POWER-ASSISTED BRAKE SYSTEM 5C–13 Brake Pipe Removal 1. Raise the vehicle and support it with suitable safety stands. 2. Remove wheel and tire assembly as necessary. 3. Clean dirt, grease, and other foreign material off the pipe fittings at both ends. 4. Remove brake pipe (1). 330RW011 5. Remove plastic clip (2). 330RW002 Installation To install, follow the removal steps in the reverse order, 1. Tighten the brake pipes to the specified torque. Master cylinder and P&B valve sides Torque: 12 N·m (1.2 kg·m/104 lbin) Others Torque: 16 N·m (1.6 kg·m/12 lbft) After installing the brake pipes, bleed the brakes as |
