audio system.

PEUGEOT Connect Radio

Radio

QUESTION

RESPONSE

SOLUTION

The reception quality of the tuned radio station
gradually deteriorates or the stored stations are
not working (no sound, 87.5 MHz is displayed,
etc.).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the "RDS" function by means of the
upper band to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels,
basement car parks, etc.) block reception,
including in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for
example when going through a car wash or into
an underground car park).

Have the aerial checked by a dealer.

I cannot find some radio stations in the list of
received stations.
The name of the radio station changes.

The station is not received or has changed its
name in the list.

Press the round arrow on the "List" tab of the
"Radio" page.

Some radio stations send other information
in place of their name (the title of the song for
example).
The system interprets these details as the
station name.

PEUGEOT Connect Radio

Media

QUESTION

RESPONSE

SOLUTION

Playback of my USB memory stick starts only
after a very long wait (around 2 to 3 minutes).

Some files supplied with the memory stick
may greatly slow down access to reading
the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

Some information characters in the currently
playing media are not displayed correctly.

The audio system does not display some types
of characters.

Use standard characters to name tracks and
folders.

Playback of streaming files does not start.

The connected device does not automatically
launch playback.

Start playback from the device.

Names of tracks and playing time are not
displayed on the audio streaming screen.

The Bluetooth profile does not allow the transfer
of this information.

PEUGEOT Connect Radio

QUESTION

RESPONSE

SOLUTION

I cannot connect my Bluetooth telephone.

The telephone's Bluetooth function may be
switched off or the telephone may not be visible.

Check that your telephone has Bluetooth
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with
the system.

You can check the compatibility of your
telephone at the Brand's website (services).

The volume of the telephone connected in
Bluetooth mode is inaudible.

The sound depends on both the system and the
telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume
of the telephone if necessary.

Ambient noise affects the quality of the
telephone call.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, etc.).

The contacts are listed in alphabetical order.

Some telephones offer display options.
Depending on the settings chosen, contacts can
be transferred in a specific order.

Modify the telephone directory display settings.

Telephone

PEUGEOT Connect Radio

Settings

QUESTION

RESPONSE

SOLUTION

When changing the setting of treble and bass
the equalizer setting is deselected.
When changing the equalizer setting, the treble
and bass settings are reset.

The selection of an equalizer setting imposes
the settings for treble and bass and vice-versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

When changing the balance setting, distribution
is deselected.
When changing the distribution setting, the
balance setting is deselected.

The selection of a distribution setting imposes
the balance settings and vice-versa.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

There is a difference in sound quality between
the different audio sources.

To allow for optimal listening quality, the
audio settings can be tailored to different
sound sources, which can generate audible
differences when changing source.

Check that the audio settings are adapted to the
sources listened to. Adjust the audio functions
to the middle position.

When the engine is off, the system stops after
several minutes of use.

When the engine is switched off, the system's
operating time depends on the state of charge
of the battery.
In normal off state, the system automatically
goes into energy economy mode to maintain an
adequate charge in the battery.

Turn the ignition on to increase the charge of
the battery.

PEUGEOT Connect Radio

PEUGEOT Connect Radio

Audio system / Bluetooth

Contents

First steps

Steering mounted controls

Radio 3
Media 5
Telephone 8
Audio settings

Configuration 12
Frequently asked questions

For safety reasons, the vehicle must
always be stationary for the driver to
perform operations that require close
attention.
When the engine is switched off and to
prevent discharging of the battery, the
system switches off after activation of
energy economy mode.

Audio system / Bluetooth

First steps

On/Off, volume adjustment.

Adjust audio options: sound
ambience, treble, bass, loudness,
distribution, left/right balance, front/
rear balance, automatic volume.

Automatic search for a lower radio
frequency.
Select the previous CD, USB track.
Scroll in a list.
Press and hold: rewind.

Display the list of stations received,
the CD/USB tracks or folders.
Press and hold: update the list of
stations received.

Cancel the current operation.
Go up one level (menu or folder).

Automatic search for a higher radio
frequency.
Select the next CD, USB track.
Scroll in a list.
Press and hold: fast forward.

Access to the main menu.

Select preset radio station.
Radio, press and hold: store a
station.
Other than radio: see the associated
sections.

Eject CD.

Select the source:
Radio: FM1, FM2, AM, CD, USB,
AUX, Streaming.
Telephone: accept an incoming call.
Telephone, press and hold: end
a call, access the calls log for the
connected telephone.

Steering mounted controls

Radio: select the previous / next
preset radio station.
CD / USB: select the genre /
artist / folder / playlist from the list
depending on classification.
Select the previous / next item in a
menu.

Radio: automatic search for a higher
frequency.
CD / MP3 / USB: select the next
track.
CD / USB: press and hold: fast
forward.

Change the audio source.
Confirm a selection.
Call/end call on the telephone.
Press and hold: access to the calls
list.

Radio: automatic search for lower
frequency.
CD / MP3 / USB: selection of the
previous track.
CD / USB: press and hold: rewind.

Content .. 15 16 17 18 ..
