Nissan Cube (2014 year). Instruction

4-24

Center display, heater, air conditioner, audio and phone systems

. The iPod nano

(1st Generation) may

remain in fast forward or rewind mode if it
is connected during a seek operation. In this
case, please manually reset the iPod

. If you are using an iPod

(3rd Generation

with Dock connector), do not use very long
names for the song title, album name or
artist name to avoid the iPod

from resetting

itself.

. Be careful not to do the following, or the

cable could be damaged and a loss of
function may occur.
— Bend the cable excessively (1.6 in (40

mm) radius minimum).

— Twist the cable excessively (more than

180 degrees).

— Pull or drop the cable.
— Store objects with sharp edges in the

storage where the cable is stored.

— Spill liquids on the cable and connectors.

. Do not connect the cable to the iPod

if the

cable and/or connectors are wet. It may
damage the iPod

. If the cable and connectors are exposed to

water, allow the cable and/or connectors to
dry completely before connecting the cable
to the iPod

(wait 24 hours for it to dry).

. If the connector is exposed to fluids other

than water, evaporative residue may cause a
short between the connector pins. In this
case, replace the cable, otherwise damage
to the iPod

and a loss of function may

occur.

. If the cable is damaged (insulation cut,

connectors cracked, contamination such as
liquids, dust, dirt, etc. in the connectors), do
not use the cable and contact a NISSAN
dealer to replace the cable with a new one.

. When not in use for extended periods of

time, store the cable in a clean, dust free
environment at room temperature and with-
out direct sun exposure.

. Do not use the cable for any other purposes

other than its intended use in the vehicle.

. iPod

charging is only possible for devices

that support charging via a FireWire

connection.

12V-charge iPod

s are not chargeable with this

system.

iPod

, iPhone

and FireWire

are trademarks of

Apple Inc., registered in the U.S. and other
countries.

Compact Disc (CD) with MP3 or WMA
(if so equipped)

Explanation of terms:
. MP3 — MP3 is short for Moving Pictures

Experts Group Audio Layer 3. MP3 is the
most well-known compressed digital audio
file format. This format allows for near “CD
quality” sound, but at a fraction of the size of
normal audio files. MP3 conversion of an
audio track from CD-ROM can reduce the
file size by approximately 10:1 ratio (Sam-
pling: 44.1 kHz, Bit rate: 128 kbps) with
virtually no perceptible loss in quality. MP3
compression removes the redundant and
irrelevant parts of a sound signal that the
human ear doesn’t hear.

. WMA — Windows Media Audio (WMA) is a

compressed audio format created by Micro-
soft as an alternative to MP3. The WMA
codec offers greater file compression than
the MP3 codec, enabling storage of more
digital audio tracks in the same amount of
space when compared to MP3s at the same
level of quality.

. Bit rate — Bit rate denotes the number of

bits per second used by a digital music files.
The size and quality of a compressed digital
audio file is determined by the bit rate used
when encoding the file.

4-24

Center display, heater, air conditioner, audio and phone systems

. The iPod nano

(1st Generation) may

remain in fast forward or rewind mode if it
is connected during a seek operation. In this
case, please manually reset the iPod

. If you are using an iPod

(3rd Generation

with Dock connector), do not use very long
names for the song title, album name or
artist name to avoid the iPod

from resetting

itself.

. Be careful not to do the following, or the

cable could be damaged and a loss of
function may occur.
— Bend the cable excessively (1.6 in (40

mm) radius minimum).

— Twist the cable excessively (more than

180 degrees).

— Pull or drop the cable.
— Store objects with sharp edges in the

storage where the cable is stored.

— Spill liquids on the cable and connectors.

. Do not connect the cable to the iPod

if the

cable and/or connectors are wet. It may
damage the iPod

. If the cable and connectors are exposed to

water, allow the cable and/or connectors to
dry completely before connecting the cable
to the iPod

(wait 24 hours for it to dry).

. If the connector is exposed to fluids other

than water, evaporative residue may cause a
short between the connector pins. In this
case, replace the cable, otherwise damage
to the iPod

and a loss of function may

occur.

. If the cable is damaged (insulation cut,

connectors cracked, contamination such as
liquids, dust, dirt, etc. in the connectors), do
not use the cable and contact a NISSAN
dealer to replace the cable with a new one.

. When not in use for extended periods of

time, store the cable in a clean, dust free
environment at room temperature and with-
out direct sun exposure.

. Do not use the cable for any other purposes

other than its intended use in the vehicle.

. iPod

charging is only possible for devices

that support charging via a FireWire

connection.

12V-charge iPod

s are not chargeable with this

system.

iPod

, iPhone

and FireWire

are trademarks of

Apple Inc., registered in the U.S. and other
countries.

Compact Disc (CD) with MP3 or WMA
(if so equipped)

Explanation of terms:
. MP3 — MP3 is short for Moving Pictures

. WMA — Windows Media Audio (WMA) is a

. Bit rate — Bit rate denotes the number of

bits per second used by a digital music files.
The size and quality of a compressed digital
audio file is determined by the bit rate used
when encoding the file.

. Sampling frequency — Sampling frequency

is the rate at which the samples of a signal
are converted from analog to digital (A/D
conversion) per second.

. Multisession — Multisession is one of the

methods for writing data to media. Writing
data once to the media is called a single
session, and writing more than once is
called a multisession.

. ID3/WMA Tag — The ID3/WMA tag is the

part of the encoded MP3 or WMA file that
contains information about the digital music
file such as song title, artist, album title,
encoding bit rate, track time duration, etc.
ID3 tag information is displayed on the
Album/Artist/Track title line on the display.

Windows

and Windows Media

are registered

trademarks or trademarks of Microsoft Corpora-
tion in the United States of America and other
countries of Microsoft Corporation of the USA.

USB (Universal Serial Bus) (if so
equipped)

WARNING

Do not connect, disconnect or operate
the USB device while driving. Doing so
can be a distraction. If distracted you
could lose control of your vehicle and

cause an accident or serious injury.

CAUTION

. Do not force the USB device into the

USB port. Inserting the USB device
tilted or up-side-down into the port
may damage the port. Make sure
that the USB device is connected
correctly into the USB port.

. Do not grab the USB port cover (if

so equipped) when pulling the USB
device out of the port. This could
damage the port and the cover.

. Do not leave the USB cable in a

place where it can be pulled unin-
tentionally. Pulling the cable may
damage the port.

The vehicle is not equipped with a USB device.
USB devices should be purchased separately
as necessary.

This system cannot be used to format USB
devices. To format a USB device, use a personal
computer.

In some states/area, the USB device for the
front seats plays only sound without images for

regulatory reasons, even when the vehicle is
parked.

This system supports various USB memory
devices, USB hard drives and iPod

players.

Some USB devices may not be supported by
this system.
. Partitioned USB devices may not be played

correctly.

