Peugeot 208 (2017 year). Instruction

PEUGEOT Connect Nav

Towards a contact

Press Navigation to display the
primary page.

Press the "MENU" button to go to the
secondary page.

Select "My destinations".

Select the "Contact" tab.

Select a contact in the list to start navigation.

Towards points of interest
(POI)

Points of Interest (POI) are listed in different
categories.

Press Navigation to display the
primary page.

Press the "MENU" button to go to the
secondary page.

Select "Points of interest".

Select the "Travel", or "Leisure"
or "Commercial" or "Public" or
"Geographic" tab.

Select "Search" to enter the name
and address of a POI.

Press "OK" to start calculation of
the route.

To a point on the map

Press Navigation to display the
primary page.

Explore the map by sliding a finger on the
screen.

Select the destination by pressing on the map.

Tap the screen to place a marker
and display the sub-menu.

Press this button to start navigation.

Press this button to save the
address displayed.

A long press on an item opens a list of
POIs nearby.

PEUGEOT Connect Nav

Towards GPS coordinates

Press Navigation to display the
primary page.

Explore the map by sliding a finger on the
screen.

Press this button to display the world
map.
Using the grid, select by zoom the
desired country or region.

Press this button to enter the GPS
coordinates.

A marker is displayed in the middle
of the screen, with the "Latitude"
and "Longitude" coordinates.

Press this button to start navigation.

Press this button to save the
address displayed.

Press this button to enter the value
for "Latitude" using the virtual
keypad.

And

Press this button to enter the value
for "Longitude" using the virtual
keypad.

TMC (Traffic Message
Channel)

TMC (Traffic Message Channel)
messages are linked to a European
standard on the broadcasting of traffic
information via the RDS system on FM
radio, transmitting traffic information in
real time.
The TMC information is then displayed
on a GPS Navigation system map and
taken into account straight away during
navigation, so as to avoid accidents, traffic
jams and closed roads.

The display of danger zones depends on
the legislation in force and subscription to
the service.

PEUGEOT Connect Nav

Connected navigation

According to version

Depending on the equipment level of the
vehicle

Network connection provided by
the vehicle

Network connection provided by
the user

Connected navigation
connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

For access to connected navigation, you
can use the connection provided by the
vehicle via the "Emergency or assistance
call" services or use your smartphone as
a modem.
Activate and enter settings for sharing
the smartphone connection.

Network connection provided by
the vehicle

The system is automatically
connected to the modem included
for the "Emergency or assistance
calls" services and does not require
a connection provided by the user
via their smartphone.

Network connection provided by
the user

Connect a USB cable.
The smartphone charges when
connected by a USB cable.

Activate the Bluetooth function on
the telephone and ensure that it is
visible to all (see the "Connect-App"
section).

Select a Wi-Fi network found by the
system and connect to it (see the
"Connect-App" section).

Restrictions of use:
- With CarPlay

, connection sharing is

only with a Wi-Fi connection.

- With MirrorLink

, connection sharing

is only with a USB connection.

The quality of services depends on the
quality of the network connection.

With the arrival of "TOMTOM
TRAFFIC", the services are
available.

USB connection

Bluetooth connection

Wi-Fi connection

PEUGEOT Connect Nav

The services offered with connected
navigation are as follows.
A Connected Services pack:
- Weather,
-  Filling stations,
-  Car park,
- Traffic,
-  POI local search.
A Danger zone pack (option).

The principles and standards
are constantly changing; for the
communication process between the
smartphone and the system to work
correctly, we recommend that you
update the operating system of the
smartphone as well as the date and
time of the smartphone and the
system.

Settings specific to
connected navigation

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with the
possibility of entering a multitude of
settings (radio presets, audio settings,
navigation history, contact favourites,
etc.); these settings are taken into account
automatically.

Press Navigation to display the
primary page.

Press the "MENU" button to go to the
secondary page.

Select "Settings".

Select "Map".

Activate or deactivate:
- "Allow declaration of danger

zones".

- "Guidance to final destination

on foot"

- "Authorize sending

information"

These settings must be made
according to each profile.

Select "Alerts".

Activate or deactivate "Warn of
danger zones".

Select this button.

Activate: Give an audible warning

For access to connected navigation, you
have to select the option: "Authorize
sending information".

The display of danger zones depends on
the legislation in force and subscription to
the service.

PEUGEOT Connect Nav

To distribute information on the
declaration of danger zones, you should
check the option: "Allow declaration of
danger zones".

Press Navigation to display the
primary page.

Press the "Declare a new danger
zone" button located in the upper
bar of the touch screen

Select the option "Type" to choose
the type of "Danger zone".

Select the "Speed" option and enter
it using the virtual keypad.

Press "OK" to save and distribute
the information.

"Danger zones" pack
updates

Press Settings to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "System settings".

Select the "System info" tab.

Select "View" to display the versions
of the different modules installed in
the system.

Select "Update(s) due".

You can download the system and map
updates from the Brand's website.
The update procedure can also be found
on the website.

