Parking brake reminder chime

A chime sounds if the parking brake is set
and the vehicle is driven. The chime will
stop if the parking brake is released or the
vehicle speed returns to zero.

Power switch reminder chime

The power switch reminder chime will sound
when the driver's door is opened while the
power switch is in the ON or READY to drive
position. Push the power switch to the OFF
position.

12-volt battery charge warning
chime

If the 12-volt battery charge warning light
illuminates, the chime will sound when a
warning message is displayed in the ve-
hicle information display.

When the chime sounds, immediately stop
the vehicle in a safe location and push the P
(Park) position switch on the shift lever and
apply the parking brake. The 12-volt battery
charge warning light turns off and the
chime will stop when the parking brake is
applied or the vehicle is placed in the P
(Park) position. Have the system checked.

It is recommended that you visit a NISSAN
certified LEAF dealer for this service. For
additional information, see “12-volt battery
charge warning light” (P. 2-16).

The vehicle information display is located
to the left of the speedometer. It displays
items such as:
• Battery information
• Energy economy
• Average vehicle speed
• Driving distance
• Driving time
• Cruise control information
• Intelligent Key information
• Indicators and warnings

LIC3872

VEHICLE INFORMATION DISPLAY

2-26

Instruments and controls

HOW TO USE THE VEHICLE
INFORMATION DISPLAY

The vehicle information display can be
changed by using the

and OK buttons located on the steer-

ing wheel.

Use this button to change
or select items.

Use these buttons to navi-
gate the vehicle informa-
tion display.

Use this button to return to
the previous menu.

Use these buttons to navi-
gate the vehicle informa-
tion display.

The

, and

but-

tons also control audio and control panel
functions

some

conditions.

Most

screens

and

menus

offer

instruction

prompts of the steering switches to indi-
cate how to control the vehicle information
display. White dots appear on the left side
of the vehicle information display when
there is more than one page of menu
items. The

and

change the

audio source and the buttons also control
voice recognition manual mode. For addi-
tional information, refer to the separate
NissanConnect® Manual.

STARTUP DISPLAY

With the vehicle in the ON position, the ve-
hicle information display may display the
following screens:
• Battery information
• Audio
• Navigation (if so equipped)
• Energy Economy

• Driving Aids
• Warnings
• Settings

Warnings will only display if there are any
present. For additional information, see
“Vehicle information display warnings and
indicators” (P. 2-34).
To control which items display in the ve-
hicle information display, see “How to use
the vehicle information display” (P. 2-27).

SETTINGS

The settings mode allows you to change
the information displayed in the vehicle in-
formation display as well as enable and
disable various vehicle features and sys-
tems. The settings include:
• VDC Setting
• Driver Assistance
• Customize Display
• Vehicle Settings
• EV Settings
• TPMS Settings
• Maintenance
• Clock
• Unit/Language
• Factory Reset

LHA4545

Instruments and controls

2-27

VDC Setting

The VDC setting menu allows the user to the adjust the VDC settings.

Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

System

Allows user to turn the Vehicle Dynamic Control (VDC) system on or off.

Driver Assistance

The driver assistance menu allows the user to change the settings for driving, parking, and braking aids.
Some menu items shown below may not be equipped on your vehicle

Menu Item

Explanation

Steering Assist

Allows user to turn the steering assist feature on or off. For additional information, see “ProPILOT Assist” (P. 5-91).

Lane

Displays the available lane options.

Lane Departure Warning

Allows user to turn the Lane Departure Warning on and off. For additional information, see “Lane Departure
Warning (LDW)” (P. 5-25).

Lane Departure Prevention

Allows user to turn the Intelligent Lane Intervention (I-LI) on and off. For additional information, see “Intelligent
Lane Intervention (I-LI)” (P. 5-30).

Blind Spot

Displays the available blind spot options.

Blind Spot Warning

Allows user to turn the Blind Spot Warning on and off. For additional information, see “Blind Spot Warning (BSW)”
(P. 5-36).

Blind Spot Intervention

Allows user to turn the Intelligent Blind Spot Intervention (I-BSI) on and off. For additional information, see “Intelli-
gent Blind Spot Intervention (I-BSI)” (P. 5-45).

Side Indicator Brightness

Allows user to set the brightness of the side indicator light.

2-28

Instruments and controls

Menu Item

Explanation

Emergency Brake

Displays the available emergency brake options.

Front

Allows user to turn the emergency brake on and off. For additional information, see “Automatic Emergency
Braking (AEB) with Pedestrian Detection” (P. 5-130) and “Intelligent Forward Collision Warning (I-FCW)” (P. 5-140).

Rear

Allows user to turn the rear emergency braking system on and off. For additional information, see "Rear Auto-
matic Braking (RAB) (P. 5-125).

Parking Aids

Displays the available parking aids.

Sonar

Allows user to select sonar system features. For additional information, see “Rear Sonar System (RSS) (P. 5-168).

Parking sonar

Allows user to turn the parking sonar on or off.

Display

Allows user to turn the parking sonar display on or off.

Volume

Allows user to change the volume of the parking aid chimes: High, Med. Low

Range

Allows user to select the range in which the parking sonar will activate: Far, Med, Near.

Moving Object

Allows user to turn the Moving Object Detection on and off. For additional information, see “Moving Object
Detection (MOD)” (P. 4-23).

Cross Traffic

Allows user to turn the cross traffic alert on and off. For additional information, see “Rear Cross Traffic Alert
(RCTA)” (P. 5-58).

Driver Attention Alert

Allows user to turn the driver attention alert on or off. For additional information, see “Intelligent Driver Alertness
(I-DA)” (P. 5-152).

Timer Alert

Allows user to set or reset an alert at a specific tune interval.

Low Temperature Alert

Allows user to turn the low temperature alert on or off.

Chassis Control

Displays the available chassis controls.

Active Trace Control (Intelligent
Trace Control)

Allows user to turn the chassis control on or off. For additional information, see “Chassis control” (P. 5-166).

e-Pedal

Displays the available e-Pedal options.

Retain Mode

Allows user to turn the retain mode on or off. For additional information, see “e-Pedal system”(P. 2-13).

Instruments and controls

2-29

Customize Display

The customize display menu allows the user to change the settings for the vehicle information display.

Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

Main Menu Selection

Displays the available main menu selection options.

Cruise

Allows user to turn the Cruise screen on or off in the vehicle information display.

Driving Aids

Allows user to turn the safety shield screen on or off in the vehicle information display.

Status

Allows user to turn the status screen on or off in the vehicle information display.

