NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

VEHICLE SECURITY ALARM SYSTEM — IF
EQUIPPED

The Vehicle Security Alarm monitors the doors and
decklid for unauthorized entry and the ignition for
unauthorized operation. If something triggers the alarm,
the Vehicle Security Alarm will prevent the vehicle from
starting. It will also emit an acoustic signal and flash the
park lights, and taillights.

Operation

The alarm activates in the following cases:

1. Wrongful opening of one of the doors or the decklid

(perimeter protection);

2. Wrongful operation of the ignition switch (key turned

to MAR-ON);

3. Cutting of the battery leads;

4. Movement inside the passenger compartment (volu-

metric protection);

5. Anomalous lifting/tilting of the car.

Operation of the alarm is indicated by an acoustic and
visual signal (flashing of the direction indicators for
several seconds). The alarm activation modes may vary
according to the market. There is a maximum number of
acoustic/visual cycles. When this is reached the system
returns to normal operation.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:

• The engine locking function is guaranteed by the Alfa

Romeo CODE, which is automatically activated when
the key is extracted from the ignition switch.

• The alarm is adapted to meet requirements in various

countries.

To Arm The System

With the doors and decklid closed and the ignition key
either turned to STOP or removed, point the key towards
the vehicle then push and release the lock button.

The system emits an acoustic and visual signal and
activates door locking.

A self-diagnosis stage lasting approximately 30 seconds
precedes the activation of the alarm. During the self-
diagnosis, the vehicle security light flashes in the instru-
ment panel at a frequency of about one flash per second.

After the self-diagnosis stage, the vehicle security light
flashes at a lower frequency (approximately one flash
every three seconds).

If, after the alarm is switched on, a second acoustic signal
is emitted and/or a visual signal via the vehicle security
light in the instrument panel, wait about four seconds
and switch off the alarm by pushing the lock button,
check that the doors and decklid are closed correctly and
then reactivate the system by pushing the unlock button.

If the alarm emits an acoustic signal even when the doors
and decklid are closed correctly, a system malfunction
has occurred: in this case, contact a dedicated Alfa Romeo
Dealership.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Disarm The System

Deactivation

Push the unlock button.

The following operations are performed:

• Two brief flashes of the direction indicators.
• Unlocking of the doors.

NOTE:

• If the central door locking system is released using the

metal insert of the key, the alarm is not disabled.

• In the event of accidental activation of the alarm, or in

any case to interrupt the acoustic and visual signal
cycle when activated, it is possible to push the unlock
button or turn the ignition key to MAR-ON for at least
five seconds, after which the system will deactivate.

Disarming

To completely disable the alarm (e.g. during a lengthy
period of car inactivity), lock the car by turning the metal
insert of the key in the door lock.

NOTE:

If the batteries of the key fob run out or there is a

fault in the system, the alarm can be switched off by
inserting the key in the ignition switch and turning it to
MAR-ON.

Volumetric/Anti-lift Protection

The Vehicle Security Alarm system monitors the doors
and decklid for unauthorized entry and the ignition
switch for unauthorized operation. The system also in-
cludes an intrusion sensor and vehicle tilt sensor. The
intrusion sensor monitors the vehicle interior for motion.
The vehicle tilt sensor monitors the vehicle for any tilting
actions (tow away, tire removal, ferry transport, etc). A
siren with battery backup which senses interruptions of
power and communications is also included.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

If a perimeter violation triggers the security system, the
siren will sound for 30 seconds and the exterior lights
will flash followed by approximately five seconds of no
activity. This will continue for eight cycles if no action is
taken to disarm the system.

The alarm takes approximately 20 seconds to arm once
the doors are locked with the key fob and once armed,
the LED indicator on the dash will blink whenever the
system is armed. If motion is detected during the arming
period, the motion detection system is disabled.

To ensure the correct operation of the protection, com-
pletely close the side windows. If a perimeter violation
triggers the security system, the siren will sound and the
exterior lights will flash.

To disable the volumetric protection, turn the ignition
key from STOP to MAR-ON twice in a row, then activate
the alarm within 15 seconds, pushing the lock button on

the remote control. When the function is deactivated, this
is indicated by the vehicle security light in the instrument
panel flashing for several seconds.

To disable the anti-lift protection, the ignition key must
be turned from STOP to MAR-ON three times in a row,
followed by activating the alarm within 15 seconds,
pushing the lock button on the remote control.

When the function is deactivated, this is indicated by the
vehicle security light in the instrument panel flashing for
several seconds.

