110
Instruments and controls
Unlock boot only: Activates or
Language settings
doors when pressing O on the
deactivates unlocking the tailgate
Select Languages.
remote control.
only when pressing
T
on the
Change language by touching the
Door unlock: Boot only: Activates
remote control.
respective entry.
or deactivates unlocking the
tailgate only when pressing
T
8" Colour Info Display
Confirm with G.
on the remote control.
Vehicle settings
Motorised tailgate/door:
Activates or deactivates the
opening or closing of the power
tailgate.
Hands-Free opening: Activates
or deactivates the function.
Safety
Recommended speed display:
Activates or deactivates the
speed limit information by traffic
sign recognition.
Press SET to open settings menu.
Active safety brake: Activates or
deactivates active emergency
Use touch buttons to operate the
Press Í.
braking and the forward collision
display.
Select Vehicle settings.
alert, the alert sensitivity can be
Unit settings
selected.
In the corresponding submenus the
Select System settings.
following settings can be changed:
Mirror adaptation in reverse:
Adjusts the exterior mirrors if
Change units for Distance and fuel
● Vehicle access
reverse gear is engaged to
consumption and Temperature.
Door unlock: Driver only:
facilitate sidewalks visibility.
Confirm with G.
Changes the configuration to
unlock the driver's door only or all
Instruments and controls
111
Driver’s attention warning:
Driving functions
Telematics services
Activates or deactivates the
driver drowsiness system.
Opel Connect
Rear wiper in reverse: Activates
Opel Connect comprises multiple
or deactivates automatic
connected services accessible via
switching on of the rear window
app, online or within the vehicle.
wiper when reverse gear is
engaged.
Note
Opel Connect is not available for all
Driving lighting
markets. For further information,
Directional headlamps: Activates
contact your workshop.
or deactivates the function.
Note
Comfort lighting
Full functionality of Opel Connect is
Guide-me-home lighting:
subject to registration and proper
Press Í.
Activates or deactivates the
activation.
function and adjusts its duration.
Select Driving functions.
Connected services may include live
Welcome lighting: Activates or
In the corresponding submenus the
navigation such as online traffic
deactivates the function and
following settings can be changed:
information and vehicle status and
adjusts its duration.
● Park Assist: Activates advanced
information such as maintenance
Mood lighting: Adjusts the
park assist, a parking maneuver
alerts.
brightness of the ambient
can be selected.
Services accessible within the vehicle
lighting.
● Blind spot sensors: Activates or
also include emergency call and
deactivates side blind spot alert.
breakdown call. These functions are
● Panoramic view system:
automatically activated. Terms and
Activation / deactivation of the
conditions apply.
function.
112
Instruments and controls
Emergency call function and
Note
For information about coverage and
breakdown call function are operated
Establishing an emergency call may
scope of services of the roadside
by the buttons in the overhead
not be possible in areas without
assistance, please refer to the
console.
sufficient network availability or due
Service and warranty booklet.
to hardware damage during an
Status LED in the overhead
accident.
Privacy settings
console
In case of an emergency, press the
Privacy settings of Opel Connect can
Illuminates green and red and
red SOS button for more than
be configured in your vehicle. This will
extinguishes after a short time, when
2 seconds. The LED flashes green to
impact the set of data being sent, e.g.,
the ignition is switched on: the system
confirm that a connection to the
in case a breakdown call is
works properly.
nearest PSAP is being established.
triggered.The emergency call
The LED illuminates steadily as long
function will not be impacted.
Illuminates red: fault in the system.
as the call is active.
Contact a workshop.
Change the privacy settings in the
Pressing the SOS button immediately
vehicle by simultaneously pressing
Flashes red: backup battery needs
a second time will terminate the call.
the . button and the SOS button.
replacement. Contact a workshop.
The LED switches off.
Versions with navigation system:
Emergency call
privacy settings can also be changed
Automatic crash notification
in the system settings menu.
The emergency call function will
In case of an accident with airbag
establish a connection to the nearest
deployment, an automatic
public safety answering point (PSAP).
emergency call is established and an
A minimum set of data including
automatic crash notification will be
vehicle and location information will
transmitted to the next PSAP.
be sent to the PSAP.
