6E1–103 X22SE 2.2L ENGINE DRIVEABILITY AND EMISSION DTC P0113 Intake Air Temperature (IAT) Sensor Circuit High Input (Cont'd) Step No Yes Value(s) Action 6 Check for poor connections at the IAT sensor and Did any terminals require replacement? — Verify Repair Go to Step 10 7 1. Ignition OFF. ground circuit for an open. 3. If the IAT sensor ground circuit is open, repair it as necessary. Was the IAT sensor ground circuit open? — Verify repair Go to Step 9 8 1. Ignition OFF. circuit for an open. 3. If the IAT sensor signal circuit is open, repair it as necessary. Was the IAT signal circuit open? — Verify repair Go to Step 9 9 Check for a poor sensor ground or IAT signal circuit Did any of the terminals need to be replaced? — Verify repair Go to Step 11 10 Replace the IAT sensor Is the action complete? — Verify repair — 11 Replace the ECM Is the action complete? — Verify repair — |
