CLUTCH 7C–27 Master Cylinder 208RX003 Legend (1) Reservoir Cap (5) Clip Disassembly 1. Disassemble reservoir cap (1), inner cap (2), seal (3), clip (5), and reservoir (4). 2. Disassembly gasket (7), yoke (9), nut (8) and body sub assembly. Inspection and Repair Make the necessary adjustments, repair, and part Reassembly To reassemble, follow the disassembly steps in the |