Breakdown call
Pressing the . button for more than
2 seconds connects you to a roadside
assistance service provider.
Lighting
113
Entry lighting
122
Lighting
Exterior lighting
Exit lighting
122
Battery discharge protection
122
Light switch
Exterior lighting
113
Light switch
113
Automatic light control
114
High beam
114
Headlight flash
114
Headlight range adjustment
115
Headlights when driving
abroad
115
Daytime running lights
115
LED headlights
115
Hazard warning flashers
118
Turn lights
118
Front fog lights
119
Turn light switch:
Rear fog light
119
AUTO : automatic light control
Parking lights
120
switches automatically
Reversing lights
120
between daytime running
Misted light covers
120
light and headlight
Interior lighting
120
8
: sidelights
Instrument panel illumination
9
: headlights
control
120
Interior lights
121
When switching on the ignition,
Reading lights
121
automatic light control is active.
Sunvisor lights
121
Control indicator 8 3 99.
Lighting features
122
Centre console lighting
122
114
Lighting
Tail lights
Daytime running light 3 115.
Pull to deactivate high beam.
High beam assist 3 115.
Tail lights are illuminated together
Automatic headlight activation
with low / high beam and sidelights.
During poor lighting conditions the
Headlight flash
headlights are switched on.
Automatic light control
Additionally, headlights are switched
on if the windscreen wipers have
been activated for several wipes.
Tunnel detection
When a tunnel is entered, headlights
are switched on immediately.
High beam
Pull to activate the headlight flash.
When the automatic light control
Pull to deactivate high beam.
function is switched on and the
engine is running, the system
switches between daytime running
lights and headlights automatically
depending on the external lighting
conditions and information given by
the wiper system.
Make sure the sensor is not blocked
3 10, 3 39.
Push to switch from low to high beam.
Lighting
115
The system switches between
Headlight range adjustment
Headlights when driving
daytime running lights and low beam
abroad
Manual headlight range
automatically, depending on the
When driving in countries where
lighting conditions.
adjustment
traffic drives on the opposite side of
the road, the headlights have to be
LED headlights
adjusted.
LED headlight system contains a
1. With the engine switched off, pull
variety of particular LEDs in each
the indicator lever and hold.
headlight which enables the control of
2. Start the engine.
the adaptive forward lighting
3. Hold the indicator lever for
functions.
another 5 seconds.
Light distribution and intensity of light
4. Release the indicator lever.
are variably triggered depending on
the lighting conditions, road type and
If the headlights are adjusted, a
driving situation. The vehicle adapts
message is displayed in the Driver
the headlights automatically to the
Information Centre each time the
situation to enable optimal light
To adapt headlight range to the
engine is started.
performance for the driver.
vehicle load to prevent dazzling, turn
To reverse the adjustment of the
thumb wheel ? to required position.
Some adaptive forward lighting
headlights, repeat the steps
functions of the LED headlights can
0 : front seats occupied
described above.
be deactivated or activated in the
1 : all seats occupied
vehicle personalisation menu. Select
2 : all seats occupied and load
Daytime running lights
the relevant setting in Settings I
compartment laden
3 : driver's seat occupied and load
Daytime running lights increase
Vehicle in the Info Display.
compartment laden
visibility of the vehicle during daylight.
Vehicle personalisation 3 108.
They are switched on automatically
The lighting functions are only
when the engine is running.
available with light switch in position
AUTO.
116
Lighting
Country light
allowing distant objects to be
Corner light
recognised across the entire width of
the road.
Town light
Activated automatically at a speed
Activated at a speed of up to 40 km/h
between 55 km/h and 115 km/h when
when turning off. The light consists of
driving in rural areas. The illumination
particular LEDs which illuminate the
of the current lane and the side of the
direction of travel. These LEDs are
Activated automatically at a speed up
road is improved. Oncoming and
triggered depending on the steering
to approx. 55 km/h and in situations
preceding vehicles are not dazzled.
angle or the activation of the turn
with exterior ambient light. The light is
lights.
