6D3–13 STARTING AND CHARGING SYSTEM (6VD1 3.2L) Measure inner diameter of bushing in the rear cover, and Standard: 12.50 mm to 12.527 mm (0.492 in to 065RS028 Measure inner diameter of bushing in the center bracket Standard: 18.01 mm to 18.127 mm (0.7091 in to 065RS029 Reassembly To install, follow the removal steps in the reverse order, D Bushing in rear cover and center bracket D Gears in reduction gear D Shift lever operating portion D Sliding portion of pinion D Plunger sliding portion of magnetic switch Reassembling Yoke Assembly Before reassembly, make sure that no metallic parts Torque Pinion Jump–out Dimension Connect the “+” cable of battery to terminal S and the “–” Dimension(L): 0.05 mm to 1.5 mm (0.002 in to 065RS030 |