Tire Pressures

Allows user to turn the tire pressures screen on or off in the vehicle information display.

Drive Computer

Allows user to turn the drive computer screen on or off in the vehicle information display.

Chassis Control

Allows user to turn the chassis control screen on or off in the vehicle information display.

ECO Info Settings

Displays the available ECO Info Settings.

ECO Drive Report

Allows user to turn the ECO drive report on or off.

View History

Allows user to view and reset the ECO drive report history.

Navigation Settings

Displays the available navigation settings.

Alerts

Allows user to turn the navigation alerts on or off.

Cruise Screen Transition

Allows user to turn the Cruise screen transition on or off.

Welcome Effect

Displays the available welcome effects.

Gauges

Allows user to turn the gauges effect on or off.

Animation

Allows user to turn the animation effect on or off.

2-30

Instruments and controls

Vehicle Settings

The vehicle settings menu allows the user to change the settings for the lights, locks, wipers and other vehicle settings.

Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

Rear Door Alert

Displays the available Rear Door Alert options. For additional information, see “Rear Door Alert”
(P. 2-60).

Horn & Alert

When selected, the alert is displayed and horn sounds.

Alert Only

When selected, only the alert is displayed.

OFF

When selected, no alert or horn will be active.

Lighting

Displays the available lighting options.

Auto Room Lamp

Allows user to turn the auto room lamp on or off

Light Sensitivity

Allows user to change when the lights illuminate based on the brightness outside the vehicle.

Light Off Delay

Allows user to change the duration of time that the automatic headlights stay on after the vehicle
is shut off.

Locking

Displays the available locking options.

Ext. Door Switch

Allows user to turn the exterior door switch on or off. When turned on, the request switch on the
door is activated.

Selective Unlock

Allows user to turn selective unlock on or off. When turned on, only the current door is unlocked
after the door unlock operation. When the door handle request switch on the driver’s or front pas-
senger’s side door is pushed to be unlocked, only the corresponding door is unlocked first. All the
doors can be unlocked if the door unlock operation is performed again within 5 seconds. When
this item is turned off, all the doors will be unlocked after the door unlock operation is performed
once.

Wipers

Displays the available wiper settings. For additional information, see “Wiper and washer switch”
(P. 2-45).

Speed Dependent

Allows user to turn the speed dependent feature on or off.

Instruments and controls

2-31

EV Settings

The EV settings menu allows the user to change the settings for charging the vehicle.
Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

Chg. Connector Lock

Allows user to lock or unlock the charging connection.

Charge Timer1

Allows user to set charge timer 1.

Charge Timer2

Allows user to set charge timer 2.

Chg. Timer Only at HOME

Allows user to set charging timer only at home.

Charge Time Screen

Allows user to select the display time screen based on charge method.

Climate Ctrl. Timer1

Allows user to set climate control timer 1.

Climate Ctrl. Timer2

Allows user to set climate control timer 2.

TPMS Settings

The TPMS settings menu allows the user to change the tire pressure units displayed in the vehicle information display.
Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

Tire Pressure Unit

Allows user to select the tire pressure units that will display in the vehicle information display.

Maintenance

The maintenance menu allows the user to set reminders for various vehicle maintenance items.
Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

Maintenance

Displays available maintenance reminder options.

Tire

Allows user to set a reminder at a specific interval or reset the current one.

Other

Allows user to set a reminder at a specific interval or reset the current one.

2-32

Instruments and controls

Clock

The clock menu allows the user to change the clock settings.
Some menu items below may not be equipped on your vehicle.

Menu Item

Explanation

Clock

Clock Mode

Allows user to select the clock setting mode.

Clock Format

Allows user to select from 12–hour and 24–hour formats.

Daylight Saving Time

Allows user to turn daylight saving time mode on or off.

Time Zone

Allows user to set a time zone.

Set Clock Manually

Allows user to set a clock manually.

Unit/Language

The unit/language menu allows the user to change the units shown in the vehicle information display.
Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

Mileage/Energy

Allows user to select the preferred mileage/energy unit of measure to display.

Tire Pressures

Allows user to select the preferred tire pressure unit of measure to display.

Temperature

Allows user to select the preferred temperature unit of measure to display.

Language

Allows user to select the preferred language to display.

Factory Reset

The factory reset menu allows the user to restore the vehicle information display settings to factory status.
Some menu items shown below may not be equipped on your vehicle.

Menu Item

Explanation

Factory Reset

Allows user to reset the vehicle information display settings to the original factory settings. Once
selected, the user can confirm or cancel the reset.

Instruments and controls

2-33

VEHICLE INFORMATION DISPLAY
WARNINGS AND INDICATORS

Some of the following warning messages
may not be equipped on your vehicle.

EV system operation for
discharged Intelligent Key
system indicator

This indicator appears when the Intelligent
Key battery is running out of power and
when the Intelligent Key system and ve-
hicle are not communicating normally.

If this indicator appears, touch the power
switch with the Intelligent Key while de-
pressing the brake pedal. For additional
information, see “NISSAN Intelligent Key®
battery discharge” (P. 5-12).

Key Battery Low

This indicator appears when the Intelligent
Key battery is running out of power.

If this indicator appears, replace the bat-
tery with a new one. For additional infor-
mation, see “NISSAN Intelligent Key® bat-
tery replacement” (P. 8-19).

Key System Error: See
Owner’s Manual

After the power switch is placed in the ON
position, this warning appears for a period
of time and then turns off.

The Key System Error message warns of
a malfunction with the Intelligent Key
system. If the warning appears while the
motor is stopped, it may be impossible to
start the motor.

If the warning appears while the motor is
running, you can drive the vehicle. However,
have it repaired as soon as possible. It is
recommended that you visit a NISSAN cer-
tified LEAF dealer for this service.

No Key Detected

This warning appears in either of the fol-
lowing conditions:

No key inside the vehicle:

This warning appears when the door is
closed with the Intelligent Key left outside
the vehicle and the power switch in the
ACC or ON position. Make sure that the
Intelligent Key is inside the vehicle.

Unregistered Intelligent Key:

This warning appears when the power
switch is placed in the ON, ACC or READY to
drive position and the Intelligent Key can-
not be recognized by the system. You can-
not place the power switch in the READY to
drive position with an unregistered key. Use
an Intelligent Key that has been registered.

For additional information, see “NISSAN
Intelligent Key® system” (P. 3-6).

Brightness indicator

This indicator shows the brightness ad-
justment of the instrument panel. For addi-
tional information, see “Instrument bright-
ness control” (P. 2-54).

