4A2–6 DIFFERENTIAL (REAR) 9. Loosen the brake tube flare nut, remove the clip and take out the brake tube. 350RW020 10. Remove the shock absorber. 11. Remove the stabilizer linkage mounting bolts and nuts (2) from the frame side. 350RW024 12. Remove the lateral rod fixing bolt and nut from the frame. 13. Remove the upper link mounting bolt and nut (3) from the axle housing. 460RW015 14. Remove the lower link fixing bolt and nut (4) from the axle housing. 460RW016 15. Jack down and remove the coil spring and insulator. 16. Axle housing assembly can be separated from the vehicle on completion of steps 1 – 15. 17. Remove the brake caliper fixing bolt, loosen the flare nut, release the clip and take out the brake 18. Remove brake disc. 19. Remove antilock brake system speed sensor fixing bolt and the clip and bracket on the axle housing. 20. Remove the brake pipe clip and fixing bolt on the axle housing and take out the brake pipe. |
