6E2–230 6VD1 3.2L ENGINE DRIVEABILITY AND EMISSIONS DTC P0502 –VSS Circuit Low Input (Cont'd) Step No Yes Value(s) Action 10 1. Ignition “OFF.” attaches the VSS wires from the transmission 3. Disconnect the green 16-way connector. that can be used with a jumper to supply B+ to the 5. Use another terminal adapter to attach a voltmeter to the blue wire with a black tracer (next to the wire in 6. At the transmission side of the green 16-way connector, locate the black wire next to the VSS 7. Raise the rear wheels off the ground with transmission in neutral. Does the DVM toggle back and forth between 0.6 V and — Go to Step 12 Go to Step 11 11 Replace the VSS. Is the action complete? — Verify repair — 12 Check for an open or short between the PCM and the Was a problem found? — Verify repair Go to Step 13 13 Replace the PCM. Is the action complete? — Verify repair — |