Chassis Control System Error: See
Owner’s Manual

This warning appears if the chassis control
is not functioning properly. Have the sys-
tem checked. It is recommended that you
visit a NISSAN certified LEAF dealer for this
service. For additional information, see
“Chassis control” (P. 5-166).

2-34

Instruments and controls

Check position of shift lever

This warning appears if the system cannot
detect the shift position. Make sure the
vehicle is placed in a position properly.

The master warning light (yellow) also illu-
minates and the chime sounds. Check the
shift position of the vehicle.

Check Rear Seat For All Articles

When the system is enabled, this message
appears when the vehicle comes to a com-
plete stop, the vehicle is transitioned from
the D (Drive) position to P (Park) position,
and the driver exits the vehicle. This mes-
sage alerts the driver, after a period of time,
to check for items in the rear seat after the
audible alert has been provided.

NOTE:
This system is disabled until a driver
enables it using the vehicle informa-
tion display. For additional informa-
tion, see “How to use the vehicle in-
formation display” (P. 2-27).

For additional information, see “Rear Door
Alert” (P. 2-60).

Rear Door Alert is activated

When the system is enabled, this message
appears when the Rear Door Alert system
is active and can remind the driver to check
the back seat.
• Using the steering wheel switch, a driver

can select “Dismiss Message” to clear the
display for a period of time. If no selection
is made, this message automatically
turns off after a period of time.

• Using the steering wheel switch, a driver

can select “Disable Alert” to disable the
horn alert for the remainder of the cur-
rent trip.

WARNING

Selecting “Dismiss Message” during a
stop within a trip temporarily dis-
misses the message for that stop with-
out turning the system off. Alerts can
be provided for other stops during the
trip. Selecting “Disable Alert” turns off
the Rear Door Alert system for the re-
mainder of a trip and no audible alert
will be provided.

NOTE:

This system is disabled until a driver en-
ables it using the vehicle information
display. For additional information, see
“How to use the vehicle information dis-
play” (P. 2-27).

For additional information, see “Rear Door
Alert” (P. 2-60).

Door open

This warning appears if any of the doors
and/or the rear hatch are open or not
closed securely. The vehicle icon indicates
which door or the rear hatch is open on the
display. Make sure that all of the doors and
the rear hatch are closed.

This warning also appears alternating with
the Shift to P range warning while the driv-
er's door is opened with the shift position in
any position other than the P (Park) posi-
tion. For additional information, see “Shift to
P range” (P. 2-37).

Instruments and controls

2-35

Driver alert

This warning appears when the previously
set time for a break is reached. You can set
the time for up to 6 hours in the setting
menu. For additional information, see
“Vehicle information display” (P. 2-26).

e—Pedal system failure! Press brake
pedal to slow or stop

This warning appears when the e-Pedal
system is malfunctioning. Have the system
checked. It is recommended that you visit a
NISSAN certified LEAF dealer for this service.

Indicators for maintenance

These indicators appear when the cus-
tomer set distance comes for replacing
tires or other maintenance items. You can
set or reset the distance for replacing tires
and other maintenance items.

WARNING

The tire replacement indicator is not a
substitute for regular tire checks, includ-
ing tire pressure checks. For additional
information, see “Changing wheels and

tires” (P. 8-35). Many factors including
tire inflation, alignment, driving habits
and road conditions affect tire wear and
when tires should be replaced. Setting
the tire replacement indicator for a cer-
tain driving distance does not mean
your tires will last that long. Use the tire
replacement indicator as a guide only
and always perform regular tire checks.
Failure to perform regular tire checks,
including tire pressure checks could
result in tire failure. Serious vehicle
damage could occur and may lead to a
collision, which could result in serious
personal injury or death.

For scheduled maintenance items and in-
tervals, see “Maintenance and schedules”
(P. 9-6).

Headlight System Error: See Owner’s
Manual

This warning appears when the LED head-
lights are not functioning properly.

If this warning appears, have your system
checked. It is recommended that you visit a
NISSAN certified LEAF dealer for this service.

Low battery charge
indicator

This light appears when the available Li-ion
battery charge is getting low. Charge as
soon as it is possible, preferably before
the Li-ion battery available charge gauge
reaches 0%.

NOTE:

The low battery charge indicator turns
off immediately before the Li-ion battery
is completely discharged and the vehicle
will stop. If the Li-ion battery becomes
completely discharged, the vehicle must
be charged in order to be driven.

Low outside air
temperature

The outside air temperature is displayed in
°F or °C in the range of −20°F to 140°F (−30°C
to 60°C).

The outside air temperature mode in-
cludes a low temperature warning feature.
If the outside air temperature is below 37°F
(3°C), the warning is displayed on the screen.

2-36

Instruments and controls

The outside temperature sensor is located
in front side of the vehicle. The sensor may
be affected by road, wind directions and
other driving conditions. The display may
differ from the actual outside temperature
or the temperature displayed on various
signs or billboards.

Low Washer Fluid

This warning appears when the washer
tank fluid is at a low level. Add washer fluid
as necessary. For additional information,
see “Windshield-washer fluid” (P. 8-8).

Press Brake Pedal

This message may appear in the following
situations:
• The driver tries to release the electronic

parking brake manually without depress-
ing the brake pedal.

• The vehicle is stopped on a steep hill; and

there is a possibility of moving back-
wards, even if the electronic parking
brake is applied.

For additional information, see “Electronic
parking brake” (P. 5-19).

Press brake pedal to
operate e-Pedal switch

This indicator appears when trying to turn
the e-Pedal off without depressing the
brake pedal when the vehicle is stopped.
Depress the brake pedal before pulling the
e-Pedal switch.

Push brake and power
switch to drive

This indicator appears while the vehicle is
in the P (Park) position. This indicator
means that the EV system will start when
the power switch is pressed with the brake
pedal depressed.

Rear seat belt reminder

This warning appears for 65 seconds after
the power switch is placed in the ON posi-
tion and the EV system is started.

This warning shows the status of the rear
seat belts. When one of the rear seat belts is
buckled, the corresponding rear seat belt
warning will appear in gray. When one of
the rear seat belts is unbuckled, the rear
seat belt warning will appear red.

After the rear seat belt status changes
from buckled to unbuckled and the vehicle
is driven above 10 mph (15 km/h), a chime

will sound and the warning will appear for
another 65 seconds.

