Nissan Quest (2017 year). Instruction - part 10

2-60

Instruments and controls

SIC2925

When the switch is in the DOOR position

the light illuminates while the liftgate is opened.
When the liftgate is closed, the light will turn off.

When the switch is in the OFF position

, the

light will turn off.

The lights will turn off after a period of
time when the lights remain illuminated to
prevent the battery from becoming dis-
charged.

The HomeLink

Universal Transceiver provides a

convenient way to consolidate the functions of
up to three individual hand-held transmitters into
one built-in device.

HomeLink

Universal Transceiver:

. Will operate most Radio Frequency (RF)

devices such as garage doors, gates, home
and office lighting, entry door locks and
security systems.

. Is powered by your vehicle’s battery. No

separate batteries are required. If the
vehicle’s battery is discharged or is dis-
connected, HomeLink

will retain all pro-

gramming.

When the HomeLink

Universal Transcei-

ver is programmed, retain the original
transmitter for future programming proce-
dures (Example: new vehicle purchases).
Upon sale of the vehicle, the programmed
HomeLink

Universal Transceiver buttons

should be erased for security purposes.
For additional information, refer to “Pro-
gramming HomeLink

” (P.2-61).

WARNING

. Do not use the HomeLink

Universal

Transceiver with any garage door
opener that lacks safety stop and

reverse features as required by
federal safety standards. (These
standards became effective for
opener models manufactured after
April 1, 1982). A garage door opener
which cannot detect an object in the
path of a closing garage door and
then automatically stop and reverse,
does not meet current federal safety
standards. Using a garage door
opener without these features in-
creases the risk of serious injury or
death.

. During the programming procedure

your garage door or security gate
will open and close (if the transmit-
ter is within range). Make sure that
people or objects are clear of the
garage door, gate, etc. that you are
programming.

. Your vehicle’s engine should be

turned off while programming the
HomeLink

Universal Transceiver.

Do not breathe exhaust gases; they
contain colorless and odorless car-
bon monoxide. Carbon monoxide is
dangerous. It can cause uncon-
sciousness or death.

CARGO LIGHTS

HomeLink

UNIVERSAL

TRANSCEIVER (if so equipped)

PROGRAMMING HomeLink

If you have any questions or are having difficulty
programming your HomeLink

buttons, refer to

the HomeLink

web site at: www.homelink.com

or call 1-800-355-3515.

NOTE:

It is also recommended that a new battery
be placed in the hand-held transmitter of
t h e

d e v i c e

b e i n g

p r o g r a m m e d

t o

HomeLink

for quicker programming and

accurate transmission of the radio-fre-
quency.

1. Position the end of your hand-held transmit-

ter 1-3 in (26-76 mm) away from the
HomeLink

surface, keeping the HomeLink

indicator light

in view.

JVI0428X

2. Using both hands, simultaneously press and

hold the desired HomeLink

button and

handheld transmitter button. DO NOT re-
lease until the HomeLink

indicator light

flashes slowly and then rapidly. When the
indicator light flashes rapidly, both buttons
may be released. (The rapid flashing indi-
cates successful programming.)

NOTE:
Some devices to be programmed may
require you to replace Step 2 with the
cycling procedure noted in the “Pro-
gramming HomeLink

for Canadian

Customers and gate openers” (P.2-62).

JVI0429X

3. Press and hold the programmed HomeLink

button and observe the indicator light.

If the indicator light

is solid/contin-

uous, programming is complete and your
device should activate when the
HomeLink

button is pressed and re-

leased.

If the indicator light

blinks rapidly for

two seconds and then turns to a solid/
continuous light, continue with Steps 4-6
for a rolling code device. A second
person may make the following steps
easier. Use a ladder or other device. Do
not stand on your vehicle to perform the
next steps.

Instruments and controls

2-61

2-62

Instruments and controls

4. At the receiver located on the garage door

opener motor in the garage, locate the
“learn” or “smart” button (the name and
color of the button may vary by manufacturer
but it is usually located near where the
hanging antenna wire is attached to the
unit). If there is difficulty locating the button,
reference the garage door opener’s manual.

5. Press and release the “learn” or “smart”

button.

NOTE:
Once the button is pressed, you have
approximately 30 seconds to initiate
the next step.

6. Return to the vehicle and firmly press and

hold the programmed HomeLink

button for

two seconds and release. Repeat the
“press/hold/release” sequence up to 3
times to complete the programming pro-
cess. HomeLink

should now activate your

rolling code equipped device.