Motorway light
wide and symmetrical. If the speed is
below 30 km/h, the headlamps are
Adverse weather light
slightly swiveled to the outside to
allow an earlier recognition of of
pedestrians and objects on each side
of the road. A special beam pattern is
designed to avoid glare for other road
users.
Activated automatically at a speed
above 115 km/h. Illumination is
Controlled by wiper or rain sensor.
adapted to the higher speed driven on
The wide light distribution - slightly
motorways. If there is no oncoming
swiveled to the outside - enables
traffic, the visibility on the side of the
improved orientation at the edge of
vehicle is increased. The visibility
the road. The intensity of the light in
range raises from 70 m to 140 m
the far distance is increased in order
Lighting
117
to recognise objects and markings on
The camera in the windscreen
Activation
the front passenger road side and
detects the lights of oncoming or
obstacles on the lane despite the
preceding vehicles. Each LED on
weather condition. By lowering the
right or left side can be triggered or
reflection on wet roads the oncoming
faded out particularly according to the
traffic is less dazzled. Adverse
traffic situation. This gives the best
weather light is activated up to a
light distribution without dazzling
speed to 70 km/h.
other road users. Once activated,
high beam assist remains active and
Curve light
switches high beam on and off
depending on surrounding
conditions. The latest setting of the
high beam assist will remain after the
ignition is switched on again.
Activate the high beam assist by
pressing f. The LED of the button
illuminates if the high beam assist is
Particular LEDs, based on steering
activated. High beam is switched on
angle and speed, are additionally
automatically at a speed above
triggered to improve lighting in
25 km/h. High beam is switched off at
curves. This function is activated at
a speed below 15 km/h, but high
speeds from 40 km/h to 70 km/h.
High beam assist includes a special
beam assist remains active.
motorway mode. When driving faster
The green control indicator f
High beam assist
than 115 km/h on motorways, the light
illuminates continuously when the
This feature activates the high beam
beam becomes smaller to avoid
high beam assist is activated, the blue
at night when the vehicle speed is
dazzling of oncoming traffic. When
7 illuminates when high beam is on.
faster than 25 km/h.
following vehicles ahead or passing,
Control indicator f 3 100, 7
dazzling for these vehicles is
3 100.
reduced.
118
Lighting
Pushing left indicator lever once
Fault in LED headlight system
force of deceleration. They are
switches on manual high beam
switched off automatically the first
When the system detects a failure in
without high beam assist.
time you accelerate.
the LED headlight system, it selects a
High beam assist switches
preset position to avoid dazzling of
automatically to low beam when:
Turn lights
oncoming traffic. A warning is
● Driving in urban areas.
displayed in the Driver Information
● Camera detects heavy fog.
Centre.
● Front or rear fog lights are
switched on.
Hazard warning flashers
If there are no restrictions detected,
the system switches back to high
beam.
Deactivation
Deactivate the high beam assist by
pressing f.
If a headlight flash is activated when
the high beam assist is activated and
up
: right turn lights
low beam is on, the high beam assist
down : left turn lights
will be deactivated. The system
A resistance point can be felt when
changes to high beam.
moving the indicator lever.
If a headlight flash is activated when
Operated by pressing ¨.
Constant flashing is activated when
the high beam assist is activated and
When braking in an emergency, the
the indicator lever is being moved
high beam is on, the high beam assist
hazard warning flashers are switched
beyond the resistance point. It is
will be deactivated. The system
on automatically depending on the
deactivated when the steering wheel
changes to low beam.
To reactivate the high beam assist,
flash the headlights again.
Lighting
119
is moved in the opposite direction or
Front fog lights
Rear fog light
indicator lever is manually moved
back to its neutral position.
Activate temporary flashing by
holding the indicator lever just before
the resistance point. Turn lights will
flash until indicator lever is being
released.
To activate three flashes, tap the
indicator lever briefly without passing
the resistance point.
If you forget to cancel the turn lights
for more than 20 seconds, the volume
of the audible signal will increase if
Operated by pressing >.
Operated by pressing r.
the speed is above 60 km/h.
Light switch in position AUTO:
Light switch in position AUTO:
switching on front fog lights will switch
switching on rear fog light will switch
headlights on automatically.
headlights on automatically.