Display the weather

Press Navigation to display the
primary page.

Press this button to display the list of
services.

Select "View map".

Select "Weather".

Press this button to display primary
information.

Declaration of "Danger
zones"

Press this button to display the
detailed weather information.

The temperature displayed at 6 a.m. will
be the maximum temperature for the day.
The temperature displayed at 6 p.m. will
be the minimum temperature for the night.

PEUGEOT Connect Nav

Applications

Internet Browser

Press Applications to display the
primary page.

Press "Connectivity" to go to the "Internet
Browser" function.

Press "Internet Browser" to display the
browser home page.

Select your country of residence.

Press "OK" to save and start the
browser.

Connection to the internet is via one of
the network connections provided by the
vehicle or the user.

Connectivity

Press Applications to display the
primary page.

Press "Connectivity" to go to the CarPlay

MirrorLink

or Android Auto functions.

Applications

Press Applications to display the
primary page.

Press "Applications" to display the
applications home page.

CarPlay

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
CarPlay

technology on the vehicle screen

when the smartphone's CarPlay

function

has been previously activated.
As the principles and standards are
constantly changing, it is recommended
that you keep your smartphone's
operating system updated.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

PEUGEOT Connect Nav

Press on "Telephone" to display the
CarPlay

interface.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Applications" to display the
primary page.

Press "Connectivity" to go to the CarPlay

function.

Press on "CarPlay" to display the
CarPlay

interface.

On connecting the USB cable, the
CarPlay

function deactivates the

system's Bluetooth

mode.

MirrorLink

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
MirrorLink

technology on the vehicle

screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked; update the operating system of
the smartphone as well as the date and
time of the smartphone and the system.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "MirrorLink

" function requires

the use of a compatible smartphone and
applications.

When connecting a smartphone
to the system, it is recommended
that Bluetooth

be started on the

smartphone

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Applications" to display the
primary page.

Press "Connectivity" to go to the MirrorLink

function.

Press "MirrorLink

" to start the

application in the system.

PEUGEOT Connect Nav

Depending on the smartphone, it may be
necessary to activate the "MirrorLink

function.

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

Once connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

There may be a wait for the availability of
applications, depending on the quality of
your network.

Android Auto smartphone
connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
Android Auto technology on the vehicle
screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked; update the operating system
of the smartphone as well as the date
and time of the smartphone and the
system.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "Android Auto" function requires
the use of a compatible smartphone and
applications.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Applications" to display the
primary page.

Press "Connectivity" to go to the "Android
Auto" function.

Press "Android Auto" to start the
application in the system.

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

PEUGEOT Connect Nav

Different audio sources remain accessible in
the margin of the Android Auto display, using
touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

In Android Auto mode, the function to
display the menu by pressing the screen
briefly with three fingers is deactivated.

There may be a waiting time for the
availability of applications, depending on
the quality of your network.

Bluetooth

connection

As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
of the Bluetooth mobile telephone with
the Bluetooth hands-free system of your
audio system must be carried out with the
vehicle stationary and the ignition on.

Activate the Bluetooth function on the
telephone and ensure that it is "visible to
all" (telephone configuration).

Procedure from the telephone

Select the system name in the list of
devices detected.

In the system, accept the connection request
from the telephone.

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Procedure from the system

Press Connect-App to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Bluetooth connection".

Select "Search".
The list of telephones detected is
displayed.

If the pairing procedure fails, it is
recommended that you deactivate and
then reactivate the Bluetooth function in
your telephone.

Select the name of the chosen
telephone in the list.

Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

PEUGEOT Connect Nav

Connection sharing

The system offers to connect the telephone
with 3 profiles:
- "Telephone" (hands-free kit, telephone

only),

- "Streaming" (streaming: wireless playing of

the audio files on the telephone),

- "Mobile internet data".

The "Mobile internet data" profile
must be activated for connected
navigation (where the vehicle does not
have "Emergency and assistance call"
services), having first activated sharing of
this connection on your smartphone.

Select one or more profiles.

Press "OK" to confirm.

Wi-Fi connection

Network connection by the smartphone Wi-Fi.

Press Connect-App to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Wi-Fi network
connection".

Select the "Secured" or "Not
secured" or "Stored" tab.

Select a network.

Using the virtual keypad, enter the
"Key" for the Wi-Fi network and the
"Password".

Press "OK" to start the connection.

The Wi-Fi connection and the sharing of
the Wi-Fi connection are exclusive.

Wi-Fi connection sharing

Creation of a local Wi-Fi network by the
system.

Press Connect-App to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Share Wi-Fi connection".

Select the "Activation" tab to activate or
deactivate sharing of the Wi-Fi connection.

And / Or

Select the "Settings" to change the name of
the system network and the password.

PEUGEOT Connect Nav

Press "OK" to confirm.

To protect against unauthorised access
and make your systems as secure as
possible, the use of a complex security
code or password is recommended.

Manage connections

Press Connect-App to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Manage connection".

