Infotainment system

Basic operation

Screen operations

The display of the Infotainment

system has a touch-sensitive surface

that allows direct interaction with the

displayed menu controls.


Do not use pointed or hard items

like ballpoint pens, pencils or

similar for touch screen operation.

Use the following finger gestures to

control the Infotainment system.


Touch is used to select an icon or

option, activate an application, or

change the location inside a map.

Touch and hold

Touch and hold can be used to move

an application and to save radio

stations on the preset buttons.


Infotainment system



Drag is used to move applications on

the home page or to pan the map. To

drag an item, it must be held and

moved along the display to the new

location. This can be done up, down,

right, or left.


Nudge is used to move items a short

distance on a list or map. To nudge,

hold and move the selected item up

or down to a new location.

Fling or swipe

Fling or swipe is used to scroll through

a list, pan the map, or change page

views. Do this by placing a finger on

the display and moving it rapidly up

and down or right and left.

Returning to the previous menu

To return to the previous menu, touch



Returning to the main screen of

current application

To return to the main screen of the

current application, touch &.



Infotainment system

Returning to the homescreen

To return to the homescreen,

touch ;.

Wi-Fi connection

The Infotainment system can be

connected to a Wi-Fi network, e.g. the

hotspot of a mobile phone, or activate

an own Wi-Fi hotspot if OnStar is


Connecting to a Wi-Fi network

To connect to a Wi-Fi network, go to

the homescreen and select Settings.

Then go to the System tab and select

Wi-Fi Networks.
A list of all available Wi-Fi networks is

displayed. After choosing a Wi-Fi

network, it might be necessary to log

in by entering a corresponding

password on the Info Display. In this

case, a corresponding window will

pop up.

Activating the Wi-Fi hotspot

If OnStar is available, a Wi-Fi hotspot

can be activated. There are two ways

to go to the Wi-Fi hotspot menu:

● Go to the homescreen and select

the Wi-Fi Hotspot icon.

● Go to the homescreen and select

Settings. Then go to the System

tab and select Wi-Fi Hotspot.

In the Wi-Fi Hotspot menu, the Wi-Fi

hotspot can be activated or

deactivated and the name and the

password of the Wi-Fi hotspot can be

changed. Also the connected devices

are indicated.

System settings

To go to the system settings menu, go

to the homescreen and select

Settings. The settings are divided into

System and Apps.
The following settings can be

changed under System:

● Time/Date
● Language
● Phones: Display connected / not

connected phones or add a


● Wi-Fi Networks: Connect to an

available Wi-Fi network.

● Wi-Fi Hotspot: Activate /

deactivate Wi-Fi services and

display name, password and

connected devices.

● Display: Select display mode,

calibrate touchscreen and turn

display off.

● Privacy: Activate / deactivate

location services and data


● Sounds: Set maximum startup

volume, activate / deactivate

audio cues and audible touch


● Voice: Set prompt lenght, audio

feedback speed and activate /

deactivate tutorial mode.

● Favourites: Manage favourites

and set number of audio


● About: Display information about

open soure software and device



Infotainment system


● Running Applications: Stop

applications, e.g. Climate or


● Restore Factory Settings: Reset

vehicle settings, delete settings

and personal data and clear

default applications

The following settings can be

changed under Apps:

● Android Auto: Activate /

deactivate the Android Auto


● Apple CarPlay: Activate /

deactivate the Apple CarPlay


● Audio (options depend on current

audio source): Change the tone

settings, auto volume, activate /

deactivate traffic programme,

DAB-FM linking, DAB

announcements, etc.

● Navigation: Change the

navigation settings.

● Phone: Sort contacts, re-

synchronise contacts, delete all

vehicle contacts, etc.


