Peugeot 207 CC (2014 year). Instruction - part 12

175

04

207CC_EN_CHAP11B_RNEG_ED01-2014

 NAVIGATION - GUIDANCE

  LIST OF PRINCIPAL POINTS OF INTEREST (POI)

  *    According  to  availability  in  the  country.

 This icon appears when several POIs are grouped

together in the same area. Zooming in on this icon

shows details of the POIs.

  Service  station

 LPG  station

 Garage

 PEUGEOT

 Motor racing circuit

 Covered car park

 Car  park

 Rest  area

  Hotel

 Restaurant

 Refreshment  area

 Picnic  area

 Cafeteria

 Railway  station

 Bus  station

 Port

  Industrial  estate

 Supermarket

 Bank

 Vending  machine

  Tennis  court

 Swimming  pool

 Golf  course

 Winter sports resort

 Theatre

  Airport

  Theme  parks

 Hospital

 Pharmacy

 Police  station

 School

 Post offi ce

 Museum

 Tourist  information

 Risk  area *

 Cinema

176

04

5

6

3

2

1

4

207CC_EN_CHAP11B_RNEG_ED01-2014

  NAVIGATION  SETTINGS

  Select "Set parameters for risk

areas" for access to the "Display

on map", "Visual alert" and "Sound

alert" functions.

  Select the "POI categories on Map"

function to select the POIs to be

displayed on the map by default.

  Press  the  NAV  button.

  Press the NAV button again or select

the Navigation Menu function and

press the dial to confi rm.

  Select the "Settings" function and

press the dial to confi rm.

POI categories on Map

Settings

Set parameters for risk areas

Navigation Menu

 NAVIGATION - GUIDANCE

  Select the "Navi volume" function

and turn the dial to set the volume

of each voice synthesiser (traffi c

information, alert messages…).

Navi volume

  The adjustment of the volume for the Risk Areas POIs is used only

during the transmission of an alert.

          UPDATING POIs

  The detailed procedure for updating POIs is available at

https://www.wipinforadars.fr.

 This requires an SDHC (High Capacity) compatible reader.

  To activate or deactivate vocal guidance, with guidance active and

the map displayed in the screen, press the dial and then select or

deselect "Voice advice".

Voice advice

177

05

2

1

3

4

5

207CC_EN_CHAP11B_RNEG_ED01-2014

 TRAFFIC  INFORMATION

          CONFIGURE THE FILTERING AND

DISPLAY OF TMC MESSAGES

  Then select the radius of the fi lter in

miles (km) required in accordance

with the route, press the dial to

confi rm.

 When all of the messages on the

route are selected, the addition of a

geographical fi lter is recommended

(within a radius of 3 miles (5 km) for

example) to reduce the number of

messages displayed on the map.

The geographical fi lter follows the

movement of the vehicle.

  The fi lters are independent and their results are cumulative.

 We recommend a fi lter on the route and a fi lter around the vehicle

of:

   -   2 miles (3 km) or 3 miles (5 km) for a region with heavy traffi c,

  -   6 miles (10 km) for a region with normal traffi c,

  -   30 miles (50 km) for long journeys (motorway).

  Press the TRAFFIC button again or

select the Traffi c Menu function and

press the dial to confi rm.

  Press  the  TRAFFIC  button.

  TMC (Traffi c Message Channel) messages contain information on

traffi c and weather conditions, received in real time and transmitted to

the driver in the form of audible announcements and symbols on the

navigation map.

 The navigation system can then suggest an alternative route to avoid a

traffi c problem.

  Select the "Geo. Filter" function and

press the dial to confi rm.

Messages on route

  The list of TMC messages appears under the Traffi c Menu sorted

in order of proximity.

All warning messages

Traffi c Menu

  Select the fi lter of your choice:

Only warnings on route

All messages

 The messages appear on the map

and on the list.

 To exit, press "Back".

Geo. Filter

178

05

2

1

3

2

1

207CC_EN_CHAP11B_RNEG_ED01-2014

       PRINCIPAL TMC SYMBOLS

  With the current audio source

displayed on the screen, press the

dial.

  The shortcut menu for the source appears and gives access to:

  Select Traffi c Announcements (TA)

and press the dial to confi rm and go

to the associated settings.

TA

    -

the  station  transmits  TA  messages.

       RECEIVING TA MESSAGES

  Red and yellow triangle: traffi c information, for example:

  Black and blue triangle: general information, for example:

 TRAFFIC  INFORMATION

  The TA (Traffi c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a traffi c

report is transmitted, the current audio source (Radio, CD, ...) is

interrupted automatically to play the TA message. Normal playback

of the audio source resumes at the end of the transmission of the

message.

