8B–2 WIPER/WASHER SYSTEM Windshield Wiper/Washer System General Description The circuit consists of the starter switch, windshield with the starter switch on, the battery voltage is applied Windshield Wiper And Washer Switch Removal and Installation Refer to Combination Switch in Steering section. Windshield Wiper Motor Removal 1. Disconnect the battery ground cable. 2. Disconnect the connector (2). 3. Remove 4 mounting bolts (3). 4. Remove the windshield wiper motor(1). 880RW002-1 5. Remove the crank arm fixing ball (4). 880RX011 Installation To install, follow the removal steps in the reverse order. |