This application is only applicable to

Multimedia Navi Pro.
Touch Users on the homescreen to

display a list of all available profiles:
Due to the option of creating profiles,

the Infotainment system can be fitted

to several drivers. Different settings

as well as favourite radio stations and

destinations will be connected to a

specific profile. Thereby, the settings

and favourites don't need to be

adjusted every time another person is

driving the vehicle.
A profile can be connected to a

specific vehicle key. While unlocking

the vehicle, the corresponding profile

will be activated, if available.

Creating a profile

1. Select Users on the homescreen.
2. Select Add User Profile.
3. Select Create Profile.
4. Enter a profile name and select


5. If desired, choose a profile picture

and select Next. Otherwise, select


6. If desired, choose a vehicle key

which is intended to be connected

to the profile and select Next.

Otherwise, select Skip.

7. Select Done.

A new profile is created. The settings

of the profile can be changed at any



Whenever a new profile is created or

the active profile is switched, the

audio application is paused and


Creating a PIN for a profile

Every profile can be secured with a

PIN. After switching on the vehicle,

the PIN has to be entered.
To create a PIN, go to the

homescreen and select Settings, go

to the Personal tab and select




Infotainment system

Switching the profile

There are two ways to switch the


● Select Users on the homescreen

and select the desired profile.

● Only if the Guest profile is not

active: Select Settings on the

homescreen, go to Personal and

select Switch User. Select the

desired profile.

Editing a profile

Only the currently active profile can

be edited. There are two ways to edit

a profile:

● Select Users on the homescreen

and select / next to the profile.

● Select Settings on the

homescreen and go to the

Personal tab.

All profile settings, e.g. name, profile

picture, connected vehicle key, can

be changed.

Deleting a profiles

To delete a profile, select f next to the

corresponding profile. The Guest

profile cannot be deleted.
The Guest profile is a default profile.

It is active when no other profile is

created or active.



Hold to


: Preset button. Hold to save

active radio station as a



: Display further preset



: Adjust the sound settings.


: Display station list / folders.


: Touch to go to the next

station / song or touch and

hold for fast forwarding.


: Enter a frequency.


: Touch to go to the previous

station / song or touch and

hold for rewinding.


: (Multimedia Navi Pro)

Select the audio source.


: (Multimedia) Select the

audio source.


Touch : and select the desired audio

The last three selected sources are

indicated above : on the screen. If

one of the last three selected audio


Infotainment system


sources is an external device, it will

still be indicated although the device

is not connected anymore.
When an external device will be

connected, the Infotainment system

doesn't automatically switch to the

external device. The external device

needs to be selected as an audio

source. When the external device will

be disconnected, another audio

source needs to be selected.

External devices

Two USB ports for the connection of

external devices are located below

the foldable armrest.
When an external audio source (via

USB or Bluetooth) is connected and

selected as audio source, the

following additional symbols will be

displayed on the audio screen:

 or l : Interrupt or resume



: Play tracks in random


Audio files

The playable audio file formats are


FLAC, MP3, Vorbis, PCM/WAVE,


Saving favourites

There are two ways to save a radio

station as a favourite:

● Touch and hold one of the preset

buttons until a corresponding

message is displayed. The

currently active radio station is

now saved as a favourite and can

be tuned in by touching the

respective preset button.

● Touch a and then the ; symbol

next to the corresponding radio

station. The radio station is saved

as a favourite when the ; symbol

is green.

Traffic programme

Traffic programme is a service of FM

radio stations. When traffic

programme is activated, the currently

playing audio source will be

interrupted when an FM radio station

is broadcasting traffic news. The

audio source will be switched back

when the traffic news are over. During

the broadcast of traffic news, the

volume will be increased.
There are two ways to activate or

deactivate traffic programme:

● Go to the homescreen, select

Settings and go to Apps. Traffic

programme can be activated or

deactivated in the Audio menu.

● When FM is the active audio

source, there is a TP button on

the audio screen. By touching

TP, traffic programme will be

activated or deactivated. A yellow

line indicates that traffic

programme is activated.