. Some characters used in other languages

(Chinese, Japanese, etc.) are not displayed
properly on display. Using English language
characters with a USB device is recom-
mended.

General notes for USB use:

Refer to your device manufacturer’s owner
information regarding the proper use and care
of the device.

Notes for iPod

use:

iPod

is a trademark of Apple Inc., registered in

the U.S. and other countries.
. Improperly plugging in the iPod

may cause

a checkmark to be displayed on and off
(flickering). Always make sure that the iPod

is connected properly.

. An iPod nano

(1st Generation) may remain

in fast forward or rewind mode if it is
connected during a seek operation. In this
case, please manually reset the iPod

Center display, heater, air conditioner, audio and phone systems

4-25

. Sampling frequency — Sampling frequency

is the rate at which the samples of a signal
are converted from analog to digital (A/D
conversion) per second.

. Multisession — Multisession is one of the

methods for writing data to media. Writing
data once to the media is called a single
session, and writing more than once is
called a multisession.

. ID3/WMA Tag — The ID3/WMA tag is the

Windows

and Windows Media

are registered

trademarks or trademarks of Microsoft Corpora-
tion in the United States of America and other
countries of Microsoft Corporation of the USA.

USB (Universal Serial Bus) (if so
equipped)

WARNING

Do not connect, disconnect or operate
the USB device while driving. Doing so
can be a distraction. If distracted you
could lose control of your vehicle and

cause an accident or serious injury.

CAUTION

. Do not force the USB device into the

USB port. Inserting the USB device
tilted or up-side-down into the port
may damage the port. Make sure
that the USB device is connected
correctly into the USB port.

. Do not grab the USB port cover (if

so equipped) when pulling the USB
device out of the port. This could
damage the port and the cover.

. Do not leave the USB cable in a

place where it can be pulled unin-
tentionally. Pulling the cable may
damage the port.

The vehicle is not equipped with a USB device.
USB devices should be purchased separately
as necessary.

This system cannot be used to format USB
devices. To format a USB device, use a personal
computer.

In some states/area, the USB device for the
front seats plays only sound without images for

regulatory reasons, even when the vehicle is
parked.

This system supports various USB memory
devices, USB hard drives and iPod

players.

Some USB devices may not be supported by
this system.
. Partitioned USB devices may not be played

correctly.

. Some characters used in other languages

(Chinese, Japanese, etc.) are not displayed
properly on display. Using English language
characters with a USB device is recom-
mended.

General notes for USB use:

Refer to your device manufacturer’s owner
information regarding the proper use and care
of the device.

Notes for iPod

use:

iPod

is a trademark of Apple Inc., registered in

the U.S. and other countries.
. Improperly plugging in the iPod

may cause

a checkmark to be displayed on and off
(flickering). Always make sure that the iPod

is connected properly.

. An iPod nano

(1st Generation) may remain

in fast forward or rewind mode if it is
connected during a seek operation. In this
case, please manually reset the iPod

Center display, heater, air conditioner, audio and phone systems

4-25

4-26

Center display, heater, air conditioner, audio and phone systems

. An iPod nano

(2nd Generation) will con-

tinue to fast-forward or rewind if it is
disconnected during a seek operation.

. An incorrect song title may appear when the

Play Mode is changed while using an iPod
nano

(2nd Generation)

. Audiobooks may not play in the same order

as they appear on an iPod

. Large video files cause slow responses in an

iPod

. The vehicle center display may

momentarily black out, but will soon recover.

. If an iPod

automatically selects large video

files while in the shuffle mode, the vehicle
center display may momentarily black out,
but will soon recover.

Compressed Audio Files (MP3/WMA/
AAC) (if so equipped)

Explanation of terms:
. MP3 — MP3 is short for Moving Pictures

Experts Group Audio Layer 3. MP3 is the
most well known compressed digital audio
file format. This format allows for near “CD
quality” sound, but at a fraction of the size of
normal audio files. MP3 conversion of an
audio track can reduce the file size by
approximately a 10:1 ratio (Sampling: 44.1
kHz, Bit rate: 128 kbps) with virtually no
perceptible loss in quality. The compression

reduces certain parts of sound that seem
inaudible to most people.

. WMA — Windows Media Audio (WMA) is a

. AAC/M4A — Advanced Audio Coding

(AAC) is a lossy audio compression format.
Audio files that have been encoded with
AAC are generally smaller in size and deliver
a higher quality of sound than MP3.

. Bit rate — Bit rate denotes the number of

bits per second used by a digital music file.
The size and quality of a compressed digital
audio file is determined by the bit rate used
when encoding the file.

. Sampling frequency — Sampling frequency

is the rate at which the samples of a signal
are converted from analog to digital (A/D
conversion) per second.

. Multisession — Multisession is one of the

methods for writing data to media. Writing
data once to the media is called a single
session, and writing more than once is
called a multisession.

. ID3/WMA Tag — The ID3/WMA tag is the

* Windows

and Windows Media

are regis-

tered trademarks or trademarks of Microsoft
Corporation in the United States of America
and/or other countries.

4-26

Center display, heater, air conditioner, audio and phone systems

. An iPod nano

(2nd Generation) will con-

tinue to fast-forward or rewind if it is
disconnected during a seek operation.

. An incorrect song title may appear when the

Play Mode is changed while using an iPod
nano

(2nd Generation)

. Audiobooks may not play in the same order

as they appear on an iPod

. Large video files cause slow responses in an

iPod

. The vehicle center display may

momentarily black out, but will soon recover.

. If an iPod

automatically selects large video

files while in the shuffle mode, the vehicle
center display may momentarily black out,
but will soon recover.

Compressed Audio Files (MP3/WMA/
AAC) (if so equipped)

Explanation of terms:
. MP3 — MP3 is short for Moving Pictures

reduces certain parts of sound that seem
inaudible to most people.

. WMA — Windows Media Audio (WMA) is a

. AAC/M4A — Advanced Audio Coding

(AAC) is a lossy audio compression format.
Audio files that have been encoded with
AAC are generally smaller in size and deliver
a higher quality of sound than MP3.

. Bit rate — Bit rate denotes the number of

bits per second used by a digital music file.
The size and quality of a compressed digital
audio file is determined by the bit rate used
when encoding the file.

. Sampling frequency — Sampling frequency

is the rate at which the samples of a signal
are converted from analog to digital (A/D
conversion) per second.

. Multisession — Multisession is one of the

methods for writing data to media. Writing
data once to the media is called a single
session, and writing more than once is
called a multisession.

. ID3/WMA Tag — The ID3/WMA tag is the

* Windows

and Windows Media

are regis-

tered trademarks or trademarks of Microsoft
Corporation in the United States of America
and/or other countries.

