6G–5 ENGINE LUBRICATION (6VD1 3.2L) 051RS005 Oil Strainer Check the oil strainer for cracking and scoring. If cracking 051RS006 Reassembly 1. Install drive gear (11). the attaching screws. Next, tighten the attaching Torque : 10 N·m (1.0 kg·m/87 lb in) After installation, check that the gear rotates 4. Install relief valve (8) and apply engine oil to the relief valve and spring (7). 5. Install spring (7). 6. Install the plug (6). Torque : 8 N·m (0.8 kg·m/69 lb in) 051RS007 7. Install oil pump assembly (5). D Carefully remove any oil from the cylinder body and CAUTION: Do not apply an excessive amount of D Attach oil pump assembly to cylinder body. D Tighten the oil pump fixing bolts. Torque : 25 N·m (2.5 kg·m/18 lb·ft) 051RW002 |