With this function you can view the access
to connected services, the availability of
connected services and modify the connection
mode.

Radio

Selecting a station

Press Radio Media to display the
primary page.

Press "Frequency".

Press one of the buttons for an
automatic search for radio stations.

Move the cursor for a manual search
for frequencies up or down.

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio stations" in the
secondary page.

Press "Frequency".

Enter the values using the virtual
keypad.
First enter the units then click on the
decimals zone to enter the figures
after the decimal point.

Press "OK" to confirm.

Radio reception may be affected by the
use of electrical equipment not approved
by the Brand, such as a USB charger
connected to the 12 V socket.
The external environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS mode.
This is a normal effect of the way in
which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

PEUGEOT Connect Nav

Make a long press on one of the
buttons to preset the station.

Activating / Deactivating
RDS

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio settings".

Select "General".

Activate / Deactivate "Station
follow".

Press "OK" to confirm.

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100% of the territory.
This explains the loss of reception of the
station during a journey.

Display text information

The "Radio Text" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio settings".

Select "General".

Presetting a station

Select a radio station or frequency.
(refer to the corresponding section)

Press "Presets".

Activate / Deactivate "Display radio
text".

Press "OK" to confirm.

PEUGEOT Connect Nav

Select "Announcements".

Activate / Deactivate "Traffic
announcement".

Press "OK" to confirm.

DAB (Digital Audio
Broadcasting) radio

Terrestrial Digital Radio

Digital radio provides higher quality
reception.
The different multiplexes offer a choice
of radio stations arranged in alphabetical
order.

Press Radio Media to display the
primary page.

Select the audio source.

Press "Band" to select the "DAB" waveband.

DAB-FM auto tracking

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB-FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station (if
there is one).

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Radio settings".

Select "General".

Play TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station that carries
this type of message. While traffic
information is being broadcast, the current
media is automatically interrupted so that
the TA message can be heard. Normal
play of the media previously playing is
resumed at the end of the message.

PEUGEOT Connect Nav

Activate / Deactivate "Station
follow".

Press "OK".

If "DAB-FM auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a variation
in volume.
Once the digital signal quality is restored,
the system automatically changes back
to "DAB".

If the "DAB" station being listened to is
not available on "FM" ("DAB-FM" option
greyed out), or "DAB/FM auto tracking " is
not activated, the sound will cut out while
the digital signal is too weak.

Media

USB port

Insert the USB memory stick in the USB port or
connect the USB device to the USB port using
a suitable cable (not supplied).

To protect the system, do not use a USB
hub.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or a USB memory stick
is connected. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Auxiliary socket (AUX)

(depending on model / depending on
equipment)

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player, etc.)
to the auxiliary jack socket using an audio
cable (not supplied).

First adjust the volume on your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

CD player

(depending on model / depending on
equipment)
Insert the CD in the player.

PEUGEOT Connect Nav

Selecting the source

Press Radio Media to display the
primary page.

Select "Source".

Choose the source.

Bluetooth

audio streaming

Streaming allows you to listen to music from
your smartphone.

The Bluetooth profile must be activated, first
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your audio system.

If play does not start automatically, it may be
necessary to start the audio playback from the
telephone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in streaming mode, the
telephone is considered to be a media
source.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those of
the portable device connected (artists /
albums / genres / playlists / audiobooks /
podcasts).
The default classification used is by
artists. To modify the classification used,
return to the first level of the menu then
select the desired classification (playlists
for example) and confirm to go down
through the menu to the desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Information and advice

The system supports USB mass storage
devices, BlackBerry

devices or Apple

players via USB ports. The adapter cable
is not supplied.
Device management is done by the audio
system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

To protect the system, do not use a USB
hub.

The audio equipment will only play audio
files with ", ".aac", ".flac", ".ogg" and ".mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other file types (.mp4, etc.) can be read.
".wma" files must be of the standard wma 9
type.
The sampling rates supported are 32, 44 and
48 kHz.

PEUGEOT Connect Nav

It is advisable to restrict file names to
20 characters, without using special characters
(e.g. " "?.; ù) in order to avoid any reading or
display problems.

Use only USB keys in FAT32 format (File
Allocation Table).

It is recommended that the original USB
cable for the portable device is used.

In order to be able to play a burned CDR or
CDRW, select standards ISO 9660 level 1, 2 or
Joliet if possible when burning the CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with the lowest speed possible (4x maximum)
for the best acoustic quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Telephone

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary and the
ignition on.

Activate the Bluetooth function on the
telephone and ensure that it is "visible to
all" (telephone configuration).

Procedure from the telephone

Select the system name in the list of
devices detected.

In the system, accept the connection request
from the telephone.

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

Procedure from the system

Press Telephone to display the
primary page.

Press "Bluetooth search".

Select "Search".
The list of telephones detected is
displayed.

If the pairing procedure fails, it is
recommended that you deactivate and
then reactivate the Bluetooth function in
your telephone.

Peugeot 208 (2017 year). Instruction - part 14