4-28

Center display, heater, air conditioner, audio and phone systems

Specification chart (for FM-AM Radio with Compact Disc (CD) player):

Supported media

CD, CD-R, CD-RW

Supported file systems

CD, CD-R, CD-RW: ISO9660 LEVEL1, ISO9660 LEVEL2, Romeo, Joliet
* ISO9660 Level 3 (packet writing) is not supported.
* Files saved using the Live File System component (on a Windows Vista-based computer) are not supported.

Supported
versions*1

MP3

Version

MPEG1 Audio Layer 3, MPEG2, MPEG2.5

Sampling frequency

8 kHz - 48 kHz

Bit rate

8 kbps - 320 kbps, VBR*4

WMA*2

Version

WMA7, WMA8, WMA9

Sampling frequency

32 kHz - 48 kHz

Bit rate

32 kbps - 192 kbps, VBR*4

Tag information (Song title and Artist name)

ID3 tag VER1.0, VER1.1, VER2.2, VER2.3, VER2.4 (MP3 only)

WMA tag (WMA only)

Folder levels

CD, CD-R, CD-RW

Folder levels: 8, Folders and files: 999 (Max. 255 files for one folder)

Displayable character codes*3

01: ASCII, 02: ISO-8859-1, 03: UNICODE (UTF-16 BOM Big Endian), 04: UNICODE (UTF-16 Non-BOM Big
Endian), 05: UNICODE (UTF-8), 06: UNICODE (Non-UTF-16 BOM Little Endian)

Files created with a combination of 48 kHz sampling frequency and 64 kbps bit rate cannot be played.

Protected WMA files (DRM) cannot be played.

Available codes depend on what kind of media, versions and information are going to be displayed.

When VBR files are played, the playback time may not be displayed correctly.

4-28

Center display, heater, air conditioner, audio and phone systems

Specification chart (for FM-AM Radio with Compact Disc (CD) player):

Supported media

CD, CD-R, CD-RW

Supported file systems

Supported
versions*1

MP3

Version

MPEG1 Audio Layer 3, MPEG2, MPEG2.5

Sampling frequency

8 kHz - 48 kHz

Bit rate

8 kbps - 320 kbps, VBR*4

WMA*2

Version

WMA7, WMA8, WMA9

Sampling frequency

32 kHz - 48 kHz

Bit rate

32 kbps - 192 kbps, VBR*4

Tag information (Song title and Artist name)

ID3 tag VER1.0, VER1.1, VER2.2, VER2.3, VER2.4 (MP3 only)

WMA tag (WMA only)

Folder levels

CD, CD-R, CD-RW

Folder levels: 8, Folders and files: 999 (Max. 255 files for one folder)

Displayable character codes*3

01: ASCII, 02: ISO-8859-1, 03: UNICODE (UTF-16 BOM Big Endian), 04: UNICODE (UTF-16 Non-BOM Big
Endian), 05: UNICODE (UTF-8), 06: UNICODE (Non-UTF-16 BOM Little Endian)

Files created with a combination of 48 kHz sampling frequency and 64 kbps bit rate cannot be played.

Protected WMA files (DRM) cannot be played.

Available codes depend on what kind of media, versions and information are going to be displayed.

When VBR files are played, the playback time may not be displayed correctly.

Troubleshooting guide (for FM-AM Radio with Compact Disc (CD) player):

Symptom

Cause and Countermeasure

Cannot play

Check if the disc or USB device was inserted correctly.

Check if the disc is scratched or dirty.

Check if there is condensation inside the player, and if there is, wait until the condensation is gone (about 1 hour) before using the
player.

If there is a temperature increase error, the player will play correctly after it returns to the normal temperature.

If there is a mixture of music CD files (CD-DA data) and compressed audio files on a CD, only the music CD files (CD-DA data) will
be played.

Files with extensions other than “.MP3 (.mp3)”, “.WMA (.wma)”, “.AAC (.aac)” or “.M4A (.m4a)” cannot be played. In addition, the
character codes and number of characters for folder names and file names should be in compliance with the specifications.

Check if the disc or the file is generated in an irregular format. This may occur depending on the variation or the setting of
compressed audio writing applications or other text editing applications.

Check if the finalization process, such as session close and disc close, is done for the disc.

Check if the disc or USB device is protected by copyright.

Poor sound quality

Check if the disc is scratched or dirty.

It takes a relatively long time before
the music starts playing.

If there are many folder or file levels on the disc or USB device, some time may be required before the music starts playing.

Music cuts off or skips

The writing software and hardware combination might not match, or the writing speed, writing depth, writing width, etc., might not
match the specifications. Try using the slowest writing speed.

Skipping with high bit rate files

Skipping may occur with large quantities of data, such as for high bit rate data.

Move immediately to the next song
when playing.

If an unsupported compressed audio file has been given a supported extension like .MP3, or when play is prohibited by copyright
protection, the player will skip to the next song.

The songs do not play back in the
desired order.

The playback order is the order in which the files were written by the writing software, so the files might not play in the desired order.
Random/Shuffle may be active on the audio system or on a USB device.

Center display, heater, air conditioner, audio and phone systems

4-29

Troubleshooting guide (for FM-AM Radio with Compact Disc (CD) player):

Symptom

Cause and Countermeasure

Cannot play

Check if the disc or USB device was inserted correctly.

Check if the disc is scratched or dirty.

Check if there is condensation inside the player, and if there is, wait until the condensation is gone (about 1 hour) before using the
player.

If there is a temperature increase error, the player will play correctly after it returns to the normal temperature.

If there is a mixture of music CD files (CD-DA data) and compressed audio files on a CD, only the music CD files (CD-DA data) will
be played.

Check if the finalization process, such as session close and disc close, is done for the disc.

Check if the disc or USB device is protected by copyright.

Poor sound quality

Check if the disc is scratched or dirty.

It takes a relatively long time before
the music starts playing.

If there are many folder or file levels on the disc or USB device, some time may be required before the music starts playing.

Music cuts off or skips

The writing software and hardware combination might not match, or the writing speed, writing depth, writing width, etc., might not
match the specifications. Try using the slowest writing speed.

Skipping with high bit rate files

Skipping may occur with large quantities of data, such as for high bit rate data.

Move immediately to the next song
when playing.

If an unsupported compressed audio file has been given a supported extension like .MP3, or when play is prohibited by copyright
protection, the player will skip to the next song.

The songs do not play back in the
desired order.

Center display, heater, air conditioner, audio and phone systems

4-29

4-30

Center display, heater, air conditioner, audio and phone systems

Specification chart (for FM-AM-SAT Radio with Compact Disc (CD) Player):

Supported media

CD, CD-R, CD-RW, USB2.0

Supported file systems

ISO9660 LEVEL1, ISO9660 LEVEL2, Apple ISO, Romeo, Joliet * ISO9660 Level 3 (packet writing) is not
supported.