Release Parking Brake

This warning appears when the vehicle
speed is above 4 mph (7 km/h) (models not
equipped with electronic parking brake) or
2 mph (4 km/h) (models equipped with
electronic parking brake) and the parking
brake is applied. Stop the vehicle and re-
lease the parking brake.

Reminder Turn OFF
Headlights

This warning appears when the power
switch is turned to the OFF position but the
headlight switch is still on. Turn off the
headlight switch.

Shift to P range

This warning appears alternately with
door/rear hatch open warning when the
driver's door is opened with the shift posi-
tion in any position other than the P (Park)
position. If this warning appears, push the P
(Park) position switch and place in the P
(Park) position.

For additional information, see “Door open”
(P. 2-35).

Instruments and controls

2-37

Shipping Mode On Push Storage Fuse

This warning may appear if the extended
storage switch is not pushed in. When this
warning appears, push in the extended
storage switch to turn off the warning.

For additional information, see “Extended
storage switch” (P. 8-19).

Tire Pressure Low - Add Air

This warning appears when the low tire
pressure warning light in the meter illumi-
nates and low tire pressure is detected. The
warning appears each time the power
switch is placed in the ON position as long
as the low tire pressure warning light re-
mains illuminated.

If this warning appears, stop the vehicle
and adjust the tire pressure to the recom-
mended COLD tire pressure shown on the
Tire and Loading Information label. For ad-
ditional information, see “Low tire pressure
warning light” (P. 2-21) and “Tire Pressure
Monitoring System (TPMS)” (P. 5-4).

T/M system malfunction Visit dealer

This warning appears if there is a malfunc-
tion in the electric shift control system but
operation of the electric shift control is still
possible. The master warning light (yellow)
also illuminates and the chime sounds.
When this occurs, check the shift position
indicator by the shift lever or in the vehicle
information display to make sure that
shifting has been performed properly. It is
recommended that you contact a NISSAN
certified LEAF dealer as soon as possible.

When Parked Apply Parking
Brake

This warning appears if there is a malfunc-
tion in the electric shift control system. This
warning appears when the parking brake is
not applied, even after the vehicle has been
parked. The master warning light (red) also
illuminates and the chime sounds.

If the power switch cannot be placed in the
OFF position, apply the parking brake and
then place the power switch in the OFF
position. The warning turns off and the
chime stops.

If this warning appears, have your system
checked. It is recommended that you visit a
NISSAN certified LEAF dealer for this service.

Automatic Emergency
Braking with Pedestrian
Detection warning
indicator

This indicator appears along, with an au-
dible warning, when the system detects
the possibility of a forward collision.

For additional information, see “Automatic
Emergency Braking (AEB) with Pedestrian
Detection” (P. 5-130) and “Intelligent For-
ward Collision Warning (I-FCW)” (P. 5-140).

Blind Spot Warning (BSW)
indicator

This indicator appears when the BSW/I-BSI
systems are engaged.

For additional information, see “Blind Spot
Warning (BSW)” (P. 5-36) or “Intelligent Blind
Spot Intervention (I-BSI)” (P. 5-45).

Cruise control indicator

This indicator shows the cruise control sys-
tem status.

When cruise control is activated, a green
circle will appear to indicate it is set. The
vehicle information display will also display
the speed the cruise control was set at. If you
accelerate past the set speed, the speed will

2-38

Instruments and controls

blink until you either cancel cruise control or
go back to the set speed. If cruise control is
on and canceled, the speed will be displayed
to show the speed the vehicle will return to if
the resume button is activated.

For additional information, see “Cruise con-
trol” (P. 5-65).

Currently not available

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system, Intelligent Blind Spot Inter-
vention (I-BSI), Intelligent Lane Intervention
(I-LI) or the ICC system is engaged.

Under the following condition, the ICC (with
ProPILOT Assist) system, Intelligent Blind
Spot Intervention (I-BSI), Intelligent Lane In-
tervention (I-LI) or the ICC system is auto-
matically canceled:
• When the VDC system is turned off.

The above system cannot be used in some
situations (VDC operates, wheel slip, and
VDC system is off.)

Driver Attention Alert
System Fault

This warning appears when the Intelligent
Driver Alertness (I-DA) system is not func-
tioning properly.

For additional information, see “Intelligent
Driver Alertness (I-DA)” (P. 5-152).

Driver Attention Alert
Take a Break?

This alert appears when the system has
detected the driver may be displaying fa-
tigue or a lack of attention.

Forward Driving Aids Temporarily
Disabled. Front Sensor Blocked.
See Owner’s Manual

This message appears when the front
radar sensor may be obstructed due to:
• mud, dirt, snow, ice, etc.
• inclement weather (rain, fog, snow, etc.)

All forward driving aids are temporarily dis-
abled until the system detects that the
front radar sensor is no longer obstructed.

For additional information, see the follow-
ing (if so equipped):
• Automatic Emergency Braking (AEB) with

Pedestrian Detection (P. 5-130)

• Intelligent Cruise Control (ICC) (P. 5-67),

(P. 5-103)

• Intelligent

Forward

Collision

Warning

(I-FCW) (P. 5-140)

Lane Departure Warning
(LDW) indicator

This indicator appears when the LDW sys-
tem is engaged.

For additional information, see “Lane De-
parture Warning (LDW) system” (P. 5-25).

Intelligent Cruise Control
(ICC) indicators

This indicator shows the Intelligent Cruise
Control (ICC) system status. The status is
shown by the color. For additional infor-
mation, see “Intelligent Cruise Control (ICC)”
(P. 5-67).

Malfunction: See Owner’s Manual

This warning appears when one or more of
the following systems (if so equipped) is
not functioning properly:
• Lane Departure Warning (LDW)
• Intelligent Lane Intervention (I-LI)
• Automatic Emergency Braking (AEB) with

Pedestrian Detection

• Intelligent

Forward

Collision

Warning

(I-FCW)

• Rear Automatic Braking (RAB)
• Rear Cross Traffic Alert (RCTA)

Instruments and controls

2-39

If one or more of these warning appears,
have the system checked. It is recom-
mended that you visit a NISSAN certified
LEAF dealer for this service.

Not Available Bad Weather

This message may appear when the Steer-
ing Assist system is engaged.

When the wiper (HI) operates, the Steering
Assist system is automatically canceled.

The system will be available when the
above conditions no longer exist.

Not Available Parking Brake On

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system is engaged.

Under the following conditions, the ICC
(with ProPILOT Assist) system is automati-
cally canceled:
• The electronic parking brake is applied.
The above system cannot be used when
the electronic parking brake is activated.