DAB announcements

DAB announcements are a service of

DAB radio stations. DAB

announcements are divided into

different categories like traffic, news,

weather, etc.
To activate or deactivate DAB

announcements, go to the

homescreen, select Settings, go to

Apps and select the Audio menu. The

different DAB announcement



Infotainment system

categories can be activated or

deactivated under DAB



The volume will not increase during

DAB announcements.

DAB-DAB linking

If this function is activated, the device

switches over to the same service

(programme) on another DAB

ensemble (if available) when the DAB

signal is too weak to be picked up by

the receiver.
To activate or deactivate DAB-DAB

linking, go to the homescreen, select

Settings, go to the Apps tab and

activate or deactivate the function in

the Audio menu.

DAB-FM linking

This function enables switching from

a DAB station to a corresponding FM

station and vice versa.
If this function is activated, the device

switches over to a corresponding FM

station of the active DAB service (if

available) when the DAB signal is too

weak to be picked up by the receiver.

To activate or deactivate DAB-FM

linking, go to the homescreen, select

Settings, go to the Apps tab and

activate or deactivate the function in

the Audio menu.

Adjusting the sound settings

To adjust the sound settings, touch

. The following settings can be


● Equalizer
● Fade / Balance


Navigation system

This application is only applicable to

Multimedia Navi Pro.
For each profile, the terms and

conditions and a privacy statement of

the navigation function need to be

accepted when starting the

navigation application for the first

time. After a short introduction about

the connected navigation feature,

also a privacy statement of the

predictive navigation function needs

to be accepted.


Infotainment system




: Enter an address or keyword.


: Store address as a favourite.


: Display recent addresses.


: Close the address bar.

+ : Zoom in.

– : Zoom out.

: Go to the Options menu.


: Display traffic information list

(netwerk connection


N | Mainzer Straße: Touch to display

additional information about the

current location.

Navigation options

The following settings are adjustable

in the Options menu %:

● Map view
● Activate / deactivate traffic on

map and automatic rerouting

● Select which points of interests

are shown on the map

● Select the routing options and the

map colours, look for map

updates, change home and work

address, etc.

● Indicate routes that should be


● Edit destinations

Starting a route guidance

1. To start a route guidance, touch



2. Enter an address, choose a

favourite or choose a point of

Points of interest are sorted by

different categories (fuel, parking,

food, etc.).

3. Touch Go and the route guidance

is started.
Different routes can also be

displayed before touching Go.

Active route guidance

The following actions are possible

during an active route guidance:

● Toggling between time of arrival,

remaining distance and

remaining travel time by touching

the time and distance information

on the screen.

● Muting the voice prompts by

touching ?.

● Displaying detailed information

on upcoming navigation

manoeuvres by touching the

green navigation bar.
Voice prompts can be replayed

and single navigation



Infotainment system

manoeuvres can be deleted by

touching /. The route will be


Stopping a route guidance

To stop an active route guidance,

touch & next to the green navigation


Connected navigation

The connected navigation function

includes live traffic information,

personalised search and routing,

predictive navigation as well as

parking and fuel price information.

Live traffic

The connected navigation function

indicates real-time traffic information

like traffic jams and road works. To

display the traffic information list,

touch 7 on the navigation screen.

Traffic information along the route

and nearby will be displayed as a list.

On the navigation screen, road works

will be indicated by road signs and

traffic density will be indicated by

orange and red roads. Traffic density

will also be indicated when the traffic

information list is empty due to no

incidents like road works or accidents.


Using the connected navigation

function consumes OnStar data or

mobile data. Additional costs could


Network connection

To use the connected navigation

function, a network connection is

necessary. OnStar or a mobile

hotspot, e.g. mobile phone, can be

When connected to a hotspot, the Wi-

Fi symbol will appear in the bottom

bar. If a mobile phone is connected

via Bluetooth, the Wi-Fi symbol will

only appear for a few seconds but the

Wi-Fi symbol will appear in the

extended status view.
Connected navigation will be

indicated by the word LIVE on the

traffic symbol 7 on the navigation



When no traffic information are

available although LIVE is indicated

on the traffic symbol 7, the network

connection might be interrupted.

