ENGINE COOLING 6B–9 Radiator Radiator and Associated Parts 110RW010 Legend (1) Oil Cooler Hose For Automatic Transmission (4) Reserve Tank Hose Removal 1. Disconnect battery ground cable. transmission (A/T). 4. Disconnect radiator inlet hose and outlet hose from the engine. 110RW002 5. Remove fan guide(1), clips (2) on both sides and the bottom lock, then remove lower fan guide(3) with fan 110RW001 |