Supported
versions*1

MP3

Version

MPEG1, MPEG2, MPEG2.5

Sampling frequency

8 kHz - 48 kHz

Bit rate

8 kbps - 320 kbps, VBR

WMA

Version

WMA7, WMA8, WMA9

Sampling frequency

32 kHz - 48 kHz

Bit rate

48 kbps - 192 kbps, VBR

Tag information

ID3 tag VER1.0, VER1.1, VER2.2, VER2.3 (MP3 only)

Folder levels

Folder levels: 8, Max folders: 255 (including root folder), Files: 512 (Max. 255 files for one folder)

Displayable character codes*2

01: ASCII, 02: ISO-8859-1, 03: UNICODE (UTF-16 BOM Big Endian), 04: UNICODE (UTF-16 Non-BOM Big
Endian), 05: UNICODE (UTF-8), 06: UNICODE (Non-UTF-16 BOM Little Endian)

Files created with a combination of 48 kHz sampling frequency and 64 kbps bit rate cannot be played.

Available codes depend on what kind of media, versions and information are going to be displayed.

4-30

Center display, heater, air conditioner, audio and phone systems

Specification chart (for FM-AM-SAT Radio with Compact Disc (CD) Player):

Supported media

CD, CD-R, CD-RW, USB2.0

Supported file systems

ISO9660 LEVEL1, ISO9660 LEVEL2, Apple ISO, Romeo, Joliet * ISO9660 Level 3 (packet writing) is not
supported.

Supported
versions*1

MP3

Version

MPEG1, MPEG2, MPEG2.5

Sampling frequency

8 kHz - 48 kHz

Bit rate

8 kbps - 320 kbps, VBR

WMA

Version

WMA7, WMA8, WMA9

Sampling frequency

32 kHz - 48 kHz

Bit rate

48 kbps - 192 kbps, VBR

Tag information

ID3 tag VER1.0, VER1.1, VER2.2, VER2.3 (MP3 only)

Folder levels

Folder levels: 8, Max folders: 255 (including root folder), Files: 512 (Max. 255 files for one folder)

Displayable character codes*2

01: ASCII, 02: ISO-8859-1, 03: UNICODE (UTF-16 BOM Big Endian), 04: UNICODE (UTF-16 Non-BOM Big
Endian), 05: UNICODE (UTF-8), 06: UNICODE (Non-UTF-16 BOM Little Endian)

Files created with a combination of 48 kHz sampling frequency and 64 kbps bit rate cannot be played.

Available codes depend on what kind of media, versions and information are going to be displayed.

Troubleshooting guide (for FM-AM-SAT Radio with Compact Disc (CD) Player):

Symptom

Cause and Countermeasure

Cannot play

Check if the disc was inserted correctly.

Check if the disc is scratched or dirty.

Check if there is condensation inside the player. If there is, wait until the condensation is gone (about 1 hour) before using the player.

If there is a temperature increase error, the CD player will play correctly after it returns to the normal temperature.

Files with extensions other than “.MP3”, “.WMA”, “.mp3” or “.wma” cannot be played. In addition, the character codes and number of
characters for folder names and file names should be in compliance with the specifications.

Check if the disc or the file is generated in an irregular format. This may occur depending on the variation or the setting of MP3/WMA
writing applications or other text editing applications.

Check if the finalization process, such as session close and disc close, is done for the disc.

Check if the disc is protected by copyright.

Poor sound quality

Check if the disc is scratched or dirty.

Bit rate may be too low.

It takes a relatively long time before
the music starts playing.

If there are many folder or file levels on the MP3/WMA disc, or if it is a multisession disc, some time may be required before the music
starts playing.

Music cuts off or skips

The writing software and hardware combination might not match, or the writing speed, writing depth, writing width, etc., might not
match the specifications. Try using the slowest writing speed.

Skipping with high bit rate files

Skipping may occur with large quantities of data, such as for high bit rate data.

Move immediately to the next song
when playing.

When a non-MP3/WMA file has been given an extension of “.MP3”, “.WMA”, “.mp3” or “.wma”, or when play is prohibited by
copyright protection, there will be approximately 5 seconds of no sound and then the player will skip to the next song.

The songs do not play back in the
desired order.

The playback order is the order in which the files were written by the writing software. Therefore, the files might not play in the desired
order.

Center display, heater, air conditioner, audio and phone systems

4-31

Troubleshooting guide (for FM-AM-SAT Radio with Compact Disc (CD) Player):

Symptom

Cause and Countermeasure

Cannot play

Check if the disc was inserted correctly.

Check if the disc is scratched or dirty.

Check if there is condensation inside the player. If there is, wait until the condensation is gone (about 1 hour) before using the player.

If there is a temperature increase error, the CD player will play correctly after it returns to the normal temperature.

Check if the disc or the file is generated in an irregular format. This may occur depending on the variation or the setting of MP3/WMA
writing applications or other text editing applications.

Check if the finalization process, such as session close and disc close, is done for the disc.

Check if the disc is protected by copyright.

Poor sound quality

Check if the disc is scratched or dirty.

Bit rate may be too low.

It takes a relatively long time before
the music starts playing.

If there are many folder or file levels on the MP3/WMA disc, or if it is a multisession disc, some time may be required before the music
starts playing.

Music cuts off or skips

The writing software and hardware combination might not match, or the writing speed, writing depth, writing width, etc., might not
match the specifications. Try using the slowest writing speed.

Skipping with high bit rate files

Skipping may occur with large quantities of data, such as for high bit rate data.

Move immediately to the next song
when playing.

The songs do not play back in the
desired order.

The playback order is the order in which the files were written by the writing software. Therefore, the files might not play in the desired
order.

Center display, heater, air conditioner, audio and phone systems

4-31

4-32

Center display, heater, air conditioner, audio and phone systems

SAA2782

MUTE button

DISP (display)/TEXT button

FM·AM radio band select button

CD PLAY button

Station preset buttons

iPod

button

AUX (auxiliary) button

Audio display

CLOCK button

10.

CD EJECT button

11.

iPod

MENU button

12.

SEEK/TRACK button

13.

ENTER button

BACK button

15.

PWR (power) button/VOL (volume) control knob

AUX IN jack

17.

AUDIO button

18.

TUNE/FF·REW button

19.

SCAN/RPT (repeat) button

FM-AM RADIO WITH COMPACT DISC
(CD) PLAYER

For all operation precautions, see “Audio opera-
tion precautions” (P.4-21).

Audio main operation

Head unit:

The auto loudness circuit enhances the low and
high frequency ranges automatically in both
radio reception and CD playback.

ON·OFF/Volume control:

Place the ignition switch in the ACC or ON
position, and then push the PWR button while
the system is off to call up the normal mode
(radio, CD, AUX and iPod

) which was playing

immediately before the system was turned off.
While the system is on, pushing the PWR button
turns the system off.

Turn the VOL control knob to adjust the volume.

MUTE button:

Push the

button to mute the audio sound.