Not Available Poor Road Conditions

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system, the ICC system, Intelligent
Blind Spot Intervention (I-BSI) or Intelligent
Lane Intervention (I-LI) is engaged.

Under the following conditions, the ICC
(with ProPILOT Assist) system, ICC system,
Intelligent Blind Intervention (I-BSI) or Intel-
ligent Lane Intervention (I-LI) is automati-
cally canceled:
• When the VDC operates.
• When a wheel slips.

The above system cannot be used in some
situations (VDC operates and wheel slip).

Not Available Seat Belt Not Fastened

This indicator appears when the ProPILOT
Assist system will not engage because the
driver’s seat belt is not fastened. For addi-
tional information, see “ProPILOT Assist”
(P. 5-91).

Not Available System Malfunction

This warning appears when one or more of
the following systems (if so equipped) are
not functioning properly:
• Intelligent Blind Spot Intervention (I-BSI)
• Blind Spot Warning (BSW)
• ProPILOT Assist

If one or more of these warning appears,
have the system checked. It is recom-
mended that you visit a NISSAN certified
LEAF dealer for this service.

Not Available Visibility is Impaired

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system is engaged.

Under the following conditions, the ICC
(with ProPILOT Assist) system is automati-
cally canceled:
• The camera area of the windshield is

fogged up or covered with dirt, water, ice,
snow, etc.

• Strong light, such as sunlight or high

beams from oncoming vehicles, enters
the front camera

The system will be available when the
above conditions no longer exist.

If the warning message continues to ap-
pear, stop the vehicle in a safe location, turn
the EV system off and clean the windshield.

Parking Sensor

This indicator illuminates when the sensor
is activated. Pressing the OK button while
the sonar screen is displayed will dismiss
this message until the next time the sen-
sors are activated. The Parking Sensor sys-
tem will remain on, unless it is disabled in

2-40

Instruments and controls

the vehicle information display. For addi-
tional information, see “Rear Sonar System
(RSS) (P. 5-168).

Parking Sensor Error: See Owner’s
Manual

This warning illuminates when there is an
error with the system. For additional informa-
tion, see “Rear Sonar System (RSS) (P. 5-168).

ProPILOT Assist/Intelligent
Lane Intervention (I-LI)/
Intelligent Blind Spot
Intervention (I-BSI) indicator

This indicator appears when the following
systems (if so equipped) is engaged:
• ProPILOT Assist system (if so equipped)
• Intelligent Lane Intervention (I-LI)
• Intelligent Blind Spot Intervention (I-BSI)

For additional information, see “ProPILOT
Assist” (P. 5-91), “Intelligent Lane Interven-
tion (I-LI) (P. 5-30), or “Intelligent Blind Spot
Intervention (I-BSI) (P. 5-45).

Rear Automatic Braking
(RAB) system warning
indicator

This indicator appears to indicate the sta-
tus of the Rear Automatic Braking (RAB)
system.

For additional information, see "Rear Auto-
matic Braking (RAB) (P. 5-125).

Steering Assist warning
indicator

This message may appear when the Steer-
ing Assist system is engaged.

It will be displayed under the following
conditions:
• Gray — When in standby mode.
• Yellow — When there is a failure.

When the steering operation is detected,
the warning turns off and the steering as-
sist function is automatically restored.

Steering Assist warning
indicator

This message may appear when the Steer-
ing Assist system is engaged.

It will be displayed under the following
conditions:
• Red — When not holding the steering

wheel or when there is no steering wheel
operation.

• Green — When in active mode.
• Black — When the system is off.

When the steering assist warning indicator
appears red, please hold the steering
wheel immediately. When the steering op-

eration is detected, the warning turns off
and the steering assist function is auto-
matically restored.

Unavailable High Cabin Temperature

This message appears when the camera
detects an interior temperature of more
than approximately 104°F (40°C).

For additional information, see “Lane De-
parture Warning (LDW)” (P. 5-25), “Intelligent
Lane Intervention (I-LI) (P. 5-30) or “Intelli-
gent Blind Spot Intervention (I-BSI) (P. 5-45).

Unavailable Side Radar Obstruction

This warning appears when there is radar
blockage detected. For additional informa-
tion, see “Blind Spot Warning (BSW)” (P. 5-36)
or “Intelligent Blind Spot Intervention (I-BSI)”
(P. 5-45).

Vehicle ahead detection
indicator

This indicator shows when the Automatic
Emergency Braking with Pedestrian Detec-
tion system is engaged and has detected a
vehicle.

For additional information, see “Automatic
Emergency Braking (AEB) with Pedestrian
Detection” (P. 5-130).

Instruments and controls

2-41

WARNING INFORMATION DISPLAYS
(models with a navigation system)

Low battery warning

When the low battery charge indicator
and the master warning light (yellow)

illuminate, the system displays a mes-

sage on the navigation system screen that
warns the driver that the Li-ion battery
power level is low.

1. The notification is displayed on the up-

per left side of the STATUS screen. Touch
[Show] to display the screen showing
detailed information.

2. The system displays a message screen

and announces the contents of the
message to warn that the Li-ion battery
power level is low. Check the message
displayed on the screen.

Touch [YES] to search for charging sta-
tions within the estimated driving range.

3. Touch

or press the

MAP

button to

return to the vehicle location screen.

NOTE:
• The low battery warning can be set to

off. For additional information, refer to
the NissanConnect® Manual.

• When the battery power level is low, the

system automatically obtains charging
station information.

Your vehicle has two types of security sys-
tems, as follows:
• Vehicle security system
• NISSAN Vehicle Immobilizer System
The security status is shown by the secu-
rity indicator light.

VEHICLE SECURITY SYSTEM

The vehicle security system provides visual
and audio alarm signals if someone opens
the doors or rear hatch when the system is
armed. It is not, however, a motion detec-
tion type system that activates when a ve-
hicle is moved or when a vibration occurs.

JVC0067X

SECURITY SYSTEMS

2-42

Instruments and controls

The system helps deter vehicle theft but
cannot prevent it, nor can it prevent the
theft of interior or exterior vehicle compo-
nents in all situations. Always secure your
vehicle even if parking for a brief period.
Never leave your keys in the vehicle, and
always lock it when it is left unattended. Be
aware of your surroundings, and park in
secure, well-lit areas whenever possible.

Many devices offering additional protec-
tion, such as component locks, identifica-
tion markers, and tracking systems, are
available at auto supply stores and spe-
cialty shops. A NISSAN certified LEAF dealer
may also offer such equipment. Check with
your insurance company to see if you may
be eligible for discounts for various theft
protection features.