Any disabling of the volumetric/anti-lift protection must
be repeated each time the instrument panel is switched
off.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

ILLUMINATED ENTRY

The interior lights will turn on whenever a door is
opened and the dimmer switch is not in the defeat
position.

The interior lights will turn on, remain on for approxi-
mately 30 seconds, and then fade to off if a door is
opened using the outside door handle and then closed or
a door is unlocked using the vehicles key.

The interior lights will turn on and remain on for about
four seconds and then fade to off if a door is opened
using the inside door handle.

NOTE:

None of the courtesy lights will operate if the

dimmer control is in the “defeat” position (extreme
downward position), unless the overhead map/reading
lights are turned on manually.

REMOTE KEYLESS ENTRY (RKE) — IF
EQUIPPED

This system allows you to lock or unlock the doors and
decklid from distances up to approximately 66 ft (20 m)
using a hand-held Remote Keyless Entry (RKE) transmit-
ter. The RKE transmitter does not need to be pointed at
the vehicle to activate the system.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:

The line of transmission must not be blocked

with metal objects.

To Unlock The Doors

Push and release the UNLOCK button on the RKE
transmitter to unlock the doors. The park lights and turn
signal lights will flash to acknowledge the signal and the
illuminated entry system will turn on.

NOTE:

The Door Unlock Indicator will illuminate in the

instrument panel when one or both doors are unlocked.

To Lock The Doors

Push and release the LOCK button on the RKE transmit-
ter: locking of doors, switching off of internal roof light
and single flashing of direction indicators.

If one or more door are open, the doors will not be
locked. This is indicated by a rapid flashing of the
direction indicators. The doors will be locked if the
decklid is open however.

When a speed of more than 12 mph (20 km/h) is reached,
the doors will be locked automatically if the Autoclose

Key Fob

1 — Vehicle Key
2 — Push To Open/Close Vehicle Key

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

function was selected. Refer to “Electronic Vehicle Infor-
mation Center (EVIC)” in “Understanding Your Instru-
ment Panel” for further information.

When the doors are locked from outside the car (using
the remote control), the door lock indicator will illumi-
nate for a few seconds and then start flashing (deterrent
function).

Transmitter Battery Replacement

NOTE:

Perchlorate Material – special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/perchlorate

The recommended replacement battery is CR2032.

Door LED Lock Indicator

Battery Replacement Procedure

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Replace the Key Fob battery with the following proce-
dure:

1. Push button #1 and move the metal insert #2 to

opening position;

2. Turn screw #3 to unlock using a fine bit screwdriver;

3. Remove battery compartment #4;

4. Replace battery #5, respecting the polarity;

5. Reinsert compartment #4 in the key and secure it by

turning screw #3 to lock.

Key Fob Screw Location

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

General Information

This device complies with Part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:

• This device may not cause harmful interference.
• This device must accept any interference received,

including interference that may cause undesired op-
eration.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

If your RKE transmitter fails to operate from a normal
distance, check for these two conditions:

1. A weak battery in the transmitter. The expected life of

the battery is a minimum of three years.

2. Closeness to a radio transmitter such as a radio station

tower, airport transmitter, and some mobile or CB
radios.

DOOR LOCKS

Central Door Locking/Unlocking

Locking Doors From The Outside

With the doors closed, push the lock button on the key
fob or turn the metal insert (located inside the key fob) in
the door lock.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

The Door Lock LED Indicator button

will illuminate

to indicate that the doors have locked.

NOTE:

Door locking is carried out with all doors shut.

Unlocking Doors From The Outside

Push the unlock button on the key or turn the metal
insert (located inside the key) in the driver side door lock.

WARNING!

• For personal security and safety in the event of a

collision, lock the vehicle doors before you drive as
well as when you park and leave the vehicle.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle. Allowing children to
be in a vehicle unattended is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Children should be
warned not to touch the parking brake, brake pedal
or the transmission gear selector.

• Do not leave the Key Fob in or near the vehicle, or

in a location accessible to children. A child could
operate power windows, other controls, or move
the vehicle.

Door Lock LED Indicator

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Locking/Unlocking Doors From The Inside

Push the Lock LED Indicator button

. The button has

an LED that indicates whether the doors are locked or
unlocked.

Pushing the Lock LED Indicator button

again cen-

trally unlocks all doors and switches off the LED.

Pushing the Lock LED Indicator button

again cen-

trally locks all the doors. The doors will be locked only
if all the doors are properly shut.