Push the

button again to release the mute

4-32

Center display, heater, air conditioner, audio and phone systems

SAA2782

MUTE button

DISP (display)/TEXT button

FM·AM radio band select button

CD PLAY button

Station preset buttons

iPod

button

AUX (auxiliary) button

Audio display

CLOCK button

10.

CD EJECT button

11.

iPod

MENU button

12.

SEEK/TRACK button

13.

ENTER button

BACK button

15.

PWR (power) button/VOL (volume) control knob

AUX IN jack

17.

AUDIO button

18.

TUNE/FF·REW button

19.

SCAN/RPT (repeat) button

FM-AM RADIO WITH COMPACT DISC
(CD) PLAYER

For all operation precautions, see “Audio opera-
tion precautions” (P.4-21).

Audio main operation

Head unit:

The auto loudness circuit enhances the low and
high frequency ranges automatically in both
radio reception and CD playback.

ON·OFF/Volume control:

Place the ignition switch in the ACC or ON
position, and then push the PWR button while
the system is off to call up the normal mode
(radio, CD, AUX and iPod

) which was playing

immediately before the system was turned off.
While the system is on, pushing the PWR button
turns the system off.

Turn the VOL control knob to adjust the volume.

MUTE button:

Push the

button to mute the audio sound.

Push the

button again to release the mute

setting.

AUDIO button:

Push the AUDIO button to change the selecting
mode as follows.

Push the TUNE (

) or SEEK (

)

button to adjust Bass and Treble to the desired
level. Use the TUNE or SEEK button also to
adjust Fade or Balance modes. Fade adjusts the
sound level between the front and rear speakers
and Balance adjusts the sound between the
right and left speakers.

To turn the beep sound off or on, push the TUNE
or SEEK button until the desired mode is
displayed. This turns on or off the beep sound
when audio buttons are pushed.

To change the Speed Sensitive Volume (Spd
Sen Vol) mode to OFF, LOW, MID or HIGH,
push the TUNE or SEEK button until the desired
mode is displayed.

Once you have adjusted the sound quality to the
desired level, push the AUDIO button repeatedly
until the normal mode display reappears. Other-
wise, the normal mode display will automatically
reappear after approximately 5 seconds.

CLOCK button:

Push the CLOCK button to turn on or off the
CLOCK display.

SIC4131

Push the CLOCK button

to turn the clock on

or off.

1. Push and hold the CLOCK button

until

the clock display starts to flash.

2. Push the SEEK/TRACK button

to adjust

the hours.

3. Push the TUNE/FF·REW button

adjust the minutes.

4. Push the CLOCK button

again to exit

the clock set mode.

The display will return to the regular clock
display after 5 seconds.

Center display, heater, air conditioner, audio and phone systems

4-33

setting.

AUDIO button:

Push the AUDIO button to change the selecting
mode as follows.

Push the TUNE (

) or SEEK (

)

To turn the beep sound off or on, push the TUNE
or SEEK button until the desired mode is
displayed. This turns on or off the beep sound
when audio buttons are pushed.

To change the Speed Sensitive Volume (Spd
Sen Vol) mode to OFF, LOW, MID or HIGH,
push the TUNE or SEEK button until the desired
mode is displayed.

CLOCK button:

Push the CLOCK button to turn on or off the
CLOCK display.

SIC4131

Push the CLOCK button

to turn the clock on

or off.

1. Push and hold the CLOCK button

until

the clock display starts to flash.

2. Push the SEEK/TRACK button

to adjust

the hours.

3. Push the TUNE/FF·REW button

adjust the minutes.

4. Push the CLOCK button

again to exit

the clock set mode.

The display will return to the regular clock
display after 5 seconds.

Center display, heater, air conditioner, audio and phone systems

4-33

4-34

Center display, heater, air conditioner, audio and phone systems

Radio operation

Radio (FM/AM) band select:

Pushing the FM·AM radio band select button will
change the band as follows:

? FM1 ? FM2 ? AM

When the stereo broadcast signal is weak, the
radio will automatically change from stereo to
monaural reception.

When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the station last
played.

TUNE (Tuning):

Push the TUNE button

for manual

tuning. To move quickly through the stations,
push and hold the TUNE button.

SEEK tuning:

Push the SEEK button

to tune from

low to high or high to low frequencies and to
stop at the next broadcasting station.

SCAN tuning:

Push the SCAN button to tune from low to high
frequencies and stops at each broadcasting
station for 5 seconds. Pushing the button again

during this 5 seconds period will stop SCAN
tuning and the radio will remain tuned to that
station.

If the SCAN tuning button is not pushed within 5
seconds, SCAN tuning moves to the next
station.

Station memory operations:

12 stations can be set for the FM band (6 each
for FM1 and FM2), and 6 can be set for the AM
band for easy access.

1. Choose the radio band using the radio band

select button.

2. Tune to the desired station using the SEEK,

SCAN or TUNE button.

3. Push and hold the desired radio station

preset button

until a beep sound is

heard. (The radio mutes when the radio
station preset button is pushed.)

4. The station indicator will then come on and

the sound will resume. Memorizing is now
complete.

5. Other buttons can be set in the same

manner.

If the battery cable is disconnected, or if the fuse
opens, the radio memory will be erased. In that
case, reset the desired stations.

Radio Data System (RDS):

RDS stands for Radio Data System, and is a
data information service transmitted by some
radio stations on the FM band (not AM band)
encoded within a regular radio broadcast.
Currently, most RDS stations are in large cities,
but many stations are now considering broad-
casting RDS data.

RDS can display:
. Station call sign, such as “WHFR 98.3”.
. Station name, such as “The Groove”.
. Music or programming type such as “Clas-

sical”, “Country” or “Rock”.

. Traffic reports about delays or construction.
If the station broadcasts RDS information, the
RDS icon is displayed.

RADIO DISPLAY change:

When the DISP button is pushed during the FM
radio mode, the radio display will change in the
following order.

FM radio:

Frequency

↔ PS/PTY

In the FM radio mode, pressing the DISP button
will switch the frequency display to the PTY
display (if available), and if the DISP button is
not pushed again within 5 seconds, it will
automatically switch to the PS display. If PTY

4-34

Center display, heater, air conditioner, audio and phone systems

Radio operation

Radio (FM/AM) band select:

Pushing the FM·AM radio band select button will
change the band as follows:

? FM1 ? FM2 ? AM

When the stereo broadcast signal is weak, the
radio will automatically change from stereo to
monaural reception.

When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the station last
played.

TUNE (Tuning):

Push the TUNE button

for manual

tuning. To move quickly through the stations,
push and hold the TUNE button.

SEEK tuning:

Push the SEEK button

to tune from

low to high or high to low frequencies and to
stop at the next broadcasting station.

SCAN tuning:

Push the SCAN button to tune from low to high
frequencies and stops at each broadcasting
station for 5 seconds. Pushing the button again

during this 5 seconds period will stop SCAN
tuning and the radio will remain tuned to that
station.

