6A–84 ENGINE MECHANICAL (6VD1 3.2L) 11. Remove rear oil seal retainer assembly. 12. Remove main bearing cap. Inspection and Repair 1. Remove the cylinder head gasket and any other material adhering to the upper surface of the cylinder 2. Carefully remove the oil pump, rear oil seal retainer, and crankcase assembly installation surface seal. 3. Wipe the cylinder block clean. flaw detector to perform a dye penetrate and Flatness 1. Using a straight–edge and feeler gauge, check that the upper surface of the cylinder block is not warped. CAUTION: Be very careful not to allow any material 2. The cylinder block must be reground or replaced if the warpage exceeds the limit. Warpage 012RS004 Cylinder Bore Use a cylinder gauge to measure the cylinder bore CAUTION: Be very careful not to allow any material Cylinder Bore Inside Diameter If the measurement exceed the specified limit, the Diameter (3.6772 in–3.6776 in) Grade B : 93.411 mm–93.420 mm (3.6776 in–3.6779 in) Grade C : 93.421 mm–93.430 mm (3.6780 in–3.6783 in) 012RS005 NOTE: For information on piston diameter, please refer D The ”Grade” mark (1) is stamped at the position |
