2A–20 POWER-ASSISTED STEERING SYSTEM Power Steering Unit Disassembled View 440RW005 Legend EndOFCallout Disassembly NOTE: The valve housing is made of aluminum and 1. Loosen lock nut and remove tie–rod end. 2. Remove clip and band, then remove bellows. 3. Remove tie-rod assembly. To remove, move the boot toward the tie-rod end, 4. Remove oil line, mounting rubber and dust cover. Inspection and Repair Inspect the following parts for wear, damage or any Tie-rod End If looseness or play is found when checked by moving Tie-rod Assembly If the resistance is insufficient or play is felt when Rubber Parts If wear or damage is found through inspection, replace Reassembly 1. Install mounting rubber and dust cover (If removed). 2. Install oil line. Torque: 13N·m (1.3kg·m/113lbin) 3. Install tie-rod assembly with tab washer. Apply grease to ball joint, install tie-rod and tab Torque: 83N·m (8.5kg·m/61lbft) After tightening, bend tab washer against width (1) Tie-rod End (7) Tab Washer (10) Mounting Rubber |