Light switch in position 8: rear fog
light can only be switched on with
front fog lights.
The vehicle rear fog light is
deactivated when towing a trailer or a
plug is connected with the socket,
e.g. when a bicycle carrier is used.
120
Lighting
Parking lights
Reversing lights
Interior lighting
The reversing light comes on when
the ignition is on and reverse gear is
Instrument panel
selected.
illumination control
Misted light covers
The inside of the light housing may
mist up briefly in poor, wet and cold
weather conditions, in heavy rain or
after washing. The mist disappears
quickly by itself. To help, switch on the
headlights.
When the vehicle is parked, the
parking lights on one side can be
activated:
1. Switch off ignition.
Brightness of the following lights can
2. Move the lever all the way up
be adjusted when the exterior lights
(right parking lights) or down (left
are on:
parking lights).
● instrument panel illumination
Confirmed by a signal and the
● Info Display
corresponding turn lights control
● illuminated switches and
indicator.
operation elements
Turn thumb wheel A and hold until
the desired brightness is obtained.
Lighting
121
Interior lights
Rear courtesy lights
During entry and exit of the vehicle,
Illuminate in conjunction with the front
the front and rear courtesy lights
courtesy light.
automatically switch on and then off
after a delay.
Reading lights
Note
In the event of an accident with
airbag deployment the courtesy
lights are turned on automatically.
Front courtesy light
Illustration shows rear courtesy lights.
Sunvisor lights
Illuminates when the cover is opened.
Operated by pressing s and t in the
courtesy lights.
w
: automatic switching on
and off
press u : on
press v
: off
122
Lighting
This function can be activated or
Lighting features
deactivated in the vehicle
personalisation.
Centre console lighting
Vehicle personalisation 3 108.
A spotlight integrated in the overhead
console illuminates the centre
The following lights will additionally
console when headlights are
switch on when the driver's door is
switched on.
opened:
● illumination of some switches
Entry lighting
● Driver Information Centre
● door pocket lights
Welcome lighting
Some or all of the following lights are
Exit lighting
switched on for a short time by
The following lights are switched on
unlocking the vehicle with the radio
when the ignition is switched off:
remote control:
● headlights
● headlights
● interior lights
● puddle lights
● centre console lighting
● interior lights
They will switch off automatically after
The number of activated lights
a delay. This function works only in
depends on the surrounding light
the dark.
conditions.
The lighting switches off immediately
when the ignition is switched on.
Battery discharge protection
Starting off 3 18.
To prevent discharge of the vehicle
battery when the ignition is switched
off, some interior lights are switched
off automatically after some time.
Climate control
123
Heated exterior mirrors b 3 38.
Climate control
Climate control systems
Heated seats ß 3 51.
Heating and ventilation
Temperature
system
Climate control systems
123
Adjust the temperature by turning
Heating and ventilation system 123
£
to the desired temperature.
Air conditioning system
124
Electronic climate control
red area
: warmer
system
127
blue area : colder
Auxiliary heater
131
Heating will not be fully effective until
Parking heater
131
the engine has reached normal
Air vents
132
operating temperature.
Adjustable air vents
132
Fixed air vents
133
Air distribution
Glovebox cooler
133
l : to windscreen and front door
Maintenance
133
windows
Air intake
133
M : to head area via adjustable air
Air conditioning regular
Controls for:
vents
operation
133
● temperature
£
K : to foot well and windscreen
Service
133
● air distribution l, M and K
All combinations are possible.
● fan speed Z
Fan speed
● demisting and defrosting à
Adjust the air flow by turning Z to the
● heated rear window and exterior
desired speed.
mirrors b
clockwise
: increase
● heated seats ß
anticlockwise : decrease
Heated rear window b 3 41.
124
Climate control
Demisting and defrosting
Heated exterior mirrors b3 38.
Air conditioning system
Heated windscreen , 3 42.
Heated seats ß 3 51.
● Press à: the air distribution is
Controls for:
directed towards the windscreen.