If the SCAN tuning button is not pushed within 5
seconds, SCAN tuning moves to the next
station.

Station memory operations:

12 stations can be set for the FM band (6 each
for FM1 and FM2), and 6 can be set for the AM
band for easy access.

1. Choose the radio band using the radio band

select button.

2. Tune to the desired station using the SEEK,

SCAN or TUNE button.

3. Push and hold the desired radio station

preset button

until a beep sound is

heard. (The radio mutes when the radio
station preset button is pushed.)

4. The station indicator will then come on and

the sound will resume. Memorizing is now
complete.

5. Other buttons can be set in the same

manner.

If the battery cable is disconnected, or if the fuse
opens, the radio memory will be erased. In that
case, reset the desired stations.

Radio Data System (RDS):

RDS can display:
. Station call sign, such as “WHFR 98.3”.
. Station name, such as “The Groove”.
. Music or programming type such as “Clas-

sical”, “Country” or “Rock”.

. Traffic reports about delays or construction.
If the station broadcasts RDS information, the
RDS icon is displayed.

RADIO DISPLAY change:

When the DISP button is pushed during the FM
radio mode, the radio display will change in the
following order.

FM radio:

Frequency

↔ PS/PTY

is not available, pressing the DISP button will
only switch between the frequency display and
the PS display.

Compact Disc (CD) player operation

Place the ignition switch in the ACC or ON
position, and insert the CD into the slot with the
label side facing up. The CD will be guided
automatically into the slot and start playing.

After loading the disc, the number of tracks on
the disc will appear on the display.

If the radio is already operating, it will auto-
matically turn off and the CD will play.

If the system has been turned off while the CD
was playing, pushing the PWR button will start
the CD.

Do not use 3.1 in (8 cm) discs.

CD PLAY:

When the CD button is pushed with the system
off and the CD loaded, the system will turn on
and the CD will start to play.

When the CD button is pushed with the CD
loaded and the radio playing, the radio will
automatically be turned off and the CD will start
to play.

CD play information:

When the DISP button is pushed for less than
1.5 seconds while the CD is being played, the
disc information display will change as follows:

CD:

CD with MP3 or WMA:

FF (Fast Forward), REW (Re-

wind):

CD:

Push the FF or REW button while a CD is
playing to fast-forward or rewind through the
track. When the button is released, the CD will
return to normal play speed.

CD with MP3 or WMA:

When the FF or REW button is pushed for less
than 1.5 seconds while the CD is being played,
the folders in the CD will change.

Push the FF or REW button for more than 1.5
seconds while CD is playing to fast-forward or
rewind through the track. When the button is

released, the CD will return to the normal play
speed.

APS (Automatic Program

Search) FF, APS REW:

When the

button is pushed while the CD is

being played, the program next to the present
one will start to play from its beginning. Push
several times to skip through programs. The CD
will advance the number of times the button is
pushed. (When the last program on the CD is
skipped through, the first program will be
played.)

When the

button is pushed, the program

being played returns to its beginning. Push
several times to skip back through programs.
The CD will go back the number of times the
button is pushed.

SCAN tuning:

When the SCAN tuning button is pushed for
more than 1.5 seconds while the CD is being
played, the beginning of all the tracks of CD will
be played for 10 seconds in sequence.

Pushing the button again during this 10 second
period will stop SCAN tuning.

If the SCAN tuning button is not pushed within
10 seconds, SCAN tuning moves to the next
disc program.

Center display, heater, air conditioner, audio and phone systems

4-35

is not available, pressing the DISP button will
only switch between the frequency display and
the PS display.

Compact Disc (CD) player operation

Place the ignition switch in the ACC or ON
position, and insert the CD into the slot with the
label side facing up. The CD will be guided
automatically into the slot and start playing.

After loading the disc, the number of tracks on
the disc will appear on the display.

If the radio is already operating, it will auto-
matically turn off and the CD will play.

If the system has been turned off while the CD
was playing, pushing the PWR button will start
the CD.

Do not use 3.1 in (8 cm) discs.

CD PLAY:

When the CD button is pushed with the system
off and the CD loaded, the system will turn on
and the CD will start to play.

When the CD button is pushed with the CD
loaded and the radio playing, the radio will
automatically be turned off and the CD will start
to play.

CD play information:

When the DISP button is pushed for less than
1.5 seconds while the CD is being played, the
disc information display will change as follows:

CD:

CD with MP3 or WMA:

FF (Fast Forward), REW (Re-

wind):

CD:

Push the FF or REW button while a CD is
playing to fast-forward or rewind through the
track. When the button is released, the CD will
return to normal play speed.

CD with MP3 or WMA:

When the FF or REW button is pushed for less
than 1.5 seconds while the CD is being played,
the folders in the CD will change.

Push the FF or REW button for more than 1.5
seconds while CD is playing to fast-forward or
rewind through the track. When the button is

released, the CD will return to the normal play
speed.

APS (Automatic Program

Search) FF, APS REW:

When the

button is pushed while the CD is

When the

button is pushed, the program

being played returns to its beginning. Push
several times to skip back through programs.
The CD will go back the number of times the
button is pushed.

SCAN tuning:

When the SCAN tuning button is pushed for
more than 1.5 seconds while the CD is being
played, the beginning of all the tracks of CD will
be played for 10 seconds in sequence.

Pushing the button again during this 10 second
period will stop SCAN tuning.

If the SCAN tuning button is not pushed within
10 seconds, SCAN tuning moves to the next
disc program.

Center display, heater, air conditioner, audio and phone systems

4-35

4-36

Center display, heater, air conditioner, audio and phone systems

RANDOM (RDM)/REPEAT (RPT):

When the RPT button is pushed for less than
1.5 seconds while the CD is being played, the
play pattern can be changed as follows:

CD:

CD with MP3 or WMA:

CD EJECT:

When the CD EJECT button is pushed with the
CD loaded, the CD will be ejected.

When this button is pushed while the CD is
being played, the CD will be ejected and the
system will turn off.

If the CD is ejected and is not removed, it
will be pulled back into the slot to protect
it.

SAA2352

Interface system for iPod

operation

Connecting iPod

The iPod

outlet connector is on the lower

center of the instrument panel. Connect the
cable

as illustrated, and then connect the

other end of the cable to your iPod

. Your

vehicle is equipped with the specialized cable
for connecting the iPod

to your vehicle audio

unit. The battery of your iPod

is charged while it

is connected to the vehicle if the iPod

supports

charging via a FireWire

connection.

When the connection is complete, a NISSAN
logo will be displayed on the iPod

and an iPod

icon on the audio display illuminates. While

connecting the iPod

to the vehicle, the iPod

can only be operated by the vehicle audio
controls.