Wait some minutes until the network

connection is built up again.

Personalised search and routing

The connected navigation function

includes personalised search and

routing. The system learns the

driver's pattern and suggests routes

and points of interest that fit the

driver's individual needs and


Predictive navigation

Predictive navigation is a

personalised and increasingly useful

function that detects common

destinations like home and work.

Additionally, the predictive navigation

function understands the driver's

patterns and uses historical driving

and traffic data to predict usual traffic



Infotainment system


The predictive navigation function

can be activated or deactivated in the

Settings menu. To go to the Settings

menu, go to the Options menu % on

the navigation screen and select


Parking information and fuel


The connected navigation function

indicates parking and fuel price

information. When the vehicle is

reaching a densely populated

destination, and if the system

determines that parking may be

limited then it will attempt to display

nearby parking destinations with price

information if available. The function

also indicates real-time fuel prices if

To display the parking and fuel prices

as well as opening hours and

telephone numbers, if available,

touch the point of interest on the map

or see the results of the points of

interest search.

Online map updates

The navigation map can be updated

when a new version is available. The

updates are also based on the driver's

driving patterns by considering

updates of typically driven places.
To update the navigation map, a

network connection is necessary.

Whether the map content is up to

date, is indicated in the Settings menu

in the Options menu %. If desired,

automatic map updates can be

activated. Additionally, a message

will be displayed if the update

exceeds 250 MB.

Speech recognition

General information

Embedded speech recognition

This application is only applicable to

Multimedia Navi Pro.
The embedded speech recognition of

the Infotainment system enables

operation of various functions of the

Infotainment system via voice input. It

recognises commands and numeric

sequences. The commands and

numeric sequences can be spoken

without a voice pause between the

individual words.
In the event of incorrect operation or

commands, the speech recognition

gives visual and / or acoustic

feedback and requests to re-enter the

desired command. Apart from this,

the speech recognition

acknowledges important commands

and will enquire if necessary.
In general, there are different ways to

speak commands for performing the

desired actions.



Infotainment system


To ensure that conversations inside

the vehicle do not lead to

unintentional triggering of the

system functions, the speech

recognition does not start until it has

been activated.
The system can only be operated by

the driver.

Important information

Language support

● Not all languages available for

the Info Display are also

available for the speech


● If the display language currently

selected is not supported by the

speech recognition, speech

recognition is not available.
In such a case, selecting another

language is necessary to control

the Infotainment system via voice


Address input of destination

Address input is only possible in the

language of the country of your


E.g., for entering an address in

France, the display and the speech

recognition must be set to French.


For a multilingual country, several

languages can be used.
E.g. French, German or Italian can

be used for Switzerland.

Input order for destination addresses

The order in which the parts of an

address need to be entered using the

speech recognition system is

dependent on the country where the

destination is located.


The system only works with

complete addresses. The city and

the street need to be entered.

Setting up speech recognition

Several settings and adaptions for the

embedded speech recognition of the

Infotainment system can be

performed, such as the frequency of

command confirmations by the user

or the level of detailed feedback given

by the system.

To set up speech recognition, select

Settings on the homescreen and then

System I Voice.

Prompt Length

The prompt length can be set to either

Informative, Short or Auto. When set

to Auto, the system provides more

detailed feedback in the beginning of

its first usage. The system adjusts

automatically to your speech habits.

The more familiar you are with the

system, the less detailed feedback is

given by the system.
To set up the prompt length, select

Settings on the homescreen and then

System I Voice I Prompt Length.

Voice pass-thru application

The voice pass-thru application of the

Infotainment system allows access to

the speech recognition commands on

a smartphone.
To activate the speech recognition on

a smartphone, press and hold w on

the steering wheel when phone

projection is active.