7. If you have any questions or are having

difficulty programming your HomeLink

but-

tons, refer to the HomeLink

web site at:

www.homelink.com or call 1-800-355-
3515.

PROGRAMMING HomeLink

FOR CA-

NADIAN CUSTOMERS AND GATE
OPENERS

Canadian radio-frequency laws require trans-
mitter signals to “time-out” (or quit) after several
seconds of transmission – which may not be
long enough for HomeLink

to pick up the signal

during programming. Similar to this Canadian
law, some U.S. gate operators are designed to
“time-out” in the same manner.

If you live in Canada or you are having difficulties
programming a gate operator or garage door
opener by using the “Programming HomeLink

”

procedures, replace “Programming HomeLink

”

Step 2 with the following:

NOTE:

When programming a garage door opener,
etc., unplug the device during the “cycling”
process to prevent possible damage to the
garage door opener components.

Step 2: Using both hands, simultaneously press
and hold the desired HomeLink

button and the

hand-held transmitter button. During program-
ming, your hand-held transmitter may automati-
cally stop transmitting. Continue to press and
hold the desired HomeLink

button while you

press and re-press (“cycle”) your hand-held
transmitter every two seconds until the fre-
quency signal has been learned. The HomeLink

indicator light will flash slowly and then rapidly
after several seconds upon successful program-
ming. DO NOT release until the HomeLink

indicator light flashes slowly and then rapidly.
When the indicator light flashes rapidly, both
buttons may be released. The rapid flashing
indicates successful programming.

Proceed with “Programming HomeLink

” step 3

to complete.

Remember to plug the device back in when
programming is completed.

OPERATING THE HomeLink

UNIVER-

SAL TRANSCEIVER

The HomeLink

Universal Transceiver, after it is

programmed, can be used to activate the
programmed device. To operate, simply press
and release the appropriate programmed
HomeLink

Universal Transceiver button. The

amber indicator light will illuminate while the
signal is being transmitted.

For convenience, the hand-held transmitter of
the device may also be used at any time.

PROGRAMMING TROUBLESHOOT-
ING

If the HomeLink

does not quickly learn the

hand-held transmitter information:
. replace the hand-held transmitter batteries

with new batteries.

. position the hand-held transmitter with its

battery area facing away from the
HomeLink

surface.

. press and hold both the HomeLink

and

hand-held transmitter buttons without inter-
ruption.

. position the hand-held transmitter 1-3 in

(26-76 mm) away from the HomeLink

surface. Hold the transmitter in that position
for up to 15 seconds. If HomeLink

is not

programmed within that time, try holding the
transmitter in another position - keeping the
indicator light in view at all times.

If you have any questions or are having difficulty
programming your HomeLink

buttons, refer to

the HomeLink

web site at: www.homelink.com

or 1-800-355-3515.

CLEARING THE PROGRAMMED IN-
FORMATION

The following procedure clears the programmed
information from both buttons. Individual buttons
cannot be cleared. However, individual buttons
can be reprogrammed, see “Reprogramming a
single HomeLink

button” (P.2-63).

To clear all programming

1. Press and hold the two outer HomeLink

buttons until the indicator light begins to
flash in approximately 10 seconds. Do not
hold for longer than 20 seconds.

2. Release both buttons.

HomeLink

is now in the programming mode

and can be programmed at any time beginning
with “Programming HomeLink

” - Step 1.

REPROGRAMMING A SINGLE
HomeLink

BUTTON

To reprogram a HomeLink

Universal Transcei-

ver button, complete the following.

1. Press and hold the desired HomeLink

button. DO NOT release the button.

2. The indicator light will begin to flash after 20

seconds. Without releasing the HomeLink

button, proceed with “Programming
HomeLink

” - Step 1.

For questions or comments, contact HomeLink

at: www.homelink.com or 1-800-355-3515.

The HomeLink

Universal Transceiver button

has now been reprogrammed. The new device
can be activated by pushing the HomeLink

button that was just programmed. This proce-
dure will not affect any other programmed
HomeLink

buttons.

IF YOUR VEHICLE IS STOLEN

If your vehicle is stolen, you should change the
codes of any non-rolling code device that has
been programmed into HomeLink

. Consult the

Owner’s Manual of each device or call the
manufacturer or dealer of those devices for
additional information.

When your vehicle is recovered, you will
need to reprogram the HomeLink

Univer-

sal Transceiver with your new transmitter
information.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.

Instruments and controls

2-63

2-64

Instruments and controls

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.

For Canada:

This device complies with Industry Canada
licence-exempt RSS standard(s). Opera-
tion is subject to the following two condi-
tions: (1) this device may not cause
interference, and (2) this device must
accept any interference, including interfer-
ence that may cause undesired operation
of the device.

