4C–14 DRIVE SHAFT SYSTEM Shift On The Fly System Shift On The Fly System and Associated Parts 412RW031 Legend EndOFCallout Disassembly 1. Remove filler plug and gasket, drain oil. 2. Loosen mounting bracket fitting bolts and remove front axle drive shaft from front axle case. 3. Remove actuator assembly and draw out actuator ASM. 4. Remove housing. 5. Remove sleeve. (1) Filler Plug (9) Clutch Gear (10) Sleeve |
