6G–8 ENGINE LUBRICATION (6VD1 3.2L)
3. Install crankcase, tighten crankcase fixing bolts to the specified torque. Torque : 10 N·m (1.0 kg·m/87 lb in) 013RW004 2. Install oil pan 1. Remove residual sealant, lubricant and moisture from mounting surface, then dry thoroughly. 2. Properly apply a 4.5 mm (07 in) wide bead of sealant (TB-1207C or equivalent) to mounting D The crankcase must be installed within 5 013RW003 3. Install oil pan, tighten oil pan fixing bolts to the specified torque. Torque : 25 N·m (2.5 kg·m/18 lb ft) 3. Install axle housing assembly and tighten fixing bolts to the specified torque. Axle case bolts 013RW005 4. Install relay lever assembly and tighten fixing bolts. Torque: 44 N·m (4.5 kg·m/33 lb ft) 5. Engage teeth of pitman arm and steering unit, and tighten nut to the specified torque. Torque : 216 N·m (22.0 kg·m/159 lb ft) 013RW006 Legend (1) Pitman Arm |