Infotainment system


The availability of this function

depends on the smartphone. For

more information on compatibility,

see our website.


Activating speech recognition


Speech recognition is not available

during an active phone call.

1. Press w on the steering wheel.

The audio system mutes, a voice

output message prompts you to

say a command, and help menus

with the most important

commands currently available are

shown on the Info Display. It is

highly recommended to follow the

wording suggestions of the

Do not talk when the speech

recognition symbol is red and no

beep sound has been heard.

2. As soon as the speech

recognition is ready for voice

input, a beep is heard. The

speech recognition symbol

changes to green.

3. Start now with a voice command

to initiate a system function (e.g.

playing a preset radio station).

Adjusting the volume of voice


Turn ) on the control panel or press


 or Á on the steering wheel

upwards or downwards during a voice


Interrupting a voice prompt

A voice prompt can be interrupted by

briefly pressing w on the steering

A beep is heard immediately, the

speech recognition symbol changes

to green, and a command can be

stated without having to wait.

Cancelling a dialogue sequence

There are various ways to cancel a

dialogue sequence and to deactivate

the speech recognition:

● Say "Cancel".
● Press n on the steering wheel.
● Press ; on the control panel.
● Select & or < in the help menu.

In the following situations, a dialogue

sequence is automatically cancelled:

● If you do not say any command

for a certain period of time.

● If you say commands that are not

recognised by the system.

Operation via speech commands

The speech recognition can

understand direct commands stating

the application and the action.
For best results:

● Listen for the voice prompt and

wait for the beep or the green

speech recognition symbol

before saying a command or




Infotainment system

● Say "Help" or read the example

commands on the screen.

● The voice prompt can be

interrupted by pressing w again.

● Wait for the beep and the green

speech recognition symbol then

speak the command naturally,

not too fast, not too slow. Use

short and direct commands.


If the system provides several

suggestions, the selection is to be

done manually and the speech

recognition symbol flashes red and

green when scrolling the list.

In case of complex commands or

when information is missing, the

system starts a dialogue sequence.
When searching for a "Point of

Interest", only major chains may be

selected by name. Chains are

businesses with at least 20 locations.

For other POIs, say the name of a

category, e.g. "Restaurants",

"Shopping centres", or "Hospitals".

Help command

After saying "Help", the help prompt

for the current screen is read aloud.

Additionally, the prompt is displayed

on the screen.
To interrupt the help prompt, press w.

A beep is heard. A command can be

said again.

Voice pass-thru application

Activating speech recognition

Press and hold s on the steering

wheel until a speech recognition icon

is displayed.

Adjusting the volume of voice


Turn ) on the control panel or press


 or Á on the steering wheel

upwards or downwards during a voice


Deactivating speech recognition

Press n on the steering wheel. The

speech recognition session is ended.


General information

Not every mobile phone fully supports

the phone function. Therefore,

deviations from the range of functions

described below are possible.

Phone main menu

● Favourites: List of favourite


● Keypad: Phone numbers can be

entered and dialed.

● Recent: List of recent phone


● Contacts: List of contacts.
● Phones: Overview of connected

and disconnected phones.


Infotainment system


Bluetooth connection

Pairing a phone

To pair a mobile phone, proceed as


1. Enable Bluetooth on the mobile

phone and ensure it is visible for

other devices.

2. In the phone menu on the Info

Display, select the Phones tab.

3. If no phone is paired yet, touch

Connect Phone.

4. Touch Add Phone.
5. Select the Infotainment system

from the Bluetooth device list on

the mobile phone.

6. Compare and confirm the shown

code on the mobile phone and on

the Info Display. Touch Pair on the

Info Display.
Some mobile phones require

access to certain phone features,

follow the instructions.

Once the mobile phone is

successfully paired, it will be

connected automatically and shown

as Connected.