How to arm the vehicle security
system

1. Close all windows.

The system can be armed even if the
windows are open.

2. Place the power switch in the LOCK or

OFF position and remove the Intelligent
Key from the vehicle.

3. Close all doors. Lock all doors. The doors

can be locked with:

• the LOCK

button on the Intelli-

gent Key

• any request switch
• the power door lock switch

4. Confirm that the security indicator light

illuminates. The security indicator light
stays on for about 30 seconds. The ve-
hicle security system is now pre-armed.
After about 30 seconds the vehicle se-
curity system automatically shifts into
the armed phase. The security light be-
gins to flash once every approximately
3 seconds. If, during this 30-second pre-
arm time period, the door is unlocked, or
the power switch is placed in the ACC or
ON position, the system will not arm.

Even when the driver and/or passengers
are in the vehicle, the system will acti-
vate with all doors locked and the power
switch in the OFF position. When placing
the power switch to the ACC or ON posi-
tion, the system will be released.

Vehicle security system activation

The vehicle security system will give the
following alarm:
• The headlights blink and the horn sounds

intermittently.

• The alarm automatically turns off after

approximately 50 seconds. However, the
alarm reactivates if the vehicle is tam-
pered with again.

The alarm is activated by:
• Unlocking the door without using the In-

telligent Key or the request switch. (Even if
the door is opened by releasing the door
inside lock knob, the alarm will activate.)

• Opening the hood.

How to stop an activated alarm

The alarm will stop when a door is un-
locked by pushing the UNLOCK

but-

ton on the Intelligent Key, door handle
request switch, or when the power switch
is pushed in the ACC or ON position.

If the system does not operate as de-
scribed above, have it checked. It is rec-
ommended that you visit a NISSAN certi-
fied LEAF dealer for this service.

Instruments and controls

2-43

NISSAN VEHICLE IMMOBILIZER
SYSTEM

The NISSAN Vehicle Immobilizer System
will not allow the power switch to be placed
in the READY to drive position without the
use of the registered key.

If the power switch fails to place the vehicle
into the READY to drive position using the
registered key, it may be due to interfer-
ence caused by another registered key, an
automated toll road device or automated
payment device on the key ring. Restart the
EV system using the following procedure:

1. Leave the power switch in the ON posi-

tion for approximately 5 seconds.

2. Place the power switch in the OFF posi-

tion and wait approximately 10 seconds.

3. Repeat step 1 and 2 again.

4. Place the power switch in the READY to

drive position while holding the device
(which may have caused the interfer-
ence) separate from the registered key.

If this procedure allows the power switch
to be placed in the READY to drive mode,
NISSAN recommends placing the regis-
tered key on a separate key ring to avoid
interference from other devices.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference
that may cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s author-
ity to operate the equipment.

For Canada:

This

device

contains

licence-exempt

transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence-exempt
RSS(s). Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause interference. (2) This de-
vice must accept any interference, in-
cluding interference that may cause un-
desired operation of the device.

Security Indicator Light

The security indicator light is located on
the meter panel. It indicates the status of
the NISSAN Vehicle Immobilizer System.

The light blinks after the power switch was
in the ACC or OFF position. This function
indicates the security systems equipped
on the vehicle are operational.

If the NISSAN Vehicle Immobilizer System is
malfunctioning, this light will remain on while
the power switch is in the ON position.

SIC2045

2-44

Instruments and controls

If the light still remains on and/or the
power switch cannot be placed in the
READY to drive position, have the system
checked. It is recommended that you
visit a NISSAN certified LEAF dealer for
this service as soon as possible. Please
bring all registered keys that you have
when visiting a NISSAN certified LEAF
dealer for service.

WARNING

In freezing temperatures the washer
solution may freeze on the windshield
and obscure your vision which may
lead to an accident. Warm the wind-
shield with the defroster before you
wash the windshield.

CAUTION

•

Do not operate the washer continu-
ously for more than 30 seconds.

•

Do not operate the washer if the
windshield-washer fluid reservoir is
empty.

•

Do not fill the windshield-washer fluid
reservoir with windshield-washer fluid
concentrates at full strength. Some
methyl

alcohol

based

windshield-

washer fluid concentrates may perma-
nently stain the grille if spilled while
filling

the

windshield-washer

fluid

reservoir.

•

Pre-mix windshield-washer fluid con-
centrates with water to the manufac-
turer’s recommended levels before
pouring the fluid into the windshield-
washer fluid reservoir. Do not use the
windshield-washer fluid reservoir to
mix the windshield-washer fluid con-
centrate and water.

NOTE:

If the windshield wiper operation is in-
terrupted by snow or ice, the wiper may
stop moving to protect its motor. If this
occurs, turn the wiper switch to the OFF
position and remove the snow or ice that
is on and around the wiper arms. In ap-
proximately 1 minute, turn the switch on
again to operate the wiper.

WIPER AND WASHER SWITCH

Instruments and controls

2-45

The windshield wiper and washer operates
when the power switch is in the ON posi-
tion.

Push the lever down to operate the wiper
at the following speed:

䊊

Intermittent — intermittent operation
can be adjusted by turning the knob
toward

(Slower) or

(Faster). Also,

the intermittent operation speed varies
in accordance with the vehicle speed.
(For example, when the vehicle speed is
high, the intermittent operation speed
will be faster.)

䊊

Low — continuous low speed operation.

䊊

High — continuous high speed operation.

䊊

MIST — one sweep operation of the wiper.

The Speed Dependent feature may be
disabled. For additional information, see
“Vehicle information display” (P. 2-26).

WASHER OPERATION

To operate the washer, pull the lever to-
ward the back of the vehicle

until the

desired amount of windshield-washer fluid
is spread on the windshield. The wiper will
automatically operate several times.

Drip Wipe

A brief period of time after using the
washer, the wiper will perform a one sweep
operation automatically to clear any re-
maining windshield-washer fluid from the
windshield.

REAR WIPER OPERATION

WARNING

In freezing temperatures the windshield-
washer fluid may freeze on the rear win-
dow glass and obscure your vision. Warm
the rear window with the defroster before
you wash the rear window.

LIC2802

LIC2813

2-46

Instruments and controls

CAUTION

•

Do not operate the washer continu-
ously for more than 30 seconds.

•

Do not operate the washer if the
windshield-washer fluid reservoir is
empty.

•

Do not fill the windshield-washer fluid
reservoir with windshield-washer fluid
concentrates at full strength. Some
methyl

alcohol

based

windshield-

washer fluid concentrates may perma-
nently stain the grille if spilled while
filling

the

windshield-washer

fluid

reservoir.

