8D–180 WIRING SYSTEM Rear Washer Motor Does Not Operate Step Action Value(s) Yes No 1 Does the rear wiper motor operate? — Go to Step 6 Go to Step 2 2 Is the fuse C–17 normal? — Go to Step 3 Replace the fuse 3 1. Disconnect the rear wiper/washer switch connector I–16. 2. Turn the switch to the rear washer position. Is there continuity between the switch side connector — Go to Step 4 Replace the switch 4 Turn the starter switch on. Is the battery voltage applied between harness side Approx. 12V Go to Step 6 Go to Step 5 5 Repair an open circuit between the fuse C–17 and Is the action complete? — Go to Step 4 — 6 1. Disconnect the rear wiper motor connector C–30. side connector C–30 terminal 1 and the battery Does the motor operate? — Go to Step 7 Repair or replace the motor 7 Reconnect the rear wiper/washer switch connector Is the battery voltage applied between harness side Approx. 12V Go to Step 9 Go to Step 8 8 Repair an open circuit between the rear wiper/washer Is the action complete? — Verify repair — 9 Repair an open circuit between connector C–30 Is the action complete? — Verify repair — |