3 Pre-driving checks and adjustments

Keys .............................................................................................. 3-3

Intelligent Key system ......................................................... 3-3
Mechanical key .................................................................... 3-4
Valet hand-off ....................................................................... 3-5

Doors ............................................................................................ 3-5

Power sliding door (if so equipped) ................................. 3-10

Precautions on power sliding door operation ........... 3-10
Switching sliding door operation ................................. 3-11
Operating sliding door switch ...................................... 3-12
Operating the power sliding door with the
Intelligent Key (if so equipped) ..................................... 3-12
Operating sliding door by power assist ..................... 3-13
Sliding door auto reverse function .............................. 3-13

Intelligent Key system ........................................................... 3-13

Intelligent Key operating range ................................... 3-15
Door locks/unlocks precaution ................................... 3-15
Intelligent Key operation ............................................... 3-16
Battery saver system ..................................................... 3-19
Warning signals .............................................................. 3-19
Troubleshooting guide .................................................. 3-20

Remote keyless entry system ............................................. 3-21

How to use remote keyless entry system ................ 3-22

Hood ......................................................................................... 3-25
Liftgate ..................................................................................... 3-26

Operating manual liftgate ............................................. 3-26
Operating power liftgate (if so equipped) ............... 3-26
Auto closure .................................................................... 3-29
Liftgate release ............................................................... 3-30

Fuel-filler door ........................................................................ 3-30

Opening fuel-filler door ................................................ 3-30
Fuel-filler cap .................................................................. 3-30

Tilt/telescopic steering ......................................................... 3-32

Tilt or telescopic operation .......................................... 3-32

Sun visors ................................................................................ 3-33

Mirrors ....................................................................................... 3-33

Inside mirror ....................................................................... 3-33
Outside mirrors ................................................................. 3-35
Vanity mirror ....................................................................... 3-36

Automatic drive positioner (if so equipped) ................... 3-36

Entry/exit function .......................................................... 3-36
Memory storage .............................................................. 3-37
System operation ........................................................... 3-38

A key number plate is supplied with your keys.
Record the key number and keep it in a safe
place (such as your wallet), not in the vehicle. If
you lose your keys, it is recommended you visit a
NISSAN dealer for duplicates by using the key
number. NISSAN does not record any key
numbers so it is very important to keep track of
your key number plate.

A key number is only necessary when you have
lost all keys and do not have one to duplicate
from. If you still have a key, it can be duplicated
without knowing the key number.

SPA2406

Type A (if so equipped)

SPA2844

Type B (if so equipped)

SPA2845

Type C (if so equipped)

Master key (2)

Mechanical key (inside the key) (2)

Key number plate (1)

INTELLIGENT KEY SYSTEM

Your vehicle can only be driven with the
Intelligent Keys which are registered to your
vehicle’s Intelligent Key system components and
NISSAN Vehicle Immobilizer System compo-
nents. As many as 4 Intelligent Keys can be
registered and used with one vehicle. The new
keys must be registered by a NISSAN dealer
prior to use with the Intelligent Key system and
NISSAN Vehicle Immobilizer System of your
vehicle. Since the registration process requires
erasing all memory in the Intelligent Key compo-

Pre-driving checks and adjustments

3-3

KEYS

3-4

Pre-driving checks and adjustments

nents when registering new keys, be sure to take
all Intelligent Keys that you have to the NISSAN
dealer.

CAUTION

. Be sure to carry the Intelligent Key

with you when driving. The Intelli-
gent Key is a precision device with a
built-in transmitter. To avoid dama-
ging it, please note the following.

— The Intelligent Key is water

resistant; however, wetting may
damage the Intelligent Key. If
the Intelligent Key gets wet,
immediately wipe until it is com-
pletely dry.

— Do not bend, drop or strike it

against another object.

— If the outside temperature is

below 14

8F (-108C) degrees, the

battery of the Intelligent Key
may not function properly.

— Do not place the Intelligent Key

for an extended period in a
place where temperatures ex-
ceed 140

8F (608C).

— Do not change or modify the

Intelligent Key.

— Do not use a magnet key holder.

— Do not place the Intelligent Key

near an electric appliance such
as a television set, personal
computer or cellular phone.

— Do not allow the Intelligent Key

to come into contact with water
or salt water, and do not wash it
in a washing machine. This
could affect the system function.