•

NOTE:

If the rear window wiper operation is in-
terrupted by snow etc., the wiper may
stop moving to protect its motor. If this
occurs, turn the wiper switch to the OFF
position and remove the snow etc. on
and around the wiper arms. After about
1 minute, turn the switch on again to op-
erate the wiper.

The rear window wiper and washer oper-
ate when the power switch is in the ON
position.

Turn the switch clockwise from the OFF
position to operate the wiper.

䊊

Intermittent (INT) — intermittent opera-
tion (not adjustable)

䊊

Low (ON) — continuous low speed op-
eration

Push the switch forward

䊊

to operate the

washer. Then the wiper will also operate
several times.

To defrost the rear window glass and out-
side mirrors, place the power switch in
the ON position and push the switch (1) on.
The indicator light will illuminate. Push the
switch again to turn the defroster off.

It will automatically turn off in approxi-
mately 15 minutes.

LIC2693

Type A (if so equipped)

REAR WINDOW AND OUTSIDE
MIRROR (if so equipped)
DEFROSTER SWITCH

Instruments and controls

2-47

CAUTION

When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.

HEADLIGHT SWITCH

Lighting

䊊

Rotate the switch to the

position,

the front parking, tail, license plate, and
instrument panel lights come on.

䊊

Rotate the switch to the

position,

the headlights come on and all the
other lights remain on.

LIC3026

Type B (if so equipped)

SIC3668

Type A (if so equipped)

LIC3241

Type B (if so equipped)

HEADLIGHT AND TURN SIGNAL
SWITCH

2-48

Instruments and controls

Autolight system

The autolight system allows the headlights
and tail lights to be set so they turn on and
off automatically.

To set the autolight system:

1. Make sure the headlight switch is in the

AUTO position

2. Place the power switch in the ON position.

3. The autolight system automatically turns

the headlights and tail lights on and off.

To turn the autolight system off, turn the
switch to the OFF,

position.

LIC4564

Type C (if so equipped)

LIC4597

Type D (if so equipped)

SIC3669

Instruments and controls

2-49

The autolight system can turn on the
headlights and tail lights automatically
when it is dark and turn off the headlights
when it is light.

For US models: The headlights and tail
lights will also be turned on automatically
at twilight or in rainy weather (when the
windshield wiper is operated continuously).

If the power switch is placed in the OFF
position and one of the doors is opened
and this condition continues, the head-
lights remain on for 45 seconds.

Automatic headlights off delay

You can keep the headlights on for up to
180 seconds after you push the power
switch to OFF and open any door then
close all the doors.

You can adjust the period of the automatic
headlights off delay from 0 seconds (OFF)
to 180 seconds. The factory default setting
is 45 seconds.

NOTE:
For additional information on adjust-
ing the automatic headlights off de-
lay, see “Vehicle information display”
(P. 2-26).

Be sure not to put anything on top of the
photo sensor

located on the top of

the instrument panel. The photo sensor
controls the autolight; if it is covered, the
photo sensor reacts as if it is dark and
the headlights will illuminate.

Headlight beam select

䊊

To select the low beam, have the lever
in the neutral position as shown and
rotate the switch to the desired posi-
tion. For additional information, see
“Headlight switch” (P. 2-48).

䊊

To select the high beam, push the lever
forward while the switch is in the
position. The high beams will come on
and the high beam indicator (blue)
will illuminate. Pull it back to return to
the low beam.

䊊

Pulling the lever toward you will flash the
headlight high beam even when the
headlight switch is in the OFF position.

SAA1232

SIC3670

2-50

Instruments and controls

High Beam Assist

The High Beam Assist system will operate
when the vehicle is driven at speeds of
approximately 19 mph (30 km/h) and
above. If an oncoming vehicle or leading
vehicle appears in front of your vehicle
when the headlight high beam is on, the
headlight will be switched to the low beam
automatically.

WARNING

•

The High Beam Assist system is a
convenience but it is not a substi-
tute for safe driving operation. The
driver should remain alert at all
times, ensure safe driving practices
and switch the high beams and low
beam manually when necessary.

•

The high beam or low beam may not
switch automatically under the fol-
lowing conditions. Switch the high
beam and low beam manually.

–

During bad weather (rain, fog, snow,

wind, etc.).

–

When a light source similar to a

headlight or tail light is in the
vicinity of the vehicle.

–

When the headlights of the oncom-

ing vehicle or the leading vehicle
are turned off, when the color of the
light is affected due to foreign ma-
terials on the lights, or when the
light beam is out of position.

–

When there is a sudden, continu-

ous change in brightness.

–

When driving on a road that passes

over rolling hills, or a road that has
level differences.

–

When driving on a road with many

curves.

–

When a sign or mirror-like surface

is reflecting intense light towards
the front of the vehicle.

–

When the container, etc. being

towed by a leading vehicle is re-
flecting intense light.

–

When a headlight on your vehicle

is damaged or dirty.

–

When the vehicle is leaning at an

angle due to a punctured tire,
being towed, etc.

•

The timing of switching the low beam
and high beam may change under the
following situations.

–

The brightness of the headlights

of the oncoming vehicle or lead-
ing vehicle.

–

The movement and direction of

the oncoming vehicle and the
leading vehicle.

–

When only one light on the on-

coming vehicle or the leading ve-
hicle is illuminated.

–

When the oncoming vehicle or the

leading vehicle is a two-wheeled
vehicle.

–

Road conditions (incline, curve,

the road surface, etc.).

–

The number of passengers and

the amount of luggage.

Instruments and controls

2-51

High Beam Assist operations

To activate the High Beam Assist system,
turn the headlight switch to the AUTO po-
sition

and push the lever forward

(high beam position). The High Beam Assist
indicator light in the meter will illuminate
while the headlights are turned on.

If the High Beam Assist indicator light does
not illuminate in the above condition, it may
indicate that the system is not functioning
properly. Have the system checked. It is
recommended that you visit a NISSAN
certified LEAF dealer for this service.

When the vehicle speed lowers to less than
approximately 12 mph (20 km/h), the head-
light remains the low beam.

To turn off the High Beam Assist system,
turn the headlight switch to the

posi-

tion or select the low beam position by
placing the lever in the neutral position.

Ambient image sensor maintenance

The ambient image sensor for the High
Beam Assist system is located in front of
the inside mirror

. To keep the proper

operation of the High Beam Assist system
and prevent a system malfunction, be sure
to observe the following:
• Always keep the windshield clean.
• Do not attach a sticker (including trans-

parent material) or install an accessory
near the ambient image sensor.

