4D–8 TRANSFER CASE 7. Raise and support vehicle with suitable stands. Drain transfer case fluid. 8. Remove transfer protector (6). 150RX010 9. Remove rear propeller shaft (7) and front propeller shaft (8). NOTE: Apply alignment marks on the flange at both front 10. Disconnect harness connectors and clip. Connector: transfer switch, 2WD–4WD actuator, 11. Support transmission case with a transmission jack. 12. Remove the top position bolt from transfer control lever hole and others under the floor. Installation 1. Apply a thin coat of molybdenum disulfide grease to the input shaft spline as shown in the figure. 260RW001 |