To disconnect the cable from the vehicle outlet,
fully depress the center connector button to
unlatch the connector and pull the connector
straight out of the outlet. To disconnect the
cable from the iPod

, fully depress the side

connector buttons and pull the iPod

connector

straight out of the iPod

iPod

, iPhone

and FireWire

are a trademark of

Apple Inc., registered in the U.S. and other
countries.

Compatibility:

The following models are available:
. Third generation iPod

(Firmware version

2.3 or later) (Audiobook and Podcast are not
available)

. Fourth generation iPod

(Firmware version

3.1.1 or later)

. Fifth generation iPod

(Firmware version

1.1.2 or later)

. iPod mini

(Firmware version 1.41 or later)

. iPod photo

(Firmware version 1.2.1 or

later)

. iPod nano

(Firmware version 1.2 or later)

The fourth generation iPod nano

, iPod touch

the second generation iPod classic

and

4-36

Center display, heater, air conditioner, audio and phone systems

RANDOM (RDM)/REPEAT (RPT):

When the RPT button is pushed for less than
1.5 seconds while the CD is being played, the
play pattern can be changed as follows:

CD:

CD with MP3 or WMA:

CD EJECT:

When the CD EJECT button is pushed with the
CD loaded, the CD will be ejected.

When this button is pushed while the CD is
being played, the CD will be ejected and the
system will turn off.

If the CD is ejected and is not removed, it
will be pulled back into the slot to protect
it.

SAA2352

Interface system for iPod

operation

Connecting iPod

The iPod

outlet connector is on the lower

center of the instrument panel. Connect the
cable

as illustrated, and then connect the

other end of the cable to your iPod

. Your

vehicle is equipped with the specialized cable
for connecting the iPod

to your vehicle audio

unit. The battery of your iPod

is charged while it

is connected to the vehicle if the iPod

supports

charging via a FireWire

connection.

When the connection is complete, a NISSAN
logo will be displayed on the iPod

and an iPod

icon on the audio display illuminates. While

connecting the iPod

to the vehicle, the iPod

can only be operated by the vehicle audio
controls.

, fully depress the side

connector buttons and pull the iPod

connector

straight out of the iPod

iPod

, iPhone

and FireWire

are a trademark of

Apple Inc., registered in the U.S. and other
countries.

Compatibility:

The following models are available:
. Third generation iPod

(Firmware version

2.3 or later) (Audiobook and Podcast are not
available)

. Fourth generation iPod

(Firmware version

3.1.1 or later)

. Fifth generation iPod

(Firmware version

1.1.2 or later)

. iPod mini

(Firmware version 1.41 or later)

. iPod photo

(Firmware version 1.2.1 or

later)

. iPod nano

(Firmware version 1.2 or later)

The fourth generation iPod nano

, iPod touch

the second generation iPod classic

and

iPhone

3G may not work with the system in

some cases.

Make sure that your iPod

firmware is updated.

12V-charge iPod

s are not chargeable with this

system.

iPod

button:

Place the ignition switch in the ACC or ON
position. Then, push the iPod

button to switch

to the iPod

mode.

If another audio source is playing and the iPod

is connected, pushing the iPod

button changes

to the iPod

mode.

If the system has been turned off while the iPod

was playing, pushing the PWR button will start
the iPod

Top menu item selecting:

When the iPod

MENU button is pushed while

the iPod

is connected, the interface for iPod

operation is shown on the audio display. The
items on the menu list can be scrolled by
pushing the SEEK button

and the

TUNE button

while the iPod

operational. To select an item, push ENTER. The
display can be changed as follows:

For more information about each item, see the
iPod

Owner’s Manual.

BACK, ENTER button:

. When the ENTER button is pushed while

the top menu is displayed, program details
are shown on the audio display.

. To select the program, push to search using

the SEEK

and ENTER button.

. When the BACK button is pushed, it returns

to the previous display.

iPod

play information:

When the DISP button is pushed while a
program is being played, the program informa-
tion display will change as follows:

* Artist Name will not be displayed for a Podcast.

FF (Fast Forward), REW (Re-

wind) button:

When the

button is pushed for more

than 1.5 seconds while the iPod

is playing, the

iPod

will play while fast forwarding or rewind-

ing. When the button is released, the iPod

will

return to the normal play speed.

When the

button is pushed for less

than 1.5 seconds while the iPod

is playing, the

next track or the beginning of the current track
on the iPod

will be played.

APS (Automatic Program

Search) FF, APS REW button:

When the

button is pushed for more

than 1.5 seconds while the iPod

is playing,

numbers of tracks can be skipped through.

When the

button is pushed for less

than 1.5 seconds while iPod

is playing, the next

track or the beginning of the current track on the
iPod

will be played.

REPEAT (RPT), RANDOM (RDM):

When the RPT button is pushed while a track is
being played, the play pattern can be changed
as follows:

Except Podcast and Audiobook:

Podcast:

ALL REPEAT

↔ TRACK REPEAT

Audiobook:

Center display, heater, air conditioner, audio and phone systems

4-37

iPhone

3G may not work with the system in

some cases.

Make sure that your iPod

firmware is updated.

12V-charge iPod

s are not chargeable with this

system.

iPod

button:

Place the ignition switch in the ACC or ON
position. Then, push the iPod

button to switch

to the iPod

mode.

If another audio source is playing and the iPod

is connected, pushing the iPod

button changes

to the iPod

mode.

If the system has been turned off while the iPod

was playing, pushing the PWR button will start
the iPod

Top menu item selecting:

When the iPod

MENU button is pushed while

the iPod

is connected, the interface for iPod

operation is shown on the audio display. The
items on the menu list can be scrolled by
pushing the SEEK button

and the

TUNE button

while the iPod

operational. To select an item, push ENTER. The
display can be changed as follows:

For more information about each item, see the
iPod

Owner’s Manual.

BACK, ENTER button:

. When the ENTER button is pushed while

the top menu is displayed, program details
are shown on the audio display.

. To select the program, push to search using

the SEEK

and ENTER button.

. When the BACK button is pushed, it returns

to the previous display.

iPod

play information:

When the DISP button is pushed while a
program is being played, the program informa-
tion display will change as follows:

* Artist Name will not be displayed for a Podcast.

FF (Fast Forward), REW (Re-

wind) button:

When the

button is pushed for more

than 1.5 seconds while the iPod

is playing, the

iPod

will play while fast forwarding or rewind-

ing. When the button is released, the iPod

will

return to the normal play speed.

When the

button is pushed for less

than 1.5 seconds while the iPod

is playing, the

next track or the beginning of the current track
on the iPod

will be played.

APS (Automatic Program

Search) FF, APS REW button:

When the

button is pushed for more

than 1.5 seconds while the iPod

is playing,

numbers of tracks can be skipped through.

When the

button is pushed for less

than 1.5 seconds while iPod

is playing, the next

track or the beginning of the current track on the
iPod

will be played.

