GW-26

< ON-VEHICLE REPAIR >

REAR REGULATOR

5. Remove the door glass bolts (A).
6. Raise up the door glass and hold with a suction lifter (A).

7. Disconnect the window motor connector.
8. Remove the window regulator bolts (A) and remove the window

regulator from the rear door panel.

INSTALLATION

Installation is in the reverse order of removal.

• After installation, inspect and adjust as necessary.

Inspection

INFOID:0000000004507207

Inspection after Removal

Check the regulator assembly for the following items. If a malfunction is detected, replace or grease it.

• Gear wear

• Regulator deformation

• Grease condition for each sliding part

Apply multi-purpose grease at points (A) shown.

FINAL INSPECTION

• Make sure the glass is securely fit into the glass run groove.

• Lower the glass slightly [approx. 10 to 20 mm (0.39 to 0.79 in)], and make sure the clearance to the sash is

parallel. If the clearance between the glass and sash is not parallel, loosen the regulator mounting bolts,

guide rail mounting bolts, and glass and carrier plate mounting bolts to correct the glass position.

PIIB3511J

ALKIA0120ZZ

ALKIA0121ZZ

SIDE WINDOW GLASS

GW-27

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

SIDE WINDOW GLASS

Components

INFOID:0000000004204558

Removal and Installation

INFOID:0000000004204559

REMOVAL

1. Remove the Upper pillar finisher. Refer to

INT-15, "Removal and Installation"

.

2. NOTE:

If the side window glass is to be reused, mark the body and the glass with mating marks.

WARNING:

When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help pre-

vent glass splinters from entering your eyes or cutting your hands.

CAUTION:

ALKIA1452ZZ

1.

Windshield glass

2.

Spacer

3.

Seal

4.

Body side outer

5.

Primer

6.

Adhesive

7.

Encapsulation

E.

7(0.28)

F.

12 (0.47)

G.

15 (0.59)

GW-28

< ON-VEHICLE REPAIR >

SIDE WINDOW GLASS

• Be careful not to scratch the glass when removing.

• Do not set or stand the glass on its edge. Small chips may develop into cracks.

• When the windshield glass is to be reused, do not use a cutting knife or power cutting tool.

After removing moldings, remove the glass using piano wire or power cutting tool (A) and an inflatable

pump (B).

INSTALLATION

Installation is in the reverse order of removal.

• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions furnished

with it.

• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out

by passenger compartment air pressure when a door is closed.

• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (preferably 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.

• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid

contact with the skin and eyes.

• Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled.

If affected by vapor inhalation, immediately move to an area with fresh air.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the side window glass in case of an accident.

CAUTION:

• Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed

on the box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.

• Do not leave primers or adhesive cartridge unattended with their caps open or off.

• The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely

cured. Curing time varies depending on temperature and humidity. The curing time will increase

under lower temperature and lower humidity.

Inspection

INFOID:0000000004204560

Repairing water Leaks for Side Window Glass

Leaks can be repaired without removing and reinstalling glass.

If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.

This can be done by applying water to the side window area while pushing glass outward.

To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.

PIIB5779E

FRONT REGULATOR

GW-29

< DISASSEMBLY AND ASSEMBLY >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

DISASSEMBLY AND ASSEMBLY

FRONT REGULATOR

Exploded View

INFOID:0000000004204561

Disassembly

INFOID:0000000004204562

Remove the window motor nuts (A) the four window regulator bolts

(B) and  the window  motor (1)  from the door module assembly. On

the back side remove the window regulator from the door module

assembly.

Assembly

INFOID:0000000004204563

Assembly is in the reverse order of disassembly.

1.    Door

2.

Inside seal

3.

Door glass

4.

Regulator assembly

5.

Door module assembly

6.

Window motor

ALKIA1297ZZ

ALKIA1298ZZ