If several paired mobile phones enter

the range of the system at the same


● only the phone first detected by

the system will be connected

automatically or

● the mobile phone assigned as

First to Connect is connected

automatically or

● Secondary Phone is enabled and

two phones are allowed to

connect at the same time

First to Connect

Assign a phone as First to Connect:

1. In the phone menu on the Info

Display, select Phones.

2. Touch / next to the paired mobile

phone to open the settings menu.

3. Enable First to Connect.

Secondary Phone

It is possible to connect a second

mobile phone alongside the primary

phone to the system.

Allow two phones to connect at the

same time via Bluetooth:

1. In the phone menu on the Info

Display, select Phones.

2. Touch / next to the paired mobile

phone to open the settings menu.

3. Enable Secondary Phone.

The phone that has been connected

first will automatically be assigned as

primary phone. The primary phone is

able to operate outgoing calls and to

receive incoming calls. It also

provides access to its contact list.
The secondary phone is only able to

receive incoming calls via the

Infotainment system. However, it is

possible to operate an outgoing call

via the secondary mobile phone itself,

but using the vehicle's microphone.

Switching mobile phone


It is possible to switch the phone

assignment of the mobile phones

from either primary to secondary

phone or vice versa.



Infotainment system

Precondition is that Secondary

Phone is enabled for both mobile

To switch the mobile phone


1. In the phone menu on the Info

Display, select Phones.

2. Touch on the respective mobile


3. The mobile phone assignment

changes from either primary to

secondary phone or vice versa.

When First to Connect is enabled for

one mobile phone, this phone will

automatically be connected as

primary phone.

Disconnecting a connected

mobile phone

1. In the phone menu on the Info

Display, select Phones.

2. Touch / next to the paired mobile

phone to open the settings menu.

3. Touch Disconnect.

Deleting a paired mobile phone

1. In the phone menu on the Info

Display, select Phones.

2. Touch / next to the paired mobile

phone to open the settings menu.

3. Touch Forget Phone.

Using smartphone


The phone projection applications

Apple CarPlay and Android Auto

display selected applications from a

smartphone on the Infotainment

screen and allow their operation

directly via the Infotainment controls.
Check with the device's manufacturer

if this function is compatible with your

smartphone and if this application is

available in the country you are in.

Preparing the smartphone

Android phone: Download the

Android Auto application to the

smartphone from the Google Play



: Make sure Siri


 is activated

on the smartphone.

Activating phone projection in the

settings menu

Press ;, select Settings on the

homescreen and go to Apps.
Scroll through the list and select

Apple CarPlay or Android Auto.
Make sure the respective application

is activated.

Connecting the mobile phone

Connect the smartphone to the USB

port via an original cable provided by

the manufacturer of the smartphone.

Returning to the Infotainment


Press ;.


Climate control


Climate control

Climate control systems ............. 165

Air conditioning system ........... 165

Electronic climate control

system .................................... 168

Auxiliary heater ........................ 174

Air vents ..................................... 174

Adjustable air vents ................. 174

Fixed air vents ......................... 175

Maintenance .............................. 175

Air intake ................................. 175

Air conditioning regular

operation ................................ 176

Service .................................... 176

Climate control systems

Air conditioning system

Illustration shows functions which

may not be available for your

particular vehicle.
Controls for:

● Fan speed E
● Temperature TEMP
● Air distribution w, x and y
● Air conditioning A/C
● Demisting and defrosting á
● Air recirculation n
● External air 5

● Heated rear window and exterior

mirrors b

● Heated windscreen ,
● Heated seats ß

Some changes of settings are

indicated briefly in the Info-Display.

Activated functions are indicated by

the LED in the respective button.

Fan speed E

Adjust the air flow by turning Z to the

desired speed.

: increase

anti-clockwise : decrease

Temperature TEMP

Adjust the temperature by turning

TEMP to the desired temperature.
red area : warmer

blue area : colder
Heating will not be fully effective until

the engine has reached normal

operating temperature.









Content      ..     8      9      10      11     ..