  -   the station does not transmit TA messages.
  -

TA  messages  are  not  activated.

179

06

3

2

1

1

207CC_EN_CHAP11B_RNEG_ED01-2014

       SELECTING A STATION

  When the current radio station is

displayed on the screen, press the

dial.

  The radio source short-cuts menu appears and provides access to

the following short-cuts:

  Select the function required and

press the dial to confi rm to gain

access to the corresponding settings.

TA

  RDS, if displayed, allows you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the entire country as radio stations do not

cover 100 % of the territory. This explains the loss of reception of

the station during a journey.

 The external environment (hill, building, tunnel, underground car park...)

may interfere with the reception, including in RDS following mode. This

phenomenon is a normal result of the way in which radio waves are

transmitted and does not in any way indicate a failure of the audio equipment.

       RDS - REGIONAL MODE

  Press the RADIO button to display

the list of stations received locally

sorted in alphabetical order.

 Select the station required by turning

the dial and press to confi rm.

Regional prog.

Radiotext

RDS

  While listening to the radio, press one of the

buttons to select the previous or next station on

the  list.

  Press one of the buttons on the numeric keypad for more than

2 seconds to store the current station.

 Press the button on the numeric keypad to recall the stored radio

station.

AM

  A long press of one of the buttons starts the

automatic search for a station with a lower or

higher  frequency.

 RADIO

180

07

207CC_EN_CHAP11B_RNEG_ED01-2014

 MUSIC MEDIA PLAYERS

       CD, MP3/WMA CD

INFORMATION AND ADVICE

  In order to be able to play a recorded CDR or CDRW, when

recording it is preferable to select the ISO 9660 level 1, 2 or Joliet

standard.

 If the disc is recorded in another format it may not be played

correctly.

 It is recommended that the same recording standard is always

used for an individual disc, with as low a speed as possible

(4x maximum) for optimum sound quality.

 In the particular case of a multi-session CD, the Joliet standard is

recommended.

  The PEUGEOT Connect Navigation will only play audio fi les

with the extension ".mp3" with a speed of between 8 Kbps and

320 Kbps and the extension ".wma" with a speed of between

5 Kbps and 384 Kbps.

 It also supports the VBR (Variable Bit Rate) mode.

 No other type of fi le (.mp4, .m3u...) can be played.

  The MP3 format, an abbreviation of MPEG 1, 2 & 2.5 Audio Layer 3

and the WMA format, an abbreviation of Windows Media Audio and

the property of Microsoft, are audio compression standards which

permit the recording of several tens of music fi les on a single disc.

  It is advisable to restrict fi le names to 20 characters, without

using special characters (e.g.: " ? ; ù) to avoid any play or display

problems.

181

07

3

2

1

6

4

5

207CC_EN_CHAP11B_RNEG_ED01-2014

             SELECTING/PLAYING  MUSIC

CD, MP3/WMA CD

  The playing and displaying of an MP3/WMA compilation may

depend on the recording programme and/or the settings used.

We recommend the ISO 9660 fi le standard.

  Press  the  MUSIC  button.

  Select the "Select music" function

and press the dial to confi rm.

  Press the up or down button to select

the next/previous folder.

  Select the music source required:

CD, MP3/WMA CD. Press the dial to

confi rm. Play begins.

Select music

  Press the MUSIC button again or

select the Music Menu function and

press the dial to confi rm.

  Press one of the buttons to select a

music track.

 Press and hold one of the buttons for

fast forward or rewind play.

Music Menu

  The list of tracks or MP3/WMA fi les appears under Music Menu.

 MUSIC MEDIA PLAYERS

182

07

4

3

1

2

207CC_EN_CHAP11B_RNEG_ED01-2014

 MUSIC MEDIA PLAYERS

  Connect the portable device (MP3/

WMA player…) to the auxiliary JACK

socket or to the USB port, using a

suitable audio cable.

  Press the MUSIC button then

press it again or select the Music

Menu function and press the dial to

confi rm.

  Select the AUX music source and

press the dial to confi rm. Play begins

automatically.

  Select the "External device" function

and press the dial to activate it.

External device

             USING THE EXTERNAL INPUT (AUX)

Music Menu

  JACK/USB  AUDIO  CABLE  NOT  SUPPLIED

  The display and management of the controls is via the portable

device.

183

08

1

2

3

4

207CC_EN_CHAP11B_RNEG_ED01-2014

 BLUETOOTH  TELEPHONE

  *    The services available depend on the network, the SIM card and the

compatibility of the Bluetooth telephone used. Check the telephone

manual and with your network provider for details of the services

available to you.

