6E2–294 6VD1 3.2L ENGINE DRIVEABILITY AND EMISSIONS 4. Install the accelerator control cable (on the throttle valve end). 101RW006 5. Install the adjusting nut. 101RW007 6. Adjust the accelerator cable at the throttle body. Refer to Accelerator Cable Adjustment. 7. Install the engine cover. Adjustment Procedure 1. Loosen the adjusting nut and lock nut. 3. Tighten adjusting nut and lock nut temporarily. 035RW004 4. Loosen adjusting nut by three turns and tighten lock nut. Then, manually operating the throttle valve, IMPORTANT: The valve lever must return up to the stopper screw. If the valve lever does not reach the 5. It does not reach the stopper screw, repeat from step 1. TS23782 |