● temperature
£
● Set temperature controller
£
to
Some setting changes are indicated
● air distribution l, M and K
warmest level.
briefly in the Info Display. Activated
● fan speed Z
● Set fan speed Z to highest level.
functions are indicated by the LED in
● demisting and defrosting à
the respective button.
● Switch on heated rear window b.
● cooling A/C
● Open side air vents as required
Temperature
and direct them towards the door
● air recirculation
4
Adjust the temperature by turning
windows.
● heated rear window and exterior
£
to the desired temperature.
Heated rear window, windscreen and
mirrors b
red area
: warmer
exterior mirrors b 3 41.
● heated windscreen ,
blue area : colder
Heated seats ß 3 51.
● heated seats ß
Heated rear windowb3 41.
Climate control
125
Heating will not be fully effective until
Cooling A/C
Activated cooling may inhibit
the engine has reached normal
Autostops.
operating temperature.
Stop-start system 3 139.
Air distribution
Air recirculation system
l : to windscreen and front door
windows
M : to head area via adjustable air
vents
K : to foot well and windscreen
All combinations are possible.
Fan speed
Adjust the air flow by turning Z to the
Press A/C to switch on cooling. The
desired speed.
LED in the button illuminates to
indicate activation. Cooling is only
clockwise
: increase
functional when the engine is running
anticlockwise : decrease
and fan is switched on.
Press
4
to activate air recirculation
mode. The LED in the button
Press A/C again to switch off cooling.
illuminates to indicate activation.
The air conditioning system cools and
Press
4
again to deactivate air
dehumidifies (dries) as soon as the
recirculation mode.
outside temperature is slightly above
the freezing point. Therefore,
condensation may form and drip from
9 Warning
under the vehicle.
The exchange of fresh air is
If no cooling or drying is required,
reduced in air recirculation mode.
switch off the cooling system for fuel
In operation without cooling the air
saving reasons.
126
Climate control
● Switch on cooling A/C.
● Press à: the air distribution is
humidity increases, so the
directed towards the windscreen.
windows may mist up from inside.
● Press
4
for air recirculation
The quality of the passenger
system on.
● Set temperature controller
£
to
compartment air deteriorates,
● Press M for air distribution.
warmest level.
which may cause the vehicle
● Set temperature control
£
to
● Switch on cooling A/C, if
occupants to feel drowsy.
required.
coldest level.
● Set fan speed Z to highest level.
In warm and very humid ambient air
● Set fan speed Z to highest level.
conditions, the windscreen may mist
● Switch on heated rear window b.
● Open all vents.
up from outside when cold air is
● Switch on heated
Heated rear window, windscreen and
directed towards it. If windscreen
windscreen ,.
exterior mirrors b 3 41.
mists up from outside, activate
Heated seats ß 3 51.
● Open side air vents as required
windscreen wiper and deactivate l.
and direct them towards the door
Maximum cooling
Demisting and defrosting the
windows.
windows
Note
If à is pressed while the engine is
running, an Autostop will be inhibited
until à is pressed again.
If à is pressed while the engine is in
an Autostop, the engine will restart
automatically.
Stop-start system 3 139.
Briefly open the windows so that hot
air can disperse quickly.
Climate control
127
● temperature on front passenger
Climate control settings menu
Electronic climate control
side
£
system
● cooling A/C
The dual zone climate control allows
● manual air recirculation
4
different temperatures for driver side
and front passenger side.
● demisting and defrosting à
In automatic mode, temperature, fan
● heated rear window and exterior
speed and air distribution are
mirrors b
regulated automatically.
● heated windscreen ,
● heated seats ß
● ventilated seats A
Heated rear window Ü 3 41.
Heated exterior mirrors Ü 3 38.
Press MENU to manually set the
Heated seats ß 3 51.
following climate control functions:
Ventilated seats A 3 51.
● air distribution l, M, K
Activated functions are indicated by
● fan speed Z
the LED in the respective control.