                PAIRING A TELEPHONE /

FIRST  CONNECTION

  For reasons of safety and because they require prolonged attention

on the part of the driver, the operations for pairing the Bluetooth

mobile telephone to the hands-free system of the PEUGEOT

Connect Navigation must be carried out with the vehicle stationary.

The ignition must be on.

  Activate the telephone's Bluetooth function

and ensure that it is "visible to all" (refer to the

telephone  instructions).

  Enter the authentication code on the telephone.

The code to be entered is displayed on the screen

of the system.

 Some telephones offer automatic reconnection of

the telephone every time the ignition is switched on.

 A message confi rms the pairing.

  To change the telephone connected,

press the PHONE button, then select

Phone Menu and press the dial to

confi rm.

  Once the telephone has been connected, PEUGEOT Connect

Navigation can synchronise the address book and the call list.

This synchronisation may take a few minutes * .

  Pairing can also be started from the telephone (refer to the

telephone  instructions).

  Visit www.peugeot.co.uk for more information (compatibility, more

help,  ...).

  Press  the  PHONE  button.

  For a fi rst connection, select

"Search phone" and press the dial to

confi rm. Then select the name of the

telephone.

Search phone

184

08

1

2

2

1

207CC_EN_CHAP11B_RNEG_ED01-2014

  *    The services available depend on the network, the SIM card and the

compatibility of the Bluetooth telephone used. Check the telephone

manual and with your network provider for details of the services

available to you.

 BLUETOOTH  TELEPHONE

                CONNECTING  A  TELEPHONE

  For reasons of safety and because they require prolonged attention

on the part of the driver, the operations for pairing the Bluetooth

mobile telephone to the hands-free system of the PEUGEOT

Connect Navigation must be carried out with the vehicle stationary.

The ignition must be on.

  Activate the telephone's Bluetooth function

and ensure that it is "visible to all" (refer to the

telephone instructions).

 The last telephone connected is reconnected

automatically.

 A message confi rms the connection.

  When a telephone is already

connected, to change it press the

PHONE button, then select Phone

Menu and press the dial to confi rm.

  Once the telephone has been connected, PEUGEOT Connect

Navigation can synchronise the address book and the call list. This

synchronisation may take a few minutes * .

  The list of telephones connected previously (4 maximum) appears

on the multifunction screen. Select the telephone required for a

new  connection.

  Visit www.peugeot.co.uk for more information (compatibility, more

help,  ...).

  Press  the  PHONE  button.

  Select "Connect phone". Select the

telephone and press to confi rm.

Connect phone

185

08

1

3

2

2

1

207CC_EN_CHAP11B_RNEG_ED01-2014

  Select the "Yes" tab to accept or "No"

to refuse and confi rm by pressing

the dial.

  RECEIVING  A  CALL

  MAKING  A  CALL

  An incoming call is announced by a ring and a superimposed

display on the multifunction screen.

Yes

  To hang up, press the PHONE button

or press the dial and select "End call"

then confi rm by pressing the dial.

End call

  Press  the  PHONE  button.

 Select "Dial number", then dial the

telephone number using the virtual

keypad.

  Select the Phone Menu function and

press the dial to confi rm.

  The list of the last 20 calls made and received in the vehicle

appears under Phone Menu. You can select a number and press

the dial to make the call.

No

  It is also possible to select a number from the address book. You

can select "Dial from address book". The PEUGEOT Connect

Navigation can record up to 1 000 entries (telephone numbers).

 Press the end of the steering mounted control for more than

two seconds to gain access to the address book.

Phone Menu

Dial number

  It is possible to make a call directly from the telephone; park the

vehicle as a safety measure.

 BLUETOOTH  TELEPHONE

   Press the end of the steering mounted control to

accept the call or end the call in progress.

  To delete a number, press the PHONE button then press and hold

on a call number to display a list of actions including:

 Delete  entry

 Delete  list

186

09

RADIO

207CC_EN_CHAP11B_RNEG_ED01-2014

 SCREEN MENU MAP(S)

  "Traffic"  Menu

  Messages  on  route

 Only warnings on route

 All warning messages

 All  messages

Within    2 miles (3 km)

 Geo.  Filter

Within    3 miles (5 km)

Within    6 miles (10 km)

Within    30 miles (50 km)

Within 60 miles (100 km)

  "Music"  Menu

  Select  music

 Sound  settings

Balance / Fader

Bass / Treble

 Linear

Equalizer

 Classic

 Jazz

 Rock/Pop

 Techno

 Vocal

Loudness

Speed dependent volume

Reset sound settings

  "Radio"  Menu

  Waveband

AM

 Linear

FM

  Manual  tune

 Sound  settings

Balance / Fader

Bass / Treble

Equalizer

                      MAIN FUNCTION

  OPTION  A

option A1

option A2

  OPTION  B...