REPEAT (RPT), RANDOM (RDM):

When the RPT button is pushed while a track is
being played, the play pattern can be changed
as follows:

Except Podcast and Audiobook:

Podcast:

ALL REPEAT

↔ TRACK REPEAT

Audiobook:

Center display, heater, air conditioner, audio and phone systems

4-37

4-38

Center display, heater, air conditioner, audio and phone systems

AUX (Auxiliary) input

AUX IN jack:

The AUX IN jack is located on the audio unit.
The AUX IN audio input jack accepts any
standard analog audio input such as from a
portable cassette tape/CD player, MP3 player or
laptop computer.

AUX (Auxiliary) button:

With an AUX device plugged in, push the AUX
button repeatedly until the display changes to
the AUX mode.

When the AUX button is pushed with no device
plugged into the jack, the audio system does not
change to the AUX mode.

NISSAN strongly recommends using a stereo
mini plug cable when connecting your music
device to the audio system. Music may not play
properly when a monaural cable is used.

SAA3425

XM band select button

CD insert slot

CD EJECT button

TUNE/SCROLL control knob and AUDIO button

Radio station preset buttons

AUX button

ON·OFF button/VOLUME control knob

FF (forward)/REW (rewind) or SEEK/CATE-
GORY button

CD button

10.

FM·AM band select button

No satellite radio reception is available unless a
SiriusXM Satellite Radio subscription is active.

4-38

Center display, heater, air conditioner, audio and phone systems

AUX (Auxiliary) input

AUX IN jack:

The AUX IN jack is located on the audio unit.
The AUX IN audio input jack accepts any
standard analog audio input such as from a
portable cassette tape/CD player, MP3 player or
laptop computer.

AUX (Auxiliary) button:

With an AUX device plugged in, push the AUX
button repeatedly until the display changes to
the AUX mode.

When the AUX button is pushed with no device
plugged into the jack, the audio system does not
change to the AUX mode.

NISSAN strongly recommends using a stereo
mini plug cable when connecting your music
device to the audio system. Music may not play
properly when a monaural cable is used.

SAA3425

XM band select button

CD insert slot

CD EJECT button

TUNE/SCROLL control knob and AUDIO button

Radio station preset buttons

AUX button

ON·OFF button/VOLUME control knob

FF (forward)/REW (rewind) or SEEK/CATE-
GORY button

CD button

10.

FM·AM band select button

No satellite radio reception is available unless a
SiriusXM Satellite Radio subscription is active.

FM-AM-SAT RADIO WITH COMPACT
DISC (CD) PLAYER

For all operation precautions, see “Audio opera-
tion precautions” (P.4-21).

The satellite radio mode requires an active
SiriusXM Satellite Radio subscription. The sa-
tellite radio is not available in Alaska, Hawaii and
Guam.

It may take some time to receive the activation
signal after subscribing the SiriusXM Satellite
Radio. After receiving the activation signal, an
available channel list will be automatically
updated in the radio. Place the ignition switch
in LOCK to ACC to update the channel list.

Audio main operation

Head unit:

The auto loudness circuit enhances the low and
high frequency ranges automatically in both
radio reception and CD playback.

ON·OFF/Volume control:

Place the ignition switch in the ACC or ON
position, and then push the ON·OFF button
while the system is off to turn on the last audio
source, which was playing immediately before
the system was turned off. While the system is
on, pushing the ON·OFF button turns the system
off.

Turn the VOL control knob to adjust the volume.

Adjusting tone quality and speaker bal-
ance:

To adjust Bass, Treble, Balance and Fade, push
the Audio control knob. When the display shows
the setting you want to change (Bass, Treble,
Balance and Fade), rotate the Audio control
knob to set the desired setting. For the other
setting methods, see “How to use the setup
button” (P.4-6).

This audio system is equipped with Speed
Volume for audio. When this feature is active,
the audio volume increases/decreases in re-
sponse to an increase/decrease in the speed
that the vehicle is being driven. For more details,
see “How to use the setup button” (P.4-6).

Adjusting AUX level:

The volume level of incoming sound can be
selected from “Quiet”, “Medium” and “Loud”
when an auxiliary device is connected to the
system. For more details, see “How to use the
setup button” (P.4-6).

Switching the display:

Pushing the AUX button will switch the displays
between USB/iPod

and AUX.

Adjusting clock:

For information about adjusting the clock dis-

play, see “How to use the setup button” (P.4-6).

FM-AM-SAT radio operation

When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the channel
last played.

The last channel played will also come on when
the ON·OFF button is pushed to ON.

If another audio source is playing when the radio
band select button is turned to ON, the audio
source will automatically be turned off and the
last radio channel played will come on.

When the stereo broadcast signal is weak, the
radio will automatically change from stereo to
monaural reception.

FM·AM radio band select:

Pushing the FM·AM radio band select button will
change the band as follows:

? FM1 ? FM2 ? AM

SiriusXM Satellite radio band select:

Pushing the XM radio band select button will
change the band as follows:

XM1

? XM2 ? XM3 ? XM1

The satellite radio is not available in Alaska,
Hawaii and Guam.

Center display, heater, air conditioner, audio and phone systems

4-39

FM-AM-SAT RADIO WITH COMPACT
DISC (CD) PLAYER

For all operation precautions, see “Audio opera-
tion precautions” (P.4-21).

The satellite radio mode requires an active
SiriusXM Satellite Radio subscription. The sa-
tellite radio is not available in Alaska, Hawaii and
Guam.

Audio main operation

Head unit:

The auto loudness circuit enhances the low and
high frequency ranges automatically in both
radio reception and CD playback.

ON·OFF/Volume control:

Turn the VOL control knob to adjust the volume.

Adjusting tone quality and speaker bal-
ance:

Adjusting AUX level:

Switching the display:

Pushing the AUX button will switch the displays
between USB/iPod

and AUX.

Adjusting clock:

For information about adjusting the clock dis-

play, see “How to use the setup button” (P.4-6).

FM-AM-SAT radio operation

When the radio band select button is pushed
while the ignition switch is in the ACC or ON
position, the radio will come on at the channel
last played.

The last channel played will also come on when
the ON·OFF button is pushed to ON.

If another audio source is playing when the radio
band select button is turned to ON, the audio
source will automatically be turned off and the
last radio channel played will come on.

When the stereo broadcast signal is weak, the
radio will automatically change from stereo to
monaural reception.

FM·AM radio band select:

Pushing the FM·AM radio band select button will
change the band as follows:

? FM1 ? FM2 ? AM

SiriusXM Satellite radio band select:

Pushing the XM radio band select button will
change the band as follows:

XM1

? XM2 ? XM3 ? XM1

The satellite radio is not available in Alaska,
Hawaii and Guam.

Center display, heater, air conditioner, audio and phone systems

4-39

Nissan Cube (2014 year). Instruction - part 11