Once the doors have been locked using the remote
control or the key, it will no longer be possible to unlock
them by pushing the Lock LED Indicator button

NOTE:

In the absence of electrical power supply (blown

fuse, battery disconnected, etc.) it is still possible to lock
the doors manually.

Emergency Door Locking Device

Passenger Side Door

The passenger side door has a device to lock it when
there is no current.

To lock it, place the metal insert of the ignition key in
housing #1 and turn it clockwise.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To restore the starting condition of the door locks (only if
battery charge restored), proceed as follows:

• Push the Unlock button on the remote control;
• Push the door locking/unlocking LED indicator but-

ton

on the dashboard; or

• Introduce the metal insert of the ignition key in the

front door pawl; or

• Pull the internal door handle.

Door Opening/Closing Mechanism Reset

If the battery is disconnected or the protection fuse
blows, the door opening/closing mechanism must be
reset as follows:

1. Close all the doors.

2. Push the unlock button on the key or the door

locking/unlocking LED indicator button

on the

dashboard.

3. Push the lock button on the key or the door locking/

unlocking LED indicator button

on the dash-

board.

Emergency Door Lock Function

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WINDOWS

Power Windows

NOTE:

• These operate when the ignition key is turned to

MAR-ON and for about three minutes after the igni-
tion key is turned to STOP or removed unless one of
the doors is opened.

• The buttons are located on the center console.

Push the corresponding buttons to open/close the de-
sired window.

Power Window Switch

1 — Driver Power Window Switch
2 — Passenger Power Window Switch

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

When one of the two buttons is pushed briefly, the
window moves in stages; if the button is held down to
open,

⬙continuous automatic⬙ operation is activated.

If the button is pushed again the window will stop in its
current position. If the button is pushed for several
seconds, the window lowers automatically (only with
ignition key in MAR-ON position).

Continuous Automatic Operation

This is activated by pushing one of the two buttons for
longer than half a second. The window will stop when it
is fully opened, or when the button is pushed again.

It can be used on both the driver side and passenger side,
only for lowering the window.

Electric Window System Reset

After a break in power supply for the control units
(battery replaced or disconnected or protective fuses for

the electric window control units replaced), the auto-
matic operation of the windows must be restored.

The restoration procedure must be performed as de-
scribed below with the doors closed:

1. Completely open the driver’s door window keeping

the operating button pushed for at least three seconds
after the (lower) end of travel position is reached.

2. Completely raise the driver side window and hold the

button down for at least three seconds once the
(upper) end of travel position has been reached.

3. Proceed in the same way as described in points 1 and

2 for the passenger side door.

4. Make sure that the reset is correct by checking that the

windows work automatically.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!

Improper actuation of the power windows may be
dangerous. Never leave children unattended in a
vehicle, and do not let children play with power
windows. Before and during window operation
make sure no one and no object (including clothing)
is in the path of the moving glass or its mechanism.
Do not leave the key fob in or near the vehicle, or in
a location accessible to children. Occupants, particu-
larly unattended children, can become entrapped by
the windows while operating the power window
switches. Such entrapment may result in serious
injury or death.

DECKLID

NOTE:

During normal car operation, the luggage com-

partment can reach temperatures above 149º F (65° C).
Pay attention when transporting objects that may be
damaged at such temperatures. Do not keep aerosol cans
in the car: danger of explosion. Aerosol cans must not be
exposed to temperatures above 122º F (50° C).

Opening Procedure

With driver side door open, pull lever #1 located at the
point illustrated in the figure.

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Raise the decklid and release supporting rod from its
locking device.

Insert the end of the rod in housing, making sure that the
rod engages in the smallest hole of the retaining clip.
Care must be taken to keep the decklid raised until the
rod is fixed in the correct position.

NOTE:

Maintain a tight grip on the decklid when raising,

in order to prevent any external occurrence (e.g. a gust of
wind) from suddenly opening the decklid to end of
travel. Additionally, in order to prevent any damage to
the car or broken windows, do not force the decklid
beyond the opening position necessary to secure the
supporting rod in the hole of the retaining clip.

Closing Procedure

1. Hold the decklid up with one hand and use the other

to remove rod from housing and reinsert it in its
locking device.

2. Lower the decklid approximately 7.8 inches (20 cm)

from the engine compartment and let it drop. Make

Decklid Release Lever Location

1 — Decklid Release Lever

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Peugeot 4C (2015 year). Instruction - part 2