● temperature for driver and
The electronic climate control system
passenger side
is only fully operational when the
● dual zone temperature
Controls for:
engine is running.
synchronisation MONO
● temperature on driver side
£
Make sure the sun sensor used by the
● cooling A/C
electronic climate control system is
● MENU enters the Climate setting
● automatic mode AUTO
not covered 3 10.
menu in the Info Display
● fan speed Z
● automatic mode AUTO
128
Climate control
Climate setting menu can also be
● Air conditioning must be
Adjust the air flow by turning rotary
displayed:
activated for optimal cooling and
ring to the desired speed. Turn
demisting. Press A/C to switch on
anticlockwise to decrease or turn
● by selecting Climate on the
air conditioning. The LED in the
clockwise to increase. Fan speed can
7'' Colour Info Display or
button indicates activation.
also be changed in the climate
● by pressing Í and then selecting
settings menu. Press MENU to enter
● Set the preselected
Climate from the menu on the
the menu.
temperatures for driver and front
8'' Colour Info Display.
passenger using the left and right
Turn rotary ring anticlockwise as far
Automatic mode AUTO
rotary ring. Recommended
as it will go: fan and cooling are
temperature is 22 °C.
switched off.
To return to automatic mode, press
Manual settings
AUTO.
Climate control system settings can
Air distribution l, M, K
be changed by activating the
following functions:
Fan speed Z
Basic setting for maximum comfort:
● Press AUTO, the air distribution
and fan speed are regulated
automatically.
● Open all air vents to allow
Press MENU to enter the menu.
optimised air distribution in
automatic mode.
Climate control
129
Touch in the Colour Info Display:
changes the temperature of the
Dual zone temperature
passenger side. The rotary ring on the
synchronisation MONO or SYNC
l : to windscreen and front door
driver's side changes the temperature
Press MENU to enter the menu.
windows
of the driver's side or of both sides,
Touch MONO or SYNC to link
M : to head area and rear seats via
depending on activation of
passenger side temperature setting
adjustable air vents
synchronisation MONO in the climate
to the driver side.
K : to front and rear foot well and
settings menu. Press MENU to enter
windscreen
When passenger side control dial will
the menu.
be adjusted, synchronisation is
To return to automatic air distribution,
Recommended temperature is 22 °C.
deactivated.
press AUTO.
Temperature is indicated in displays
beside the rotary rings and in the
Air conditioning A/C
Temperature preselection
£
climate settings menu.
If the minimum temperature Lo is set,
the climate control system runs at
maximum cooling, if cooling A/C is
switched on.
If the maximum temperature Hi is set,
the climate control system runs at
maximum heating.
Note
If A/C is switched on, reducing the
set cabin temperature can cause the
engine to restart from an Autostop or
inhibit an Autostop.
Press A/C to switch on cooling. The
Set the preselected temperatures
LED in the button illuminates to
separately for the driver and the front
Stop-start system 3 139.
indicate activation. Cooling is only
passenger to the desired value using
functional when the engine is running
the left and right rotary ring. The
and climate control fan is switched on.
rotary ring on the passenger side
130
Climate control
Press A/C again to switch off cooling.
Press
4
again to deactivate
Demisting and defrosting the
recirculation mode.
windows à
The air conditioning system cools and
dehumidifies (dries) when outside
temperature is above a specific level.
9 Warning
Therefore condensation may form
and drip from under the vehicle.
The exchange of fresh air is
reduced in air recirculation mode.
If no cooling or drying is required,
In operation without cooling, the
switch off the cooling system for fuel
air humidity increases, so the
saving reasons.
windows may mist up from inside.
The quality of the passenger
Manual air recirculation
4
compartment air deteriorates,
which may cause the occupants to
feel drowsy.
In warm and very humid ambient air
● Press à. The LED in the button
conditions, the windscreen may mist
illuminates to indicate activation.
up from outside, when cold air is
● Temperature and air distribution
directed towards it. If windscreen
are set automatically and the fan
mists up from outside, activate
runs at high speed.
windscreen wiper and deactivate l.
● Switch on air conditioning by
pressing A/C, if required.
● Switch on heated rear window b.
Press
4
to activate the air
● Switch on heated
recirculation mode. The LED in the
windscreen ,.
button illuminates to indicate
● To return to previous mode,
activation.
press à again. To return to
automatic mode, press AUTO.















Content      ..     4      5      6      7     ..