• Do not strike or damage the areas around

the ambient image sensor.

LIC3802

LSD2847

2-52

Instruments and controls

If the ambient image sensor is damaged
due to an accident, it is recommended that
you visit a NISSAN certified LEAF dealer for
this service.

Battery saver system

• When the headlight switch is in the

position while the power switch

is in the ON position, the lights will auto-
matically turn off 45 seconds after the
power switch has been placed in the OFF
position.

• When the headlight switch remains in the

position after the lights

automatically turn off, the lights will turn
on when the power switch is placed in the
ON position.

CAUTION

•

When you turn on the headlight
switch again after the lights auto-
matically turn off, the lights will not
turn off automatically. Be sure to turn
the light switch to the AUTO or OFF
position when you leave the vehicle
for extended periods of time, other-
wise the battery will be discharged.

•

Never leave the light switch on when
the power switch is in the OFF, ACC or
ON position for extended periods of
time even if the headlights turn off
automatically.

LED DAYTIME RUNNING LIGHTS
(DRL) SYSTEM (Type A) (if so
equipped)

The LED portion of the headlights auto-
matically illuminates at 100% intensity
when the power switch is in the READY to
drive position with the parking brake re-
leased. The LED DRL system operates with
the headlight switch in the OFF (if so
equipped) or

position. Turn headlight

switch to the

position for full illumina-

tion when driving at night.

If the parking brake is applied before the
power switch is in the READY to drive posi-
tion, the LED DRL system does not operate.
The LED DRL system illuminates once the
parking brake is released. The LED DRL sys-
tem will remain on until the power switch is
pushed to the OFF position.

WARNING

When the LED DRL system is active, tail
lights on your vehicle are not on. It is
necessary at dusk to turn on your head-
lights. Failure to do so could cause an
accident injuring yourself and others.

LED DAYTIME RUNNING LIGHTS
(DRL) SYSTEM (Type B) (if so
equipped)

The LED DRL automatically illuminate at
100% intensity when the power switch is in
the READY to drive position. The LED Day-
time Running Lights (DRL) operate with the
headlight switch in the OFF (if so equipped)
or

position. When you turn the head-

light switch to the

position for full

illumination, the LED lights switch from LED
DRL to the park function.

The LED DRL will remain on until the power
switch is placed in the OFF position.

It is necessary at dusk to turn the head-
light switch ON for interior controls and
switches to illuminate, as those remain
OFF while the switch is in the OFF position.

Instruments and controls

2-53

WARNING

When the LED DRL system is active, tail
lights on your vehicle are not on. It is
necessary at dusk to turn on your head-
lights. Failure to do so could cause an
accident injuring yourself and others.

INSTRUMENT BRIGHTNESS
CONTROL

Press the “+” button to increase the bright-
ness of the instrument panel lights.

Press the “-” to decrease the brightness of
the instrument panel lights.

TURN SIGNAL SWITCH

Turn signal

Move the lever up or down until it latches

to signal the turning direction. When the turn
is completed, the turn signal cancels auto-
matically.

Lane change signal

Move the lever up or down until the turn

signal begins to flash, but the lever does
not latch, to signal a lane change. Hold the
lever until the lane change is completed.

LIC3801

SIC3671

2-54

Instruments and controls

Move the lever up or down until the turn
signal begins to flash, but the lever does
not latch, and release the lever. The turn
signal will automatically flash three times.

Choose the appropriate method to signal
a lane change based on road and traffic
conditions.

FOG LIGHT SWITCH (if so equipped)

To turn the fog lights on, rotate the head-
light switch to the

position, then

rotate the switch to the

position. To

turn them off, rotate the switch to the OFF
position.

The headlights must be on for the fog
lights to operate.

EMBLEM LIGHT

Regardless of headlight switch position,
the emblem light illuminates when the
power switch is in the ON position and
turns off when the power switch is placed
in the OFF position.

SIC3672

Instruments and controls

2-55

To sound the horn, push the center pad
area of the steering wheel.

WARNING

Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system. Tam-
pering with the supplemental front air
bag system may result in serious per-
sonal injury.

To turn on the ECO mode, push the ECO
switch. The ECO mode indicator appears
on the vehicle information display.

To turn off the ECO mode, push the ECO
switch again. The ECO mode indicator will
turn off.

For additional information, see “ECO mode”
(P. 5-155).

The front seats and the rear outboard
seats (if so equipped) can be warmed by
built-in heaters. The switches, located on
the center console and at the side of the
front passenger seatback, can be operated
independently of each other.

1. Place the power switch in the ON position.

2. Push the LO or HI position of the switch,

as desired, depending on the tempera-
ture. The indicator light in the switch will
illuminate.

3. To turn off the heater, return the switch

to the level position. Make sure the indi-
cator light goes off.

LIC3805

LIC3806

LIC4145

Front

HORN

ECO SWITCH

HEATED SEAT SWITCHES (if so
equipped)

2-56

Instruments and controls

The heater is controlled by a thermostat,
automatically turning the heater on and
off. The indicator light will remain on as long
as the switch is on.

When the vehicle’s interior is warmed, or
before you leave the vehicle, be sure to turn
the switch off.

NOTE:

The heated seats consume less power
than the heater and can be used to either
help extend vehicle range by reducing
heater use or to maximize comfort by
supplementing the heater.

WARNING

Do not use or allow occupants to use
the seat heater if you or the occupants
cannot monitor elevated seat tem-
peratures or have an inability to feel
pain in those body parts in contact with
the seat. Use of the seat heater by such
people could result in serious injury.

CAUTION

•

Do not use the seat heater for ex-
tended periods or when no one is us-
ing the seat.

•

Do not put anything on the seat which
insulates heat, such as a blanket,
cushion, seat cover, etc. Otherwise, the
seat may become overheated.

•

Do not place anything hard or heavy
on the seat or pierce it with a pin
or similar object. This may result in
damage to the heater.

•

Any liquid spilled on the heated seat
should be removed immediately with
a dry cloth.

•

When cleaning the seat, never use gaso-
line, thinner, or any similar materials.

•

If any malfunctions are found or the
heated seat does not operate, turn
the switch off and have the system
checked. It is recommended that you
visit a NISSAN certified LEAF dealer
for this service.

LIC2498

Rear

Instruments and controls

2-57

Nissan Leaf (2024 year). Manual in english - page 7
