POWER-ASSISTED BRAKE SYSTEM 5C–53 302RS019 5. Apply special grease (approximately 1g) to the piston and attach the dust boot to the piston and 302RS020 6. Install guide bolt and lock bolt dust boot. 7. Install the dust boot on the support bracket after applying special grease (Approx. 1g) onto the dust 302RS021 8. Install lock bolt and guide bolt and tighten the bolt to the specified torque. Torque: 43 N·m (4.4 kg·m/32 lbft) |