. If an Intelligent Key is lost or stolen,

NISSAN recommends erasing the ID
code of that Intelligent Key. This will
prevent the Intelligent Key from
unauthorized use to unlock the
vehicle. For information regarding
the erasing procedure, it is recom-
mended you visit a NISSAN dealer.

SPA2033

MECHANICAL KEY

To remove the mechanical key, release the lock
knob at the back of the key.

To install the mechanical key, firmly insert it into
the key until the lock knob returns to the lock
position.

Use the mechanical key to lock or unlock the
doors and glove box, if they are equipped with a
key cylinder.

See “Doors” (P.3-5) and “Storage” (P.2-44).

CAUTION

Always carry the mechanical key in-
stalled in the key.

VALET HAND-OFF

When you have to leave a key with a valet, give
them the Intelligent Key itself after removing the
mechanical key to protect your belongings.

To prevent the glove box from being opened
during valet hand-off, follow the procedures
below.

1. Remove the mechanical key from the In-

telligent Key.

2. Lock the glove box with the mechanical key.

3. Hand the Intelligent Key to the valet, keeping

the mechanical key in your pocket or bag.
Insert the mechanical key into the Intelligent
Key when you retrieve your vehicle.

For glove box lock, see “Storage” (P.2-44).

WARNING

. Always have the doors locked while

driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping
to prevent persons from being
thrown from the vehicle. This also
helps keep children and others from
unintentionally opening the doors,
and will help keep out intruders.

. Before opening any door, always

look for and avoid oncoming traffic.

. To help avoid risk of injury or death

through unintended operation of
the vehicle and or its systems,
including entrapment in windows
or inadvertent door lock activation,
do not leave children, people who
require the assistance of others or
pets unattended in your vehicle.
Additionally, the temperature inside
a closed vehicle on a warm day can
quickly become high enough to
cause a significant risk of injury or
death to people and pets.

SPA2527-B

LOCKING WITH MECHANICAL KEY

The power door lock system allows you to lock
or unlock all doors simultaneously using the
mechanical key.
. Turning the driver’s door key cylinder to the

rear of the vehicle

will lock all doors.

. Turning the driver’s door key cylinder once

to the front of the vehicle

will unlock the

driver’s door. After returning the key to the
neutral position

, turning it to the front

again within 5 seconds will unlock all doors.

. Models with center multi-function control

panel:
You can switch the lock system to the mode
that allows you to open all the doors when

Pre-driving checks and adjustments

3-5

DOORS

3-6

Pre-driving checks and adjustments

the key is turned once. (See “How to use
SETTING button” (P.4-15).)

OPENING AND CLOSING WINDOWS
WITH THE MECHANICAL KEY (if so
equipped)

The driver’s door key operation also allows you
to open and close the window that is equipped
with the automatic open/close function. (See
“Power windows” (P.2-52).)

To open the windows, turn the driver’s door key
cylinder to the front of the vehicle for longer
than 1 second. The door is unlocked and the
window keeps opening while turning the key.

This function can also be performed by pushing
and holding the door UNLOCK button of the
key. (See “Remote keyless entry system” (P.3-
21).)

To close the windows, turn the driver’s door key
cylinder to the rear of the vehicle for longer
than 1 second. The door is locked and the
window keeps closing while turning the key.

SPA2847

LOCKING WITH INSIDE LOCK KNOB

To lock the door individually, move the inside
lock knob to the lock position

then close the

door.

To unlock, move the inside lock knob to the
unlock position

When locking the door without Intelligent
Key, be sure not to leave the Intelligent
Key inside the vehicle.

SPA2300

LOCKING WITH POWER DOOR LOCK
SWITCH

Operating the power door lock switch will lock
or unlock all the doors. The switches are located
on the driver’s and front passenger’s door
armrests.

To lock the doors, push the power door lock
switch to the lock position

with the driver’s

or front passenger’s door open, then close the
door.

When locking the door this way, be certain
not to leave the Intelligent Key inside the
vehicle.

To unlock the doors, push the power door lock
switch to the unlock position

Lockout protection

When the power door lock switch (driver or front
passenger) is moved to the lock position with
any door open, all doors will lock and unlock
automatically. With the Intelligent Key left in the
vehicle and any door open, all doors will unlock
automatically and a chime will sound after the
door is closed.

These functions help to prevent the Intelligent
Key from being accidentally locked inside the
vehicle.

AUTOMATIC DOOR LOCKS

. All doors will be locked automatically when

the vehicle speed reaches 15 MPH (24
km/h).

. All doors will be unlocked automatically

when the ignition switch is placed in the
OFF position.

