7A–60 AUTOMATIC TRANSMISSION (4L30–E) D Ensure free rotation of pump using J–23082–01 241RW010 38. Overdrive clutch end play measurement. 1. Fit J–25022 and J–24773–1 turbine shaft puller on turbine shaft. 2. Position axial play checking tool on converter housing mating face. 3. Pull turbine shaft upwards with puller until first resistance is met. (due to weight of overdrive 4. Maintain shaft in this position and set indicator to zero. 5. Pull turbine shaft further upwards with puller. Read end play shown on indicator. End play: 0.1mm – 0.8mm (0.004 in – 0.031in) 6. Remove axial play checking tool and puller. NOTE: If end play is not correct, repeat selective washer 252RW001 39. Inspect extension housing oil seal and replace if necessary, using J–36797 extension housing oil seal D Rotate transmission to horizontal position, with D Inspect parking wheel seal ring. Replace if D Install wheel parking lock assembly (35). 40. Install speed wheel (36) and snap ring (37). NOTE: Use extra long, needle nose pliers. 41. Install gasket onto extension assembly with a thin coating of oil. D Install extension housing assembly (38), and align D Install actuator assembly into extension assembly. D Install seven 8 mm hexagon socket head screws. Torque: 32 N • m (24 lb ft) 42. Inspect speed sensor O-ring. Replace if necessary. D Install speed sensor assembly (39) and 10 mm Torque: 9 N • m (78 lb in) |