1

2

3

1

2

4

1

2

3

4

3

3

3

3

2

2

2

2

4

4

4

4

4

3

3

3

3

3

2

3

2

2

3

3

3

3

1

2

3

2

3

187

207CC_EN_CHAP11B_RNEG_ED01-2014

  Abort  guidance/Resume  guidance

  Destination  input

 Geo  position

 Map

  Stopovers

Add stopover

 Navigate  HOME

 Choose from address book

Rearrange route

 Choose from last destinations

Replace stopover

Delete stopover

Recalculate

 Fast  route

 Short  route

 Optimized  route

  POI  search

POI nearby

  Route  options

Route type

 Short  route

 Fast  route

  "Navigation"  Menu

 City

 Street

Enter new address

 Country

Navigate HOME

 City  district

 House  number

 Start route guidance

 Postal  code

 Save to address book

 Intersection

 Address  input

POI near destination

POI in city

POI in country

POI near route

Choose from address book

3

3

Choose from last destinations

TMC station information

Loudness

Speed dependent volume

Reset sound settings

3

3

3

1

2

4

4

4

4

4

4

4

4

4

4

4

3

2

3

3

2

3

4

4

4

4

3

3

3

3

4

4

4

2

4

2

3

3

3

3

3

3

4

 Classic

 Jazz

 Rock/Pop

 Techno

 Vocal

4

4

4

4

4

188

207CC_EN_CHAP11B_RNEG_ED01-2014

 Avoid  ferries

Recalculate

  Settings

Navi volume

POI categories on Map

Set parameters for risk areas

 Display on map

 Visual  alert

 Sound  alert

3

2

4

3

3

3

4

4

4

  Dial  from  address  book

  "Phone"  Menu

Search phone

  Call  lists

  Connect  phone

Select ring tone

Phone / Ring tone volume

Phones connected

Enter mailbox number

  Settings

 Disconnect  phone

 Rename  phone

 Delete  pairing

 Delete all pairings

 Show  details

  "SETUP"  menu

  System  language *

English

Español

Deutsch

Italiano

Français

Nederlands

Polski

Portuguese

  Date  &  Time *

Set date & time

Date format

Time format

1

2

2

2

2

3

3

4

4

4

4

4

2

3

3

3

1

2

3

3

3

3

3

3

3

3

3

3

3

2

 Avoid  motorways

Route dynamics

 Traffi c independent

 Semi-dynamic

Avoidance criteria

 Avoid toll roads

 Optimized  route

3

3

4

4

4

4

4

  *    Available  according  to  model.

189

207CC_EN_CHAP11B_RNEG_ED01-2014

  **   The parameter settings vary according to vehicle.

 Dark  blue

Map colour

 Night mode for map

  Units

 Day mode for map

  Vehicle **

Vehicle information

 Alert  log

 Status  of  functions

Temperature

 Celsius

 Fahrenheit

Metric / Imperial

 Kilometres (Consumption: l/100)

 Kilometres (Consumption: km/l)

 Miles  (Consumption:  MPG)

  System

 Auto. Day/Night for map

Factory reset

Software version

Automatic scrolling

3

4

4

2

4

3

4

4

2

3

4

4

3

4

4

4

2

4

3

3

3

Colour

 Pop  titanium

 Toffee

 Blue  steel

 Technogrey

3

4

4

4

4

  Display

Brightness

2

3

190

207CC_EN_CHAP11B_RNEG_ED01-2014

 FREQUENTLY  ASKED  QUESTIONS

QUESTION

ANSWER

SOLUTION

 There is a difference in

sound quality between

the different audio

sources (radio, CD...).

 For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

 Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the Linear musical ambience and

set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

 The CD is ejected

automatically or is not

played by the player.

 The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.

 The CD is protected by an anti-pirating protection system which is not

recognised by the audio system.

   -   Check that the CD is inserted in the player the

right way up.

  -   Check the condition of the CD: the CD cannot

be played if it is too damaged.

  -   Check the content in the case of a recorded

CD: consult the advice in the Audio section.

  -   The audio system's CD player does not play

DVDs.

  -   Because of their quality level, certain

writeable CDs will not be played by the audio

system.

 The CD player sound is

poor.

 The CD used is scratched or of poor quality.

 Insert good quality CDs and store them in suitable

conditions.

 The audio system settings (bass, treble, ambiences) are unsuitable.

 Set the treble or bass level to 0, without selecting

an ambience.