The automatic unlock function can be
deactivated or activated. To deactivate or
activate the automatic door unlock system,
perform the following procedure:

1. Close all doors.

2. Place the ignition switch in the ON position.

3. Within 20 seconds of performing Step 2,

push and hold the power door lock switch to
the

position (UNLOCK) for more than 5

seconds.

4. When activated, the hazard indicator will

flash twice. When deactivated, the hazard
indicator will flash once.

5. The ignition switch must be placed in the

OFF and ON position again between each
setting change.

When the automatic door unlock system is
deactivated, the doors do not unlock when the
ignition switch is placed in the OFF position. To
unlock the door manually, use the inside lock
knob or the power door lock switch (driver’s or
front passenger’s side).

SLIDING DOORS

CAUTION

. Always use the door handle to open

or close the sliding door. Do not
attempt to open or close the door by
merely placing your hand on the
door edge or door slide roller as this
may cause injury.

. When opening the door on a slope,

be sure to fully open the door until it

locks.

Pre-driving checks and adjustments

3-7

3-8

Pre-driving checks and adjustments

SPA2818

Locking with inside lock knob

To lock without an Intelligent Key, push the lock
knob to the lock position

, and then close the

door.

To unlock, pull the inside lock knob to the unlock
position

SPA2387

Opening/Closing the sliding door

The sliding door will be latched at the fully
opened/closed position.

To open/close the sliding door manually, pull the
door handle or the inside door handle.

SPA2104

CAUTION

Do not put your hands or feet on the
harness

or the bracket

. This

may cause damage to the vehicle or
personal injury.

SPA2701

CAUTION

Before closing the sliding door, make
sure that no objects are placed on the
door step. Otherwise, the harness

could be damaged.

SLIDING DOOR AUTO CLOSURE
FUNCTION (if so equipped)

The auto closure function will operate when the
sliding door is not fully closed.

WARNING

When the auto closure function is
operating, keep hands and feet away
from the sliding door to prevent inju-
ries.

SPA2819

CHILD SAFETY SLIDING DOOR LOCK

The child safety sliding door locks help prevent
sliding doors from being opened accidentally,
especially when small children are in the vehicle.

When the levers are in the lock position

, the

child safety sliding door locks engage and the
sliding doors can only be opened by the outside
door handles.

To disengage, move the levers to the unlock
position

Pre-driving checks and adjustments

3-9

3-10

Pre-driving checks and adjustments

The power sliding door system will allow you to
open or close the sliding doors automatically
using the door handles, the sliding door switch,
the Intelligent Key or sliding door one-touch
switch.

JVP0184X

WARNING

. There are some small distances

immediately before the closed posi-
tion which cannot be detected.
Make sure that all passengers have
their hands, feet etc., inside the
vehicle before closing the door.

. Do not put your hands or feet on the

vehicle body

or the sliding door

while operating the sliding door.

. Operate the sliding door only when

the vehicle is completely stopped.

. Before operating the power sliding

door, be sure there is nothing inter-
fering with the door opening or
closing.

. Do not operate the power sliding

door when the vehicle is on a steep
incline.

. Do not touch the sliding door rail or

cable. If you touch the power sliding
door cable the door could automa-
tically operate.

PRECAUTIONS ON POWER SLIDING
DOOR OPERATION

. Do not perform the power sliding door

operation frequently when the engine
is stopped. This could cause a dis-
charged battery.

. Do not start the engine while the

sliding door is in an power operation.
The door may not operate properly.

. Make sure that the sliding doors are closed

before starting the vehicle.

. Under the following cases, turn the power

door main switch off:
— When the sliding door is malfunctioning.
— When operating the sliding door manu-

ally.

POWER SLIDING DOOR (if so
equipped)

— When you need to keep the sliding door

open for a period of time.

— When washing the vehicle or performing

any maintenance work.

SPA2071

. Be careful not to damage the sensor

the sliding door.

When reconnecting the battery cable with the
sliding door open (in case of a discharged
battery, etc.), be sure to fully close the sliding
door manually once before performing the
power operation. Otherwise, the power open
or close function may not operate properly.

SPA2547

Power door main switch

SWITCHING SLIDING DOOR OPERA-
TION

Using the power door main switch located on
the instrument panel, you can switch the sliding
door between power and manual operation. To
turn on the power operating mode, push the
switch to the ON position. To turn off the power
operation, push the switch to the OFF position,
and then the sliding door can be manually
operated.

When the power door main switch is pushed to
the “OFF” position, the power operation is not
available by the sliding door one-touch switch
and power assist.

Pre-driving checks and adjustments

3-11

Content .. 8 9 10 11 ..
